V - 2000 2hp / V - 3000 3hp Dust Collector Owner’s Manual
Powerful Economical Made in the USA
Oneida Air Systems, Inc. was founded in 1993 to bring cost effective, state-of-the-art
dust collection systems and material handling ductwork to woodworking shops. OAS
designs and manufactures industrial grade dust collection systems that create a prac-
tical, safe and healthy work place environment.
1.800.732.4065 www.oneida-air.com
Appearance may vary sligthly.
1001 W. Fayette St., Syracuse, NY 13204
V-SYSTEMS
V-SYSTEMS

1
V - Systems Owner’s Manual O.A.S. 2008
c
Thank You for Choosing an Oneida Air Systems Product!
OAS manufactures and sells dust collection equipment only. Our qualied technicians and sales staff are available
7:30am - 6:00pm EST Mon. - Thurs. and 7:30am - 5:00pm EST Fri. to answer any questions concerning OAS products
and dust collection. Call for ductwork design and ductwork quotes, including system pricing and shipping cost.
Read the entire Owner’s Manual before installing or operating system!
Proudly Made
in the USA
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
IX.
X.
XI.
XII.
XIII.
XIV.
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
System Start-Up Information
System Specications
Parts List
Fan Wheel Motor Assembly
Fan Wheel Motor Assembly
Cyclone Leg Assembly
Plenum Elbow Assembly
Filter Assembly
Drum Assembly
Directions for Cleaning Filter
Electrical Data
Troubleshooting
Fire Hazards - Read Before Installing System
Terms and Conditions
Fan Motor Maintenance
Table of Contents Page

I. System Start-Up Information
2
V - Systems Owner’s Manual O.A.S. 2008
c
1. Read the installation and maintenance instructions as well as the recommended safety practices in this
manual
2. Install ductwork completely before operating collector:
A.) Seal ductwork with silicone sealant or duct tape.
B.) Have dust bin in place and sealed.
Caution
The Direct Drive Fan / Blower makes the system top heavy! Use extreme care when setting the unit
up! It is recommended that at least two people lift the system up. Do NOT over tighten bolt on Fan
/ Blower to Cyclone body connection ring! Use a Nylock nut and regular hex nut. If bolt is
over torqued it can break, causing Fan / Blower to disconnect.
Warning
Do not operate Fan / Blower unless Fan Housing is attached to Cyclone body and Dust Drum is in
place. Dust Drum and Cyclone must be in place and sealed or motor will overheat!
Warning
Check amperage draw on motor with all gates open. Current draw should not exceed maximum
motor amperage as stated on motor plate. (OAS is not responsible for damage to motors caused by
improper installation, wiring or failure to follow these directions.)

3
V - Systems Owner’s Manual O.A.S. 2008
c
II. System Specications System
Performance
System
Dimensions
Options
Height w/ 35 Gallon Drum: 87 1/4” (2hp) - 89” (3hp)
Footprint w/ Ext. Cartridge: 48”x 48”x 48”
Inlet Diameter: 6”
Powder Coated Paint Finish Over Steel
Integral
Fan Blower
Filter Media
Included
Sound
Level
Dust Bin
U.S. Made Baldor or Leeson
2 or 3 Horsepower Single Phase
TEFC Motor, 1.15 Service Factor / Insulation Class F
for extra protection and motor life
Voltage: 115 - 230
Amperage: 23 / 11.5 (2hp) or 29 / 14.5 (3hp)
(3) Tripod Aluminum Legs
Filter w/ Internal Silencer
FREE D.I.Y. Duct Design Guide
Hardware Tool Kit
Pre-Wired Magnetic Starter -
With Standard Silencer & Filter: 73 dBA @ 10’
Without Silencer: 75 dBA @ 10’
Our Quietest System.
35 Gallon Fiber Drum - ODK350701 Standard
55 Gallon Fiber Drum - ODK550701 - Additional Charge
Fan Wheel - Cast Aluminum Alloy 356-51 / Backward
Inclined / Non-Sparking, Non-Ferrous as Required by
NFPA Fire Code / Dynamic, Two-Plane Balanced to ISO
6.3 Specications. The Same as Aircraft Turbine Rotors.
Industrial
Quality
Motor
ASHRAE
Tested
*Oneida reserves the right to change or modify specs and system appearance without notice.
Actual system appearance may vary.
w/ On-Off Switch Preset for Add-On Remote
with Amperage Overload Protector (1 Phase)
Oneida V - 2000 2hp / V - 3000 3hp
Part # Description
See Accessories
page for pricing.
13”x 26” 143 Sq. Ft. High Eff. Poly-Blend Filter Media (2hp)
Accredited, Independent Lab Tested
Filter Media Captures 99.9% of Test Material from 1 Micron
Remote Control - Radio Frequency
Bag Gripper
13” x 39” Spun-Bond Filter
HEPA Filter Media
Shop Plan Design Service
Approx. 1140 CFM @ 2.5” S.P. (2hp)
Approx. 1285 CFM @ 3” S.P. (3hp)
XXV020126
XXV020139
XXV030139
V-2000 w/ Blended Filter
V-2000 w/ Spun-Bond Filter
V-3000 w/ Spun-Bond Filter
13”x 39” 95 Sq. Ft. High Eff. Axtar Spun-Bonded Polyester Filter
Media (2 & 3hp)
Accredited, Independent Lab Tested
Filter Media Captures 99.9% of Test Material from 0.2 - 2 microns
Teon-Like Coating Facilitates Dust Release
OR
See Specications Below
Line of Sight Not Required.
Performance: V-2000
6 inch pipe 1140 CFM @ 2.5” W/C SP
5 inch pipe 913 CFM @ 4.5” W/C SP
4 inch pipe 760 CFM @ 6.3” W/C SP
3 inch pipe 620 CFM @ 8.1” W/C SP
0 CFM @ 10.5” W/C SP
(2hp)
87 1/4”
(3hp)
89”
45”
24”
V-SYSTEMS
Performance: V-3000
6 inch pipe 1285 CFM @ 3” W/C SP
5 inch pipe 1045 CFM @ 5.4” W/C SP
4 inch pipe 840 CFM @ 7.4” W/C SP
3 inch pipe 670 CFM @ 9.2” W/C SP
0 CFM @ 13.1” W/C SP
Dimensions shown w/ 2” ex hose between drum and cone collars.
Allow 1 - 2” from ceiling for motor venting.

III. Parts List V-Systems
1. Motor / Blower Assembly - BXI020107 (2hp) / BXI030107 (3hp)
1a. Motor (1) - BMZ020105 (2hp) / BMZ030170 (3hp)
1b. Pre-Wired Mag. Starter w/ Remote Option (1) - AMR221114 (2hp)
(1) - AMR221417 (3hp)
1c. Wire Connector (1) - WCC000000
1d. Cord Connector (1) - WCC025038 (2hp) / WCC027063 (3hp)
1e. Cord Connector (1) - WCN120000 (2hp) / WCN340000 (3hp)
1f. Fanwheel (1) - BWX137800 (2hp) / BWX142598 (3hp)
1g. Allen Hex Key (1) - ATK030160
1h. Blue Thread Locker (1) - YSS000037
1i. Lock Washer (4) - AFL010500
1j. Bolt (4) - AFB155200
1k. Silicone Tube (1) - ASC000028
1l. Gasket (6 ft.) - RGZ000000
1m. Sheet Metal Screws (6) - AFS014000
1n. Nyloc Nut (1) - AFT900516
V-SYSTEMS
2. Cyclone Body Metal (1) - SCX002107
3. V Tube (1) - SXV002107
4
V - Systems Owner’s Manual O.A.S. 2008
c
1f
1a
4
1l
4
3
17
7
13
5
15
10
12
11
8
9
Motor Box -
BXI020107 (2hp) / BXI030107 (3hp)
Cyclone Box -
4. Fan Housing incl. Duct Ring (1) - BHX002107 (2hp)
(1) - BHX030107 (3hp)
Housing Box -
5. 13”x 26” Poly-Blend (1) FCB132600 - 2hp
13” x 39” Spun Bond Filter (1) - FCS133995 - 2 & 3hp
Filter Box -
6. Hex Head Bolts (3) - AFB155175
7. Plenum (1) - FPX002107
8. Spun Dust Bin (1) - RFG130805
9. Wire Form Clip (3) - AFC000000
10. Filter Bracket Bottom (1) - RBX000000
11. 5/16” Fender Washer (1) - AFW170000
12. 5/16” Thumb Nut (1) - AFT000001
13. Internal Silencer (1) - BSC130000
14. Drum Kit 35 Gal. 7” Inlet (1) - ODK350701
14a. 35 Gal. Drum (1) - SDS350000
14b. 7” Flex Hose (1 ft.) - DHF070000
14c. 6-8” Hose Clamp (2) - ACB080000
Drum Box -
15. 5/16” x 20” Threaded Rod (2) - YSS000200
16. Coupling for Threaded Rod (1) - VRH051618
17. Aluminum Tubing Legs (3) - VRT010257
18. Leg Caps (3) - RCR012500
Pipe Box -
18
16
Motor Box - 21”x 21”x 20” - 90 lbs (2hp) / 104 lbs. (3hp)
Cyclone Box - 23”x 23”x 44” - 50 lbs.
Housing Box - 31”x 12”x 29” - 40 lbs.
Filter Box - 14”x 14”x 41” - 14 lbs. Spun-Bond
Filter Box - 14”x 14”x 29” - 12 lbs. Poly-Blend
Drum Box - 23”x 23”x 27” - 35 lbs.

IV. V-Systems Fan Wheel Motor Assembly
1. Open box and unpack Motor, Mag-
netic Starter, Fan Wheel and Hardware
package. Wheel and Hardware pack-
age is packed underneath Motor. See
right.
Note that Magnetic Starter is attached
to Motor by it’s cord.
2. To easily remove Motor, cut down
the sides of outside box as shown
above.
3. Pull out cut cardboard side from
bottom of box.
4. Lift out inside cardboard retainer,
then remove rest of box.
5. Carefully cut away plastic wrap and
remove bottom board. Lift and place
motor on it’s top on solid surface as
seen below. 6. Add a bead of silicone around
bottom of motor as indicated, against
shoulder of machined ridge. Note: This
seals Motor and Fan Housing, prevent-
ing dust blow out.
V - Systems Owner’s Manual O.A.S. 2008
c
Silicone

7. Put Fan Housing topside down over
motor shaft and line up the bolt holes
as shown below.
Fan Housing holes should line up with
Motor bolt holes.
8. Put included Lock-Tite on bolt shafts
and put all four bolts with Lock Washer
in the holes and nger tighten.
9. Then with a Torque Wrench, tighten
each bolt to 30 lbs. using a crossing
pattern. Do NOT tighten in a circle.
8. Put 1/2” high wooden pieces on
Fan Housing oor to rest Fan Wheel
on. Line up the two key ways in the
Fan Wheel and the Motor Shaft. There
must be 1/2” from top of Fan Wheel to
top of Motor Shaft in order for spinning
Fan Wheel to clear bolt heads.
1/2”
10. Insert Key into slot with narrower
side to shaft, then lightly tap with ham-
mer and nail set until key top is level
with shaft top being careful to avoid
hitting fan with hammer.
11 Put Lock-Tite on provided Set
Screws then put screw in hole in Fan
Wheel as shown. Tighten screw with
provided Allen wrench to 12 - 15 lbs.
Remove wooden pieces from under
Fan Wheel. Repeat procedure with
Set Screw in other hole.
Top View
Key
1/2”
Shaft
Motor
Fan Wheel Fan Wheel
Bolt
Head Bolt
Head
6
V - Systems Owner’s Manual O.A.S. 2008
c

V. V-Systems Cone Leg Assembly
12. Put included self-sticking gasket
on top rim of cone. Make sure there is
NO gap where both ends of gasket
meet. This is VERY important for an
air tight seal.
13. Insert legs into triangular holders
and tighten bolts securely.
15. Put Clamp Ring over cone for later
connection. Lower V-Tube into cone
making sure pins are inside the cone.
16. Put a bead of silicone on the top of
the V-Tube sheet.
Note: This is very important to seal
the Fan Housing to the Cyclone
Cone to prevent dust blow out.
14. Pick up cyclone
and set up on legs.
Bead of Silicone
Parts of this procedure require
at least two people to complete.
Use extreme caution and good
sense when assembling this
unit. Parts of it are very heavy.
17. Determine where you want Fan
Motor Outlet in relation to Cone Inlet,
then lift Fan Motor Housing on top of
cone, making sure the V-Tube guide
pins are inside the housing. The Fan
Motor Housing is extremely heavy. It
is at least a two person job. Do NOT
attempt to do this yourself! It could
be extremely dangerous!
18. Make sure Clamp Ring is evenly
over both the cone lip and housing lip.
Put bolt through ring then put hex nut
on rst, then put on the Ny-Lock nut
with nylon facing out and tighten.
Caution:
The Ny-Lock nut is required to
prevent the bolt from vibrating off
during operation. Don’t over tighten
nuts! Bolt could break!
7
V - Systems Owner’s Manual O.A.S. 2008
c

VI. V-Systems Plenum Elbow Assembly
19. Attach plenum with sheet metal
screws and seal well with silicone to
prevent dust blow out..
VII. V-Systems Filter Assembly
Insert Silencer into Filter. Plastic ring on Silencer must sit on the
inside of the Filter gasket. If you have the Spun-Bond Filter you
will get two rods that you must attach
with an included rod connector. The
blended Filter with the metal cage only
uses one rod.
20. Attach Filter Rod to Plenum. If you
have the Spun-bond lter, you will need 2
rods attached with a connector as shown
below. Before you connect the rod to
the Plenum, you must position the lter
underneath with the rod inside as shown
above. Make sure the silencer is inserted
in the lter as shown in inset before at-
taching the lter.
21. This is easiest with 2 people. Have
one person hold the lter up against
the Plenum plate while the second
person holds the bracket as shown and
puts it up on the lter rod, followed by
the washer and then the Thumb Nut.
8
V - Systems Owner’s Manual O.A.S. 2008
c
20. 21.

22. Position top of clip over metal rim,
then push bottom of clip underneath
the rim of the dust pan. Space the
three clips equally around the dust
pan, making sure the pan is even with
the lter bottom and tightly sealed as
shown right.
Fit over Filter rim.
Side view
of clip.
VIII. V-Systems Dust Drum Assembly
Collector
Hose Clamp
Hose Clamp
Flex Hose
Dust Bin
21. Pull Flex Hose up over cone end
and tighten Hose Clamp over it to
secure it. Pull other end of Flex Hose
over Dust Drum collar and tighten
second Hose Clamp over it to secure it
to drum.
22. Plug in Magnetic Starter and you
are ready to connect your collector to
your ductwork and go!
9
V - Systems Owner’s Manual O.A.S. 2008
c
