National Cycle VStream N20014 Installation instructions

10mm Box Wrench
5mm Hex Key
Phillips Screw Driver
PARTS LIST
Index Description Qty.
1 Windscreen, Quantum Hardcoated polycarbonate 1
With RainZip treatment
2 RainZip treatment, 3oz. Bottle 1
Bag 1008
3 M6 x 16 Stainless Screws w/ Nylok 4
4 Collar L .177 4
5 Foam Pads 4
REMOVAL AND RE-IN TALLATION
Retain all fasteners and parts. Most will be re-
used. Four M6 x 16 crews and Collars are supplied.
Installation of windscreen will be in reverse order
of removal.
Position stock windscreen in highest position.
1. Move mirror forwar . Lift rubber sleeve to expose insi e
attachment point. Repeat on opposite si e.
2. Gently pry “bracket” over hex bolt to in or er to remove
har ware hol ing front bo y panel in place. Repeat on
opposite si e. Figure 1. (10mm Box Wrench)
To avoid hardware dropping into mirror cavity
stuff a small cloth under hardware! Item (A)
3. Remove har ware hol ing front panel in place. Repeat
on opposite si e.
Attention Note
pecial notes and cautionary measures
which can prevent damage to the accessory
or motorcycle.
Tips for facilitation of operation,control
and adjustment, as well as maintenance.
N20014 V tream®pecial Edition
Windscreen for GL1800 2001~
Installation and Owner’s Manual
Quantum™ Hardcoated polycarbonate
with RainZip® Treatment
National Cycle, Inc. PO Box 158, Maywood, IL 60153-0158 SA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / e mail: [email protected]
Page 1 / 4 10-118545-000 03/10
Figure 1
Figure 2
A
Thank you for purchasing a National Cycle® product. Please read these instructions carefully and thoroughly
before beginning work. Dealers if installing this windshield for a customer please give them this manual. It con-
tains information needed to properly maintain and use this product.

REMOVAL AND RE-IN TALLATION CONTINUED
Position mirror back (toward rider) in order to
remove front panel. Repeat on opposite side. Figure 3
4. Unsnap front panel. Figure 4.
5. Remove front an si e har ware hol ing win screen in
place. Figure 5 and 6 (5mm Hex Key and Phillips
crew Driver)
6. Remove stock win screen.
Figure 3
Figure 5 Figure 6
Figure 4
National Cycle, Inc. PO Box 158, Maywood, IL 60153-0158 SA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / e mail: [email protected]
Page 2 / 4 10-118545-000 03/10

APPLICATION OF RAINZIP TREATMENT
Quantum™ hardcoat friendly
To keep your new windscreen clear for many years,
National Cycle has applied their exclusive Quantum™
scratch resistant hardcoat. And, to help keep the screen
clearer in the rain National Cycle treated this pecial
Edition windscreen with their exclusive RainZip® rain repel-
lant. RainZip is hydrophobic. In other words, it is afraid of
water, when water hits the surface of the screen it beads
up, so at 40 mph the wind pushes the water off.
The time in which you will need to reapply this coating will
depend riding conditions. If you use your bike regularly
after about 3 months you may notice the treatment not
working as effectively. When this happens, first clean your
windshield throughly, then buff with a microfiber soft cloth
or unused soft chamois. Buffing the windshield will “re-
new” the RainZip® treatment.
Around 5 months you may want to reapply the RainZip®
treatment. Order RainZip treatment N1410-01 when you
are ready to apply to windscreen.
For your convenience we have included one, 3oz bottle
N1410 RainZip Treatment with your pecial Edition
V tream windscreen. Apply as directed.
1. Clean the windshield thoroughly with National Cycle
hield Wash (N1401-01) or mild soap and water.
2. hake bottle and apply RainZip treatment liberally using
the white synthetic cloth supplied, not an ordinary cloth or
paper towel.
3. Let dry until surface becomes white.
4. Wipe clean with circular motions using the microfiber
cloth.
Go on line for in-depth product knowledge and our how-to
video: www.nationalcycle.com/rainzip
National Cycle, Inc. PO Box 158, Maywood, IL 60153-0158 SA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / e mail: [email protected]
Page 3 / 4 10-118545-000 03/10
REMOVAL AND RE-IN TALLATION CONTINUED
7. Install the ie cut Foam Pa s (item 5). Clean the insi e
surface of the fairing with a mil etergent an water. Dry
throughly. Do not use wax or polish. Figure 7
8. Install VStream win screen in reverse or er.
Use the four, M6 x 16 Screws an Collars supplie in Bag
#1008 as in icate in figure 7. Use stock har ware in other
locations.
5555
Figure 7

MAINTENANCE
Cleaning: Wash with a clean soft cloth, plenty of warm water and, if necessary, a non-abrasive soap such as dish-
washing liquid. Flannel or soft chamois make good cleaning cloths. Do not use rain protective products on the screen
due to the solvent action of the alcohol in these products. Do not allow brake fluid, alcohol, or strong solvents to con-
tact the screen. Refer to page three for information about RainZip hydrophobic treatment.
National Cycle Windshield Wash Part number N1401 is recommended for everyday cleaning. Product is supplied with
a handy travel size container and rag for easy storage on the motorcycle.
Ask your local dealer or visit: www.nationalcycle.com
Never ride your motorcycle with loose accessory mounting hardware. Check the hardware for tightness regularly.
Today's motorcycles are built with enough frame rigidity to withstand the moderate loads imposed on them by the foreseeable addi-
tion of an accessory(ies). If an accessory(ies) adversely affects your motorcycle's stability, immediately remove the accessory(ies).
Do not ride a motorcycle that exhibits unsafe handling traits.
Have experienced service personnel correct any problem before riding with the accessory(ies) installed. For further questions con-
cerning handling problems associated with an accessory(ies), contact your dealer, motorcycle manufacturer, or accessory manufac-
turer.
National Cycle 3-Year Limited Warranty
Register your windshield on Line at: www.nationalcycle.com/register.html
or contact Customer ervice at National Cycle, Inc. / PO Box 158 / Maywood, IL 60153 / U A
708/343/0400
National Cycle hereby warrants to the original registered owner of a National Cycle polycarbonate wind-
shield for a period of three years from the date of purchase against breakage. This limited warranty is
expressly limited to the replacement of the polycarbonate windscreen. This limited warranty does not
include scratches, coating failure, cosmetic wear and tear, replacement of hardware, or any consequential
damages or expenses including labor cost of installation, removal and/or replacement, inconvenience,
inbound freight expenses or damage to any other component of the motorcycle or any other accessories.
Certain chemicals, generally known as acidic hydrocarbons, are known to cause polycarbonate damage and will not be covered
under this limited warranty. Please refer to the cleaning instructions supplied with all National Cycle windshields.
National Cycle, Inc. PO Box 158, Maywood, IL 60153-0158 SA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / e mail: [email protected]
Page 4 / 4 10-118545-000 03/10
WIND HIELD ADJU TMENT
The Special E ition VStream allows full use of the win shiel a justment feature on your Gol wing 1800.
Here are helpful trouble shooting tips if fin the range limite :
1. If this is an ol er motorcycle, the a juster coul be frozen. Check mechanism insi e fairing.
2. Use the har ware supplie in Bag#1008 uring the installation. The stock bolts pinch own on the shiel not alllow-
ing it to move.
3. To lower the shiel , first, it must be raise to the highest position to allow the a juster to release. Then it can be
lowere .
4. The support pa s in place on your new VStream win shiel make it a little har er to move the shiel until they are
“broken in”.
