ParaBody 822104 User manual

822104 ADJUSTABLE SIT-UP BENCH
ASSEMBLY INSTRUCTIONS
Part # 6797501 1 Revision:01/17/00

" ~ ~3/8 X 2-3/4."
FIGURE 2
STEP 2:
¯ Insert two 2" SQ. ENDCAPS(16) into the ends of the BASE(4) as shownin FIGURE
¯ SECURELYassemble the PAD(5) to the MAINPADSUPPORT(3) and BASE(4) using two 3/8" X 2-3/4"
(11), two 3/8" LOCKWASHERS(9), two 3/8" WASHERS(8), and 3/8" LOCKNUTS(10). See FI GURE
FIGURE 3
STEP 3:
¯ Apply eight 1-3/4 X 3/4" PARAGLIDES(18) to the INSIDEof the MAINPADSUPPORT(3) as shown
FIGURE3. (NOTE:Throughly clean the inside surface before attaching PARAGLIDES.)
¯ Securely assemb 1 e one SPPO-NGPIN AS SEMBLY(17) and one THUMBSCREW(14) to the MAIN
SUPPORT(3). See FIGURE
¯ Insert one 2" SQ. ENDCAP(16) into the end of the robe on the MAINPADSUPPORT(3) as shownin FIGURE
I 1/2 I 1/2 [ 1/2 I 1/2 I 1/2 I 1/2 I
3 4 I560 1 2 [ I l , I I I , I I I I l I
4

FIGURE 4
STEP4:
¯Slide the four ROLLERPADS(7) onto the MAINPADSUPPORT(3) using 3/4 X 16" TUBES (6), and four
STAKLOCKCOLLARS(13) as shown in FIGURE
FIGURE 5
STEP 5:
¯Pull back the SPRINGPIN and CAREFULLYslide the MAINPADSUPPORT(3) over the FRONtBASE
SUPPORT(1) as shownin FIGURE
¯Insert one 1-3/4" SQ. ENDCAP(15) into the ends of the FRONTBASESUPPORq[’(1) as shownin FIGURE
THIS CONCLUDESTHE ASSEMBLYOF THE 822104 ADJUSTABLESIT-UP BENCH
5

]KEY
1
2
3
!4
5
6
7
8
9
PART#
6522102
6483302
6522403
6522603
6666502
6125101
6194601
3102501
3102601
DESCRIPTION
FRONT BASE SUPPORT
TOBE
MAIN PAD SUPPORT
BASE~
PAD ASSEMBLY
3/4X 16" TUBE
ROLLERPAD
3/8" WASHER
3/8" LOCKWASHER
PARTSLIST
1
1
1
.1
1
2
2
6
2
KEY PART#
10 3102802
11 3102922
12 3102904
13 3105401
14 6145801
15 6236701
16 6405201
17 6412001
DESCRIFrlON
3/8" LOCKNUT
~8X2-3/4" BOLT
3/8 X 3" BOLT
ST~naRIX2C’KCOLLAR
1-i/4" SQ. ENDCAP
?.- SQ.ZNDCAP
SPR ;PIN ASSEMBLY
6416601 1-1/2 X3/4" PARAGIJDE(QTY8)
2
2
2
4
1
1
5
1
1
FIGURE1
STEP 1:
¯ Insert two 2" SQ. ENDCAPS(16) into the ends of the TUBE(2) as shownin FIGURE
¯SECURELYassemble the TUBE(2) to the FRONTBASESUPPORT(1) using two 3/8 X 3" BOLTS(12),
3/8" WASHERS(8), and two 3/8" LOCKNUTS (10). See FIGURE
3

] IMPORTANTNOTES]
WELCOMETO THEWORLDOF se,io.,,,’,ee,,
Please note:
* Thank you for purchasing the Parabody 822104 ADHUSTABLESIT-UPBENCH.
Please read these instructions thoroughlyandkeepthemfor future reference. Thisproduct
mustbe assembledona fiat, level surface to assure its properfunction.
* Werecommendcleaning your product (pads and frame) on a regular basis, using warmsoapy
water. Touch-uppaint can be purchasedfromyour Parabodycustomerservice representative
at [phone].
Thereis a risk assumedby individuals whouse this type of equipment.To.minimizerisk, please
followthese rules:
1. Inspect equipmentdaily. Tightenall loose connectionsandreplace wornparts immediately.
Failure to doso mayresult in serious injury.
2. Donot allow minorsor children to play on or aroundthis equipment.
3. Exercisewithcare to avoidinjury.
4. If unsureof properuseof equipment,call yourlocal Parabodydistributor or call the
Parabodycustomerservice departmentat [phone].
[Tools Required for Assembly]
* 9/16" wrench
* Ratchet with 9/16" socket
*Adjustable wrench
*Tape measure
Bolt Length Ruler ] -
NOTE: BOLT LENGTH IS MEASURED FROM THE UNDERSIDE OF TIlE HEAD OF THE BOLT.
, IIi!iiii~
BOLT LENGTH
BOLT LENGTH RULER:
1/2 I 1/2 ] 1/2 ] 1/2 ] 1/2 I 1/2 ~
65 I I I 4 I I I I
I I 1 I I
