PCM4-CAM
NTV-KIT750
Overview
The PCM4-CAM Kit interfaces a backup camera input (with active parking lines) and 1 additional
video input (front cam, etc) to the factory media screen in the 2017 Porsche vehicles equipped
with PCM4.0, 2015+ Audi A3 and 2015+ Golf VII. Installation is performed behind the radio (disc
player).
Kit Content
Infrared Receiver
OSD Menu Remote
Power/CAN Harness
LVDS
Video
Cable
PCM4-CAM Interface
Wire trigger cable (optional)

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
2 | P a g e
Interface Connectors
Dip Switch Settings
Dip SW:
1
2
3
4
5
6
UP
N/A
N/A
AUDI/GOLF
N/A
HIGH RES
KEEP DOWN
DOWN
N/A
N/A
PORSCHE
N/A
LOW RES
KEEP DOWN
Power/CAN Harness
Dip Switches
Note: Remove power to the unit prior to
making adjustments to the dip switches.
Video OUT
(to screen)
Video IN (from
radio)
Not Used
Wire trigger
(optional)
Infrared Receiver
Not Used

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
3 | P a g e
Installation (Porsche)
1. Remove the factory radio. Disconnect any associated harnesses and set the radio aside.
2. Grab the provided Power/CAN Harness from the PCM4-
CAM kit. Connect the following wires to the car radio’s
main power plug*:
3. Locate the factory Green (at the radio, NOT
the screen),4-pin round LVDS video
connector that was removed from the radio
in step 1. Connect this factory plug to the
PCM4-CAM interface at the port labeled ‘VIDEO OUT’.*
4. Connect the smaller white plug
side of the provided LVDS
Video Cable to the port on
the PCM4-CAM interface
labeled VIDEO-IN.
Interface wires
Connect to car
Radio Plug
Black (Ground)
Chassis Ground
PIN 15 (Brown)
Red (Constant 12v)
Constant 12v (+)
PIN 16 (Red/Yellow)
Green (Rev 12v in)*
Reverse Lamp (+)
---
*Note: this Green wire is ONLY used if CAN
connection does not switch display to
reverse image while in reverse properly.
Installation connections remain the same for Audi and Golf. Be sure to set dip switches appropriately.

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
4 | P a g e
5. Connect the free end of the provided LVDS Video Cable (green) back to the factory radio
at the appropriate port (if keyways must be cut, do so).
6. Connect the provided 12-pin plug & play portion from the main power harness to the
main factory quad-lock connector as shown below. Pay attention to the orientation, as
this is vital to proper operation:
Remove gray OEM 12-pin
Connect OEM 12-pin to provided 12-pin
(black, PIN-side). NOTE: blue and green wire
corner locations on provided plug vs OEM.
Connect the female 12-pin
side of the plug & play
portion to the OEM main
quad-lock connector as
shown. Note the paint dot
must face towards the
power wires.

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
5 | P a g e
7. Connect ground and power for your camera (use an ACC source for power) and run to
the front of the vehicle.
8. Connect the video feed from the camera to the RCA among the main power harness
labeled ‘CAMERA’.
9. Connect the white plug from the Power/CAN Harness to the port on the PCM4-CAM
interface labeled ‘POWER CAN’.
10. Optional: If adding an additional video input (including front camera), connect the video
signal to the RCA among the Power/CAN Harness labeled ‘FRONT’.
11. Start the car and test for proper functionality before replacing any dash pieces.
12. If the screen does not transition to reverse image when in reverse, connect the Green
wire labeled ‘REVERSE’ to an OEM reverse lamp 12v (+) wire. This is sometimes the
case with manual transmission-equipped vehicles.

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
6 | P a g e
PCM4-CAM Install Diagram

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
7 | P a g e
In the event that REAR MODE has been changed to OEM or
OFF and you can no longer access the OSD menu:
1. Car must be on, radio resting on Reverse Gear Screen
2. Press OK on the remote 4 times then press MODE (not
MENU). Note: there will be no indication of OK presses this
time.
3. Reverse (aftermarket) guidelines should appear. Now
press OK on the remote 4 times then press MENU (not
MODE) to enter the OSD menu as typical.
- SET –FRON CAM must be turned on if adding a front
camera and the user wishes for automatic front camera
switching. Options for 5, 7, 9 or 11 seconds are user
selectable for the length of time the front camera input
stays active once the vehicle is placed out of reverse.
Menu Adjustments (dynamic guidelines, AUX video, front camera etc)
Before you start:
The IR-Eye must be connected, ( connects to main harness)
Make sure the car’s ignition is on and radio is on
You must be in Reverse Camera mode.
Press the OK BUTTON 4 times (numbers will display per press), then
press POWER.
The OSD Menu will appear on screen (auto-time out in about 5
seconds if no action occurs).
Use if adding only AUX input/front cam
Use if adding aftermarket rev camera (default)
Use if vehicle has OEM reverse camera
Functional Parking Guidelines ON/OFF
Parking Distance Control
ON/OFF (while in reverse)
Adjust FPG Position
Adjust PDC Position
‘Safe to move?’ ON/OFF
PDC
CAN control
while in reverse
(see below)
Front camera timer
(after reverse)

BHM
06/16/16
NTV-DOC262
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
8 | P a g e
PCM4-CAM Operation (Porsche)
Once all connections are made, placing the vehicle in
reverse will display the connected camera image on the
PCM4 screen.
If an AUX video source is connected to the secondary RCA,
press and hold the phone hang up button on the steering
wheel for 2 seconds to display this video source at any
time.
Alternatively (or if vehicle is not equipped with
steering wheel controls), pressing the MAP
button once will cycle between the navigation
map and provided AUX video, if active (OSD
menu).
PCM4-CAM Operation (AUDI A3)
Once all connections are made, placing the
vehicle in reverse will display the connected
camera image on the media screen.
If an AUX video source is connected to the
secondary RCA, press and hold the iNAV button
on the steering wheel for 2 seconds to display
this video source at any time.
Press & hold
