Mocka Portia Console Table User manual

WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
Hardware Supplied
Phillips screwdriver required
Portia Console Table
1
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
A C DB
bolt
x8
screw
x4
adjuster
x5
allen key
x1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1

12
Attach panel [2] to 3x panels [3] with 4x bolts (A).
Tighten with an Allen key (C).
Portia Console Table
2
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Assembly Instructions
Attach panel [4] to 3x panels [3] and with 4x bolts (A).
Tighten with an Allen key (C).
2
3
A
C
3
3
3
C
A
4
3
3
3
3

Attach 1x safety strap (V) to panel [1] as shown using 1x
washer (Z) and 1x screw (W). Tighten with a screwdriver.
34
Attach panels [2] to panel [1] with 4x screws (D). Tighten with a
screwdriver. Insert the 5x adjusters (B) into panel [4] as shown.
Portia Console Table
3
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Assembly Instructions
2
1
4
D
B
V
W
Z
1
V
W
Z

Once assembled lift furniture into place, do not drag. Use a drill
to create a small hole lining up with the top of the safety strap (V).
Fasten to the wall using 1x washer (Z), 1x wall anchor (X) and 1x
wall screw (Y). Ensure unit is balanced and steady before use.
You’re done, enjoy!
5
Portia Console Table
4
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
Assembly Instructions
X
Y
Z
X
YZ
