MRC SRI6PF User manual

Installation - Operation Manual
SRI6PF/20PF-2
FLY INCUBATORS
3, Hagavish st. Israel 58817 Tel: [phone], Fax: [phone]
[email protected]
MRC. 6.23

2 | Page
For Fly Cultivation
This unit is designed for the growth, cultivation, incubation, and storage of fruit flies (Drosophila
melanogaster). Other models are specifically manufactured for biological oxygen demand
applications.
Use of this unit outside its intended range of applications voids the manufacturing defect warranty. If
you have any questions, consult your incubator dealer or customer service representative to identify
a model suitable for your study or process.
Pictured on Cover: SRI6PF-2 left, SRI20PF-2 right
Warning: This product contains chemicals, including triglycidyl isocyanurate, known to the State of
California to cause cancer as well as birth defects or other reproductive harm. For more information,
go to www.P65Warnings.ca.gov.
¡Advertencia! Este producto contiene sustancias químicas, incluido el triglicidil isocianurato, que el
estado de California sabe que causa cáncer, así como defectos de nacimiento u otros daños
reproductivos. Para obtener más información, visite www.P65Warnings.ca.gov.
Avertissement! Ce produit peut vous exposer à des produits chimiques, dont l'isocyanurate de triglycidyle,
reconnu par l'État de Californie pour provoquer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez le site www.P65Warnings.ca.gov.

3 | Page
Refrigerated Incubator Peltier FLY
100 – 120 Voltage Models: SRI6PF and SRI20PF
220 – 240 Voltage Models: SRI6PF-2 and SRI20PF-2 Part
Number (Manual): 4861674-1

4 | Page
TABLE OF CONTENTS
MODEL CERTIFICATIONS......................................................................................................................................7
Electromechanical and Heating Safety ........................................................................................................................... 7
CE Compliant........................................................................................................................................................................... 7
UKCA Compliant..................................................................................................................................................................... 7
ISO Certified Manufacturer..................................................................................................................................................8
INTRODUCTION..................................................................................................................................................... 9
Read this Manual....................................................................................................................................................................9
Safety Considerations and Requirements ......................................................................................................................9
Contacting Assistance ........................................................................................................................................................ 10
Manufacturing Warranty .................................................................................................................................................... 10
Engineering Improvements ............................................................................................................................................... 10
Temperature Reference Sensor Device ......................................................................................................................... 11
RECEIVING YOUR UNIT.......................................................................................................................................13
Inspect the Shipment........................................................................................................................................................... 13
Orientation Photos ............................................................................................................................................................... 14
Recording Data Plate Information....................................................................................................................................17
INSTALLATION......................................................................................................................................................19
Installation Procedure Checklist ...................................................................................................................................... 19
Required Ambient Conditions.......................................................................................................................................... 20
Required Clearances........................................................................................................................................................... 21
100 – 120 Volt Power Source Requirements............................................................................................................... 22
220 – 240 Volt Power Source Requirements ............................................................................................................. 23
Lifting and Handling ........................................................................................................................................................... 24
Removing from the Pallet.................................................................................................................................................. 24
Leveling.................................................................................................................................................................................. 24
Install the Incubator ............................................................................................................................................................ 25
Deionized and Distilled Water......................................................................................................................................... 25
Installation Cleaning and Disinfection .......................................................................................................................... 25
Install the SRI20PF Side Air Ducts.................................................................................................................................. 26
Shelving Installation.............................................................................................................................................................27
Access Port Stopper ........................................................................................................................................................... 29
GRAPHIC SYMBOLS............................................................................................................................................. 31
CONTROL PANEL OVERVIEW ........................................................................................................................... 33
OPERATION.......................................................................................................................................................... 35
Theory of Operation ........................................................................................................................................................... 35
Put the Incubator into Operation .....................................................................................................................................37
Set Clock and Cycle Mode Start Times ........................................................................................................................ 38
Set the Night Mode Temperature................................................................................................................................... 40
Set the Day Mode Temperature ..................................................................................................................................... 42
Set the Over Temperature Limit...................................................................................................................................... 44
Loading Samples................................................................................................................................................................. 46
Day – Night Auto-cycle...................................................................................................................................................... 46
Chamber Power Outlet.......................................................................................................................................................47
Humidifying the Incubator..................................................................................................................................................47
Condensation and the Dew Point .................................................................................................................................. 48
Door Alarm Setting ............................................................................................................................................................. 49
USER MAINTENANCE ..........................................................................................................................................51
Cleaning and Disinfecting.................................................................................................................................................. 51
Door Components............................................................................................................................................................... 52
Electrical Components....................................................................................................................................................... 52
Calibrate the Temperature display ................................................................................................................................ 53
UNIT SPECIFICATIONS........................................................................................................................................61

5 | Page
Weight...................................................................................................................................................................................... 61
Dimensions............................................................................................................................................................................. 61
Capacity .................................................................................................................................................................................. 61
Shelf Capacity by Weight.................................................................................................................................................. 62
Power...................................................................................................................................................................................... 62
Temperature ......................................................................................................................................................................... 63
PARTS AND CONSUMABLES ............................................................................................................................ 65

6 | Page
TABLE OF CONTENTS

7 | Page
MODEL CERTIFICATIONS
Model Certification and Compliance Statements
ELECTROMECHANICAL AND HEATING SAFETY
IEC 61010-1:2010, AMD1:2016 and 61010-2-010:2019 Safety Certified
+ USA, Canada, Europe Differences
These unit models are certified by Intertek as compliant with the International Electrotechnical
Commission’s 61010 safety standards for electrical and mechanical hazards as well as the
heating of materials in laboratory devices. The units also conform or are certified to the
following national and group differences.
Conforms to UL Standards (United States)
UL 61010-1 (3rd Ed.); Am. 1
UL 61010-2-010:2019
Certified to CSA Standards (Canada)
CAN/CSA-C22.2 No 61010-1 + Amd 1
CAN/CSA-C22.2 #61010-2-010:2019
Certified to EN Standards (European Standards)
EN 61010-1:2010/A1
EN 61010-2-010:2019
Intertek is an OSHA-recognized NRTL, a Standards Council of Canada accredited
certification body, and an EU Notified Body.
CE COMPLIANT
These unit models meet all required electromagnetic compatibility (EMC), EU
low-voltage, and RoHS safety directives.
UKCA COMPLIANT
These unit models meet all required Electromagnetic Compatibility (EMC), low-
voltage, and RoHS safety directives.
5019746

8 | Page
CERTIFICATIONS
ISO Certified Manufacturer
An ISO 9001 certified manufacturer

9 | Page
INTRODUCTION
Thank you for purchasing anincubator. We know you have many choices in today’s competitive
marketplace when it comes to constant temperature equipment. We appreciate you choosing ours. We
stand behind our products and will be here if you need us
READ THIS MANUAL
Failure to follow the guidelines and instructions in this user manual may create a protection impairment
by disabling or interfering with the unit safety features. This can result in injury or death.
Before using the unit, read the manual in its entirety to understand how to install, operate, and maintain
the unit in a safe manner. Ensure all operators are given appropriate training before the unit begins
service.
Keep this manual available for use by all operators.
SAFETY CONSIDERATIONS AND REQUIREMENTS
Follow basic safety precautions, including all national laws, regulations, and local ordinances in your area
regarding the use of this unit. If you have any questions about local requirements, please contact the
appropriate agencies.
SOPs:Because of the range of potential applications this unit can be used for, the operator or their
supervisors must draw up a site-specific standard operating procedure (SOP) covering each application
and associated safety guidelines. This SOP must be written and available to all operators in a language
they understand.
Intended Applications and Locations:The incubators are intended for constant temperature, non-
humidified microbiological incubation applications in professional, industrial, and educational
environments. The units are not intended for use at hazardous or household locations.
Power: Your unit and its recommended accessories are designed and tested to meet strict safety
requirements.
•The unit is designed to connect to a power source using the specific power cord type
shipped with the unit.
•Always plug the unit power cord into a protective earth grounded electrical outlet
conforming to national and local electrical codes. If the unit is not grounded properly, parts
such as knobs and controls can conduct electricity and cause serious injury.
•Do not bend the power cord excessively, step on it, or place heavy objects on it.
•A damaged cord can be a shock or fire hazard. Never use a power cord if it is damaged or
altered in any way.
•Use only approved accessories. Do not modify system components. Any alterations or
modifications to your unit not explicitly authorized by the manufacturer can be dangerous
and will void your warranty.

10 | Page
INTRODUCTION
CONTACTING ASSISTANCE
Phone hours for MRC Customer Support are 6 am – 4:30 pm Pacific Coast Time (west coast of
the United States, UTC -8), Monday – Friday. Please have the following information ready when
calling or emailing Customer Support: the model number, serial number, and part number (see
page 17).
Hagavish st. Israel 58817 Tel: [phone], Fax: [phone] [email protected] ,3
MANUFACTURING WARRANTY
For information on your warranty and online warranty registration please visit
Mnufacturing.com/warranty
ENGINEERING IMPROVEMENTS
Our Manufacturing continually improves all of its products. As a result, engineering changes and
improvements are made from time to time. Therefore, some changes, modifications, and
improvements may not be covered in this manual. If your unit’s operating characteristics or
appearance differs from those described in this manual, please contact your dealer or customer
service representative for assistance.

11 | Page
INTRODUCTION
TEMPERATURE REFERENCE SENSOR DEVICE
Must be purchased separately
Temperature Calibrations
If you are not using a third-party service, a reference sensor device is required for calibrating
your unit’s temperature display.
•See the Calibrating the Temperature Display procedure on page 53 for more information.
Device Accuracy
Reference devices must meet the following standards:
•Accurate to at least 0.1°C
The device should be regularly calibrated, preferably by a third party.
Temperature Probe
Use a digital device with a wire thermocouple probe that can be introduced into the unit chamber
through the access port or door space. Select a thermocouple suitable for the application temperature
you will be calibrating at.
Why a Probe?
Reference readings taken from outside the chamber using wire temperature probes avoid chamber
door openings. Openings disrupt the chamber temperature. Each disruption requires a minimum 1-hour
wait to allow the chamber to re-stabilize before continuing.
No Alcohol or Mercury Thermometers
Alcohol thermometers do not have sufficient accuracy to conduct accurate temperature calibrations.
Never place a mercury thermometer in the unit chamber. Always use thermocouple probes.
Temperature
Reference

12 | Page
INTRODUCTION

13 | Page
RECEIVING YOUR UNIT
INSPECT THE SHIPMENT
•When a unit leaves the factory, safe delivery becomes the responsibility of the carrier.
•Damage sustained during transit is not covered by the manufacturing defect warranty.
•Save the shipping carton until you are certain that the unit and its accessories function
properly.
When you receive your unit, inspect it for concealed loss or damage to its interior and exterior. If you
find any damage to the unit, follow the carrier’s procedure for claiming damage or loss.
1. Carefully inspect the shipping carton for damage.
2. Report any damage to the carrier service that delivered the unit.
3. If the carton is not damaged, open the carton and remove the contents.
4. The unit should come with an Installation and Operation Manual.
5. Verify that the correct number of accessory items have been included.
Model Shelves Static Shelf Brackets Sliding Shelf Brackets
SRI6PF-2 2 4 0
SRI20PF-2
5
8
2
Model Leveling Feet Power Cord Humidification Kit Side Air Duct Panels
SRI6PF-2 4 1 1 0
SRI20PF-2
4
1
1
2
6. A rubber stopper should come installed in the access port inside the incubation chamber.
Verify the presence of the stopper.
7. Carefully check all packaging for accessories before discarding.

14 | Page
RECEIVING
Control Panel
Peltier Thermoelectric Chiller – Heater Housing
SRI20PF Chamber Power
Outlet, NEMA 5-15R 100 –
120 Volt*
Drain Port – TEC-H Housing
Standard Shelf Bracket
Shelf Standard Rail
Door Gasket
Chamber Door
Day Phase Illumination LEDs
ORIENTATION PHOTOS
SRI20PFs
*SRI20PF-2 Chamber Power Outlet, CEE7/3 220 – 240 Volt
Humidification Pan
(behind the sliding shelf)
Access Port

15 | Page
RECEIVING
Control Panel
Peltier Thermoelectric Chiller – Heater Housing
Drain Port – TEC-H Housing
SRI6PF Chamber Power
Outlet, NEMA 5-15R 100 – 120
Volt*
Chamber Door
Door Gasket
Access Port
Day Phase Illumination LEDs
SRI6PFs
Humidification Pan
*SRI6PF-2 Chamber Power Outlet, CEE7/3 220 – 240 Volt

16 | Page
RECEIVING
Power Panel
Data Plate
Chamber Access Port
Power Panel Closeup
Power Cord Inlet with Fuse Holder
Second Fuse Holder (220V Incubators only)

17 | Page
RECEIVING
RECORDING DATA PLATE INFORMATION
Record the unit model number, serial number, and part number below for future reference.
Customer Support needs this information to provide accurate help during support calls and emails.
•The data plate is located on the left exterior wall of the incubator, toward the back and just
above the power cord inlet.
MODEL NO:
SERIAL NO:
PART NO:

18 | Page
RECEIVING

19 | Page
INSTALLATION
INSTALLATION PROCEDURE CHECKLIST
Carry out the procedures and steps listed below to install the incubator in a new workspace location
and prepare it for use. All procedures are found in the Installation section of this manual.
Pre-Installation
Check that the required ambient condition for the unit are met, page 20
Check that the spacing clearance requirements are met, page 21
•Unit dimensions may be found on page 5858
Check that a suitable electrical outlet and power supply is
present, page 22
Installing the Incubator in a suitable workspace location
Review the lifting and handling instructions, page 24
Make sure the incubator is level, page 24
Install the incubator in its workspace location, page 25.
Set up the Incubator for use
Clean and disinfect the unit and shelving (recommended), page 25
SRI20PFs only: Install the side air ducts inside the incubation
chamber, page 26
Install the shelving, page 27
Verify the stopper has been installed in the access port, page 29

20 | Page
INSTALLATION
REQUIRED AMBIENT CONDITIONS
Ambient Temperature Ranges: These units are built for use indoors under climate-controlled conditions
of 15.0°C to 30.0°C (59.0°F to 86.0°F).
SRI6PFs Ambient Impact on Cooling
•In workspace temperatures of 15.0°C to 27.0°C (59.0°F to 80.6°F) the SRI6PF incubators can
achieve an operational chamber temperature range of 15.0°C to 40.0°C.
•Sustained workspace temperatures of 27.1°C to 30.0°C (80.7°F to 86°F) will gradually raise
the lowest achievable incubation chamber temperature. See page 63.
SRI20PFs Ambient Impact on Cooling
•In workspace temperatures of 15°C to 25.0°C (59°F to 77.0°F) the SRI20PF incubators can
achieve an operational chamber temperature range of 15.0°C to 40.0°C.
•Sustained workspace temperatures of 25.1°C to 30°C (77.1°F to 86.0°F) will gradually raise
the lowest achievable incubation chamber temperature. See page 63.
The following ambient conditions will affect the unit temperature performance.
•Ambient Temperature Variation: The workspace temperature should not change by 2°C
(3.6°F) or more during operation.
•Maximum Humidity: No greater than 80% Relative Humidity (at 25°C / 77°F).
Air Quality: The units are rated to operate in a Pollution Degree 2 environment.
Maximum Altitude: 2000 meters (6562 feet).
Additional Environmental Factors: When selecting a location to install the unit, consider all
environmental conditions that can adversely impact its temperature performance. These include:
•Proximity to ovens, autoclaves, or any other device producing significant radiant heat.
•Heating and cooling vents or other sources of fast-moving air currents.
•High-traffic areas.
•Direct sunlight.
