Panasonic JS-950 Series User manual

C
ontents
For USA / For CANADA / For EU /
For Korea / For Taiwan
English
Read Me First …..….……..... 6
1.Getting Started
2.Operation
3.Appendix
Deutsch
Einführung ……….……….. 32
1.Vorbereitung
2.Betrieb
3.Anhang
Français
Lisez-moi d'abord …..…….. 61
1. Pour commencer
2. Opération
3. Annexe
Español
Lea esto primero …..……... 88
1. Operaciones iniciales
2. Operación
3. Apéndice
Русский
Сначала прочитайте....... 115
1. Начало работы
2. Эксплуатация
3. Приложение
한국어
먼저 읽어 주십시오 …...... 144
1. 시작하기
2. 조작
3. 부록
臺灣
使用前須知 …..……....….. 170
1. 開始使用
2. 操作
3. 附錄
User’s Manual
POS Workstation
Model No. JS-950 Series
Before operating this product,please read the instructions carefully,
and save this manual for future use.

1
■For USA
For USA
Federal Communications Commission Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses and can radiate radio frequency energy and, If not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own
expense.
Mercury caution
This product has a fluorescent lamp that contains mercury. Dispose may be regulated in your
community due to environmental considerations. For disposal or recycling information, please
contact your local authorities, or the Electronic Industries Alliance:
http://www.eiae.org
Ce produit possede une lampe fluorescente contenant du mercure. Ceci est a mettre au rebut
selon la regulation locale dans votre communaute en raison des considerations a prendre pour
la protection de l'environnement. Pour obtenir les informations relatives a la mise au rebut ou au
recyclage, veuillez prendre contact avec les autorites locales ou Electronic Industries Alliance:
http://www.eiae.org
Battery
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate
Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/Perchlorate.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.

2
■For CANADA
■For EU
For EU
This is a class A product. In a domestic environment, this product may cause radio interference
in which case the user may be required to take adequate measures.
Importer’s name and address to follow EU rules:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, F. R. Germany
For CANADA
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

3
■For Korea
상호 또는 성명 : 파나소닉코리아주식회사
기기의 명칭 : POS-WORKSTATION
기본모델명 : JS-950WS-040/ JS-950WS-050
제조자/제조국가 : UNIVERSAL SCIENTIFIC INDUSTRIAL CO.,LTD./ 대만
제조날짜 : 본체 밑면의 시리얼 번호를 참조하시기 바랍니다.
yymXXXXXX
yy: 년도 표시(yy means year) (2007＝07, 2008＝08,.....)
m: 월표시(m means month)
A: 1월B: 2월C: 3월D: 4월E: 5월F: 6월
H: 7월J: 8월K: 9월L: 10월M: 11월N: 12월
■For Taiwan
甲類
此設備經測試證明符號BSMI（經濟部標準檢驗局）之甲類數位裝置的限制規定。這些限制的目
的是為了在商業環境中使用此設備時，能提供合理的保護以防止有害的干擾。此設備會產生、使
用並散發射頻能量：如果未導照製造廠商的指導手冊來安裝和使用，可能會干擾無線電通訊。請
勿在住宅區使用此設備。
安全：電池處理
警告：新電池安裝不正解會有爆炸的危險。更換電池時，請僅使用相同或製造商建議的同
等類型電池。請勿將廢棄電池丟棄於一般垃圾中。請聯絡當地廢棄物處理機構以獲取有關
最近的廢棄電池存放站的地址。
您的電腦使用鋰幣電池。鋰幣電池為長效用電池，很有可能您永遠都不需要更換它。然而，
如果確實需要更換，請參閱您的電腦說明文件。
請勿將廢棄電池丟棄於一般垃圾中。請聯絡當地廢棄物處理機構以獲取有關最近的廢棄電
池存放站的地址。
安全：電池聲明（台灣）
廢電池請回收
주의사항
이기기는 업무용으로 전자파적합등록을 한기기이오니 판매자 또는 사용자는 이점을 주의
하시기 바라며 만약 잘못 판매 또는 구입하였을 때에는 가정용으로 교환하시기 바랍니다.
警告使用者：
這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干
擾，在這種情況下，使用者會被要求采取某些適當的對策。

4
Warning :
This is a class A product. In a domestic environment, this product may cause radio interference
in which case the user may be required to take adequate measures.
Warnung :
Dies ist ein Produkt der Klasse A. Wenn im Heim betrieben, kann das Produkt
Hochfrequenzstörungen verursachen, gegen die der Benutzer u.U. geeignete Maßnahmen
treffen muss.
Avertissement :
Il s'agit d'un produit de classe A. Dans un environnement privé, ce produit risque de créer des
interférences radio auquel cas des mesures correctives adéquates peuvent être exigées de la
part de l'utilisateur.
Upozornění :
Toto je výrobek třídy A. Ve vnitřním prostředí může tento výrobek způsobovat rádiové rušení. V
takovém případěmůže být požadováno, aby uživatel přijal příslušná opatření.
Advarsel :
Dette er et klasse-A produkt. I hjemmeomgivelser kan dette produkt forårsage radiostøj, i
hvilket tilfælde brugeren kan være nødsaget til at træffe fyldestgørende forholdsregler.
Предупреждение :
Это изделие класса А. Вдомашних условиях данное изделие может вызвать
радиопомехи, что может требовать от пользователя принятия соответствующих мер.
Varoitus :
Tämä on luokan A tuote. Kotiympäristössä tämä tuote saattaa aiheuttaa häiriöitä
radiolähetyksiin, jolloin käyttäjän tulee kenties suorittaa asianmukaiset toimenpiteet.
Advarsel :
Dette er et klasse A produkt. Ved innendørs bruk kan dette produktet forårsake radiointerferens.
I slike tilfeller kan det være nødvendig for brukeren å treffe nødvendige tiltak.
Varning :
Detta är en klass A produkt. I inomhusmiljö kan denna produkt orsaka radiostörningar. I sådant
fall åligger det användaren att vidta lämpliga åtgärder.
Upozornenie :
Toto je výrobok triedy A. Vo vnútornom prostredí môže tento výrobok spôsobovaťrádiové
rušenie. V takom prípade môže byťpožadované, aby používateľprijal príslušné opatrenia.
Attenzione :
Questo è un prodotto di classe A. In ambiente domestico, questo prodotto può causare
interferenze radio, nel qual caso può essere necessario che l'utente adotti misure adeguate.

5
Aviso :
Éste es un producto de clase A. En la instalación en una vivienda, este producto puede causar
interferencias de radio, en cuyo caso puede resultar necesario que el usuario tome medidas
pertinentes.
Waarschuwing :
Dit is een Klasse A product. In een huiselijke omgeving kan dit product radiostoring
veroorzaken, in welk geval de gebruiker verplicht kan zijn afdoende tegenmaatregelen te
nemen.
Advertência :
Este é um produto da classe A. Quando este produto for utilizado num ambiente doméstico,
poderá provocar interferências radiofónicas e, neste caso, pode ser necessário que o utilizador
tome as providências adequadas.
ﺮﻳﺬﺤﺗ :
اذــــه ﺞـــــﺗﻧﻣ صفﻧ أ. ﻲــﻓ فورــــظﻟا ﺔـــــــــﻳﻠﺣﻣﻟا، دـــﻗ بﺑـــﺳﻳ اذــــه ﺞــــــــﺗﻧﻣﻟا دـــﻗ بﺑـــﺳﻳ ﻞﺧادـــــﺗ يوــــــﻳدار ﻲـــﻓو ﻞـــﺛﻣ ﻩذـــه ﺔــــــــﻟﺎﺣﻟا ﻰــﻠﻋ مدﺧﺗـــــــــﺳﻣﻟا
ذﺎـــــــﺧﺗا رﻳﺑادــــــــــــﺗﻟا ﺔـــــــــﻣزﻼﻟا.

6
English
Read Me First
Introduction
Thank you for purchasing the JS-950 series Panasonic POS Workstation.
This manual describes the instructions for the POS Workstation.
Please read this manual carefully before using this product.
List of JS-950 series Product
Name Model Number. Remarks
JS-950WS-040 CPU:3.2GHz,Memory:512MＢor1GB
Main Unit POS Workstation JS-950WS-050 CPU:3.2GHz,Memory:2GB
JS-950D2R010 12” resistive Touch screen
JS-950D2C020 12” capacitive Touch screen
JS-950D5R010 15” resistive Touch screen
JS-950D5C010 15” capacitive Touch screen
Display
Unit Touch Display Unit
JS-950D5C020 15” capacitive Touch screen
JS-950H35010 3.5HDD moduleStorage
Unit Storage module Unit JS-950HCF010 Dual CF module
MSR Unit JS-950MG-010 Magnetic stripe reader module
Dallas Key Reader Unit JS-950DP-010 Dallas KEY Reader module
ID module
Unit Fingerprint Sensor Unit JS-950FS-010 Fingerprint Sensor module
JS-950RD-010 Rear Display module 2line
Rear Display Unit JS-950RD-020 Rear Display module 4line
JS-950SD-010 2nd Display module 8.4” resistive TP
Rear
Display
Unit 2nd Display Unit JS-950SD-020 2nd Display module 8.4” w/o TP
JS-950KT-UH0 AC cord kit UH
JS-950KT-UM0 AC cord kit UM
JS-950KT-A10 AC cord kit A
JS-950KT-E10 AC cord kit E
JS-950KT-F10 AC cord kit F
JS-950KT-K10 AC cord kit K
JS-950KT-W10 AC cord kit W
AC cord Kit AC cord kit
JS-950KT-Z10 AC cord kit Z

7
1. Getting Started
■Precautions
[POS Workstation: JS-950 series]
IMPORTANT
Install a socket outlet adjacent to the equipment so that it will be easily
accessible.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
1. Avoid Radio Frequency Interference
Do not place the POS Workstation near a television or radio receiver.
2. Avoid Stacking
Do not place heavy objects on the POS Workstation.
3. Keep Small Objects Away
Do not insert paper clips or other small objects into POS Workstation.
There is the risk of heat, fire or explosion.
4. Keep Dry
There is the risk of heat, fire or explosion.
5. Do Not Disassemble the POS Workstation
Do not attempt to disassemble the POS Workstation. There is the risk of heat, fire or
explosion.
6. Do Not Touch the Plug with Wet Hands.
There is the risk of electric shock.
7. Be Certain to Plug Fully Into the Outlet.
There is the risk of electric shock or fire.
8. When Unplugging, Make Sure to Hold the Body of the Plug.
If the power cord or outlet is damaged, there is a risk of electric shock, short circuit or fire.
9. Do Not Use a Damaged Power Cord or Plug.
There is the risk of electric shock or fire.
10. Clean the Dust off the Plug, Periodically.
There is the risk of heat or fire.
11. Do not use With Any Other Battery
Please use the specified battery.
CAUTION: Risk of explosion if battery is replced by an incorrect type.
Dispose of used batteries according to the instructions and local requirements.

8
12. Do not Touch the Power-cord or Plug During a Storm.
There is the risk of electric shock or fire.
13. Do not use the POS Workstation outdoors.
This product assumes the indoor use. There is the risk of breakdown.
14. Do not put the POS Workstation on a slope or an unstable place.
This can cause damage to the unit or injury by falling.
Note:
Do not open the Rear cover and Filter cover while the POS Workstation is operating.

9
■Name of each part & function
1. Operator’s Display
2. Front SW cover
3. POP Holder
4. Rear Display
5. USB connector
6. Power SW
Attention: Do not push Power SW by mistake when you insert the USB connector.
1
2 3
4
5
6

10
2. Operation
■AC Cord Kit Installation
1. How to install the AC Cord
(1) Carefully lay the Main Body Unit on a clear, flat surface as shown in figure (1).
(2) Unpack the AC Cord, and then connect it to AC Inlet as shown in figure (2).
(3) Fit the Cord Clamp to AC Cord, and fix it by attached screw as shown in figure (3)-1, 2 and
3.
(4) Carefully replace the Main Body Unit in upright position as shown in figure (4).
Note:
3 types of Clampers for fixing AC Cord are enclosed in Carton Box of Main Unit.
Select 1 type of Clamper according to diameter of AC Cord.
Confirm the AC Code doesn't move after fixing the AC Code with the clamper.
Standard Configuration List for AC Cord and Clamper
Model No. Clamper type
JS-950KT-UH0 PC-3 ø5.6
JS-950KT-UM0 PC-03C ø6.9
JS-950KT-A10 PC-3 ø5.6
JS-950KT-E10 PC-03C ø6.9
JS-950KT-F10 PC-03C ø6.9
JS-950KT-K10 PC-03C ø6.9
JS-950KT-W10 PC-03C ø6.9
JS-950KT-Z10 PC-03C ø6.9
(1) (2) (3)-1
(3)-2 (3)-3 (4)
AC Inlet

11
■Display Unit Installation
1. How to install the display unit
(1) Open the screw cover of the main unit (POS Workstation).
(2) Hold the display unit with both hands and insert the connector section of the display unit
into the connector inlet guide of the main unit slowly to connect the connector.
Note: When the connector section is connected, do not press the LCD surface of the
display unit.
(Failure to observe this may result in damage to functions of the LCD or touch panel.)
(3) Tighten the 2 thumbscrews of the main unit by hand to secure the display unit.
* Be sure to use hand when tightening the thumbscrews. Hold wire between the tips of
one’s first two fingers as shown in figure (3), and then tighten it.
* Make sure that no looseness is detected when trying to move the display unit.
(4) Close the screw cover of the main unit.
2. How to replace the display unit
(1) Place the main unit to make the display unit at right angle to the mounting table.
(2) Open the screw cover of the main unit.
(3) Loosen the 2 thumbscrews securing the display unit.
* The thumbscrews shall be loosened until the screws rotate without resistance.
(4) Hold the both sides of the display unit and pull out the unit slowly.
(5) Prepare a new display unit and perform replacement in accordance with the procedure 1,
“How to install the display unit”.
Be sure to disconnect the power cable of the main block (POS Workstation) and confirm the
power is “OFF” before the operation below.
(1) (2) (3)
(4)

12
■Storage Unit Installation
1. How to mount the storage unit
(1) Disconnect the 2 latches on the upper portion of the filter cover of the main unit by both
hands, pull the cover toward you while pressing the cover downward at the same time, and
remove the filter cover.
(2) Insert the storage unit into the prescribed inlet of the main unit slowly and connect the
connector of the main unit with the connector of the storage unit.
(3) Tighten the 2 thumbscrews supplied with the main unit by hand to secure the storage unit.
(4) Hitch the lower portion of the filter cover to the main unit, and push the cover until the
latches of both sides on the upper portion are connected to secure the cover.
2. How to replace the storage unit
(1) Place the main unit to make the display unit in parallel with the mounting table.
(2) Disconnect the 2 latches on the upper portion of the filter cover of the main unit by both
hands, pull the cover toward you while pressing the cover downward at the same time, and
remove the filter cover.
(3) Loosen the 2 thumbscrews securing the storage unit by hand, hold the band on the front
side of the storage unit and pull the band toward you slowly.
(4) Prepare a new storage unit.
Note: Exercise care to avoid any impact to the storage unit(s).
Be sure to disconnect the power cable of the main block (POS Workstation) and confirm the
power is “OFF” before the operation below.
(1) (2)
(3) (4)

13
■Rear Display Unit Installation
1. How to mount the rear display unit
(1) Loosen the thumbscrew on the lower portion of the rear cover at the rear display side of the
main unit by hand, and remove the rear cover.
* The thumbscrew shall be loosened until the screw rotates without resistance.
(2) Prepare a rear display to be used. (The contents here explain the 2-line type.)
(3) Connect the hook of the rear display to the hole of the main unit, and tighten the 2
thumbscrews by hand to secure it.
(4) Connect the connector of the rear display with the connector of the main unit.
* The cable connector has a clip to prevent the cable from coming out from the main unit.
(5) Gently press cable toward Display Unit so that it will not extend beyond the case.
In case of installation of 2 line Rear Display module, clamp the cable as shown in the fig.
(5)-1. In case of installation of 4 line Rear Display module, you do not need to clamp cable.
(6) Peel off the blind seal attached on the window of the rear cover.
(7) Attach the rear cover on the main unit, and tighten the thumbscrew on the lower portion by
hand to secure the cover.
Be sure to disconnect the power cable of the main block (POS Workstation) and confirm the
power is “OFF” before the operation below.
(4)－１
(1)-1 (1)-2 (2)
(5)-2
(5)-1 (7)
(3)-2 (4)
(3)-1

14
2. How to replace the rear display
(1) Loosen the thumbscrew on the lower portion of the rear cover of the main unit by hand,
and remove the rear cover.
* The thumbscrew shall be loosened until the screw rotates without resistance.
(2) Disconnect the connector of the rear display from the connector of the main unit.
(3) Loosen the 2 thumbscrews securing the rear display, and remove the rear display.
* The thumbscrews shall be loosened until the screws rotate without resistance.
(4) Prepare a new rear display.
(5) Follow the steps (3), (4) and (5) of “How to mount the rear display unit”.

15
■2nd display unit Installation
1. How to mount the 2nd Display Unit
(1) Loosen the thumbscrew on the lower portion of the rear cover at the rear display side of the
main block by hand, and remove the rear cover.
* The thumbscrew shall be loosened until the screw rotates without resistance.
(2) Prepare a 2nd display unit to be used. (The contents here explain the 950SD010 type.)
Confirm the wiring that VGA Cable and Speaker Cable are put along case of inside wall as
shown in the fig. (2).
(3) Connect the connector of the 2nd display with the connector of the main block as shown in
fig. (3).
(4) Attach the rear cover on the main block as shown in fig. (4)-1. And also, route the 2nd
display’s cable (950SD010has 2 cables) in the groove as shown in fig. (4)-2. Then, tighten
the thumbscrew on the lower portion by hand to secure the cover.
(5) In case of 950SD010, connect VGA cable and speaker cable to predefined I/F on I/O
panel.
(6) Stand-up correctly.
Be sure to disconnect the power cable of the main block (POS Workstation) and confirm the
power is “OFF” before the operation below.
(3)-2 (4)-1
(1)-2
(6)
(1)-1
(3)-1
(4)-2 (5) LINE OUT
(2)

16
2. How to replace the 2nd Display Unit
(1) In case of 950SD010, disconnect VGA cable and speaker cable from I/O panel.
(2) Loosen the thumbscrew on the lower portion of the rear cover of the main block by hand,
and remove the rear cover.
* The thumbscrew shall be loosened until the screw rotates without resistance.
(3) Disconnect the connector of the 2nd Display Unit from the connector of the main block.
(4) Prepare a new rear display.
(5) Follow the steps (3), (4) and (5) of “How to mount the 2nd Display Unit”.

17
■ID module Unit installation
1. Contents
2. How to mount the ID module unit (Please see the following pictures.)
(1) Place the main unit to make the display unit at right angle to the mounting table.
(2) Decide which side, right or left, of the display unit the ID module unit is mounted on.
(The contents here explain the case of the magnetic card reader mounting on the right
side.)
(3) Remove Display Unit. See Display Unit Installation.
(4) Remove the 2 screws on the rear side of the display unit using a screwdriver.
After removal of the screws, the peripheral screws can be removed from the front side of
the display unit.
(5) Slide the USB cable cover toward you while pushing both sides of the USB cable cover at
the hinge section of the display unit inward to remove the cover.
(6) Prepare an ID module unit to be mounted.
* The ID module unit is supplied with 2 pieces of peripheral screws, 2 pieces of screws, 1
piece of long cable cover, and 1 piece of short cable cover as accessories. And Dallas
KEY reader is supplied with cable clamp
(7) Handle the cable of the ID module unit (positioning and securing the cable).
・The guide channel is provided for cable positioning and securing inside the mounting
channel of the ID module unit.
・The cable shall be run under the ID module unit.
(8) Put the ID module unit in the position where the peripheral screws were removed on the
display unit.
(9) Cable cover has direction as shown in the fig. (9)-1. Insert salient portion of Cable cover to
concave portion of Display unit as shown in the fig. (9)-2 and (9)-3. Then completion
picture is fig. (9)-4.
(10) In case of the magnetic card reader and fingerprint sensor, connect the connector of the
display unit with the connector of those module units.
Secure the cable along the guide channel on the rear side of the display unit as shown in
the fig. (10)-1.
In case of the Dallas KEY reader, secure the cable along the guide channel on the rear
side of the display unit. And loosen a screw as shown in the fig. (10)-2. Use clamp to clip
the ground of USB cable and put it in the position where the screw of fixing LCD hinge
were removed on the LCD hinge. (10)-3.
Be sure to disconnect the power cable of the main block (POS Workstation) and confirm the
power is “OFF” before the operation below.
ID module 1pcs Peripheral screw
2pcs Screw 2pcs Cable cover
Long type 1pcs
Short type 1pcs
(Use only
Dallas KEY reader)
Cable clamp 1pcs

18
Tighten the screw to clamp the cable and wiring the cable as shown in the fig. (10)-4.
(11) Slide USB cable cover as shown in the fig. (11)-1. In case of Dallas KEY reader, slide the
USB cable cover with care to avoid the cable from the rib of the USB cable cover as shown
in the fig. (11)-2.
(12) Put the supplied 2 peripheral screws in from the front side of the ID module unit and tighten
the screws using a screwdriver from the rear side to secure it.
(13) Install Display Unit according to Display Unit Installation.
(1) (4)
(3)
(5) (7)
(6) Use only
Dallas KEY reader
(9)-3
(
10
)
-1
(9)-4
(8) (9)-2
(9)-1
Hinge cover side (salient)
(10)-2 (10)-4
(10)-3

19
3. How to replace the ID module unit
(1) Remove Display Unit according to Display Unit Installation.
(2) Prepare an ID module unit to be used.
* The ID module unit is supplied with 2 pieces of peripheral screws, 2 pieces of screws, 1
piece of long cable cover, and 1 piece of short cable cover as accessories.
(3) Slide the USB cable cover toward you while pushing both sides of the USB cable cover at
the hinge section of the display unit inward to remove the cover.
(4) Disconnect the connector of the ID module unit from the connector of the main unit, and
detach the cable from the guide channel.
(5) Remove the 2 screws on the rear side of the display unit using a screwdriver.
After removal of the screws, the peripheral screws can be removed from the front side of
the mounted ID module unit.
(6) Perform replacement in accordance with the procedure 1, “How to mount the ID module
unit”.
(11)-1 (11)-2
Rib
(12)
