Operating Instructions
BP 805 271 BE (0209) 1
Angle Valve
electromagnetically actuated
with automatic voltage
adaptation 85 … 248 VAC
EVB 016 … 040 MA/MX

2BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
In all communications with Pfeiffer Vacuum, please specify the information given on
the product nameplate. For convenient reference copy that information into the
nameplate replica below.
Typ:
No:
F-No:
Pfeiffer Vacuum, D-35614 Asslar
Nominal voltage
This document applies to products with the following part numbers:
Aluminum housing
with FPM seals
Stainless steel housing
with FPM seals
Nominal diameter
PFA34505 PFA34535 DN 16 ISO–KF
PFA44505 PFA44535 DN 25 ISO–KF
PFA54505 PFA54535 DN 40 ISO–KF
The part number (No) can be taken from the product nameplate.
If not indicated otherwise in the legends, the illustrations in this document cor-
respond to the valve with the nominal diameter DN 25 ISO-KF. They apply to
valves with other nominal diameters by analogy.
We reserve the right to make technical changes without prior notice.
The electromagnetically actuated bellows sealed angle valves are used as shut-off
or venting devices in vacuum applications.
The angle valves are opened electromagnetically and closed by means of a
prestressed pressure spring. They close, or remain closed, on power loss.
The following trade marks and firms are the property of their respective owners:
Loctite®Loctite Corporation
Torx®Camcar/Textron, Inc.
All other trade marks or trade names are the property of their respective owners.
Product Identification
Validity
Intended Use
Functional Principle
Trade Marks

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 3
Contents
Product Identification 2
Validity 2
Intended Use 2
Functional Principle 2
Trade Marks 2
1 Description 4
1.1 Operating Modes 4
1.2 Indication of Positions and Faults 5
1.3 Position Indicator (in REMOTE mode only) 5
2 Safety 6
2.1 Symbols Used 6
2.2 General Safety Instructions 6
2.3 Liability and Warranty 6
3 Technical Data 8
4 Installation 10
4.1 Vacuum Connection 10
4.2 Electrical Connection 11
4.2.1 Removing the Cover 11
4.2.2 Setting the Operating Mode Selection Switch 12
4.2.3 Connecting the Feeder Line 13
4.2.4 Connecting the Control Cable (for REMOTE Mode Only) 14
4.2.5 Mounting the Cover 15
5 Operation 16
5.1 Signaling Behavior 16
5.2 Indication of Positions and Faults 16
6 Deinstallation 18
6.1 Electrical Connection 18
6.2 Vacuum Connection 19
7 Troubleshooting 20
8 Maintenance 21
9 Spare Parts 28
10 Returning the Product 30
11 Disposal 30
Declaration of Contamination 31

4BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
1 Description
The angle valve has two operating modes:
· REMOTE mode
Drive via control voltage 15 … 30 VDC.
· LOCAL mode
Drive via supply voltage 85 … 248 VAC.
The operating mode is selected by setting a switch (®212).
In the REMOTE mode, the supply voltage of 85 … 248 VAC is constantly fed. The
angle valve is opened and closed via the control contact (0 VDC).
a
b
c
d
PE
N
L
15 ... 30 VDC
Valve closed
Valve open
Control contact
0 VDC
85 ... 248 VAC
Customer's connection
Protective resistor
for 30 ... 60 VDC
4.7kW 100 mA
The angle valve is opened and closed directly via the supply voltage.
a
b
c
d
PE
N
L
Customer's connection
85 ... 248 VAC
1.1 Operating Modes
REMOTE mode
LOCAL mode

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 5
Green LED lit
Red LED lit
Red LED flashing
= valve open
= valve closed
= fault, for instance
a temperature overload
The integrated position indicator allows for polling the valve positions. In the event
of a fault, the signal "valve closed" is constantly fed.
a
b
c
d
PE
N
L
Protective resistor
for 30 ... 60 VDC
Valve closed
Valve open
Control contact
Customer's connection
15 ... 30 VDC
0 VDC
85 ... 248 VAC
4.7kW
100 mA
1.2 Indication of Positions
and Faults
1.3 Position Indicator
(in REMOTE mode only)

6BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
2 Safety
DANGER
Information on preventing any kind of physical injury.
WARNING
Information on preventing extensive equipment and environmental damage.
Caution
Information on correct handling or use. Disregard can lead to malfunctions or
minor equipment damage.
20 Dimensions in mm
®2See page ...
· Adhere to the applicable regulations and take the necessary precautions for the
process media used.
Consider possible reactions of the process media due to the heat generated by
the product (®29).
· Adhere to the applicable regulations and take the necessary precautions for all
work you are going to do and consider the safety instructions in this document.
· Before beginning to work, find out whether any vacuum components are con-
taminated. Adhere to the relevant regulations and take the necessary pre-
cautions when handling contaminated parts.
Communicate the safety instructions to all other users.
Pfeiffer Vacuum assumes no liability and the warranty becomes null and void if
end-users or third parties
· disregard the information in this document
· use the product in a non-conforming manner
· make any kind of changes (modifications, alterations etc.) to the product
· use the product with accessories and options not listed in the corresponding
product documentation.
The end-user assumes the responsibility in conjunction with the process media
used.
2.1 Symbols Used
2.2 General Safety
Instructions
2.3 Liability and Warranty

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 7
Notes

8BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
3 Technical Data
Connection flange DN 16 ISO-KF DN 25 ISO-KF DN 40 ISO-KF
Actuation opening: electromagnetically
closing: by pressure spring
Supply voltage
Frequency
Power consumption
85 … 248 VAC
50 / 60 Hz
400 W (max. upon switching on)
Pickup-/Holding power 405 / 8.1 W 416 / 8.3 W 367 / 7.5 W
Control voltage
Power consumption
15 … 30 VDC 1)
3 … 5 mA
Position indicator
switching voltage 2)
switching current 3)
15 … 30 VDC
100 mA
Type of protection
Protection class
IP 54 according to DIN 40 050
II
Cable diameter
feeder line
control cable
5 … 7 mm
5 … 7 mm
Installation angle
Flow direction
any
any
Cycle life 4) 2 million
Switching frequency
at 40 °C 5)
at 50 °C 5)
30 / min
20 / min
Opening time
Closing time
Dead time 6)
100 ms
240 ms
50 ms
120 ms
240 ms
170 ms
230 ms
700 ms
500 ms
Pressure range
Bursting pressure
1×10-8mbar … 1.3 bar (absolute)
3 bar (overpressure)
Pressure difference Dp
in closing direction
in opening direction
Opens to a pressure
difference Dp
1.3 bar
1.3 bar
1.3 bar
Ambient temperature 0 … 50 °C
Tightness 1×10-9mbar l/s
1) 30 … 60 VDC with serial resistor (RV= 4.7 kW, installation ®214)
2) Corresponds to the control voltage
3) Must be protected with a quick-acting 100 mA fuse provided by the end-user
4) Cycles without expendable parts (seals) and under clean operating conditions
5) Ambient temperature
6)
Dead time
Control-
signal Valve position
open
close
t
off
on
Opening time Closing time

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 9
Connection flange DN 16 ISO-KF DN 25 ISO-KF DN 40 ISO-KF
Conductance 7) 4 l/s 16 l/s 40 l/s
Materials
housing
inside section
seals
shell
aluminum (3.2374) or
stainless steel (1.4301)
1.4301 and 1.4541
FPM
PAGV 30
Weight
aluminum housing
stainless steel housing
1.3 kg
1.5 kg
2.2 kg
2.9 kg
4 kg
5.4 kg
7) For air with molecular flow
DN
DN
DN A B C D E F G
DN 16 ISO–KF 160 58 40 96 84.5 59 7.5
DN 25 ISO–KF 194 76 50 111 96.5 75 10
DN 40 ISO–KF 230 98 65 138 119.5 96 13.5
Dimensions in mm

10 BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
4 Installation
Skilled personnel
The vacuum connection may only be established by persons who have
suitable technical training and the necessary experience or who have
been instructed by the end-user of the product.
DANGER
Caution: overpressure in the vacuum system >1 bar
Injury caused by released parts and harm caused by escaping process
gases can result if clamps are opened while the vacuum system is
pressurized.
Do not open any clamps while the vacuum system is pressurized. Use
the type clamps which are suited to overpressure.
Caution
Caution: vacuum component
Dirt and damages impair the function of the vacuum component.
When handling vacuum components, take appropriate measures to
ensure cleanliness and prevent damages.
Caution
Caution: dirt sensitive area
Touching the product or parts thereof with one's bare hands increases
the desorption rate.
Always wear clean, lint-free gloves and use clean tools when working
in this area.
Keep the protective lids.
Remove the protective lids and install the valve to the vacuum system by means of
the small flange fittings.
Any installation angle and flow direction may be chosen.
Clamp
ISO-KF
connection
flange
Protective lid
Seal with
centering ring
4.1 Vacuum Connection
Procedure

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 11
Skilled personnel
The electrical connection, in accordance with the VDE 0100
guidelines, may be made only by a licensed electrician, qualified as per
VDE 0105. The line cables shall be isolated from the line supply during
all electrical work.
DANGER
Caution: mains voltage
Products that are not professionally connected to ground can be
hazardous in the event of a malfunction.
Connect the product according to the local regulations and ground it
correctly.
Caution
Caution: electrostatic fields
If the valve is installed in the vicinity of switched or electronically
controlled heavy electric loads, such as furnaces, heaters, motors or
RF generators, disturbances may occur.
Install a mains filter in the supply line of the valve.
Caution
Caution: high voltage tests
The valve is factory tested according to the DIN EN 60 204 standard.
Additional high voltage tests may destroy the valve.
Do not carry out any further high voltage tests.
Remove the clamp.
Remove the cover.
4.2 Electrical Connection
4.2.1 Removing the Cover

12 BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
The operating mode must be selected before the electrical connection is
established. If a 15 … 30 VDC control voltage is available, choose REMOTE.
a
b
c
d
PE
N
L
a
b
c
d
PE
N
L
15 ... 30 VDC
0 VDC
4.7kW
85 ... 248 VAC 85 ... 248 VAC
Valve closed
Valve open
Control contact
Customers' connection
Customer's connection
Control voltage
15 ... 30 VDC
available?
Yes No
LOCAL mode
Setting the operating mode switch
REMOTE mode
100 mA
Protective resistor
for 30 ... 60 VDC
4.2.2 Setting the Operating
Mode Selection Switch

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 13
Prepare the feeder line.
Caution
The cable must meet the following specifications:
· flexible
· conductor cross-section 1 mm2
· 3 poles with protective conductor (P+N+PE)
· 5 … 7 mm diameter
(for the cable feedthrough to meet the IP 54 specifications)
40
8
ø5...7
8
50
Connect the feeder line.
Pierce the cable
feedthrough.
Loosen the strain-
relief clamp and
introduce the cable.
Fasten the strain-
relief clamp.
Connect the conductors.
PE
LN
4.2.3 Connecting the Feeder
Line

14 BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
Prepare the control cable (for REMOTE mode only).
Caution
The cable must meet the following specifications:
· flexible
· conductor cross-section 0.75 mm2
· 4-pole with protective conductor
· 5 … 7 mm diameter
(for the cable feedthrough to meet the IP 54 specifications)
40
8
ø5...7
Connect the control cable.
b
c
d
a
PE
N
L
15 ... 30 VDC
0 VDC
4,7 kW
85 ... 248 VAC
100 mA
Valve open
Valve closed
Control contact
Customer's connection
Protective resistor
for 30 ... 60 VDC
Pierce the cable
feedthrough.
Loosen the strain-
relief clamp and
introduce the cable.
Fasten the strain
relief clamp.
4.2.4 Connecting the Control
Cable (for REMOTE Mode
Only)

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 15
Connect the conductors.
a
b
c
d
Mount the cover.
Caution
Be careful not to squeeze any cable leads.
Mount the clamp again.
4.2.5 Mounting the Cover

16 BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
5 Operation
The product is ready for operation as soon as it has been installed.
DANGER
Caution: bursting pressure
Overpressures >3 bar (e.g. in the event of an explosion) can cause the
inside section and housing to burst. This could result in injuries caused
by catapulted parts and health damages due to leaking process gases.
Protect the entire vacuum system against overpressures >3 bar.
0 V
248 V
0 V
24 V
0 V
24 V
0 V
24 V
0 V
248 V
Position indicator
"Valve closed"
REMOTE mode LOCAL mode
Supply voltage
Control contact ® 24
Position indicator
"Valve open"
Fault
(same contact as
"Valve closed")
Valve closed
Valve opening
Valve open
Fault
REMOTE mode LOCAL mode
red LED lit
both LEDs dark
green LED lit
red LED flashing
both LEDs dark
red LED lights up
briefly
green LED lit
red LED flashing
5.1 Signaling Behavior
5.2 Indication of Positions
and Faults

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 17
1×10-8mbar … 1.3 bar (absolute)
Caution
Caution: pressure difference Dp
bar p + Dp
Dp
bar
p
p
Closing direction
At Dp >1.3 bar the valve may no longer be tight.
Avoid pressure differences Dp >1.3 bar.
Caution
Caution: pressure difference Dp
bar
p
bar p + Dp
Dp
p
Opening direction
At Dp >1.3 bar the valve is opened.
Avoid pressure differences Dp >1.3 bar.
Caution
Caution: pressure difference Dp
p
bar p + Dp
Dp
bar
p
Opening
At Dp >1.3 bar the valve cannot open.
Avoid pressure differences Dp >1.3 bar.
Pressure range
Pressure difference Dp in
closing direction
Pressure difference Dp in
opening direction
Opening against a pressure
difference Dp

18 BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
6 Deinstallation
Skilled personnel
The electrical connection, in accordance with the VDE 0100 guide-
lines, may be made only by a licensed electrician, qualified as per
VDE 0105. The line cables shall be isolated from the line supply during
all electrical work.
DANGER
Caution: mains voltage
Touching live parts is hazardous.
Switch all mains and control voltage sources off and secure them
against inadvertent power-on before performing any electrical work on
the product.
Remove the cover (®211).
Disconnect the feeder line.
Disconnect the control cable (for REMOTE mode only).
Mount the cover (®215).
6.1 Electrical Connection
Procedure

BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi 19
Skilled personnel
The vacuum connection may only be disassembled by persons who
have suitable technical training and the necessary experience or who
have been instructed by the end-user of the product.
DANGER
Caution: contaminated parts
Contaminated parts can be detrimental to health and environment.
Before beginning to work, find out whether any parts are contaminated.
Adhere to the relevant regulations and take the necessary precautions
when handling contaminated parts.
Caution
Caution: vacuum component
Dirt and damages impair the function of the vacuum component.
When handling vacuum components, take appropriate measures to
ensure cleanliness and prevent damages.
Caution
Caution: dirt sensitive area
Touching the product or parts thereof with one's bare hands increases
the desorption rate.
Always wear clean, lint-free gloves and use clean tools when working
in this area.
Vent the vacuum system and disassemble the small flange connection. Place the
protective lids.
Centering ring
with O-ring
Clamp
Protective lid
ISO-KF
connection
flange
6.2 Vacuum Connection
Procedure

20 BP 805 271 BE (0209) EVB 016 … 040 MA/MX.oi
7 Troubleshooting
Valve leaks
Valve seat dirty or
gasket defective
Red LED flashing Valve does not
stay open
Position indicator
dirty
Valve actuator
blocked
Cool valve,
keep ambient tem-
perature < 50° C
or insulate valve
Replace
hoisting magnet
if necessary
Troubleshooting
Disassemble and clean the valve
(see section Maintenance)
Replace inside
section, gaskets
if necessary
Replace
electronics
if necessary
Temperature
overload
Ambient tempe-
rature too high
Problem
Cause
Remedy
Spare parts
® 228
