No Butts Bin NSKCS02ZC User manual

Assembly Instructions
Shelter type: NSKCS02ZC
NSKCS02ZC-03-120918
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]

1
10
3
5
2
4
8
9
1
10
3
6
6
5
5
4
7
11
11
11
11
11
2
Tools required: (Not supplied)
Drill/Screwdriver
Socket set

3
PARTS LIST & FITTINGS
Fittings
M10 x
3
4
Hex
head
bolt
M10 x 3
1
8
x 3
1
7
Hex head
bolt
M10 / 12
Anchor
bolt
M10
Nuts
M10
Standard
Washers
M12
Standard
Washers
1" Tech
screws
Plastic
caps
M10
QTY.
20 6 / 10 6 16 52 6 120 52
ITEM
NO.
PART
NO.
DESCRIPTION DIMENSION (inch) IMAGE QTY.
1
RP1
Outside Roof Panel
113 x 79
1
42
2
KFF
Kimmeridge Front Frame Assembly
77 3
4
x 39
2
3
KRF
Kimmeridge Rear Frame Assembly
881
3
x 38
3
42
4
KST
Kimmeridge Straight Tie Bar Assembly
602
52
5
CTB
Central Tie Bar
763
44
6
TB1
Tie Bar 1
773
42
7
CP
Center Post Assembly
773
41
8
TCC
Top Center Curve
522
51
9
LCC
Lower Centre Curve
621
51
10
SP
Side Panel
711
2
x 77
1
32
11
KEF
Kimmeridge External Foot
46
12
EC50
Plastic end cap
2 x 2
2

KFF
KRF
KST
COMPLETE FRAME (CF)
CTB
CTB
TB1
Step 1
4
If you have received the "Split End" version (If not go straight to Step 1)
Join the three frame sections to make the Complete Side Frame using
the M10x
3
4
bolts.
Take the CF Side Frame and attach the CTB Tie Bar to it in the positions
shown below. Now secure the TB1 Tie Bar 1 to the Side of the shelter
using M10 Bolt supplied.
Note: Solid ends do not require any M10x
3
4
fixings
2 people recommended
to fit this shelter.
Note: Shelter has 2 sides Left
and Right. Make sure all holes
are in correct position before
assembling.

Loosely fasten TCC Top Centre Curve to CTB Central Tie Bar , after
doing this place CP Central Post under TB1 Tie Bar 1 and bolt through
all 3 parts.
TCC
CP
CTB
TB1
Put the LCC Lower Centre Curve in place do not tighten the bolts to
far as the second side will be attached here.
LCC
Step 2
5
Step 3

CTB
CTB CF
TB1
CP
LCC
TCC
SP
SP
RP1
RP1
6
Step 5
Offer each panel to the shelter as shown below and secure in place using
Tec-Screws. (1 Screw every 8 inches)
Step 4
Repeat Step 1, 2 and 3 with the opposite side of the shelter this time
securing all centre bolts tightly making one complete unit.
Always clean off swarf when
fitting the roof panels to
avoid rust stains.

KEF
KEF
KEF
KEF
KEF
KEF
7
Step 6
Finally move shelter to desired position and instert KEF Kimmeridge External
Foot into each leg. (Note: the slot in the foot is to allow adjustment on an
uneven surface) Secure in Place using the Anchor Bolts supplied.

8
THANK YOU
FOR PURCHASING THIS PRODUCT
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
All Parts and Fixings checked by:
Print Name: Signature:
