Neilsen CT3730 Operation instructions

ORIGINAL MANUAL
LI-ION CORDLESS IMPACT WRENCH 24V CT3730
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.UNITED KINGDOM

EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety and
health requirements of the EC Directive based on its design and type, as brought
into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will
lose its validity.
Product description: LI-ION CORDLESS IMPACT WRENCH 24V
Model: CT3730
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
Harmonized standards：
：：
：
EN 60745-1, EN 60745-2-2, EN 55014-1, EN 55014-2
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2016-04-20
EC Directive of Electromagnetic Compatibility 2014/30/EU

24V 1.3Ah Li-Ion
Speed:0-2200rpm
Impact frequency:0-2900Bpm
Max Torque:300Nm
1/2" square head
230-240V~ 50Hz 60W
CORDLESS IMPACT WRENCH

This symbol designates
that this tool complies to
European directives.
Were ear and eye
protection
Read original manual
V
volts
A
amperes
Hz
hertz
W
watt
F
farads
Kg
kilograms
h
Hours
min
minutes
s
seconds
No load speed
./min or
min¯¹
Revolutions or
reciprocations per minute
alternating current
class II construction
1, 2, 3, ...
Speed Selector settings
Diameter
Off position
Arrow
Warning symbol
IPXX
IP symbol
domestic waste. Recycle them at the special
disposal centers provided for the purpose.
Contact your local authorities or stockiest for
advice on recycling.
Electrical products must not be thrown out with

Model CT3730
2

CHARGING THE BATTERY
1. Place the charging stand near a
230/240V/50Hz electrical outlet.
2. Take the BS1363A plug (Fig1)(1) put it
into the 230/240v/50Hz mains outlet.
3. Turn the battery (2) upside down and
slide it into the matching slots in the
charger stand (3) do not insert the battery
the wrong way round.
NOTES:
a) Make sure the battery slides fully into
the slots in the charger.
b) The green indicator light will come on
when the battery is properly inserted into
the charger stand.
c) When in charging, green indicator light
come on, red indicator light flash. Check
to make sure battery is inserted fully into
the charger and the electrical outlet is
“live”.
d) When the green & red indicator both
come on, this means that the battery has
been fully recharged. Only then can the
power plug be pulled out of the socket.
The battery can then be taken out of the
base and can be used immediately.
NOTES:
a) A new battery or one that is completely run
down should be charged for 1- 1.5 hours (for
fast charge). After normal use, a battery
should be fully charged in about 1 hour.
b) It is normal for the battery charger to hum
and be warm to the touch during operation.
c) If the battery does not charge properly,
check to make sure the electrical outlet is
“live” and that the air surrounding the battery
and charger is between 10oC (50oF) and 40oC
(105oF).
The charger in Fig (1) may very from kit to
kit this picture is for reference only.
INSTALLING BATTERY IN TOOL
1. Remove the discharged battery (1) from
the tool by pressing on the battery
release buttons (2) on each side of the
battery and pulling the battery out of the
tool handle (3) (see Fig. 2).
2. Slide the fully charged battery into the
matching slots in the tool handle where
the discharged battery has been
removed.
NOTE: Make sure the battery is fully
engaged with the mounting slots in the
tool handle. The battery release buttons
will “click” into place when the battery is
fully installed.
Do not immerse battery pack in water.
Sudden cooling could cause hot battery to
explode or leak.
ASSEMBLY & OPERATION
WARNING
!
Fig. 2
Fig. 1
3
1
2

This wrench is equipped with a variable speed

Add:20 station road,Rowley Regis,west midlands B650 JU.U.K.
,
Made in China
