B400 Series
The most versatile small workgroup printers—
with mid-workgroup features
B410d
B410dn
B420dn
B430d
B430dn

B400 Series Highlights:
As fast as 30 ppm print speed;•
5.5-second time to first page1
Clear, crisp output at up to 1200 x 1200 dpi• 2
Separate toner and image drum configuration•
for lower operating costs
Compatible with Windows• ®Vista®, XP, 2003
and 2000; Mac®OS X 10.3 and higher
297 MHz processor•
Upgradable to 320 MB RAM• 4
Standard USB and parallel ports; available•
with internal print server connectivity
Optional 530-sheet 2nd paper tray•
1-Year limited warranty with Overnight•
Exchange5; 5-Year limited printhead warranty
Live, toll-free technical support 24/7/365• 5
Fast, reliable and feature-rich, B400 Series printers increase
productivity and improve the bottom line.
The B400 Series of Digital Monochrome printers
from OKI Printing Solutions will give you more
choices, so you never have to settle for ordinary
performance again.
If you’re looking to improve the productivity and
lower the operating costs of your business, the
B400 Series offers all of that and more.
For starters, the five models in the B400 Series
deliver up to 30 ppm, with the first page printing
in as little as 5.5 seconds.1They produce output
in black & white that’s clear and crisp, at up
to 1200 x 1200 dpi resolution2, using a two-
piece consumables system for long-lasting
performance and a low cost of operation.
All B400 Series printers come with duplex
(2-sided) printing standard, leading to fewer
user interventions and savings on media costs.
B410 and B430 models have a standard paper
capacity of 250 sheets and can be outfitted
with an optional 530-sheet 2nd paper tray. The
B420dn has a 530-sheet standard capacity
which can also be expanded with a 530-sheet
2nd paper tray.
In terms of durability and reliability, B400 Series
printers are tough—with a monthly duty cycle as
high as 70,000 pages.3
Fit for any work environment – B400 Series
printers, with their compact size, fit just about
any work space.
All have PCL®5e emulation, and B430 models
have PostScript®3™emulation standard. They
all perform equally well with the most popular
Windows®operating systems and Mac®OS 10.3
and higher.
With USB and parallel interfaces, all B400
Series printers offer broad-based connectivity.
Equipped with an OkiLAN®print server, the
B410dn, B420dn and B430dn models make
network printing more affordable—which
translates into a much lower cost per user, a
vital consideration as your office network grows
and expands in functionality.
Backed by unmatched support. OKI Printing
Solutions is so confident in the reliability and
performance of the B400 Series that we provide
an industry-leading 5-year printhead warranty
and a 1-year printer warranty with Overnight
Exchange.5
If you need technical assistance—24/7/365—
you can speak to a live expert located in
North America by calling 800.OKI.DATA
(800.654.3282).5
The B400 Series: EXPECT MORE versatility
from OKI Printing Solutions.

THE B400 SERIES AT A GLANCE
B410d/dn and B430d/dn – 250-sheet
standard paper capacity; B420dn –
530-sheet standard capacity
Multi-purpose tray:
B420dn/B430dn – 50-sheet
capacity, B410d/dn – single sheet
Toner capacity: all models – 3,500 pages; B420dn and
B430d/dn – 7,000 pages; B420dn only – 10,000 pages
Up to 30 ppm print speed1
High monthly duty cycle: B420dn
and B430d/dn rated at 70,000 pages;
B410d/dn rated at 50,000 pages
Resolution: B430d/dn – 1200 x 1200 dpi,
B410d/dn and B420dn – 2400 x 600 dpi
Duplex (2-sided) printing capability
standard on all models
Standard memory: B430d/dn – 64 MB,
B410d/dn and B420dn – 32 MB
Max. memory: B430d/dn – 320 MB,
B410d/dn and B420dn – 288 MB
Optional 530-sheet
2nd paper tray
LCD screen display
B420dn and B430d/dn operator panel: 16-character x 2-line LCD
display; convenient access to printer status and menu-driven
functionality via large, clearly marked buttons (also available via
printer driver on PC6 )
B410d/dn operator panel: 16-character x 2-line LCD display;
access to printer status and functionality via printer driver on PC
1Published performance results based on laboratory testing.
Individual results may vary.
2B430d/dn only; B410d/dn and B420dn at up to 2400 x 600 dpi
3B420dn and B430d/dn; B410d/dn rated at up to 50,000 pages/mo.
4B430d/dn only. Memory DIMMs sold separately.
5Available in the U.S. and Canada only.
6Available when network extension is installed.

Printed in the USA
MS15938-0908
Oki Data Americas, Inc.
USA
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: 800.OKI.DATA (800.654.3282)
Fax: [phone]
www.okiprintingsolutions.com
Canada
2735 Matheson Blvd. East
Mississauga, Ontario L4W 4M8
Tel: [phone]
Fax: [phone]
Latin America
2000 Bishops Gate Blvd.
Mount Laurel, NJ 08054-4620
Tel: [phone]
Fax: [phone]
Oki Data de México, S.A. de C.V.
Mariano Escobedo, 748 8º Piso
Col. Nueva Anzures C.P. 11590
México, D.F.
Tel: [phone]
Fax: [phone]
Oki Data do Brasil Informática Ltda.
Av. Alfredo Egídio de Souza Aranha, 100
Bloco C – 4º andar
04726-170 – São Paulo – SP – Brasil
Tel: [phone]
Fax: [phone]
Ordering Information
Description Part Numbers
B410d – Black (120V) 91642801
B410d – Tan (220V) 62431102
B410dn – Black (120V) 91642803
B410dn – Tan (220V) 62431104
B420dn – Black (120V) 91642903
B420dn – Tan (220V) 62431204
B430d – Black (120V) 91643001
B430d – Tan (220V) 62431302
B430dn – Black (120V) 91643003
B430dn – Tan (220V) 62431304
Options
2nd Tray Mechanism – Black 43990704
2nd Tray Mechanism – Tan 43990701
32 MB DIMM Memory Expansion270057301
256 MB DIMM Memory Expansion270057401
OKIcare®Warranty Extensions5 U.S. Canada
B410/420/430 2-Year Exchange 38005002 38005012
B410/420/430 3-Year Exchange 38005003 38005013
B410/420/430 2-Year Depot 38004802 38004812
B410/420/430 3-Year Depot 38004803 38004813
Supplies (Type 9)
Toner Cartridge: Avg. life – 3,500 pg.343979101
Toner Cartridge (B420dn and B430d/dn only):
Avg. life – 7,000 pg.343979201
High-Capacity Toner Cartridge (B420dn only ):
Avg. life – 10,000 pg.343979206
Image Drum (all models):
Avg. life – 25,000 pg.443979001
Print Media Sheets Per Box
Bright White Proofing Sheets (32 lb.):
8.5" x 11" 500 52206101
SynFlex™Paper (Waterproof and Tear-resistant)
8.5" x 11" 100 52205901
Premium Envelopes (size #10): 100 52206301
Premium Envelopes (size #10): 500 52206302
For more information on Digital Monochrome Printers
and supplies from OKI Printing Solutions, including
OKIcare®Extended Service Programs: 1.800.OKI.DATA
(800.654.3282).5
Specifications are subject to change without notice.
Featured products may not be available in all countries.
Please contact your local office for regional availability.
© 2009 Oki Data Americas, Inc. OKI, OkiLAN, OKIcare Reg. T.M.,
M.D., M.R., Oki Electric Industry Co., Ltd. Overnight Exchange
logo, 7-Day/24-Hour logo, SynFlex T.M., Oki Data Americas, Inc.
Windows, Windows NT, Vista, Reg. T.M., Microsoft Corp. PCL
Reg. T.M., Hewlett-Packard Co. PostScript Reg. T.M., PostScript 3
T.M., Adobe Systems, Inc. IBM, ProPrinter Reg. T.M., International
Business Machine, Inc. Epson Reg. T.M., Seiko Epson Corp.
Mac Reg. T.M., Apple, Inc. PostNet Reg. T.M., USPS. USB-IF logo
T.M., Universal Serial Bus Implementers Forum, Inc.
B400 Series
Specifications
Performance Print Speed Up to 30 pages per minute 1
CPU 297 MHz
Time to First Page 5.5 seconds1
Print Resolution B410d/dn and B420dn – 2400 x 600 dpi;
B430d/dn – 1200 x 1200 dpi
Duty Cycle (Pages/Month) B410d/dn – 50,000; B420dn and B430d/dn – 70,000
Compatibility Emulations B410d/dn and B420dn – PCL®5e, PCL 6; IBM®ProPrinter®III XL;
Epson®FX; B430d/dn – PostScript®3™; PCL®5e, PCL 6; IBM®
ProPrinter®III XL; Epson®FX
Operating Systems W i n d o w s ®Vista®/Vista x64, XP Home Edition/Professional/x64
Edition, 2003 Server/x64 Edition, Enterprise Server/x64 Edition,
Data Center Server/x64 Edition, 2000 Workstation/Professional/
Server/Advanced Server (SP4 or later); Mac®OS X 10.3 and higher
Connectivity Standard Interfaces B410d and B430d – USB v2.0; B410dn, B420dn and B430dn –
USB v2.0, Parallel, OkiLAN 10/100 Base-TX internal Ethernet
print server card
Memory Standard RAM B410d/dn and 420dn – 32 MB; B430d/dn – 64 MB
Maximum RAM B410d/dn and 420dn – 288 MB; B430d/dn – 320 MB2
Paper Handling Duplex Standard on all models
Standard Paper Capacity B410d/dn – 251-sheets (std. 250-sheet paper tray + 1-sheet MPT)
B430d/dn – 300-sheets (std. 250-sheet paper tray + 50-sheet MPT)
B420dn – 580-sheets (std. 530-sheet paper tray + 50-sheet MPT)
Multipurpose Tray (MPT) B410d/dn – single sheet; B420dn and B430d/dn – 50 sheets
Additional Paper Capacity Optional 530-sheet Letter/ Legal Universal 2nd paper tray
Maximum Paper Capacity
(with Opt. 2nd Tray + MPT)
B410d/dn – 781 sheets (with optional 530-sheet Paper Tray)
B430d/dn – 830 sheets (with optional 530-sheet Paper Tray)
B420dn – 1,110 sheets (with optional 530-sheet Paper Tray)
Paper Types Letter, Legal, Executive, A4, A5, A6, B5;
C5, C6, DL, Com 9, Com 10 and Monarch envelopes
Paper Size 3.4" x 5.5" min. to 8.5" x 14" max.
Standard Paper Output 150 sheets, face-down
Alternate Paper Output 50 sheets, face-up
Paper Weight Main 250-sheet tray and optional 530-sheet tray 16 lb. –
32 lb. bond (60 – 120 gsm); 50/single-sheet manual feed
16 lb. – 43 lb. bond (60 – 163 gsm)
Resident Fonts Scalable Fonts All models – 87 PCL fonts; B430d/dn only – 136 PostScript fonts
PCL Bitmap Fonts Line Printer; OCR-A/B
Bar codes UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, Code 39,
Code 128, EAN/UCC 128, CODABAR, ZiP+4 POSTNET
Supplies Toner Cartridge 3,500 pages3– all models; 7,000 pages3– B420dn and B430d/dn;
10,000 pages3– B420dn only
Image Drum 25,000 pages4 – all models
Environmental Size (WxDxH) B410d/dn and B430d/dn – 14.5" x 15.6" x 10.6"
(36.9 cm x 39.5 cm x 26.8 cm); B420dn – 14.5" x 15.6" x 11.7"
(36.9 cm x 39.5 cm x 29.72 cm)
Weight 24 lb. (10.8 kg)
Power Consumption Typical 450W; Peak 800W; Idle 70W
Warranty Printer 1-Year limited warranty on parts and labor
with Overnight Exchange5
Printheads 5-Year limited LED printhead warranty
1Published performance results based on laboratory testing. Individual results may vary.
2Memory DIMMs sold separately.
3Declared yield in accordance with ISO/IEC 19752. All models ship with 1,500-page
“starter” toner cartridge.
4Estimated life, continuous printing (may vary depending on the number of printed pages per job).
5Available in the U.S. and Canada only.
Printed in the USA
MS 15938/0109
