Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x4
washer
Z
Y
wall
anchor
x2
X
safety
strap x2
WV
screw
x2
wall
screw
x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
Phillips & Flathead screwdrivers
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
bolt
x34
x8
A B C D EFG H
JKL M
I
Hardware Supplied
dowel
x12
screw
x72
slide
rail x6
slide
rail x6
slide
rail x6
slide
rail x6
locking
nut x34
screw
x8
wedge
x8
screw bolt
x8
handle
x6
N
screw
x24
Allen
Key
x1
O P
small
screw
x10
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Attach 3x slide rails (F) and 3x slide rails (G) to panels [3] and [4] as shown
and secure with 18x screws (E). Insert 4x bolts (C) into panels [3] and [4].
Tighten with a screwdriver.
Insert 6x bolts (C) into panel [1]. Tighten with a screwdriver.
F
F
F
F
CL
E
G
G
G
G
CR
E
4
C
C
C
C
C
C
CC
CC
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
E
1
3
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach 3x slide rails (G) and 3x slide rails (F) to panel [5] as shown
and secure with 18x screws (E). Tighten with a screwdriver.
Attach panels [3] and [4] to the panel [6] secure with 4x locking nuts (D).
Tighten with a screwdriver.
F
CL
E
G
CR
E
F
F
F
G
G
G
E
E
E
E
E
E
E
E
E
EE
E
EE
E
E
E
E
6
4
FLIP
5
5
D
D
D
D
D
D
3
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Slide panel [7] down along the grooves between the panels [3] and [4].Attach panel [5] to panel [6] secure with 2x long screws (B).
Tighten with a screwdriver.
6
3
4
7
B
B
5
6
B
B
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Attach panel [1] to the panels [3], [4] and [5] with 6x dowels (A) and
secure with 6x locking nuts (D). Tighten with a screwdriver.
Slide panel [7] down along the grooves between the panels [3] and [4].
4
AA
A
A
D
D
D
D
1
3
3
5
4
7
Inca Six Drawer
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
Attach panel [2] to panels [3], [4] and [5] with 6x dowels (A) and
secure with 6x long screws (B). Tighten with a screwdriver.
2
8
8
10
9
10
9
L
L
L
L
L
L
L
L
L
P
Attach panel [8] to panels [9] and [10] secure with 8x bolt (L). Tighten with
an Allen Key (P).
A
A
A
A
B
B
B
B
B
B
4
3
5
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
11 12 Drawers x6
11
12
C
C
C
C
N
2
Attach panels [8] and [9] to panel [2] with 10x small screws (N).
Tighten with a screwdriver.
Insert 4x bolts (C) into panels [11]/[12]. Tighten with a screwdriver.
N
N
N
NN
N
N
N
N
N
8
8
9
9
14 Drawers x6
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 Drawers x6
O
O
O
O
14
13
15
13
14
16
Attach panels [13] and [14] to panels [15] as shown using
4x screws (O). Tighten with a screwdriver.
Slide panels [16] along the grooves between the side panels [13]
and [14] as shown.
16 Drawers x6
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 Drawers x6
D
D
D
D
13
12
11
11
12
14
E
E
H
I
14
13
E
E
Attach panels [11]/ [12] to panels [13] and [14] secure with
4x locking nuts (D). Tighten with a screwdriver.
Attach slide rail (I) and slide rail (H) to the underside of the side panels as shown.
Secure with 4x screws (E) and tighten with a screwdriver.
18
Inca Six Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
17 Drawers x6
M
EE
12
11
Attach 1x handle (M) to panels [11]/[12] secure with 2x screws (E).
Tighten with a screwdriver.
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
12
12
12
11
11
11
