Introduction
The MBT 201 Universal Soldering/Desoldering Systems provide the user with the power and
versatility to remove and install SMD and Thru-Hole devices. The power source incorporates a highly
responsive SensaTemp (closed-loop) temperature control system which provides power to the two
output channels on the MBT 201 systems. Accessory handpieces (standard & optional) and special
use tips allow the user to remove and replace a wide variety of surface mount components.
The self-contained AUTO SNAP-VAC pump provides an automatic minimum on-time of 1.2 seconds
to virtually eliminate re-sweat joints, tip clogging and maintenance while dramatically increasing tip
life.
Virtually all of today’s specialized handpieces with large SMD tips suffer from a problem in which the
actual tip temperature that the work sees can be more than 100°F cooler than the Set Tip
Temperature on the Variable Temperature Control. MBT 201 systems feature PACE’s unique Tip &
Temperature Selection System which allows the user to set the true temperature desired for any
size and type of tip or handpiece.
The MBT 201 systems are available in a 115 VAC (97-127 VAC) version or a 230 VAC (196-253 VAC)
version. The 230 VAC version system bears the CE Conformity Marking which assures the user that
it conforms to all the requirements of council directive EMC 89/336/EEC. The systems package
includes the power source with a selection of accessories and functional aids. These systems are
as follows.
General Information
MBT 201-SD SYSTEM - Consists of MBT 201 (115 VAC, 60 Hz Version) Power Source, PS-90
Soldering Iron, SX-80 Sodr-X-Tractor, SX & PS Tip & Tool Stands, Tip &
Temperature Selection System Charts and Accessory Kit.
MBT 201E-SD SYSTEM - Consists of MBT 201E (230 VAC, 50 Hz Version) Power Source, PS-90
Soldering Iron, SX-80 Sodr-X-Tractor, SX & PS Tip & Tool Stands, Tip
& Temperature Selection System Charts and Accessory Kit.
The MBT 201 systems meet all applicable EOS/ESD, temperature stability and other government and
industry specification requirements (including MIL-STD-2000A). They contain PACE’s unique
SensaTemp temperature management system for high performance and safety, plus a Tip Offset
Compensation feature for superior thermal process control.
1

Specifications
POWER REQUIREMENTS
MBT 201 System - Version operates on 97-127 VAC, 50/60 Hz.
138 Watts, 1.2 Amp typical; 184 Watts, 1.6 Amp maximum
MBT 201E System - Version operates on 196-264 VAC, 50 Hz.
138 Watts, 0.6 Amp typical; 199 Watts, 0.9 Amp maximum
VACUUM AND AIR
Measurements at front panel AUTO SNAP-VAC and Controllable PRESSURE Ports of power source.
Vacuum Rise Time: Evacuates 33 cc (2 cubic inch) volume
to 25 cm Hg. (10 in. Hg.) in 200 ms.
Vacuum: 51 cm Hg. (20 in. Hg.) (nominal).
Pressure: .48 Bar (7 P.S.I.) (nominal, "MAX" setting).
Air Flow: 9 SLPM (0.32 SCFM) maximum.
ENVIRONMENTAL REQUIREMENTS
Ambient Operating Temperature: 0°C to 50°C (32°F to 120°F).
Storage Temperature: -40°C to 100°C (-40°F to 212°F).
General Information
2

PHYSICAL PARAMETERS
Size: 13.5 cm H X 16.5 cm W X 20.3 cm D
(5.3 in. H X 6.5 in. W X 8.0 in. D)
Weight: MBT201 3.7 kg. (8.1 lbs.)
MBT201E 3.7 kg. (8.1 lbs.)
TEMPERATURE SPECIFICATIONS
Tip Temperature Range: 232°C to 482°C (450°F to 900°F), nominal.
Accuracy: ±5% of control setting
Tip Temperature Stability: ±1.1°C (2°F) at idle from Set Tip Temperature.
NOTE
True minimum and maximum Operating Tip Temperatures may vary
depending on handpiece & tip selection.
EOS / ESD
Tip-To-Ground
Resistance: Less than 2 ohms.
AC Leakage: Less then 2 millivolts RMS from 50Hz to 500Hz, min.
General Information
3

General Information
StandardHandpieces
All capabilities are dependent upon the use of the appropriate Functional Accessories or Work Aids.
Available handpieces and their associated assembly and repair functions are listed below (a manual
is provided separately with each handpiece which describes the applications and recommended
procedures for that particular tool).
PS-90 Soldering Iron - Standard handpiece on MBT 201 & MBT 201E systems. Provides a wide range
of SMD and thru-hole installation and removal capability as well as unsurpassed thermal performance on
heavy, multilayer thru-hole assemblies at safe, lower working temperatures. A wide variety of 3/16"
shank, quick change thru-hole and SMD tips (for chip components, SOTs, SOICs and other components)
areavailable.
SX-80 Sodr-X-Tractor Handpiece - Standard handpiece on MBT 201 & MBT 201E systems. Provides
thermally enhanced thru-hole desoldering on heavy multilayer assemblies, especially during continuous
use. With the unique Flo-D-Sodr tip, the Sodr-X-Tractor performs safe, continuous SMT land cleaning
and preparation. The slim-line, pencil-grip design and finger-actuated vacuum switch allow easy use and
manipulation in tight places.
OptionalHandpieces
TT-65 ThermoTweez Handpiece - Provides safe, one-handed reflow and removal of PLCCs, LCCCs,
chip components and other surface mount devices. Its high thermal capacity and targeted heat quickly
removes large SMDs without damage to the board or adjacent components, even on heavy, multilayer
assemblies. The unique, vertically oriented design and a wide variety of quick change tips easily reach
into tight work areas for safe SMD removal.
PS-70 Soldering Iron - Designed for high volume, single point soldering operations. It's thin heater and
balanced feel make the PS-70 the perfect choice for applications where visibility and iron control is
required, such as micro-soldering applications. The PS-70 is one of the most responsive irons on the
market due to its quick-heat generator that provides fast and stable heat flow as needed. The PS-70
uses 1/8" shank, quick change PERMAGROUND tips.
4

General Information
TP-65 ThermoPik Handpiece - Provides safe, one-handed reflow and removal of a wide variety of
PQFPs and FlatPacks in just seconds. The high thermal efficiency design targets controlled
SensaTemp heat directly at the solder joints, away from sensitive substrate areas and adjacent
components. The ThermoPik’s self-adjusting integral vacuum pick and unique design provide easy, one-
handedoperation.
DTP-80 Dual ThermoPik Handpiece - Provides safe, one-handed reflow and removal of a wide variety of
PQFPs and FlatPacks in just seconds. Its high thermal capacity and targeted heat quickly removes
large SMDs without damage to the board or adjacent components, even on heavy, multilayer assemblies.
The unique, vertically oriented design and a wide variety of quick change tips easily reach into tight work
areas for safe SMD removal. The Dual ThermoPik’s self-adjusting integral vacuum pick and unique design
provideeasy,one-handed operation.
TJ-70 ThermoJet Handpiece - Provides safe, rapid installation of SMDs including chip components,
SOTs, SOICs, PLCCs, LCCCs and FlatPacks. The slim-line design and precision focused air flow lets
you easily target controlled heat right at the solder joints without damaging the board or adjacent
components. A finger-actuated air switch and SensaTemp control provide safe, “on-demand” capability
without constant running of the air pump.
OptionalHandpieces
5

ProductApplication
These products are very versatile and may be used to satisfy a variety of application requirements. If you
require assistance in the use of this product for your particular application, contact your local authorized
PACE distributor or PACE directly as shown on page ii.
PartsIdentification
1. POWER SWITCH - Turns system ON (“1”) and OFF (“0”); controls input power to system.
2. CH 1 VARIABLE TEMPERATURE CONTROL - Allows the operator to adjust the tip
temperature for handpiece/tip combination connected to channel 1.
3. CH 2 VARIABLE TEMPERATURE CONTROL - Allows the operator to adjust the tip
temperature for handpiece/tip combination connected to channel 2.
4. CH 1 POWER RECEPTACLE - Provides power, tip ground, sensing circuitry and finger switch
connection from MBT system to the handpiece connected to channel 1.
5. CH 2 POWER RECEPTACLE - Provides power, tip ground, sensing circuitry and finger switch
connection from MBT system to the handpiece connected to channel 2.
6. CH 1 LED - Green LED provides visual indication of duty cycle control of channel 1. Indicator
lights as power is applied to the connected handpiece.
7. CH 2 LED - Green LED provides visual indication of duty cycle control of channel 2. Indicator
lights as power is applied to the connected handpiece.
8. AUTO SNAP-VAC PORT - Quick connect fitting which provides quick-rise vacuum for Sodr-X-
Tractor or ThermoPik handpieces. Vacuum is present when handpiece finger switch or optional
foot pedal is actuated. Vacuum continues a minimum of 1.2 seconds after switch (or foot
pedal)actuation.
9. CONTROLLABLE PRESSURE PORT - Quick connect fitting with adjustable valve which
provides variable air flow for the ThermoJet handpiece. Air pressure is present when handpiece
finger switch or optional foot pedal is actuated. Air pressure ceases 1.2 seconds after switch
(or foot pedal) is released.
10. EARTH GROUND RECEPTACLE - Provides positive earth ground to which a ground cable can
be connected from the workpiece or work surface as part of a static control program.
General Information
6
