No Butts Bin SR1606 User manual

Assembly Instructions
Shelter type: SR1606
SR1606-02-221216-USA
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]

7
14
12
2
3
1
9 20
15
17
4
5
20
10
11
8
13
614
15
14
14 15
14
15
17
17
17
17
EXPLODED VIEW
2
Fittings Bolt set M10
Nut Washer
Black
Cap
T25 T50 AB1210
11
2 x 11 2
End Caps
3/8th x 2 3/8"
1" Tech
screw
2" Tech
screw
1/2 x 4"
Concrete Bolt
Pack A+B
40 40 80 80 136 66 13
Required 40 40 72 72 76 55 8 7
Spare
0 0 8 8 60 11 5

3
PARTS LIST
ITEM NO. DESCRIPTION DIMENSION
PART NO. IMAGE
QTY.
1 BRACKET
4 1
4
x 4
1
4
x 1
1
2
CB1 6
2 BRACKET
8 5
8
x 1
1
2
JF1 8
3 BRACKET
4 3
8
x 1
7
8
RB2 10
4
POST
78 3
4
P4
1
5
ROOF TIE
81 7
8
ST4
2
6
NBBS S1
5 3
4
S1 STUB
2
7
BRACKET
5 1
8
x 1
1
8
JF2
4
8
ROOF RAFTER 85 R5
1
9
ROOF RAFTER 85 R4
4
10 BRACKET
3 3
4
x 1
3
4
L1 8
11
SEALING STRIP
Trim to 87
1
2
SS
8
12 ROOF PANEL
87 1
2
x 41
3
8
PCE2 2
13
ROOF PANEL
87 1
2
x 40
1
2
PCC2
2
14
ROOF STRIP
85 7
8
RC2
5
15
ROOF END
CAPPING
78 3
4
2MD
4
16
ROOF END
CAPPING
7 2MD
2
17 FOOT BRACKET
4 3
8
x 3
7
8
FT1 8
18 BRACKET
8 1
4
x 1
1
8
JF3 1
19 PLASTIC END CAP
11
2
x 1
1
2
EC 40 7
20 FRAME
78 3
4
x 40
3
4
S1 6

40 3
4
"
164 5
8
"
CB1
CB1
CB1
JF1
JF1
JF1
JF1
JF1 S1
S1
S1
S1
S1
S1
Please note 50mm
Tec Screws are for
roof panels only
CHECK
DIMENSIONS
TO ENSURE
CORRECT
ALIGNMENT
CB1
CB1
JF1 JF1JF1
S1
S1 S1 S1 S1
S1
Step 1
Assemble S1 frames to make up the main structure using CB1 brackets
for the corners and JF1 brackets for the straight joints.
4

RB2
RB2
R5
R4
S1 STUB DETAIL
S1 Stub
JF2
JF1
CB1
Step 2
Attach the R5 and R4 rafters to the outside edges of the shelter using RB2
brackets on the rear and JF2 brackets at the front.
5

L1
L1
RB2RB2
P4
ST4
ST4
JF3
Step 3
Assemble the T-section by joining the two ST4 tie bars using a JF3 bracket
then join the P4 post using two RB2 brackets and attach a L1 bracket to
each end.
6

R4
R4
R4
L1
L1
L1
L1
L1
L1
RB2
RB2
RB2
FT1 FT1
FT1
FT1
FT1
FT1
Step 4
Attach the T-section to the shelter, then fix the R4 rafters in place using
RB2 brackets on the rear and L1 brackets on the front.
Bolt the FT1 brackets to the shelter and move it to its final position
before using anchor bolts to secure it to the ground.
7

PCE2
PCE2
PCC2
PCC2
SSSS
SSSS
SSSS
SSSS
Step 5
Stick the sealing strips ( SS ) to the rafters and line up the PCE2 panels with
the outside of the shelter then equally space the PCC2 panels in the gap.
8

2MD
2MD
2MD
2MD
RC2
RC2
RC2
RC2
RC2
Step 6
Screw down the RC2 strips to secure the roof panels an d push the 2MD
end caps on the bottom of the panels.
9

FT1
FT1
FT1
FT1
FT1
FT1
FT1
FT1
Step 7
Attach the FT1 brackets to the shelter and move it to its final position
before using anchor bolts to secure it to the ground.
10

38 7
8
"
87"
36 3
4
"
40 3
4
"
40 3
4
"
40 3
4
"
36 7
8
"
80 1
8
"
164 5
8
"
4 1
4
"
11
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 8" oversized on all four sides.

12
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
All Parts and Fixings checked by:
Print Name: Signature:
