Motorola MD60 Series User manual

User’s Guide >
MD60 Series
Digital 5.8 GHz
Cordless Expansion Handset and Charger
4110W44o.book Page 1 Friday, July 25, 2003 3:37 PM

4110W44o.book Page 2 Friday, July 25, 2003 3:37 PM

1
Welcome
Congratulations on your purchase of a Motorola product!
Product registration is an important step. Registering
helps us facilitate warranty service and permits us to
contact you if your Motorola product requires an
update or other service.
To register your product online, visit:
www.motorola.com/warranty/cordless
Please retain your original dated sales receipt for
your records. For warranty service of your Motorola
product, you will need to provide a copy of your dated
sales receipt to confirm warranty status. Registration
is not required for warranty coverage.
For a large-print version of this guide, or for product-
related questions, please call:
1-800-353-2729 in the USA
1-888-390-6456 TTY (Text Telephone)
On the Web:
www.motorola.com/cordless
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners.
© Motorola, Inc. 2003
6864110W44-O
4110W44o.book Page 1 Friday, July 25, 2003 3:37 PM

2
FCC and Interference Information
FCC and Interference
Information
This equipment complies with Parts 15 and 68 of the FCC rules and
the requirements adopted by the Administrative Council for Terminal
Attachments (ACTA).
A plug and jack used to connect this equipment to the premises wiring
and telephone network must comply with applicable FCC Part 68 rules
and requirements adopted by the ACTA. A compliant telephone cord
and modular plug is provided with this product. It is designed to be
connected to a compatible modular jack that is also compliant. See
installation instructions for details.
Notification of the Local Telephone Company
On the bottom of this equipment is a label that contains, among other
information, a product identifier in the form US:AAAEQ##TXXXX. You
must, upon request, provide this information to your telephone
company.
The digits represented by ## in the product identifier indicate the
Ringer Equivalency Number (REN) for this equipment. The REN is
useful in determining the number of devices you may connect to your
telephone line and still have all of these devices ring when your
telephone number is called. In most (but not all) areas, the sum of the
RENs of all devices connected to one line should not exceed 5. To be
certain of the number of devices you may connect to your line as
determined by the REN, contact your local telephone company.
Notes :
• This equipment may not be used on coin service provided by the
telephone company.
• Connection to party line service is subject to state tariffs. Contact
the state public utility commission, public service commission or
corporation commission for information.
4110W44o.book Page 2 Friday, July 25, 2003 3:37 PM

3
FCC and Interference Information
• If your home has specially wired alarm equipment connected to
the telephone line, ensure the installation of this cordless phone
does not disable your alarm equipment. If you have questions
about what will disable alarm equipment, consult your telephone
company or a qualified installer.
• Notice must be given to the telephone company upon permanent
disconnection of your telephone from your line.
• The FCC requires that you connect your cordless telephone to the
nationwide telephone network through a modular telephone jack
(USOC RJ11C/RJ11W or RJ14C/RJ14W).
Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the
telephone network, the telephone company shall, where practicable,
notify you that temporary discontinuance of service may be required.
Where prior notice is not practical and the circumstances warrant such
action, the telephone company may temporarily disconnect service
immediately. In case of such temporary discontinuance, the telephone
company must:
1. Promptly notify you of such temporary discontinuance;
2. Afford you the opportunity to correct the situation;
3. Inform you of your right to bring a complaint to the Commission
pursuant to procedures set forth in Subpart E of Part 68, FCC
Rules and Regulations.
The telephone company may make changes in its facilities, equipment,
operations, or procedures that could affect the operation of the
equipment. If this happens, the telephone company will provide
advance notice in order for you to make necessary modifications to
maintain uninterrupted service.
4110W44o.book Page 3 Friday, July 25, 2003 3:37 PM

4
FCC and Interference Information
Interference Information
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment on and
off, the user is encouraged to try to correct the interference with one or
more of the following measures:
Reorient or relocate the receiving antenna (that is, the antenna for the
radio or television that is “receiving” the interference).
Reorient or relocate and increase the separation between the
telecommunications equipment and the receiving antenna.
Connect the telecommunications equipment into an outlet on a circuit
different from that to which the receiving antenna is connected.
4110W44o.book Page 4 Friday, July 25, 2003 3:37 PM

5
FCC and Interference Information
If these measures do not eliminate the interference, please consult
your dealer or an experienced radio/television technician for additional
suggestions. Also, the Federal Communications Commission has
prepared a helpful booklet, “How to Identify and Resolve Radio/TV
Interference Problems.” This booklet is available from the U.S.
Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
The FCC requires this product to be serviced only by Motorola or its
authorized service agents. Changes or modifications not expressly
approved by Motorola could void not only the user's authority to
operate the equipment, but also the limited warranty.
Hearing Aid Compatibility
This telephone system meets the FCC standards for hearing aid
compatibility.
4110W44o.book Page 5 Friday, July 25, 2003 3:37 PM

6
Important Safety Instructions
Important Safety Instructions
Follow these safety precautions when using your cordless phone to
reduce the risk of fire, electric shock, and injury to persons or property:
1. Keep all slits and openings of the phone unblocked. Do not set the
phone on a heating register or over a radiator. Ensure that proper
ventilation is provided at the installation site.
2. Do not use while wet or while standing in water.
3. Do not use this product near water (for example, near a bath tub,
kitchen sink, or swimming pool).
4. Do not allow anything to rest on the power cord. Place the power
cord so that it will not be walked on.
5. Never insert objects of any kind into the product slits as that may
result in fire or shock.
6. Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
7. Do not disassemble this product. If service or repair work is
required, contact the Motorola address found in the back of this
user’s guide.
8. Do not overload wall outlets and extension cords.
9. Avoid using during an electrical storm. Use a surge protector to
protect the equipment.
10. Do not use this cordless phone to report a gas leak, especially if
you are in the vicinity of the gas line.
Caution: To reduce the risk of fire, use only No. 26 AWG or larger UL
Listed or CSA Certified Telecommunication Line Cord.
4110W44o.book Page 6 Friday, July 25, 2003 3:37 PM

7
Important Safety Instructions
Unplug this cordless phone immediately from an outlet if:
•
The power cord or plug is damaged or frayed.
• Liquid has been spilled into the product.
• The product has been exposed to rain or water. Do not retrieve
the handset or base until after you have unplugged the power
and phone from the wall. Then retrieve the unit by the
unplugged cords.
• The product has been dropped or the cabinet has been
damaged.
• The product exhibits a distinct change in performance.
Installation Guidelines
1. Read and understand all instructions and save them for future
reference.
2. Follow all warnings and instructions marked on the product.
3. Do not install this product near a bath tub, sink, or shower.
4. Operate this phone using only the power source that is indicated
on the marking label. If you are unsure of the power supply to your
home, consult with your dealer or local power company.
5. Do not place this product on an unstable cart, stand, or table. This
product may fall, causing serious damage to the product.
6. Adjust only those controls that are covered by the operating
instructions. Improper adjustment of other controls may result in
damage and will often require extensive work to restore the
product to normal operation.
7. Clean this product with a soft, damp cloth. Do not use chemicals
or cleaning agents to clean this phone.
4110W44o.book Page 7 Friday, July 25, 2003 3:37 PM

8
Important Safety Instructions
8. Use only the power supply that came with this unit. Using other
power supplies may damage the unit.
9. Because cordless phones operate on electricity, you should have
at least one phone in your home that is not cordless in case the
power in your home goes out.
10. To avoid interference to nearby appliances, do not place the base
of the cordless phone on or near a TV, microwave oven, or VCR.
Caution: To maintain compliance with the FCC’s RF exposure
guidelines, place the base unit at least 20 cm from nearby persons.
Battery Safety Instructions
• Do not burn, disassemble, mutilate, or puncture the battery. The
battery contains toxic materials that could be released, resulting
in injury.
• Caution: There is a risk of explosion if you replace the battery
with an incorrect battery type. Use only the battery that came
with your phone or an authorized replacement recommended by
the manufacturer.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
• Do not dispose of batteries in fire, which could result in
explosion.
• The rechargeable batteries that power this product
must be disposed of properly and may need to be
recycled. Refer to your battery’s label for battery type.
Contact your local recycling center for proper disposal methods.
ITC03-201
4110W44o.book Page 8 Friday, July 25, 2003 3:37 PM

9
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FCC and Interference Information. . . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . 6
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Choosing a Location . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting the Charging Base . . . . . . . . . . . . . . . . . 12
Installing the Battery Pack in the Handset. . . . . . . . . 13
Charging the Handset . . . . . . . . . . . . . . . . . . . . . . . . 14
Handset Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Handset Standby Screen Example . . . . . . . . . . . . 15
Using the Soft Keys . . . . . . . . . . . . . . . . . . . . . . . . 15
Using the Menu Key. . . . . . . . . . . . . . . . . . . . . . . . 16
Registering an Expansion Handset. . . . . . . . . . . . . . 16
Setting Up Your Expansion Handset. . . . . . . . . . . . . 18
Setting the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Personalizing Your Expansion Handset. . . . . . . . . . . 19
Setting the Ringer Volume . . . . . . . . . . . . . . . . . . . 19
Setting the Ringer Tone . . . . . . . . . . . . . . . . . . . . . 20
Setting the Keypad Tone . . . . . . . . . . . . . . . . . . . . 21
Setting the Contrast. . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the Language. . . . . . . . . . . . . . . . . . . . . . . 22
Setting the Vibrate Control. . . . . . . . . . . . . . . . . . . 23
Setting the Low Battery Tone. . . . . . . . . . . . . . . . . 23
Setting the Range Tone . . . . . . . . . . . . . . . . . . . . . 24
4110W44o.book Page 9 Friday, July 25, 2003 3:37 PM

10
Using the Basic Functions . . . . . . . . . . . . . . . . . . . . 25
Making and Ending a Call. . . . . . . . . . . . . . . . . . . . . 25
Adjusting the Volume on the Handset
During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using the Speakerphone on the
Handset (handsfree operation) . . . . . . . . . . . . . 26
Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Muting a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Putting a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . 28
Saving a Name/Number in the Phonebook. . . . . . . . 28
Inserting Pauses in a Phone Number . . . . . . . . . . . . 29
Saving a Caller ID or Redial Number
in the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . 29
Calling a Number from the Phonebook . . . . . . . . . . 30
Deleting Phonebook Entries . . . . . . . . . . . . . . . . . . . 30
Editing Phonebook Entries . . . . . . . . . . . . . . . . . . . . 31
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . 32
Erasing Numbers in Redial Memory . . . . . . . . . . . . . 32
Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Reviewing the List of Caller ID Calls . . . . . . . . . . . 33
Dialing a Number from Caller ID . . . . . . . . . . . . . . 34
Saving a Caller ID Number in the Phonebook. . . . 34
Deleting Caller ID Numbers. . . . . . . . . . . . . . . . . . 35
Finding a Lost or Misplaced Handset . . . . . . . . . . . . 35
Entering Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using the Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using a Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4110W44o.book Page 10 Friday, July 25, 2003 3:37 PM

11
Advanced Features . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Using Conference Calling . . . . . . . . . . . . . . . . . . . . . 39
Using the Intercom . . . . . . . . . . . . . . . . . . . . . . . . . . 40
From the Base Station to All Handsets . . . . . . . . . 40
From the Base Station to a Specific Handset . . . . 40
From a Handset to the Base Station . . . . . . . . . . . 41
From a Handset to a Handset . . . . . . . . . . . . . . . . 41
From a Handset to All Handsets and
Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Answering a Base Station to Handset
Intercom Call. . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Transferring Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Unannounced Transfer
from the Base Station or a Handset . . . . . . . . . 42
Announced Transfer
from the Base Station or a Handset . . . . . . . . . 43
Motorola Limited Warranty
for the United States and Canada. . . . . . . . . . . . . . . 44
4110W44o.book Page 11 Friday, July 25, 2003 3:37 PM

12
Getting Started
Getting Started
To set up your Motorola digital expansion handset,
choose a location, connect the charging base, and
install the battery pack, as described in this user’s
guide.
You can add 5 expansion handsets to your system,
for a total of 6 handsets. Expansion handsets do not
need to be plugged into a phone line. Instead, install
the battery pack, as described on page 13, then plug
the power cord into a power outlet where you want to
place the handset.
Choosing a Location
The location should be:
•Away from electrical appliances such as a TV,
personal computer, or another cordless phone.
•In a high and central location with no obstructions,
such as walls.
If you hear noise while using the handset near a
microwave or another cordless phone’s base station,
move away from the microwave or base station and
closer to your handset’s base station.
Connecting the Charging Base
Important: Before installing or handling batteries,
read the Battery Safety Instructions on page 8.
4110W44o.book Page 12 Friday, July 25, 2003 3:37 PM

13
Getting Started
Plug the power cord into a power outlet.
Installing the Battery Pack in the
Handset
Important: Before installing or handling batteries,
read the Battery Safety Instructions on page 8.
1. Remove the battery cover by pressing on the
recess and sliding the cover down and off the
handset.
2. Insert the battery into the battery compartment with
the contacts facing down and aligned with the
contacts in the battery compartment.
3. Slide the battery cover upward and into place.
charge
Charging LED
031615
Battery
Compartment
Contacts
4110W44o.book Page 13 Friday, July 25, 2003 3:37 PM

14
Getting Started
Charging the Handset
Place the handset in the charging base. The
CHARGING LED is solid red when the handset is
charging, see the illustration on page 13.
Note: For the initial charge, charge the battery for at
least 12 hours.
Note: When the handset battery needs charging,
lflashes and LOW BATTERY displays on the
handset.
Handset Controls
Left Soft Key Right Soft Key
Intercom
Volume Buttons
Speaker
Phone Button
(handsfree)
On/Flash
Off/Cancel
Menu Key
4110W44o.book Page 14 Friday, July 25, 2003 3:37 PM

15
Getting Started
Using the Display
When the handset is not in use, the standby screen
displays.
Handset Standby Screen Example
Using the Soft Keys
From the standby screen, the left and right soft keys
perform the function displayed above the key. For
example, pressing the left soft key (REDIAL), opens
the list of previously dialed phone numbers.
When in the MENU list, use the soft keys to scroll (t
and s) through the list. When setting some features,
for example KEYPAD TONE, use the soft keys to
select ON or OFF. When setting other features, for
example RINGER VOLUME, use the soft keys (tand
s) to increase or decrease ringer volume. Use the
soft keys to scroll through the selections of other
features. For example, when setting RINGER TONE,
use the soft keys (<and >) to scroll through the
selections.
This guide shows soft key presses as the function
followed by (a), for example, press REDIAL (a)
or scroll (a).
Time Ringer Off
Left Soft Key
Function
Battery Meter
Right Soft Key
Function
VSU
m
4:26 PM
W
Menu
4110W44o.book Page 15 Friday, July 25, 2003 3:37 PM

16
Getting Started
Using the Menu Key
Use the MENU key (a) to open the menu list and to
confirm (OK) settings. On the display, the currently
selected item is highlighted. Use the left and right soft
keys (a) to scroll (tand s) to items above and
below the currently highlighted item.
Registering an Expansion Handset
The handset that came with your base station is
already registered as Handset 1. You need to
register only new handsets you add to your phone
system.
Note: When a handset is not registered or is
searching for the base station, SEARCHING FOR
BASE displays.
You can register up to 5 expansion handsets to the
base station, for a total of 6 handsets. If you try to
register a 7th handset, Unable to Register
displays.
4110W44o.book Page 16 Friday, July 25, 2003 3:37 PM

17
Getting Started
Note: Install and charge the battery pack before you
register a new handset.
Action
1Ensure the base station is off. Press vif
necessary.
2Press MENU (a) on the base station.
3Scroll (a) to DISPLAY BASE-ID, then
press OK (a). The base station displays
the 15-digit
base ID code .
4Press NEW (a) on the handset. The
ENTER BASE ID screen displays.
5Using the keys on the handset, enter the
15-digit
base ID code , then press OK (a).
If you make a mistake while entering the
code, press the left soft key (<) to clear it.
6The
base ID code may contain numbers and
characters such as #. Make sure to enter all
15 numbers and characters.
7If ENTER BASE ID displays, 1 or more
characters were entered incorrectly. Re-
enter the
base ID code .
8Several screens display briefly, the handset
sounds a confirmation beep, and then
returns to the standby screen.
GettingStarted.fm Page 17 Friday, July 25, 2003 4:53 PM

18
Setting Up Your Expansion Handset
Setting Up Your Expansion
Handset
Setting the Time
Action
1 Press MENU (a).
2 Scroll to SET TIME, then press OK (a).
3 Using the keypad, enter the time (2 digits
each for the hour and minutes). Use a
leading zero for a single-digit hour, (for
example, 03:56). If you make a mistake,
press (left arrow) (a) to clear the digit(s).
4 Press AM/PM (a) to switch between am
and pm, then press SAVE (a).
5 Press OFF to return to the standby screen.
4110W44o.book Page 18 Friday, July 25, 2003 3:37 PM
