Neilsen CT2818 Operation instructions

233 PIECE ROTARY TOOL KIT CT2818
ORIGINAL INSTRUCTION
SAVE THESE INSTRUCTIONS AND PRECAUTIONS.
READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.

EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety
and health requirements of the EC Directive based on its design and type, as
brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration
will lose its validity.
Product description: 233 PIECE ROTARY TOOL KIT
Model: CT2818
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
EC Directive of Electromagnetic Compatibility 2014/30/EU
Harmonized standards
EN 60745-1, EN 60745-2-23, EN 55014-1, EN 55014-2, EN 61000-3-3,
EN 61000-3-2
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2016-12-08

1. APPLICATION
This rotary tool can be used for drilling, grinding, sanding and polishing, as
well as engraving, cutting and removing rust in tight spaces or inaccessible
places. The tool can be used on most metals, glass, wood and ceramics. For
best performance and results keep the speed as even as possible without
exercising too much pressure. As a guideline, use the tool at low speed for all
large accessories, such as polishing for example, and at high speed for
smaller accessories such as those used for engraving. For grinding and
engraving, hold the tool as if it were a pen.
WARNING! For your own safety, read this manual and the general
safety instructions carefully before using the appliance. Your power
tool should only be given to other users together with these
instructions.
2. DESCRIPTION (FIG A)
1. ON/OFF switch
2. Speed adjusting wheel
3. Carbon brush holder
4. Spindle lock button
5. Collar
6. Collet nut
FIG.A

3. SYMBOLS
The following symbols are used in this manual and/or on the machine:
Denotes risk of
personal injury or
damage to the tool
Read manual before
use
In accordance with
essential safety
standards of
applicable European
directives
Class II- The
machine is double
insulated; Earthing
wire is therefore no
necessary
Mandatory use of
eye protection
Wear a mask in
dusty conditions
Wear noise protection
4. GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and
follow instructions may result in electric shock, fire and/or serious injury.
Keep safety warnings and instructions for future reference. The term
"power tool" in the safety warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
4.1 Working area
Keep working area clean and well lit. Untidy and dark areas can lead to
accidents.
Do not operate power tools in potentially explosive surroundings, for
example, in the presence of inflammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or fumes
Keep children and bystanders at a distance when operating a power tool.
Distractions can cause you to lose control of it.

4.2 Electrical safety
Always check that the power supply corresponds to the voltage
on the rating plate.
Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use adapter plugs with earthed power tools. Unmodified plugs and
matching outlets will reduce the risk of a lethal electric shock.
Avoid body contact with earthed surfaces such as pipes, radiators,
kitchen ranges and refrigerators. There is an increased risk of a lethal
electric shock if your body is earthed.
Do not expose power tools to rain or wet conditions. If water gets inside a
power tool, it will increase the risk of a lethal electric shock.
Do not damage the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep the cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
a lethal electric shock.
When operating a power tool outdoors, use an extension cable suitable
for outdoor use. Using a cord suitable for outdoor use reduces the risk of
a lethal electric shock.
If operating a power tool in a damp location is unavoidable, use a power
supply protected by a residual current device (RCD). Using an RCD
reduces the risk of a lethal electric shock.
4.3 Electrical safety
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool when you are tired or
under the influence of drugs, alcohol or medication. Amoment of
inattention when operating a power tool may result in serious personal
injury.
Use safety equipment. Always wear eye protection. Using safety
equipment such as a dust mask, non-skid safety shoes, a hard hat, or
hearing protection whenever it is needed will reduce the risk of personal
injury.
Avoid accidental starts. Ensure the switch is in the off position before

inserting the plug. Carrying power tools with your finger on the switch or
plugging in power tools when the switch is in the on position makes
accidents more likely.
Remove any adjusting keys or spanners before turning on the power tool.
A spanner or key left attached to a rotating part of the power tool may
result in personal injury.
Do not reach out too far. Keep your feet firmly on the ground at all times.
This will enable you retain control over the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from the power tool. Loose clothes, jewellery or
long hair can become entangled in the moving parts.
If there are devices for connecting dust extraction and collection facilities,
please ensure that they are attached and used correctly. Using such
devices can reduce dust-related hazards.
4.4 Power tool use and care
Do not expect the power tool to do more than it can. Use the correct
power tool for what you want to do. Apower tool will achieve better results
and be safer if used in the context for which it was designed.
Do not use the power tool if the switch cannot turn it on and off. Apower
tool with a broken switch is dangerous and must be repaired.
Disconnect the plug from the power source before making adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store power tools, when not in use, out of the reach of children and do not
allow people who are not familiar with the power tool or these instructions
to operate it. Power tools are potentially dangerous in the hands of
untrained users.
Maintenance. Check for misalignment or jammed moving parts,
breakages or any other feature that might affect the operation of the
power tool. If it is damaged, the power tool must be repaired. Many
accidents are caused by using poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to jam and are easier to control.

Use the power tool, accessories and cutting tools, etc., in accordance
with these instructions and in the manner intended for the particular type
of power tool, taking into account the working conditions and the work
which needs to be done. Using a power tool in ways for which it was not
intended can lead to potentially hazardous situations.
4.5 Service
Your power tool should be serviced by a qualified specialist using only
standard spare parts. This will ensure that it meets the required safety
standards.
5. SPECIFIC SAFETY WARNINGS
Do not use the tool on light metal with a magnesium content
exceeding 80%, as this type of metal is flammable.
Make sure that the accessories used are suitable for the maximum speed
stated in the technical data. Make sure that the accessories are mounted
according to the instructions.
Only use accessories and adapters supplied by the manufacturer.
Make sure that sparks cannot hit any persons or set flammable materials
alight.
Always wear safety goggles, hearing protection and if necessary other
protective means, such as working gloves, hard hat, etc.
6. MULTIFUNCTION POWER TOOL START-UP
Never start up or stop the tool is the accessory is in contact with the piece to
be worked on. Hold it firmly and press the ON/OFF switch. The tool will run
continuously until the switch is turned to OFF position. The speed can be
adjusted while the tool is running.
7. SPEED ADJUSTMENT
The multifunction power tool is equipped with speed control. Do not change
the speed while the tool is working. The speed switch is located on the rear
of the tool. Turn it to increase or reduce speed. Use the tool at low speed for
polishing and similar operations, but use higher speed for drilling or cutting

action.
8. IMPORTANT GENERAL SAFETY TIPS!
1. The Tool should be unplugged when changing accessories.
2. If you stall the tool, switch it off immediately.
3. Periodically check the tightness of your collet chuck, especially during
prolonged use of the same accessory
4. After use, always disconnect your power tool
5. Do not undertake repair of the power tool your self.
6. Do not leave your tool unattended while switched on.
7. Do not use or store your tool in damp or wet conditions.
9. USEFUL HINTS & TIPS
1. Your rotary tool will become warm after prolonged use and so must be
switched off and allowed to cool down.
2. To ensure smooth running, the spindle should be oiled periodically.
3. Do not apply too much radial pressure to the accessory bits while
polishing, cleaning, sanding or grinding. By doing this you will put a strain on
the spindle and adversely affect the precision of the tool.
4. Always work with a sensitive touch so as not to impede the efficiency of
your mini tool.
5. When drilling metal, always mark the drilling point with a centre punch
first, so that your rotary tool does not slip.
6. Always ensure that you have maximum contact between the accessory
shaft and the collet chuck.
7. Vary the speed on the tool for the work in hand, eg. Low speed for
polishing & cleaning and high speed for engraving
10. PLACING ACCESSORIES INTO THE TOOL
Always switch the tool off first. Hold the locking button at the front of the tool
down and undo the collet chuck (anti-clockwise). Insert the collet that matches
the shaft size of the accessory to be used. Place the collet nut over the collet
and then insert the accessory shaft into the collet chuck ensuring maximum
shaft contact. Then tighten up the collet nut. (DO NOT USE PLIERS).

11. FLEXYDRIVE ASSEMBLY
Remove the front ring nut from the tool by turning in an anti-clockwise
direction. Partially unscrew the blocking ring nut from the spindle . Partially
extract the internal transmission cable from the flexydrive. Insert the flexydrive
transmission cable into the spindle of the tool pushing it in as far as possible.
Keep the spindle block button pressed in and screw the spindle blocking ring
nut turning it in a clockwise direction. Tighten using the spanner for this
purpose. Screw the threaded end of the flexydrive onto the body of the tool
and tighten, screwing in a clockwise direction
12. TECHNICAL DATA
Voltage / frequency
230V/50Hz
Power input
135W
No load speed
10000-32000/min
Collet size
3,2mm
Protection class
II
13. CLEANING AND MAINTENANCE
Attention !Before performing any work on the equipment, pull
the power plug.
8.1 Cleaning
Keep the ventilation slots of the machine clean to prevent overheating
of the
Regularly clean the machine housing with a soft cloth, preferably after
each
Keep the ventilation slots free from dust and dirt.
If the dirt does not come off use a soft cloth moistened with soapy
water.
Never use solvents such as petrol, alcohol, ammonia water,
etc. These solvents may damage the plastic parts.

ENVIRONMENT
Should your appliance need replacement after extended use,
do not discard it with the household rubbish but dispose of it in
an environmentally safe way.
Waste produced by electrical machine items should not be
handled like normal household rubbish. Please recycle where
recycle facilities exist. Check with your Local Authority or retailer for
recycling advice.

14. EXPANDED VIEW

15. PARTS LIST
ITEN
DESCRIPTION
QTY
1
Plug
1
2
Cord sleeve
1
3
Screw M3 x 10
1
4
Trimming circuit bord
1
5
Switch
1
6
Screw M3 x 15
6
7
Left body
1
8
Stator
1
9
Brush
2
10
Right body
1
11
Rotor
1
12
Spindle lock button
1
13
Nose cap
1
14
Collet
1
15
Collet nut
1
16
Bearing
2
CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.

Made in china
