No Butts Bin SR1605-F User manual

Assembly Instructions
Shelter type: SR1605-F
SR1605-F-02-150219-USA

Tools required:
Drill/Screwdriver
Mallet
Hack saw
1
2
3
13
12
17
18
46
15
16
15
11
8
10
3
5
7
9
714
EXPLODED VIEW
Spanner
Torx bit
ITEM
NO. PART NAME
DRG NUMBER LENGTH
Default/QT
Y.
1 S1C Frame S1C
Default
5
2 CB1 Bracket CB1
Default
6
3 JF1 Bracket JF1
Default
6
4 S1 Stub S1
Default
2
5 JF2 Bracket JF2
Default
4
6 RB1 Bracket RB1
Default
8
7 R4 Rafter R4
Default
4
8 ST9 Roof Tie ST9
Default
2
9 JF3 Bracket JF3
Default
2
10 P4 Post P4
Default
1
11 L1 Bracket L1
Default
6
12 FT1 Bracket FT1
Default
3
13 FT3 Bracket FT3
Default
4
14 Sealing Strip - 2195mm Sealing Strip
Default
6
15 PCE2 - Roof Sheet PCE2
Default
2
16 PCC2 - Roof Sheet PCE1
Default
1
17 RC2 - Roof Strip RC1
Default
4
18 2MD Roof Edging 2MD
2110 4
19 40x40 End cap BOUGHT IN ITEM
40 x 40 x 20
11

3
PARTS LIST
ITEM
NO.
PART NO.
DESCRIPTION
DIMENSION
(MM)
DIMENSION
(INCHES)
IMAGE QTY.
1
S1C
FRAME 2000 x 1035 78.74 x 40.55 5
2
CB1
CORNER
BRACKET
110 x 110 4.33 x 4.33 6
3
JF1 PLATE/BRACKET
130 x 30 x 3 8.66 x 1.57 6
4
S1 STUB
STUB
140 x 40 x
40
5.51 x 1.57 x
1.57 2
5
JF2 PLATE/BRACKET
130 x 30 5.12 x 1.18 4
6
RB1
BRACKET 110x46x40 4.33 x 1.18 8
7
R4
RAFTER
2159 x 40 x
40
85.04 x 1.57 x
1.57 4
8
ST9
ROOF TIE 1562x40x40
61.50 x 1.57 x
1.57 2
9
JF3
PLATE/ BRACKET 210 x 30 8.66 x 1.18 2
10
P4
POST
1995 x 40 x
40
78.54 x 1.57 x
1.57 1
11
L1
BRACKET 95 x 45 x40 3.74 x 1.77 6
12
FT1
FOOT BRACKET
109 x 100 x
40
4.29 x 3.93 x
x1.57
3
13
FT3
FOOT BRACKET
109 x 100x
80
4.29 x 3.93 x
3.27 4
14
SS
SEALING STRIP TRIM TO FIT TRIM TO FIT
3
ROLLS
15
PCE2
ROOF PANEL 2220 x 1050 87.40 x 41.34 2
16
PCC2
ROOF PANEL 2220 x 1030 87.40 x 40.55 1
17
RC2
ROOF STRIP 2180 85.83 4
18
2MD
ROOF EDGE TRIM TRIM TO FIT TRIM TO FIT 4
19
EC40
PLASTIC END
CAP
40 x 40 1.57 X 1.57 14
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T38 AB1210
M10 X 60mm
25mm Tech
screw
38mm Tech
screw
M10 x 100mm Concrete
Bolt
Pack A+B
40 40 80 80 136 66 13
Required
39 39 78 78 64 40 7

1035
3145
1075
40.748
123.819
42.323
A
Check the dimensions
of the shelter to ensure
correct alignment
MEASUREMENTS IN BLUE - MM
MEASUREMENTS IN GREEN - INCHES
S1C
CB1
JF1
CB1CB1
Ensure correct alignment on corners
DETAIL A
SCALE 1 : 5
JF1
JF2
CB1
S1 STUB
Step 1
Assemble S1C frames to make up the main structure using CB1 brackets
in the corners and JF1 brackets on the straight joints. Attach the S1 stub
as shown using JF1 , CF1 and JF3 brackets.
4

R4
RB1
RB1
R4
Step 2
Attach first R4 rafters using RB1 brackets on the back of the
shelter and S1 stubs in the middle.
5

C
JF3
RB1
ST9
P4
DETAIL C
SCALE 1 : 4
JF3JF3
RB1RB1
Step 3
Assemble the T-frame using two ST9 tie bars and a P4 post. Join the two
ST9 bars together first using JF3 brackets, then attach the P4 post using
two RB2 brackets.
6

FT1
FT3
RB1
R4R4
L1
R4R4
RB1
L1
FT1
FT3
Step 4
Use L1 brackets to attach the T-bar to the front of the shelter and install
the remaining R4 rafters using RB1 brackets on the rear and L1 brackets
at the front. Attach the FT1 and FT3 brackets and move the shelter in to
its final position before using anchor bolts to secure it to the ground.
7

PCE2
PCE2
PCC2
SS
PCE2
PCE2
PCC2
SS
Step 5
Stick sealing strips (SS) to the rafters and align the PCE2 panels to the outside
of the shelter and centralise the PCC2 panel in the centre. Apply more
sealing strips to the top of the roof panels, above the previous strips.
8

GENERAL NOTE:
THE 38MM TECH SCREWS ARE
FOR FIXING ROOF STRIPS
(RC) ONLY
2MD
RC2
RC2
2MD
Step 6
Screw down the RC2 strips directly into the rafter with the 38mm TEC
screws to secure the roof panels. Next, clip on the 2MD edge trim to the
edges of the roof panels. Then fit the Black plastic caps on exposed
nuts and bolts. Fit the square end caps (EC40) to any open ends of
box sections.
9

Notes:
10

995
1044.50 1035 1035
1044.50
3228 TO FOOT HOLE CENTERS
2187
127.087
41.122 40.748
40.748
3145
123.819
39.173
41.122
86.119
11
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base:
200mm/7.87in oversized on all sides

12
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
MAINTENANCE:
To ensure your product gives you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
All Parts and Fixings checked by:
Print Name: Signature:
