Panasonic SC-HG1-ETC User manual

2019.12 panasonic.net/id/pidsx/global
EtherCAT-compatible
Communication Unit for HG Series
SC-HG1-ETC
User’s Manual
WUME-SCHG1ETC-2

WUME-SCHG1ETC-22
(MEMO)

WUME-SCHG1ETC-2 3
Introduction
Thank you for purchasing an SC-HG1-ETC EtherCAT-compatible Communication Unit for HG
Series.
Before using this product, read and understand this User’s Manual. Use the product correctly
and in the optimum manner.
Keep this manual in a safe location for reference whenever necessary.
Type of Manual
The following user’s manuals are available for the SC-HG1-ETC series. Refer to the appropriate
manual according to your need.
The user’s manuals are also available for download from our website (https://panasonic.net/id/
pidsx/global).
Unit name or purpose of use Manual name Manual code
EtherCAT-compatible Communication
Unit for HG Series SC-HG1-ETC User’s Manual WUME-SCHG1ETC
Contact-Type Digital Displacement
Sensor HG-S Series HG-S User’s Manual WUME-HGS
Thru-Beam Type Digital Displacement
Sensor HG-T Series HG-T User’s Manual WUME-HGT
Please note
1) No part of this manual may be reproduced or reprinted in any form or by any means without
prior written permission from Panasonic.
2) The contents of this manual are subject to change without notice for future improvement.
3) This manual has undergone strict quality control; but should you discover any dubious infor-
mation, mistakes, misplaced pages, or missing pages, please contact your local dealer.
4) Ethernet is a registered trademark of Fuji Xerox Co., Ltd.
5) EtherCAT® is a registered trademark and patented technology, licensed by Beckho󰀨 Automa-
tion GmbH, Germany.
6) The ownerships of all other trademarks belong to their respective owners.

WUME-SCHG1ETC-24
Manual Conguration
1 Before Using This Product
This chapter explains precautions for safe use, terminolo-
gy, package contents, and the name and function of each
component.
2 System Conguration This chapter explains the types and conditions of devices
that can be connected to this product.
3 Installation and Setup This chapter explains the procedures for installation, con-
nection to external devices, and communication setup.
4 EtherCAT Network Com-
munication This chapter explains the communication methods.
5 EtherCAT Operating Procedure
This chapter explains the network configuration setup
method and the procedure for operation after power ON.
6 Specication and Dimensions
This chapter explains the specications and dimensions.
7 Warranty This chapter explains warranty.
8 Maintenance This chapter explains maintenance and inspection.
9 Troubleshooting
This chapter explains troubleshooting and error codes.
10 Sample Programs
This chapter explains sample programs.

WUME-SCHG1ETC-2 5
Contents
Introduction··················································································· 3
Type of Manual·············································································· 3
Manual Conguration······································································ 4
1 Before Using This Product ···························································· 1-1
1.1 Safety Precautions ··································································· 1-2
1.2 Handling Precautions································································· 1-3
1.3 Terminology ············································································· 1-5
1.4 Contents of Package ································································· 1-6
1.5 Name and Function of Each Component········································ 1-7
2 System Conguration··································································· 2-1
2.1 System Conguration of This Product············································ 2-2
2.2 Compatible Devices ·································································· 2-4
3 Installation and Setup ·································································· 3-1
3.1 Preparation for Operation ··························································· 3-2
3.2 Installation ··············································································· 3-3
3.2.1 Installing and Removing the SC-HG1-ETC ································ 3-3
3.2.2 Installing and Removing the SC-HG1-ETC and Compatible Devices ··· 3-4
3.2.3 Connecting and Disconnecting the Ethernet Cable ····················· 3-6
3.3 Setup······················································································ 3-8
3.3.1 Station Aliases ····································································· 3-8
4 EtherCAT Network Communication················································· 4-1
4.1 Communication Overview ··························································· 4-2
4.1.1 Communication with Master Device·········································· 4-2
4.1.2 Communication between SC-HG1-ETC and Controller················· 4-3
4.2 Memory Allocation····································································· 4-4
4.2.1 Object Dictionary·································································· 4-4
4.2.2 PDO Mapping······································································ 4-6
4.3 Command Transmission Procedure ·············································· 4-11
4.3.1 Read Command··································································· 4-11
4.3.2 Write Command ··································································· 4-15
4.4 Command List ·········································································· 4-17
4.4.1 HG-S Series Command List···················································· 4-17
4.4.2 HG-T Series Command List···················································· 4-22
4.5 Reading Received Light Waveforms·············································· 4-33
4.5.1 Format of Received Light Waveform········································· 4-33
4.5.2 Reading Measured Waveforms ··············································· 4-35
4.5.3 Reading Reference Waveforms··············································· 4-38
4.6 Registering Reference Waveforms················································ 4-41
4.7 Self-monitoring Function····························································· 4-46
4.7.1 Using the Self-monitoring Function··········································· 4-46
4.7.2 Statuses and Measures ························································· 4-47
4.8 Other Precautions ····································································· 4-49

WUME-SCHG1ETC-26
5 EtherCAT Operating Procedure······················································ 5-1
5.1 Network Conguration Setup Method ············································ 5-2
5.2 Example of Operating Procedure after Power ON ···························· 5-7
5.2.1 Operation Flow ···································································· 5-7
5.3 Reading Judgment Output ·························································· 5-8
5.4 External Inputs ········································································· 5-8
5.5 Checking Error Information ························································· 5-9
6 Specication and Dimensions························································ 6-1
6.1. Specications ·········································································· 6-2
6.2. Dimensions············································································· 6-3
7 Warranty ··················································································· 7-1
7.1 Important Information about Order and Use of This Product ··············· 7-2
8 Maintenance ·············································································· 8-1
8.1 Maintenance and Inspection························································ 8-2
8.1.1 Maintenance Precautions······················································· 8-2
8.1.2 Main Inspection Items ··························································· 8-2
9 Troubleshooting ·········································································· 9-1
9.1 Error Codes and Solutions ·························································· 9-2
9.2 Solutions to Problems ································································ 9-4
10 Sample Programs······································································ 10-1
10.1 Assumed System Conguration for the Sample Program ················· 10-3
10.2 Sample Program ····································································· 10-4
10.3 Sample Program Overview························································ 10-5

1-1
1 Before Using This Product
1.1 Safety Precautions ···································································· 1-2
1.2 Handling Precautions································································· 1-3
1.3 Terminology ············································································· 1-5
1.4 Contents of Package ································································· 1-6
1.5 Name and Function of Each Component········································ 1-7

1.1 Safety Precautions
WUME-SCHG1ETC-21-2
1.1 Safety Precautions Always observe
This section explains important rules that must be observed to prevent personal injury and prop-
erty damage.
■ The hazards that may occur if the product is used incorrectly are described and classied by
level of harm.
WARNING Risk of death or serious injury.
CAUTION Risk of minor injury or property damage.
WARNING
●Never use this product as a sensing device for personnel protection.
●For sensing devices for personal protection, use products that conform to the laws and standards
related to personal protection in each country, such as OSHA, ANSI, and IEC.

1.2 Handling Precautions
WUME-SCHG1ETC-2 1-3
1.2 Handling Precautions
■The following symbols are used to indicate safety information that must be observed.
Indicates an action that is prohibited.
Indicates an action that must be taken.
Indicates a matter that requires caution.
Information
Indicates supplemental information.
Reference Indicates reference to details about the subject in question.
Note Indicates points to be noted when the product is operated.
Specications
●This device has been developed / produced for industrial use only.
●This product uses an EEPROM. The EEPROM has a service life of one million setting opera-
tions.
● Do not use this product outside the range of the specications. Risk of an accident and prod-
uct damage.
There is also a risk of a noticeable reduction of service life.
Power supply
●Incorrect wiring damages the internal circuits, so check the wiring before turning ON the pow-
er.
● Verify that uctuations of power input supply voltage do not exceed the rating, including the
connected devices.
●Note that there is a risk of damage and burning if a voltage greater than the rated voltage is
applied or AC power is directly applied.
●If power is supplied from a commercial switching regulator, ensure that the frame ground (F.G.)
terminal is connected to an actual ground.
● Ensure that the power supply capacity is su󰀩cient.
●Do not use this product during the initial transient time immediately after the power supply is
switched ON.
●For DC power supply, always use an isolation transformer. If an autotransformer is used, the
main unit or power supply may become damaged.
●If surges occur in the power supply that is used, connect a surge absorber to the source of
the surge occurrence to absorb surges.

1.2 Handling Precautions
WUME-SCHG1ETC-21-4
Wiring
●Before wiring or connection work, always make sure that the power is OFF. Failure to do so
may result in electric shock or damage.
●When noise generating devices (such as switching regulators and inverter motors) are used
around this product, always ground the frame ground (F.G.) terminal of each device sepa-
rately.
●To avoid noise, make the wiring as short as possible.
●Do not wire the controller in parallel with a high-voltage line or power line or use the same
conduit as these lines. Doing so may result in malfunctioning due to induction.
●Use Ethernet cables compatible with EtherCAT.
●Do not apply stress such as excessive bending or pulling to the connector base of the Ether-
net cable. Doing so may result in malfunctioning due to damage or connection failure.
●Always ground the shield of the Ethernet cable on the master device side. This product does
not have a grounding terminal.
● For the detailed connection specications, refer to the EtherCAT Installation Guide published
by the EtherCAT Technology Group (ETG).
Operating environment
●This product is suitable for indoor use only.
●Avoid using the product in steamy or dusty locations or other similar locations.
●Avoid using the product in atmospheres that contain corrosive or other harmful gases.
●Ensure that the product does not come into contact with organic solvents such as thinner.
●Ensure that the product does not come into contact with strong acid or alkaline.
●Ensure that the product does not come into contact with oil or grease.
● This product cannot be used in an environment that contains ammable or explosive gases.
● Performance may not be satisfactory in a strong electromagnetic eld.
●Do not use this product in locations subject to severe vibration or shock.
●Do not drop the product or otherwise subject to shock. Doing so may result in failure.
●For details on how to use the PC to be connected, refer to the instruction manual provided
with the PC.
Other precautions
●Never attempt to disassemble, repair, or modify the product.
●When the product becomes unusable or unneeded, dispose the product appropriately as in-
dustrial waste.
●Design the system so that protection and safety circuits for protecting the system from prob-
lems are located outside.

1.3 Terminology
WUME-SCHG1ETC-2 1-5
1.3 Terminology
Term Description
System
terms
EtherCAT A master-slave open network communication system using Real-Time
Ethernet
Cyclic communication A function that transmits data bidirectionally in specied certain cycles
Mailbox communica-
tion (CoE)
A handshake communication function that is used to exchange aperiod-
ic data
ESI le
An XML le that contains recognition information such as the manufac-
turer and model number of an EtherCAT slave device and information
required for setup and communication
Station alias A station number assigned to each slave device on the EtherCAT network
Unit names
EtherCAT master device
A device that controls the entire network. It communicates with each
slave device connected to the network.
EtherCAT slave device A device that connects to the network controlled by a master device and
communicates with the master device
Ethernet cable Category 5e or higher Ethernet cables that satisfy the 100BASE-TX
standard. (Double shielded twisted pair cable or straight cable)
End plate or commer-
cially available tting Used to secure on a DIN rail

1.4 Contents of Package
WUME-SCHG1ETC-21-6
1.4 Contents of Package
The following items are included in the product package. Before using the product, make sure
that no items are missing.
●Controller: 1 pc. ●Instruction manual (English /
Japanese, Chinese / Korean):
2 pcs.
●General Information for Safety,
Compliance, and Instructions:
1 pc.

1.5 Name and Function of Each Component
WUME-SCHG1ETC-2 1-7
1.5 Name and Function of Each Component
1 2
3
4
5
11
10
9 8 76
Name Function
1Station ID (x16) Rotary switch for setting a station alias. (Note 1)
[Station aliases can be set between 00 and FF]
2Station ID (x1)
3IN RJ45 connector for EtherCAT connection. This connector connects the master
device and the Ethernet cable.
4OUT RJ45 connector for EtherCAT connection. This connector connects the slave
device and the Ethernet cable.
5Male connector for lateral
connection
This connector connects a controller (master unit or slave unit). Electric power
required for the communication unit is supplied from the master unit or slave
unit through this connector.
6ERR. indicator (Red)
This indicator indicates the state of communication between the communica-
tion unit and the controller connected to it.
OFF: Normal operation state
ON: Communication error occurs between the communication unit and the
controller
7POWER indicator (Green) OFF : The power is OFF
ON : The power is ON
8RUN indicator (Green)
OFF: INIT state
Flashing {single ash (Note 2)}: SAFE-OPERATIONAL state
Flashing {blinking (Note 3)}: PRE-OPERATIONAL state
ON: OPERATIONAL state
9L/A IN indicator (Green) OFF : The communication unit is not connected to the Ethernet
Flashing : Link is normal and data is sent or received
ON : Link is normal and data is not sent or received
10 L/A OUT indicator (Green)
11 ECAT ERR indicator (Red)
OFF : Normal operation state
Flashing {Double ash (Note 4)} : Watchdog timeout occurs
Flashing {Blinking (Note 3)} : Conguration error occurs
Notes: 1) For numerical display on the switch, refer to each switch.
2) The indicator repeatedly lights for 0.2 seconds and goes out for 1 second.
3) The indicator repeatedly lights for 0.2 seconds and goes out for 0.2 seconds.
4) The indicator repeatedly lights for 0.2 seconds, goes out for 0.2 secondslights up for 0.2 seconds, and goes,
out for 1 second in this order.
Reference
●For details on how to set EtherCAT station aliases, refer to “3.3.1 Station Aliases” or the respective
manuals for the EtherCAT master device and conguration tool that you use.
● For details on how to congure EtherCAT operation settings, refer to “4.3 Command Transmission
Procedure”.

WUME-SCHG1ETC-21-8
(MEMO)

2-1
2 System Conguration
2.1 System Conguration of This Product············································ 2-2
2.2 Compatible Devices ·································································· 2-4

2.1 System Conguration of This Product
WUME-SCHG1ETC-22-2
2.1 System Conguration of This Product
This product is a communication unit that monitors sensor ON/OFF output, the amount of detec-
tion, and other data through EtherCAT communications between each controller and the Ether-
CAT master device.
This product can be connected to up to 15 controllers (one master unit and 14 slave units).
Electric power required for this product is supplied from the master controller connected to it.
End plate MS-DIN-E (option)
SC-HG1-ETC
Connect to EtherCAT master device
To power supply
To power supply
Controller - Master unit (Option)
Controller - Slave unit (Option)
(Maximum 14 units connectable)
Connection between slave units

2.1 System Conguration of This Product
WUME-SCHG1ETC-2 2-3
Information
●If HG-SC series and HG-TC series controllers are used in combination, connect the slave con-
trollers of the same series as the master controller on the near side of the master controller and
connect the slave controllers of di󰀨erent series from the master controller on the far side of the
master controller.
Example: When the master controller is HG-SC□
Controller - Slave unit
HG-SC□
Controller - Slave unit
HG-TC□
Controller - Master unit
HG-SC□
SC-HG1-ETC
●If HG-TC series and HG-SC series controllers are used in combination, there are limitations on
the functions below.
Item Description of limitation
1Calculation
function
Calculation is only performed when the slave unit is the same series as the
master unit.
Calculation is not performed when the slave unit series is di󰀨erent from the
master unit series. "CALC" does not appear in the display of a slave unit of a
di󰀨erent series.
2Input all
The master unit only performs input all when the slave units are the same
series.
A slave unit of a di󰀨erent series from the master unit does not perform input
even when the external input settings match those of the master unit.
3Copy function
Copying is only performed when the slave unit is the same series as the mas-
ter unit.
When copying is executed, "NOW COPY" appears even on the display of a
slave unit of a di󰀨erent series from the master unit , but copying is not per-
formed.
4Interference
prevention
This function is only available on the HG-TC series controller. The function is
not executed on the HG-SC series controller.

2.2 Compatible Devices
WUME-SCHG1ETC-22-4
2.2 Compatible Devices
This product
Product name Appearance Model
EtherCAT-compatible
Communication Unit
for HG Series
SC-HG1-ETC
Controller
●HG-SC series
Type Appearance Model Output
Contact-type digital displacement sensor
Master unit
High-performance
type
Analog current
output
+
I/O
HG-SC101 NPN open-collector transistor
HG-SC101-P PNP open-collector transistor
Slave unit
High-performance
type
Analog current
output
+
I/O
HG-SC111 NPN open-collector transistor
HG-SC111-P PNP open-collector transistor
Standard type
(I/O)
HG-SC112 NPN open-collector transistor
HG-SC112-P PNP open-collector transistor
Wire-saving type HG-SC113 −
●When connecting slave units to the master unit, connect only NPN output type units or
only PNP output type units. Dissimilar output types cannot be connected together.
●If an HG-SC series controller manufactured in January 2019 or earlier is connected with
an HG-TC series controller, operation will not take place normally. Use an HG-SC series
controller manufactured in February 2019 or later.

2.2 Compatible Devices
WUME-SCHG1ETC-2 2-5
●HG-TC series
Type Appearance Model Output
Thru-beam type digital displacement sensor
Master unit
High-performance
type
Analog output
+
I/O
HG-TC101 NPN open-collector transistor
HG-TC101-P PNP open-collector transistor
Slave unit
High-performance
type
Analog output
+
I/O
HG-TC111 NPN open-collector transistor
HG-TC111-P PNP open-collector transistor
Wire-saving type HG-TC113 ―
●When connecting slave units to the master unit, connect only NPN output type units or
only PNP output type units. Dissimilar output types cannot be connected together.
●If an HG-SC series controller manufactured in January 2019 or earlier is connected with
an HG-TC series controller, operation will not take place normally. Use an HG-SC series
controller manufactured in February 2019 or later.
End plate
Product name Appearance Model
End plate MS-DIN-E

WUME-SCHG1ETC-22-6
(MEMO)
