INSTALLATION GUIDE OF DG-85 FOUR-ELEMENT
INTELLIGENT PIR INTRUSION DETECTOR
Lens
Walk-test LED
PIR
LED
Code switch
Sensitivity adjust
Figure 1.General View Figure 2.Inside View
2.Specifications
Top view
Side view
Connect terminals
Models:
Input Voltage 9-16VDC
Cyrrent Drain 30mA@ 12VDC
Detection Range 11.6m*11.6m
Alarm output NC.>100mA/28VDC
Anti white light resistance
>20000LUX
Installation height:2m-2.7m
Tamper switch NC.100mA/28VDC
DG-85
DG-85DMF
DG-85DMT
PIR Section:Lens Date
NO.of Curtain Beams (11+11+9)*2=62
Tripping Indication:
lndicator lights for about 10-30 seconds
Anti -EMI/RFI 10V/m 10MHz-1000MHz
Motion test 0.2m/s-3.5m/s(0.6ft-11ft)
Humidity 5%-95% RH
Accessories:
BR-1:Surface mounted swivel bracket,adjustable 30
down and 45 left/right.
Environmental:
Operating Temp: -10 C to 50 C(14 F to 122 F )
Storage Temp :-20 C to 60 C (-4 F to 40 F)
Physical
Size(H*W*D):176*85*69mm
3.Installation
3.1 General Guidelines
No direct facing cold
/hot source
No direct sun shine Keep away from high
pressure power
No facing metal wall Installation base
should be stable
1.Brief Introduction
DG-85 is a kind of PIR intrusion detector integrating the most
advanced security technology. It adopts 2 dual PIR sensors with
high accuracy, intelligent digi-tal chip, advanced ,<True Motion
Recognition & Anti-pests>of tware technology, which can help
it to make an accurate judgment of trueintruder or other interfer
-ence that can cause wrong alarm.And it is with function of auto
-matic memory of environmental change, which can avoid wro
-ng alarm a used by hot & cold air, opera-tion machine interfere
-nce. It can prevent effectively the interference cause by a 25 kg
past or 10 cats, insect, mouse, birds etc. Its super filter can be
used indoor and outdoor. This has clear various interference
that com-mon PIR detector can't overcome; and put an end to
wrong alarm and miss alarm .DG-85 has two different working
modes: bus mode and relay mode, can be used for all kinds of
control panels on the market.
This device is coherent to Europe parliament direct 1999/5/EC
necessary items and rules, and also coherent to the main spirits
of radio and telecom terminal equipments on March 9 . 1999.
The device also reaches the Canadian standard RSS-210. It can
be used indoor and outdoor, which can reach its maximum prote-
ction and avoidance of above interference.
th
3.2Anti-pests installation
Theupperpartofthe
detection area is non
anti-pests area
Never face the detector to
the place that pests can
climb up directly
20KgAnti-pests weight The installation height
of the detector is 2.2-2.4
meters can Anti-pests

Wall mounting
holes
Cable hole
Bracket mounting
holes
3.3Illustrated Installation Procedure
1 Open holes on base:
A.Mask the drilling
porints and drill in the
the wall.
B.Route the cables
into the base via the
rear channel.
C.Insert two nails and
arrach the base to the
wall with two screws.
D.Insert the bottom
edge of the large PCB
under this tab&press
the top edge in.
3 function of coding switch:
Corner mounting
holes
DG-85 has two different working modes:bus mode and relay mode,the mode choosing
can be conducted by DIP switch.
4 Setting of coding switch:
theswitch1ofDIP=OFF
When setting to the relay mode DG-85 transmits alarm and temper signal by relay as stan-
dard sensors, same as the figure, can be powered by contacted the power of panel and the
"RED","BLK" of the sensor,"GRN","YEL" unused, on relay mode, the setting only can
be amended by DIP switch and trim pot-ntiometer
Relay mode
Bus mode theswitch1ofDIP=ON
When setting to bus mode DG-85 transmits alarm, tamper signals and datas by bus,and set-
ting the sensor as well. On bus mode, DG-85 can be directly connected with control panel. sa-
me as the figure, can be pow-red by contacted the power of panel and the "RED","BLK" of
the sens-r,"GRN","YEL" connected with the correspondance terminals. On bus m-de,the set-
ting can be amended by DIP switch and trim potentiometer, also can by system keypad(shou-
ld be compated with system)get into programming mode.
Single or dual edge processing
This setting direct the DSP digital signal process working mode.Single side mode
is used the normal situation few of interference. Both sides process(out/in analysis)
mode can effectively reduce fault alarm. So, we recommend use this working mode
when the sensor in stallated near interfere resource.
LED setting
LED light 5 second when detected the energy of the moving signal can result alarm enough,
when the energy of the signal not enough, LED blink.
NC COM
Tamper
Alarm output
Power
DG-85 PCB
RED BLK GRN YEL TMP TMP
Communicate
bus
GRN AUX+ AUX-
YEL
ZONE 24H/ZONE
When relay mode,
these two wires not
connect
5 Sensitivity adjustment:
The trim potentiometer will turn bigger when turn clockwise, reverse result
when turn counter-colockwise 0.25s-2s
7. Motion test to protected area
The best operation height of DG-
85 is 2.1 meter, a little higher or
loweris also permitted. Confi
-rm the adjustable height mark o
-ntheright upside on cover tally
with the installation height.
If another installationheight is
needed, re-adjust the PCB in acc
-ordance with your needs. Mot
-ion test is necessarily required
inthe protection area in order
to confirm that areas need pro
-tection are within the prote-
ctive area.
6. PCB height setting
A. Install the cover, close the fastening position.
Guarantee that the front and back cover close
Tightly without any space or the looseness of
anti-water cover can't prevent humidity entering
into the parts.
B. Crossing to any direction of the detection area,
your walking will cause the LED indicator to
light for 2-3 seconds (refer to the right diagram)
C. Perform motion test from contrary directions
in order to confirm the boundary of two sides.
Make confirmed that detection center pointing to
the center of protected area.
Contral panel
2 Wire up the terminal block
Function
Bus mode Relay mode
Work mode
Digital signal process
LED
Tamper confirm
Invalid
Valid
Invalid
Valid
Invalid
Valid
Single side
Both sides
Relay
Bus
Unused
Unused
DIP switch1=OFF
DIP switch1=ON
DIP switch2=OFF
DIP switch2=ON
DIP switch3=ON
DIP switch3=OFF
Unused
Unused
Unused
Unused
001 1 =OFF
001 1 =ON
001 2 =OFF
001 2 =ON
001 3 =OFF
001 3 =ON
001 5 =ON
001 5 =OFF
002 001=010
Trim potentiometer 0 10
Sensitivity
Moving signal instruct
Even the most sophisticated detcetors can sometimes be defeated or may fail to warn due to :DC power failure/improper connection, malicious mask-
ing of the lens,tampering with the optical system, decreased sensitivity in ambient temperatures near that of the human body and unexpected fail-
ure of a component part.The above list includes the most common reasons for failure recommended that the detector and the entire alarm system be ch-
ecked weekly, to ensure proper performance.An alarm system should not be regarded as a substitute for insurance. Home & property owners or renters sh-
ouldbe prudent enough to continue insuring their lives & property, even though they are protected by an alarm system.
WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user s authority to operate the equipment.
This device has been tested and found to comply with the limits for a Class B digitaldevice, pursuant harmful interference in residential installations .This equipment
generates,uses and can radiate radio frequency energy and ,if not installed and used in accordance with the ins-tructions ,may cause harmful in-terference to radio and t-
elevision reception. However, there is no guarantee that interference will not occur in aparticular installation .If this device does cause such interference , which can be ver-
fied by turning the device off and on ,the user is encouraged to eliminate the interference by one or more of the followingmeasures:
- Increase the distance between the device and the receiver.
- Connect the device to an outlet on a circuit different from the one that supplies power to the receiver.
4.Special comments
P/N 20605002A00
