Operating Manual
3S Full Face Mask – Negative Pressure
Order No.: 10089056/02

MSA Europe GmbH
Schlüsselstrasse 12
8645 Rapperswil-Jona
Switzerland
[e-mail]
www.MSAsafety.com
© MSA 2018 All rights reserved

3S Full Face Mask – Negative Pressure 3
GB
Contents
1 Safety Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Correct Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Liability Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Mask Versions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Marking/Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Donning the Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Leak Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Removing the Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Cleaning, Disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4.1 Cleaning/Disinfection with a Washing Machine . . . . . . . . . . . . . . . . .11
4.2 Cleaning/Disinfection with an Ultrasonic Cleaner . . . . . . . . . . . . . . . .11
4.3 Cleaning by Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4.4 Disinfection by Hand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.1 Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.2 Maintenance Intervals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.3 Maintenance of the Exhalation Valve . . . . . . . . . . . . . . . . . . . . . . . . 13
5.4 Replacing the Speech Diaphragm . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.5 Tightness Test of the Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.6 Visual Test and Function Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 Safekeeping and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7.1 Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7.2 Full Face Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.3 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7.4 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3S Full Face Mask – Negative Pressure 4
Safety Regulations
GB
1 Safety Regulations
1.1 Correct Use
Series 3S Full Face Mask with standard thread connection according to EN 148-1 are not complete
respiratory protective devices by themselves, but serve as facepieces [EN 136 CL3+] for use with
respiratory filters, compressed air breathing apparatus, fresh air hose breathing apparatus and
compressed air line breathing apparatus.
The mask as part of a respiratory protective device ensures an appropriately tight fit of the user’s face
against the ambient atmosphere.
It is imperative that this operating manual be read and observed when using the device. In particular,
the safety instructions, as well as the information for the use and operation of the device, must be care-
fully read and observed. Furthermore, the national regulations applicable in the user's country must be
taken into account for a safe use.
WARNING!
This product is supporting life and health. Inappropriate use, maintenance or servicing may affect the
function of the device and thereby seriously compromise the user's life.
Before use the product operability must be verified. The product must not be used if the function test
is unsuccessful, it is damaged, a competent servicing/maintenance has not been made, genuine MSA
spare parts have not been used.
Alternative use, or use outside this specification will be considered as non-compliance. This also
applies especially to unauthorized alterations to the product and to commissioning work that has not
been carried out by MSA or authorized persons.
1.2 Liability Information
MSA accepts no liability in cases where the product has been used inappropriately or not as intended.
The selection and use of the product are the exclusive responsibility of the individual operator.
Product liability claims, warranties also as guarantees made by MSA with respect to the product are
voided if it is not used, serviced, or maintained in accordance with the instructions in this manual.
Changes and modifications not expressly approved by the manufacturer will void the user’s authority
to operate the equipment.

3S Full Face Mask – Negative Pressure 5
Description
GB
2 Description
The face blank is made of a special soft rubber compound and assures a snug, comfortable fit and a
tight seal. The face blank is also available in yellow silicone. Some versions of the mask are also avail-
able in small size.
The inhalation air flows from the connector of the mask past the inhalation valve to the inside of the
lens [thus keeping the lens largely fog-free] and then through the check valves into the nose cup.
The exhalation air passes through the exhalation valve directly to the ambient air.
Fig. 1 Overview full face mask
1 Face blank 5 Connector with inhalation valve
2 Head strap 6 Exhalation valve
3 Buckle 7 Carrying strap
4Lens
1
2
3
4
5
6
7

3S Full Face Mask – Negative Pressure 6
Description
GB
2.1 Mask Versions
2.2 Marking/Certification
Marking
The mask is marked on the outer face blank as shown in Fig. 2:
Fig. 2 Marking of mask body
MSA 3S • Standard version with polycarbonate lens
MSA 3S small • as standard version, small size
MSA 3S-V • as standard version, with polycarbonate lens with silicate coating
MSA 3S-Vg • as standard version, with Triplex [laminated] glass
MSA 3S-EZ • as standard version, special Nomex harness
MSA 3S-Transponder • as standard version, with transponder
MSA 3S-Si • as standard version, face blank, inner mask and harness made
from silicone
MSA 3S-V-Si • as standard version, with polycarbonate lens with silicate coating,
face blank, inner mask and harness made from silicone
1 Mask Version
2 Part Number
3 Marking [date code, serial number]
4 CE-marking with notified body number
[DEKRA EXAM, Zertifizierungsstelle Dinnendahlstr. 9, 44809 Bochum]
5X: ATEX classification A, B or C according to the Lens typ.
6 EN standard, class
1
2
3
45
6

3S Full Face Mask – Negative Pressure 7
Description
GB
Certification
Mask with Lenses from Polycarbonate with Silicate Coating
The masks according to chapter
comply with the following directives, standards or standardised documents:
Mask with Lenses from Polycarbonate
The masks according to chapter 2.1
comply with the following directives, standards or standardised documents:
Directive 2014/34/EU [ATEX] : BVS 05 ATEX H 027 X
for masks
I M1
II 1 G IIA T6 -40 °C Ta +60 °C
II 1 D
Directive 89/686/EC or
Regulation (EU) 2016/425,
respectively
:EN 136 CL3+
0158
DEKRA EXAM GmbH, Dinnendahlstr. 9, 44809
Bochum, Germany, Notified body number: 0158
Directive 2014/34/EU [ATEX] : BVS 05 ATEX H 027 X
for masks
I M1
II 1 G IIA T6 -40 °C Ta +60 °C
II 1 D
I M1
II 1 G IIB T6 -40 °C Ta +60 °C
II 1 D
Directive 89/686/EC or
Regulation (EU) 2016/425,
respectively
:EN 136 CL3+
0158
DEKRA EXAM GmbH, Dinnendahlstr. 9, 44809
Bochum, Germany, Notified body number: 0158

3S Full Face Mask – Negative Pressure 8
Description
GB
Mask with Lenses from Triplex [laminated] Glass
The masks according to chapter 2.1
comply with the following directives, standards or standardised documents:
The Declaration of Conformity can be found under the following link:
https://MSAsafety.com/DoC
Directive 2014/34/EU [ATEX] : BVS 05 ATEX H 027 X
for masks
I M1
II 1 G IIA T6 -40 °C Ta +60 °C
II 1 D
I M1
II 1 G IIB T6 -40 °C Ta +60 °C
II 1 D
I M1
II 1 G IIC T6 -40 °C Ta +60 °C
II 1 D
Directive 89/686/EC or
Regulation (EU) 2016/425,
respectively
:EN 136 CL3+
0158
DEKRA EXAM GmbH, Dinnendahlstr. 9, 44809
Bochum, Germany, Notified body number: 0158

3S Full Face Mask – Negative Pressure 9
Use
GB
3Use
The mask is either carried using the harness in front of the chest or in the mask container.
In order to protect the inside of the mask from dirt, the harness hook is engaged in the front buckle
when the mask is held in front of the chest.
WARNING!
Ensure that the top of the mask seal only lies on the user's forehead. Hair should not be between the
mask's seal and the user’s skin.
The mask could otherwise leak. This danger also exists for instance for mask wearers with beards or
deep scars in the sealing area.
3.1 Donning the Mask
WARNING!
In order to guarantee a proper fit for those wearing glasses, the 3S Full Face Mask spectacle kit must
be worn since ordinary glasses cannot be worn under the mask.
(1) Spread the harness with both hands.
(2) Position the chin into the chin cup.
(3) Pull the head straps over your head.
Whilst doing so, ensure that the harness is sitting
correctly and not twisted.
(4) If necessary adjust mask and tighten the straps in order
as shown firmly and evenly.
When tightening the head straps ensure that the correct
sequence is followed [Figure Pos. 1 - 3, for EZ harness
Pos. 1].
When using the EZ harness if necessary readjust the
head plate by pulling the loop at the back of the head.
1
3
22
1

3S Full Face Mask – Negative Pressure 10
Use
GB
3.2 Leak Check
In order to check the mask-to-face tightness a leak test must be performed before each use.
3.3 Removing the Mask
(1) Seal the mask connector or the inlet opening side of an
attached filter with the ball of your hand.
(2) Test tightness by inhaling and exhaling. Whilst doing so:
when inhaling there must be negative pressure, no
inflowing air should be noticeable.
(3) If necessary retighten the straps.
If the leak test fails the mask must not be used.
(1) Loosen the head harness, press the buckles forwards
using your thumbs.
Do not grip the mask by the exhalation valve!
(2) Grip the mask by the connector and pull off backwards
over your head.

3S Full Face Mask – Negative Pressure 11
Cleaning, Disinfection
GB
4 Cleaning, Disinfection
The cleaning and disinfection of the masks is performed in accordance with the cleaning intervals
chapter 5.2.
There are three possible kinds of cleaning:
• Using a washing machine
• disk washing type (Meiko)
• tumbling type (Miele)
• Using an ultrasonic cleaner
• Cleaning by hand.
WARNING!
Do not use cleaning products containing hydrocarbons or solvents [e.g. nitro-thinner].
Cleaned parts must not be dried in radiant heat [sun, radiators]. When using a drying cabinet, the
temperature must not exceed +60°C.
Perform a tightness test after every cleaning, disinfection and maintenance or after every exchange of
parts.
4.1 Cleaning/Disinfection with a Washing Machine
(1) After cleaning check the two screws for the lens ring. Retighten the screws hand-tight if neces-
sary.
4.2 Cleaning/Disinfection with an Ultrasonic Cleaner
4.3 Cleaning by Hand
(1) Remove inhalation and exhalation valve discs.
(2) Unbutton the nose cup.
(3) Unscrew the speaking diaphragm with the special tool.
(4) Clean mask using lukewarm water and mild cleaning agent EW 80 and thoroughly rinse in
running water.
(5) Disinfect the mask after cleaning. Removed components must be separately cleaned and disin-
fected.
(6) Dry mask and components and reassemble mask in reverse order.
(7) Perform a tightness test [chapter 5.5].
Follow the washing agent’s user instructions on this CD/DVD.
When cleaning/disinfecting with an ultrasonic cleaner please follow the cleaning agent’s
user instructions on this CD/DVD.

3S Full Face Mask – Negative Pressure 12
Maintenance
GB
4.4 Disinfection by Hand
(1) Disassemble and clean the mask (see chapter 4.3).
(2) Disinfect the mask using recommended disinfectant. Please observe the user instruction for the
disinfectant.
(3) Thoroughly rinse mask in running water.
(4) Dry mask and components and reassemble mask in reverse order.
(5) Perform a tightness test (see chapter 5.5).
5 Maintenance
5.1 Maintenance Instructions
This device should be regularly checked and serviced by trained specialists. Inspection and service
records must be maintained. Always use original parts from MSA.
Repairs and maintenance must be carried out only by authorised service centres or by MSA. Changes
to devices or components are not permitted and will result in loss of approval.
MSA is liable only for maintenance and repairs carried out by MSA.
5.2 Maintenance Intervals
*) For a 2-year interval cleaned and disinfected masks have to be stored airtight. Otherwise masks
should be cleaned and disinfected at least semi-annually. After each cleaning and disinfection the
facepiece must be checked.
**) For airtightly packed facepieces, which are not exposed to increased climatic and mechanical stress
[for example transport on vehicles], this interval can be extended to 2 years.
Clean the mask before disinfecting.
Use a disinfectant according to the user instructions on this CD/DVD.
MSA recommends the following maintenance intervals. If necessary considering the
usage, tasks may be at even shorter intervals than indicated.
Observe national laws and regulations!
If in any doubt, ask your local MSA contact person.
Work to be
Performed
Maximal Intervals
Before use After Use 6-monthly Two
years
Four
years
Six
years
Cleaning and Disin-
fection*) XX
*)
Visual, Functional
and Tightness
Check **)
XX
**)
Replacement of the
exhalation valve
disc
X
Replacement of the
Speech Diaphragm X
User check X

3S Full Face Mask – Negative Pressure 13
Maintenance
GB
5.3 Maintenance of the Exhalation Valve
In case of a leak remove the exhalation valve disc and replace it with a new one as follows:
(1) Remove the protective housing.
(2) Remove the exhalation valve disc or
(3) remove exhalation valve. For this purpose unscrew the threaded socket from the mask inside
with the special tool.
(4) Replace the defective components.
(5) Reassemble the parts in reverse order.
(6) Perform a tightness test [chapter 5.5].
WARNING!
The air vents of the protective housing are turned to the front side. After maintenance the protective
housing must be fitted in the same position.
5.4 Replacing the Speech Diaphragm
(1) Unbutton the nose cup.
(2) Unscrew the threaded socket from the mask inside with the special tool.
(3) Remove the speech diaphragm.
(4) Assemble the new speech diaphragm with the gasket towards the connector.
(5) Perform a tightness test [chapter 5.5].
5.5 Tightness Test of the Mask
(1) Fit mask tight onto the test instrument.
(2) Generate a negative pressure of 10 mbar.
(3) Measure the pressure change after 1 min.
The mask including the exhalation valve meets the requirements if for a moistened exhala-
tion valve and a negative pressure generated inside the mask the pressure change does not
exceed 1 mbar in a minute.
Leaking masks must not be used.
The year of manufacture is located on the valve disc.
The year of manufacture is located on the speech diaphragm.
The testing of the masks for tightness is performed using an applicable MSA test device
in accordance with the relevant operating manual.

3S Full Face Mask – Negative Pressure 14
Safekeeping and Storage
GB
5.6 Visual Test and Function Test
Visual Test
(1) Inspect the mask for possible damages like for example deformations, stickings or cracks. Valve
discs, especially exhalation valve discs, are crucial functional elements of the mask.
(2) Defective or damaged parts have to be replaced immediately.
Functional Test
After assembling the mask the mobile parts, especially the valve discs, have to be tested for unre-
stricted mobility.
6 Safekeeping and Storage
WARNING!
In order to avoid damage to or the deformation of the masks keep no additional loose objects in the
mask container.
For the safekeeping of the mask the mask container should be used. This also applies to masks with
installed filters, except CO and NO filters.
MSA rubber products are protected by an anti-aging agent that can become visible as a light coating.
This coating is harmless and can be removed during cleaning.
To ensure a long life for rubber components, keep them in a cool, dry place that is protected from ultra-
violet radiation, according to ISO 2230:2002, Rubber Products – Guidelines for Storage.

3S Full Face Mask – Negative Pressure 15
Ordering Information
GB
7 Ordering Information
7.1 Exploded View
Fig. 3 Full face mask exploded view
1 Nose cup [without valves] 11 Inhalation valve seat
2 Nose cup valve disc 12 Inhalation valve disc
3 Nose cup valve seat 13 Connector
4a Head harness EZ 14 Lens ring
4b Head harness 15 Lens
5 Carrying strap 16 Screw for lens ring
6 Threaded ring 17 Buckle with hook
7 Slide ring 18 Speech diaphragm
8 Exhalation valve housing 19 Threaded ring
9 Exhalation valve disc 20 Buckle with hook and D-ring
10 Protective housing
12319
4a
4b
5
181716
14
15
14
13
12
11
10
9
8
6
7
20

3S Full Face Mask – Negative Pressure 16
Ordering Information
GB
7.2 Full Face Mask
7.3 Accessories
Description Article No.
3S D2055000
3S – small D2055779
3S – V D2055772
3S – Vg D2055774
3S – silicone D2055718
3S – V silicone D2055769
3S – EZ D2055767
3S – Transponder 10013877
Description Article No.
3 S spectacles [plastic frame] D2055954
3 S spectacles [metal frame] D2055811
Special tool [for replacing exhalation valve and speech diaphragm] D2055038
Cover lens, adhesive [package of 10] D2055706
Exhalation valve closure D5135047
Mask hanger [package of 4] D2055753
Mask tightness test kit [for more MSA testing instruments refer to
www.MSAsafety.com] D6063705

3S Full Face Mask – Negative Pressure 17
Ordering Information
GB
7.4 Replacement Parts
Description Article No.
Maintenance Set
[inhalation valve, exhalation valve, valve seat, 2 nose cup valve discs] D2055999
Nose Cup, without valves [rubber] D2055025-SP
Nose Cup, without valves [silicone] D2055213-SP
Lens [polycarbonate, package of 10] 10080822
Lens [polycarbonate with silicate coating] D2055757
Lens [laminated glass] D2055730
Lens ring, assembly D2055746
Screw for lens ring [package of 10] D2055996
Clamp [package of 10] 10095118
Clamp for 3S-small [package of 10] D0013834-SP
Speech diaphragm [package of 2] D2055708
Nose cup valve seat [package of 10] 10096173
Nose cup valve disc [package of 20] D2055731
Threaded ring [exhalation valve] D2055011-SP
Inhalation valve disc [package of 20] D2056714
Inhalation valve seat [package of 5] D2055725
Exhalation valve, assembly: D5135927
Protective housing [package of 4] 10096172
Slide ring [package of 4] 10096058
Exhalation valve disc [package of 10] D5135912
Exhalation valve housing D5135702
Threaded ring D5135041-SP
Head harness [rubber] [package of 10] 10102911
Head harness [silicone] D2055219-SP
Buckle with hook [package of 10] 10096406
Buckle with hook and D-ring [package of 10] 10096408
Carrying strap, assembly D2055707-SP

For local MSA contacts, please visit us at MSAsafety.com
Because every life has a purpose...
