Oneida Air Systems XXK100300 User manual

10 HP
Direct Drive
Dust Collectors
Owner’s Manual
9_11
Oneida Air Systems, Inc. 1001 West Fayette St., Syracuse, NY 13204
Phone [phone].476.5151 Fax [phone] www.oneida-air.com
ZBM000017

10hp Direct Drive © O.A.S. 2010
1
Thank You for Choosing an Oneida Air Systems Product!
OAS manufactures and sells dust collection equipment only. Our qualied technicians and sales staff
are available 7:30am - 6:00pm EST Mon. - Thurs. and 7:30am - 5:00pm EST Fri. to answer any ques-
tions concerning OAS products and dust collection. Call for ductwork design and ductwork quotes,
including system pricing and shipping cost.
Read the entire Owner’s Manual before installing or operating system!
Proudly
Made in
the USA
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
IX.
X.
XI.
XII.
XIII.
XIV.
XV.
XVI.
XVII.
2
3
4
5
6
7 - 8
9
9
10
11
12
13
14
15
16
17
18 - 20
System Start-Up Information
General Assembly
General Specications & Fan Performance Curve
Dimensions
Stand Assembly
General Assembly Instructions
Fan / Blower Maintenance
Congurations
Filter Maintenance
Wire Diagram
Accessories
Troubleshooting
Fire Hazards - Read Before Installing System
Terms and Conditions
Filter Efciency Gauge Instructions
Fan Motor Lunbrication
Supplemental Instructions for Magnetic Motor Starters
Table of Contents Page

10hp Direct Drive © O.A.S. 2010
2
I. System Start-Up Information
Caution
Warning
Warning
1. Read the installation and maintenance instructions as well as the recommended safety practices in
this manual.
2. Install Ductwork completely:
(A.) Seal ductwork with silicone sealant or duct tape.
(B.) Have Dust Bin in place and sealed.
3. Have licensed electrician wire Fan / Blower according to wire diagram in this owner’s manual.
4. Have a licensed electrician check current draw on motor with all gates open. Current draw should not
exceed maximum motor amperage. (OAS is not responsible for destroyed motors.)
The Dust Collector & Fan / Blower is heavy! Handling and installation
should always be performed by experienced and trained personnel who
have experience with rotary equipment. In addition to the following instruc-
tional manual, care should be taken to ensure compliance with specic
safety requirements mandated bt federal, state and local codes.
Do not operate Fan / Blower without connecting ductwork. Never oper-
ate Fan / Blower without belt shaft guard in place. Keep clear of exhaust.
Keep hands and objects clear of inlet and outlet.
Check amperage draw during operation with all blast gates open. Make
certain amperageis not outside operating limit indicated on motor plate!
If amperage is too high - shut down immediately! (See Troubleshooting
section.)

10hp Direct Drive © O.A.S. 2010
3
II. General Assembly - XXK100300 - 3 Phase
10hp Direct Drive System - XXK010300 3 phase
1. Motor Blower Assembly - BXI050100 - 1ph - BXI070300 - 3ph
1a. Motor - 1ph / BMZ070370 - 7.5hp 3 ph
1b. Fan Housing - BHX070000
1c. Fan Wheel - BWX179800
1d. 7.5hp shaft spacer - BBS070001
1e. Bolt 5/16” - 24 x 1” left thread - AFB155160
1f. Motor Plate - RMP000000
1g. 5/16” Washer - AFW155160
1h. Bolt 1/2” - 13 x 3/4” HH (4) AFB155200
1i. Lockwasher 1/2” (4) - AFL010500
1j. Fender Washer 5/16” x 1 1/2” (2) - AFW170000
1k. Washer Flat 3/8” (8) - AFW190000
1l. Whiz Lock Nut 3/8” GR5 (4) - AFT000004
1m. Bolts 3/8” - 16 x 1” HHGR (4) - AFS015100
2. Cyclone Barrel - SXI070000
3. Cyclone Cone - SCX070000
4. Bolts 3/8” 16 x 1” (16) - AFS015100
Washers 3/8” (32) - AFW190000
3/8” Wiz Lock Nuts (16) - AFT000004
5/16” Wiz Lock Nuts (16) - AFT155175
5. Neoprene Gasket (30”) - RGZ000000
6. Owner’s Manual - ZBM000017
7. Plenum Filter Assembly - FXK020100
7a. Plenum Assembly 3 Filters - FPX020700
7b. Dust Bin 18” (3) - FPZ000018
7c. Filter Cartridge 130 sq. ft. 18” dia. x 62” L (3) - FCS186200
7d. Internal Silencer (3) - BSC180000
8. Filter Efciency Gauge Kit - FXK000000
8a. Fil. Eff. Gauge - VRG001005
8b. Vinyl Tubing (8’) - VRV003125
8c. Static Pressure Tip - VRP001875
8d. Mounting Flange for Pitot Tube - VRP010000
8e. Gauge Bracket - FXX000000
9. 55 gal. Steel Drum Kit - SEK551001
9a. Drum Lid w/ 10” ring - SEX55100
9b. Hose Clamps (2) - ACB120000
9c. 55 gal. Steel Drum - SES550000
9e. Flex Hose (10” dia. x 1’) - DHF100000
10. Stand with Plenum Support - STZ070000
b
5
f
5

10hp Direct Drive © O.A.S. 2010
4
III. General Specications & Fan Performance Curves
Physical and Electrical Data for 10hp Direct Drive Systems
System Performance Dust Bin
Sound
System Dimensions
Integral Fan Blower - 10hp External Cartridge Filter
Fan Wheel Diameter: 17” Welded Carbon Steel
Cyclone Inlet: 12”
TEFC 60 Hz Motor - Single Phase
Insulation Class: F4
Voltage: 208 - 230/460 3 Phase
Amperage: 26.2 - 23.8 / 11.9
Made in U.S.A.
3 Pleated Cartridge - 390 Sq. Ft.
Spun-Bonded polyester BIA ZH1/487 test - Rated C
Captures 99.99% of test material over 20 microns
Captures 99,9% of test material between 0.2 - 2
microns @ 11 fpm
10hp - 3800 cfm @ 2.3” SP no lter 55 Gal. Steel Drum
Large Dust Bins available
w/ Filters but no Internal Silencers:
85 - 87dBA @ 10’

10hp Direct Drive © O.A.S. 2010
5
IV. Dimensions For minimum mounting heights with 55 gal. drum
115.9

10hp Direct Drive © O.A.S. 2010
6
V. Angle Iron Stand

10hp Direct Drive © O.A.S. 2010
7
VI. Assembly Instructions

10hp Direct Drive © O.A.S. 2010
8
VI. Assembly Instructions (Cont.)
Wait a few minutes
for internal dust to
settle then unscrew
thumb nuts from
J-Hooks and remove
dust bin. Empty dust
carefully. Replace
dust bin. Do not over
tighten thumb nuts.
Filter
J-Hook
Dust Bin
Thumb Nut
Drum Grounding Wire
To attach the Drum
Grounding Wire, start a
small hole in bottom of
cone above ex hose
and in the top of the
dust drum, then attach
the wire with the 3/8”
included self-tapping
screws.
5. Attach ex hose to bot-
tom of collector and to lid
of dust bin. Securely fas-
ten hose clamps. There
must be an air tight seal
between the collector and
dust bin.
6. Make sure the dust bin lid sits se-
curely and the rubber gasket on the bin
lid is in place on the barrel. Maintain an
air tight seal between cyclone and dust
bin to prevent motor from overheating.
7. Attach the ductwork from the wood-
working machines to the inlet of the
collector.
8. On external lter models, attach the
Plenum Assembly or connect to your
own plenum box.
9. Attach feet of Angle Iron stand to the
oor.
Note: Assembly with tube lters - Note plenum
height requirements of tube lters - 6’ tubes - 8’ ple-
num / 8’ tubes - 10’ plenum / 10’ tubes - 12’ plenum.
Adjust system height accordingly.

10hp Direct Drive © O.A.S. 2010
9
VII. Fan / Blower Maintenance
A high pressure blower requires a certain amount of resistance which will prevent motor over amperage.
Make sure power source matches wire voltage congurations.
Check set screw and key in fan wheel, make sure fan wheel is secure. Fan blower should not vibrate.
1. Electical - Failure to follow instructions and safe electrical procedures could result in serious injury or death. Discon-
nect all power and discharge all capacitors before servicing. Install and ground per local and national codes. Consult a
licensed electrician with questions or if repairs are required.
Electrical Connections_
A.) All wiring, fusing, and grounding must comply with National Electrical Codes and local codes.
B.) To determine proper rotation and voltage connections, refer to the wire diagram of this manual.
C.) Use the proper size of line current protection and motor controls as required by the National Electrical Code and local
codes. Recommended use is 125% of full load amps as shown on the nameplate for motors with 40 degrees celsius
ambient and a service factor over 1.0. Recommended use is 115% of full load amps as shown on nameplate for all other
motors. Do not use protection with larger capacities than recommended. Three phase motors must have all three phases
protected.
2. Cleanliness - Keep both the interior and exterior of the motor free from dirt, water, oil, and grease.
4. Service - Notice - If lubrication instructions are shown on the motor nameplate, they will supercede this general
instruction.
3. Safety- Motors should be installed, protected and fused in accordance with the latest issue of National Electrical
Code, NEMA Standard Publication No. 2 MG 2 and local codes. Rotating parts such as pulleys, coupling, external fans,
and unusual shaft extentions should be permanently guarded. Keep hands and clothing away from moving parts. Elec-
trical repairs should be made by trained, qualied personnel only.
Warning! Rotating Fan Blades. Keep Objects Clear of Inlet and Outlet!
VIII. Fan / Blower Maintenance
