National Cycle N20019 User manual

National Cycle, Inc. PO Box 158 aywood, IL 60153-0158 USA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / [email protected]
©2019 National Cycle, Inc. Page 1 of 4 10-118578-000 09/19
Thank y u f r purchasing a Nati nal Cycle pr duct. Read these instructi ns carefully and th r ughly bef re beginning w rk. Dealers, if installing this wind-
screen f r a cust mer, please give them this manual up n c mpleti n. It c ntains inf rmati n needed t pr perly maintain and use this pr duct.
Note:
Tips for facilitation of operation, control and
adjustment, as well as maintenance work.
Attention:
Special notes and cautionary measures which can
prevent damage to the accessory or motorcycle.
CONTENTS OF KIT
uantum® Hardcoated Polycarbonate
Deluxe VStream® Windscreen for:
Honda GL1800 2018~
N20019, Mid, Clear
N20020, Tall, Clear
TOOLS RE UIRED
Pointed tool for removal of
plastic rivet
5mm and 4mm Hex Wrench
10mm Box Wrench
Tape (optional)
Fig 1
Fig 2
PREPARATION
1. Position motorcycle securely on its stand.
2. Place Windshield in high position. Fig. 1
INSTALLATION
Remove the OEM windscreen
OE Hardware will not be re-used.
3. Remove the two plastic Rivets, located
inside of left and right stay. (Pointed Tool).
Fig. 2
Item Description Part No. ty.
1 Deluxe VStream® Windscreen with Vent 1
KIT-N20020
2 ount Arm Left 34-350222-000 1
3 ount Arm Right 34-350223-000 1
BAG#1332
4 Grommet 44-447350-000 4
5 Collar 49-495592-000 4
6 Cap Trim 34-346047-000 4
7 Screw 6x20 SS 51-514221-000 4
8 Nut, 6 Cap 42-483005-000 4
9 Screw, Button, 6 x 16 51-516317-000 4
10 etal Washer 44-490511-000 4
(2)
(9)
(10) (4) (8)
(6)
(5) (7)
(3)

National Cycle, Inc. PO Box 158 aywood, IL 60153-0158 USA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / [email protected]
©2019 National Cycle, Inc. Page 2 of 4 10-118578-000 09/19
4. Remove left and right Outer Covers. Fig 3
5. Remove the four screws and washers holding
the OE shield in place. (5mm Hex Wrench)
Fig 4
6. Remove the OE Windshield
Remove the OEM Windshield Mount Arm
7.Loosen the Screws holding the OE arm
(5mm Hex Wre ch) Fig 5
8. ove mount arm forward and downward to
remove from bracket (a)
Remove the OEM I ter al Bolt Plate
9. Remove the internal bolt plate. Fig 6
Plate is directional. Keep the left and right
separate.
Fig 4
Fig 5
Fig 6
Fig 3
(a)
Note the two
keyways

National Cycle, Inc. PO Box 158 aywood, IL 60153-0158 USA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / [email protected]
©2019 National Cycle, Inc. Page 3 of 4 10-118578-000 09/19
10. Place OE plate on bracket. Align the two
keyways.
Install National Cycle Mount Arms
11. Use the Screw (9) and Washer (10) to
mount the ount Arm (2 and 3) to the
motorcycle. Tighten screws firmly. (4mm Hex
Wrench) Fig 8
Install VStream Windshield to Mount Arms
12. Insert one Grommet (4) into each hole in
Windshield. Fig 9
13. Insert one Collar (5) into each Grommet.
Fig 9
14. Insert a Trim Cap (6) onto Screw (7).
15. Install Windshield to motorcycle with Screw
assembly and Nut (8). (4mm Hex Wrench,
10mm Box Wrench) Fig 10
To ease installation at the lower two holes,
use Tape to hold Nut (8) to Box Wrench.(Tape)
Fig 10
16. Fully tighten Screws and Nuts (4mm Hex
Wrench, 10mm Box Wrench)
Align the two
keyways
Fig 7
Fig 8
Fig 10
Fig 9
(4)and (5)
(7)
(6)
(3) (2)
(8)
(9)
(10)

National Cycle, Inc. PO Box 158 aywood, IL 60153-0158 USA
708-343-0400 / Fax: [phone] / www.nationalcycle.com / [email protected]
©2019 National Cycle, Inc. Page 4 of 4 10-118578-000 09/19
CLEANING AND MAINTENANCE
To clean the screen, wash with a clean soft cloth and plenty of warm water and, if
necessary, a non-abrasive soap such as dishwashing liquid. Flannel or soft chamois
make good cleaning cloths. Paint, glue residue or grease removal: oisten cotton
wad with naphtha or turpentine followed by a wash as above.
National Cycle Shield Wash™ (N1401-01) makes a good daily cleaner and comes
with a handy travel-size bottle. Shield Wash is safe for all windshields and helmet
visors.
Do not clean polycarbonate in hot sun or high temperatures. Do not clean the screen
with household glass cleaners.
Do not allow brake fluid, alcohol, or strong solvents to contact the screen.
RAIN REPELLENT
Do not use rain protective products made for glass. We recommend National Cycle’s
RainZip® (N1410-01) to keep your windscreen clear in rainy weather.
Register Your Wi dshield O li e at www. atio alcycle.com
Natio al Cycle 3-Year Limited Warra ty
National Cycle hereby warrants to the original registered owner of a National Cycle polycarbonate windshield for a period of
three years from the date of purchase against breakage. This limited warranty is expressly limited to the replacement of the
polycarbonate windscreen. This limited warranty does not include scratches, coating failure, cosmetic wear and tear, replace-
ment of hardware, or any consequential damages or expenses including labor cost of installation, removal and/or replace-
ment, inconvenience, inbound freight expenses or damage to any other component of the motorcycle or any other acces-
sories. Certain chemicals, generally known as acidic hydrocarbons, are known to cause polycarbonate damage and will not be
covered under this limited warranty. Please refer to the cleaning instructions supplied with all National Cycle windshields.
Visit www. atio alcycle.com for further details or call or write Natio al Cycle
Never ride your motorcycle with loose accessory mounting hardware. Check the hardware for tightness regularly.
Today's motorcycles are built with enough frame rigidity to withstand the moderate loads imposed on them by the foreseeable addition of an
accessory(ies). If an accessory(ies) adversely affects your motorcycle's stability, immediately remove the accessory(ies). Do not ride a motorcycle
that exhibits unsafe handling traits.
Have experienced service personnel correct any problem before riding with the accessory(ies) installed. For further questions concerning handling
problems associated with an accessory(ies), contact your dealer, motorcycle manufacturer, or accessory manufacturer.
Sunlight reflected off the inside curvature of the windscreen can, at certain times of the day, cause extreme heat buildup on the motor-
cycle’s instruments and possibly even melt them. Exercise care in parking to avoid this. Park your motorcycle facing the sun, or place
an opaque object over the instruments and dash panel.
VStream® Windscreen Patent n . 7,387,328
Ask for Shield Wash™ and RainZip® at your local dealer
or visit www.nationalcycle.com.
WARNING
Vent Adjustment
For maximum airflow, open windshield
vent fully and use in conjunction with OE
pop-up vent.
Enjoy your new VStream® Windshield!
