No Butts Bin SR1557-F User manual

Assembly Instructions
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
SR1557-F-01-140219-USA
Shelter type: SR1557-F

13
11
12
12
12
11
8
14
7
6
4
5
1
2
3
9
10
2
BALLOON VIEW
Wrench
Torx bit
Tools required (Not included):
Drill/Screwdriver
Mallet
Hack saw
ITEM
NO. PART NAME
DRG NUMBER LENGTH
Default/QT
Y.
1 S1C Frame S1C
No Plastics
11
2 CB1 Bracket CB1
Default
8
3 JF1 Bracket JF1
Default
16
4 P1 Post P1
Default
1
5 ST3 Roof Tie ST3
Default
1
6 FT1 Bracket FT1
Default
3
7 FT3 Bracket FT3
Default
10
8 RB1 Bracket RB1
Default
20
9 R2 Rafter R2
Default
6
10 Sealing Strip - 2195mm Sealing Strip
Default
10
11 PCE2 - Roof Sheet PCE2
Default
2
12 PCC2 - Roof Sheet PCE1
Default
3
13 RC2 - Roof Strip RC1
Default
6
14 2MD Roof Edging B1
2110 6
15 40x40 End cap BOUGHT IN ITEM
40 x 40 x
20 15

3
PARTS LIST
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T38 AB1210
M10 x 60
25mm
Tech
screw
38mm
Tech
screw
M10 x 100
Concrete Bolt
Pack A+B
40 40 80 80 136 66 13
Required 39 39 78 78 64 40 13
ITEM NO. PART NO. DESCRIPTION
DIMENSION
(MM)
DIMENSION
(INCH)
IMAGE QTY.
1 S1C Frame 2000x1035 78.74x40.75 11
2 CB1 Bracket 110x110x40 4.33x4.33 8
3 JF1 Bracket 220x40 7.87x1.58 16
4 P1 Post 2000x1030 78.74x40.55 1
5 ST3 Roof Tie 2060x40x40 81.1x1.58x1.58 1
6 FT1 Foot Bracket 109x100x40 4.29x3.94x1.58 3
7 FT3 Foot Bracket 109x100x80 4.29x3.94x3.15 10
8 RB1 Bracket 110x42x40 4.33x1.81 20
9 R2 Rafter 2200x40x40 86.61x1.58x1.58 6
10 SS Sealing Strip Trim to 2200 Trin To 86.6 5 ROLLS
11 PCE2 Roof Panel 2220x1050 86.6x43.34 2
12 PCC2 Roof Panel 2220x1030 86.6x40.55 3
13 RC2 Roof Strip 2180 85.83 6
14 2MD
Roof End
Capping
Trim To Fit 6
15 EC40
Plastic End
Capping
40x40 1.58x1.58 28

Ensure correct alignment
on all four corners
CB1CB1
CB1
2110
5215
83.07
205.31
Measure the length and width
of the shelter to ensure correct
alignment
JF1
CB1
S1C Frame
Step 1
Assemble all S1C Frames to make up the main structure using JF1 bracket
for straight joints and CB1 brackets for the corners.
4
GENERAL NOTE:
THE 38mm TECH SCREWS ARE
FOR FIXING ROOF STRIPS
(RC) ONLY
BLUE DIMENSIONS - MM
GREEN DIMENSIONS - INCHES

A
ST3
P1
FT3
FT1
P1
ST3
FT1
FT3
CB1
JF1
DETAIL A
SCALE 1 : 5
CB1 BENEATH
JF1 INSIDE
Step 2
Attach P1 Post using one JF1 bracket then attach ST3 Tie bar using
two CB1 brackets and one JF1 bracket.
Move shelter in to its final position and ensure the structure is square.
Then attach FT1 and FT3 brackets to secure the shelter to the ground.
5
NOTE: Insert EC40 into ST3
and P1 before installing.

RB1
R2
RB1
R2
SS
J
995
39.17
40.75
1035
40.75
1035 1035
40.75
1035
40.75
1035
40.75
SCALE - 1:30
Step 3
Attach R2 Rafters using RB1 brackets. Use four RB1 brackets to secure
each Rafter and two for the end Rafters. Apply SS sealing strips along
the length of the rafters.
ROOF DETAIL
6

RC2
PCE2
PCE2
PCC2
PCC2
PCC2
2MD
7
2MD
RC2
PCE2
PCC2
Step 4
Attach PCC2 roof panels and PCE2 roof panels on top of the sealing strips.
Screw down the RC2 on the ends an centers, seal off the end of the
panels with the 2MD end caps. Then fit the Black plastic caps on exposed
nuts and bolts. Fit the EC40 square end caps to any open ends of box
sections.
GENERAL NOTE:
THE 38mm SCREWS ARE
FOR FIXING ROOF STRIPS
(RC) ONLY

1035 995
1044.50 1035 1035
1035 1035
1044.50 1035
1044.50 1035 1035 2171.50
5286 OR 208.11 TO FOOT HOLE CENTERS
5215 OR 205.32
2110 OR 83.07
40.75 39.17
41.12
40.75 40.75 40.75 40.75
41.12 40.75
41.12 40.75 40.75 85.49
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 200mm OR 7.87in oversized on all 4 sides.
8

NOTES
:
9

NOTES
:
10

NOTES
:
11

12
