No Butts Bin SR1584 User manual

Assembly Instructions
Shelter type: SR1584
SR1584-01-240219-USA
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]

6
12
11
1
9
10
8
4
3
5
7
13
17
14
16
15
2
2
EXPLODED VIEW
Spanner
Torx bit
Tools required:
Drill/Screwdriver
Mallet
Hack saw
ITEM
NO. PART NAME
DRG NUMBER LENGTH
Default/QT
Y.
1 S1 Frame S1 3
2 S3 Frame S3 2
3 CB1 Bracket CB1
Default
4
4 JF1 Bracket JF1
Default
5
5 RB1 Bracket RB1
Default
8
6 Rafter R3 4
7 L3 Bracket L3
Default
2
8 P4 Post P4 1
9 B3 Beam B3 2
10 L1 Bracket L1
Default
6
11 FT1 Bracket FT1
Default
3
12 FT3 Bracket FT3
Default
4
13 Sealing Strip SS 6
14 ACE3 Roof Panel ACE3
Default
2
15 ACC3 Roof Panel ACC3
Default
1
16 RC3 Roof Strip RC3
Default
4
17 A2 Angle A2
Default
3
18 40x40 End cap BOUGHT IN ITEM
40 x 40 x
20 8

3
PARTS LIST
Fittings
Bolt set M10
Nut Washer
Black
Cap
T25 AB1210
M10 x 60mm
25mm
Tech
screw
M10 X 100mm
Concrete Bolt
Pack C
30 30 60 60 102 8
Required
30 30 60 60 72 7
ITEM
NO.
PART NO. DESCRIPTION DIMENSION (MM) DIMENSION (INCH) IMAGE QTY.
1 S1 Frame 2000x1035 78.74x40.55 3
2 S3 Frame 2000x517 78.74x20.35 2
3 CB1 Bracket 110x110x40 4.33x4.33x1.57 4
4 JF1 Bracket 220x40 8.66x1.57 5
5 RB1 Bracket 110x42x40 4.33x1.81x1.57 8
6 R3 Rafter 1035x40x40 40.75x1.57x1.57 4
7 L3 Bracket 73x38 2.87x1.50 2
8 P4 Post 1995x40x40 78.54x1.57x1.57 1
9 B3 Beam 1562x40x40 61.50x1.57x1.57 2
10 L1 Bracket 95x45 3.74x1.77 6
11 FT1 Bracket 109x100x40 4.29x3.93x1.57 3
12 FT3 Bracket 109x100x80 4.29x3.93x3.15 4
13 SS Sealing Strip Trim To 1035 Trim To 40.75 2 ROLLS
14 ACE3 Roof Panel 1070x1050 42.13x41.34 2
15 ACC3 Roof Panel 1070x1030 42.13x40.55 1
16 RC3 Roof Strip 1070 42.13 4
17 A2 Roof Edge 1035 40.75 3
18 EC40 End Cap 40x40 1.57x1.57 14

517
3145
557
20.35
123.82
21.93
USE DIMENSIONS TO CHECK
ALIGNMENT OF THE SHELTER
JF1
CB1
S3
S1
CB1 CB1
Ensure correct alignment
on corners
4
Step 1
Assemble S1 and S3 frames to make up the main structure using CB1
brackets in the corners and JF1 brackets on the straight joints.
MEASUREMENTS IN BLUE - MM
MEASUREMENTS IN GREEN - INCHES

RB1
R3
L3
R3
RB1
L3
5
Step 2
Attach R3 rafters using RB1 brackets on the back of the shelter and
L3 brackets in the middle.

B
L1
B3
RB1
JF1
P4
L1
A
P3
B3
DETAIL A
SCALE 1 : 5
JF1
RB1
DETAIL B
SCALE 1 : 4
L1
6
Step 3
Assemble the B3 's and P4 using the JF1 and RB1 brackets as
shown below.
Attach front beams (B3) and centre post (P4) to the
rafters using the L1 brackets .

FT1
FT3
FT3
FT1
Step 4
Attach the FT1 and FT3 foot brackets, Move the Shelter into its final
position and make sure its square. Then use concrete anchor bolts to
secure it to the the ground.
7

ACE1
ACC1
ACE1
SS
A2
A2
A2
RC3
RC3
SS
RC3
ACE3
ACC3
ACE3
A2
8
Step 5
Apply the sealing strips (SS) to the top of the R3 rafters as shown. Place
ACE3 and the ACC3 roof panels with a small gap on sealing strips
use RC3 strips and screws supplied to secure panels in place. Finally
screw A2 angles to the rear of the shelter.

477
1044.50
1035 1035
20.73
3228 HOLE CENTERS ON FEET
3145
127.09
18.78
41.12 40.75 40.75
526.50
123.82
9
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base:
200mm or 7.87in oversized on all
four sides.

NOTES
:
10

NOTES
:
11

12
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
All Parts and Fixing checked by:
Print Name: Signature:
