Parts List
76 ◆Specifications and Parts DSX-80/160 Hardware Manual
Parts List
Station Equipment
Description Part Number
22-Button Display Telephone with Speakerphone 1090020 (Black)
1090025 (White)
34-Button Backlit Display Telephone with Speakerphone 1090021 (Black)
1090026 (White)
34-Button Backlit Display Telephone with Full-Duplex Speaker-
phone
1090022 (Black)
1090027 (White)
34-Button Backlit Super Display Telephone with Full-Duplex
Speakerphone
1090023 (Black)
1090028 (White)
60-Button DSS Console 1090024 (Black)
1090029 (White)
DTH-1-1 Single Line Telephone 780034
DTR-1-1 Single Line Telephone 780020 (Black)
780021 (White)
DTR-1HM-1 Single Line Telephone 780025 (Black)
780026 (White)
Analog Door Box 922450
2PGDAD Module 0891027
DSX Cordless Lite II Telephone
Description Part Number
Cordless Lite II Telephone 730087
Cordless Lite II Base Unit AC Adaptor 730618
Cordless Lite II Base Unit Wall Mount Bracket 730608
Cordless Lite II Handset Charger 730632
Cordless Lite II Handset Charger AC Adaptor 730619
Cordless Lite II Wall Mount Bracket for Handset Charger 730633
Cordless Lite II Handset Battery 730631
Cordless Lite II Belt Clip 730634
Cordless Lite II M175 Headset 750637
Cordless Lite II MX150 Headset 750642

Parts List
DSX-80/160 Hardware Manual Specifications and Parts ◆77
Specifications
and Parts
DESI Labels
Description Part Number
DSX Telephone Labels
DSX 22-Button Display Telephone (White) 1093086
DSX 22-Button Display Telephone (Black) 1093085
DSX 34-Button Display Telephone (White) 1093084
DSX 34-Button Display Telephone (Black) 1093083
DSX 34-Button Super Display Telephone (White) 1093082
DSX 34-Button Super Display Telephone (Black) 1093081
DSX 60-Button DSS (White) 1093080
DSX 60-Button DSS (Black) 1093079
DTR-1-1 Telephone Labels
Black 780400
Metallic Green 780401
Metallic Silver 780402
Lime Green 780403
Preprint (blank) 780459
DTR-1HM-1 Telephone Labels
Black 780404
Metallic Green 780405
Metallic Silver 780406
Lime Green 780407
Preprint (blank) 780460
DTH-1-1 Telephone Labels
Metallic Silver 780450
DSX Telephone Headsets
Description Part Number
See Headsets (page 5).

Parts List
78 ◆Specifications and Parts DSX-80/160 Hardware Manual
Common Equipment
Description Part Number
DSX-80 4-Slot KSU
DSX-160 8-Slot KSU
1090002
1090003
DSX Power Supply 1091008
Installation Cable 808920
DSX Serial Adaptor
(requires customer-provided 6-conductor line cord)
1091014
Cards
Description Part Number
CPU Card 1090010
16 Port Digital Station Card (16ESIU) 1091004
16 Port Analog Station Card with HV Message Waiting
(16SLIU)
1091007
8 Port Analog Station Card with HV Message Waiting (8SLIU) 1091010
T1/E1/PRI Line Card 1091006
16 Port CO Line Card (16COIU) 1091005
8 Port CO Line Card (16COIU) 1091009
IntraMail
Description Part Number
IntraMail 8 Port x 16 Hour 1091013
IntraMail 4 Port x 8 Hour 1091011

Parts List
DSX-80/160 Hardware Manual Specifications and Parts ◆79
Specifications
and Parts
Replacement Parts
Description Part Number
Handset and Cord Assembly 1091016
22 Button Clear Plastic Cover 1091018
34 Button Clear Plastic Cover 1091019
34 Button Super Display Clear Plastic Cover 1091020
60 Button DSS Clear Plastic Cover 1091021
RFI Bead Kit 88901
Replacement Battery for CPU Card EX0254-0040
