No Butts Bin NSKCS01ZC User manual

Assembly Instructions
Shelter type: NSKCS01ZC
NSKCS01ZC-04-010519
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]

1
2
4
5
6
3
7
2
Tools required: (Not supplied)
Drill/Screwdriver
Socket set
ITEM
NO. PART NAME
DRG NUMBER LENGTH
Default/QT
Y.
1 Central Tie Bar KTB-001-01
Default
3
2 Outside Roof Panel
Default
1
3
Kimmeridge Straight
Tie Bar Assembly
KSJ-004-01
Default
2
4
Kimmeridge Rear
Frame Assembly
KSJ-003-01
Default
2
5
Kimmeridge Front
Frame Assembly
KSJ-002-01
Default
2
6 Side Panel SP
Default
2
7
Kimmeridge External
Foot
153
Default
4

3
PARTS LIST & FITTINGS
Fittings
M10 x
3
4
Hex
head
bolt
M10 x 3
1
8
Hex head
bolt
M10 / 12
Anchor
bolt
M10
Nuts
M10
Standard
Washers
1'' Tech
screws
Plastic caps
M10
QTY.
20 4 4 4 32 110 32
ITEM
NO.
PART
NO.
DESCRIPTION DIMENSION (Inch) IMAGE QTY.
1
CTB
Central Tie Bar
763
43
2
RP1
Outside Roof Panel
113 x 79
1
41
3
KST
Kimmeridge Straight Tie Bar Assembly
602
52
4
KRF
Kimmeridge Rear Frame Assembly
881
3
x 38
3
42
5
KFF
Kimmeridge Front Frame Assembly
77 3
4
x 39
2
6
SP
Side Panel
711
2
x 77
1
32
7
KEF
Kimmeridge External Foot
44
8
EC50
Plastic end cap
2 x 2
2

KFF
KRF
KST
COMPLETE FRAME (CF)
CTB
CTB
CTB
Step 1
4
If you have received the "Split End" version (If not go straight to Step 1)
Join the three frame sections to make the Complete Side Frameusing the
M10x
3
4
bolts.
Take the CF Side Frame and attach the CTB Tie Bar to it in the positions
shown below using the M10x
3
4
Bolts supplied.
Note: Solid ends do not require any M10x
3
4
fixings
2 people recommended
to fit this shelter.
Note: Shelter has 2 sides Left
and Right. Make sure all holes
are in correct position before
assembling. (Facing into
shelter)

Repeat Step 1 with the other side of the shelter. (Structure should now
stand without support.) Make sure all bolts are tight at this point.
CTB
CTB
Secure the polycarboonate supplied with the shelter to the outer
perameter, using 1'' TEC Screws in the fixing kit. (Note: 8'' Spacings
Between TEC Screws )
CTB
CF
RP1
SP
SP
Step 2
5
Step 3
Always clean off swarf when
fitting the roof panels to
avoid rust and stains.

KEF
KEF
KEF
KEF
6
Step 5
Once in desired location bolt the foot to the shelter (M10x3
1
8
) and to
ground (M10/12 Anchor Bolt) using fixings within the kit provided.
Step 4
Now all the polycarbonate is attached, move shelter to desire location.
Note: Use at least 2
people to move
shelter.
Note: Add Plastic End Caps
(M10) at this point, all caps
should be used.

NOTES:

8
THANK YOU
FOR PURCHASING THIS PRODUCT
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16Birch Lane, Madison, CT 06443
All Parts and Fixings checked by:
Print Name: Signature:
