Pfeiffer Vacuum TPG 300 User manual

OPERATING INSTRUCTIONS
EN
Translation of the Original
PLUG-IN BOARDS
for total pressure measuring and control units TPG 300/TPG 500

Dear Customer,
Thank you for choosing a Pfeiffer Vacuum product. Your new total pressure measuring and
control unit should support you in your individual application with full performance and without
malfunctions. The name Pfeiffer Vacuum stands for high-quality vacuum technology, a
comprehensive and complete range of top-quality products and first-class service. From this
extensive, practical experience we have gained a large volume of information that can
contribute to efficient deployment and to your personal safety.
In the knowledge that our product must avoid consuming work output, we trust that our
product can offer you a solution that supports you in the effective and trouble-free
implementation of your individual application.
Please read these operating instructions before putting your product into operation for the
first time. If you have any questions or suggestions, please feel free to contact info@pfeiffer-
vacuum.de.
Further operating instructions from Pfeiffer Vacuum can be found in the Download Center on
our website.
Disclaimer of liability
These operating instructions describe all models and variants of your product. Note that your
product may not be equipped with all features described in this document. Pfeiffer Vacuum
constantly adapts its products to the latest state of the art without prior notice. Please take
into account that online operating instructions can deviate from the printed operating
instructions supplied with your product.
Furthermore, Pfeiffer Vacuum assumes no responsibility or liability for damage resulting from
the use of the product that contradicts its proper use or is explicitly defined as foreseeable
misuse.
Copyright
This document is the intellectual property of Pfeiffer Vacuum and all contents of this
document are protected by copyright. They may not be copied, altered, reproduced or
published without the prior written permission of Pfeiffer Vacuum.
We reserve the right to make changes to the technical data and information in this document.
2/48

Table of contents
1 About this manual 7
1.1 Validity 7
1.1.1 Applicable documents 7
1.1.2 Variants 7
1.2 Target group 8
1.3 Conventions 8
1.3.1 Instructions in the text 8
1.3.2 Pictographs 8
1.3.3 Abbreviations 8
1.4 Trademark proof 9
2 Safety 10
2.1 General safety information 10
2.2 Safety instructions 10
2.3 Safety precautions 11
2.4 Proper use 11
2.5 Foreseeable improper use 11
2.6 Responsibilities and warranty 12
2.7 Owner requirements 12
2.8 Personnel qualification 12
2.8.1 Ensuring personnel qualification 12
2.8.2 Personnel qualification for maintenance and repair 13
2.8.3 Advanced training with Pfeiffer Vacuum 13
2.9 Operator requirements 13
3 Product description 14
3.1 Function 14
3.1.1 Pirani measuring system 14
3.1.2 Cold cathode measuring system 14
3.2 Identifying the product 14
3.3 Structure of the plug-in boards 14
3.4 Interfaces 15
3.4.1 "OUTPUT" connection on PI 300 and CP 300 15
3.4.2 "CONTROL" connection on PE 300DC9 15
3.4.3 "RELAY" connection on IF 300A/C/P 16
3.4.4 "RELAY" connection on IF 300B 16
3.4.5 "RS-232" connection on IF 300A 17
3.4.6 "RS-232" connection on IF 300B 17
3.4.7 "RS-422" connection on IF 300C 18
3.4.8 "Profibus" connection on IF 300P 18
3.5 Scope of delivery 19
4 Transport and storage 20
4.1 Transporting the product 20
4.2 Storing the product 20
5 Installation 21
5.1 Installing/removing plug-in boards 21
5.2 Connecting gauges 21
5.2.1 Connecting Pirani gauges 21
5.2.2 Connecting the cold cathode gauge 22
5.3 Connecting interfaces and connections 23
5.3.1 Connecting the analog signal to the measurement boards 23
5.3.2 Connecting relays to the interface boards 23
5.3.3 Connecting the "RS-232-C" interface of the IF 300A 24
5.3.4 Connecting the "RS-232-C" interface of the IF 300B 24
Table of contents
3/48

5.3.5 Connecting the "RS-422" interface of the IF 300C 24
5.3.6 Connecting the "Profibus-DP" interface on the IF 300P 25
6 Calibrating the Pirani measuring circuit 26
7 Malfunctions 27
8 Shipping 29
9 Recycling and disposal 30
9.1 General disposal information 30
9.2 Disposing of plug-in boards 30
10 Service solutions by Pfeiffer Vacuum 31
11 Accessories 33
11.1 Accessory information 33
11.2 Ordering accessories 33
12 Technical data and dimensions 37
12.1 Technical data 37
12.2 Dimensions 41
13 Appendix 43
13.1 Relation: measuring signal and pressure 43
13.2 Gas type dependence 44
13.3 Units of pressure 46
13.4 Gas throughputs 46
Table of contents
4/48

List of tables
Tbl. 1: Applicable documents 7
Tbl. 2: Variants 7
Tbl. 3: Abbreviations used 9
Tbl. 4: Switch functions on IF 300A/C/P 16
Tbl. 5: Switching functions on IF 300B 17
Tbl. 6: Disturbances during installation 27
Tbl. 7: Interference during operation and calibration 27
Tbl. 8: Disturbances as a result of defects 27
Tbl. 9: Disturbances with the RS-232-C interface 28
Tbl. 10: Disturbances with the RS-422 interface 28
Tbl. 11: Disturbances with the Profibus-DP interface 28
Tbl. 12: Pirani gauges 33
Tbl. 13: Cold cathode gauges 34
Tbl. 14: Measuring cable for TPR 010 34
Tbl. 15: Measuring cable for TPR 017 and TPR 018 35
Tbl. 16: Extension cable for TPR 010, TPR 017 and TPR 018 35
Tbl. 17: Measuring cable for IKR 050 and IKR 060 35
Tbl. 18: Measuring cable for IKR 070 36
Tbl. 19: Plugs and interface cable 36
Tbl. 20: Dummy plates 36
Tbl. 21: Technical data PI 300D / PI 300DN 37
Tbl. 22: Technical data PE 300DC9 37
Tbl. 23: Technical data CP 300C9/C10/T11/T11L 39
Tbl. 24: Technical data IF 300A 39
Tbl. 25: Technical data IF 300B 40
Tbl. 26: Technical data IF 300C 40
Tbl. 27: Technical data IF 300P 41
Tbl. 28: Units of pressure and their conversion 46
Tbl. 29: Gas throughputs and their conversion 46
List of tables
5/48

List of figures
Fig. 1: "OUTPUT" connection with 2 sockets 15
Fig. 2: "CONTROL" connection on PE 300DC9 15
Fig. 3: Switch and logic on the "CONTROL" connection 15
Fig. 4: "RELAY" connection on IF 300A/C/P 16
Fig. 5: "RELAY" connection on IF 300B 16
Fig. 6: "RS-232" connection on IF 300A 17
Fig. 7: "RS-232" connection on IF 300B 17
Fig. 8: "RS-422" connection on IF 300C 18
Fig. 9: "Profibus" connection on IF 300P 19
Fig. 10: Coax cable and triax cable 22
Fig. 11: Locking the triax plug 23
Fig. 12: Folding ferrite for IF 300B 23
Fig. 13: Connecting the interface cable to IF 300B 24
Fig. 14: ATM and HIGH VAC trimming potentiometers 26
Fig. 15: Pirani measuring cable connection diagram 34
Fig. 16: Pirani extension cable connection diagram 34
Fig. 17: Dimensions of measurement boards 41
Fig. 18: Dimensions of interface and relay boards 42
Fig. 19: Relation: Measuring signal and pressure with TPR gauges 43
Fig. 20: Relation: Measuring signal and pressure with IKR gauges 44
Fig. 21: Displayed pressure for TPR gauges 45
Fig. 22: Displayed pressure for IKR gauges 45
List of figures
6/48

1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
This document describes the function of the products listed in the following and provides the most im-
portant information for safe use. The description is written in accordance with the valid directives. The
information in this document refers to the current development status of the products. The document
retains its validity assuming that the customer does not make any changes to the product.
1.1.1 Applicable documents
Designation Document
Operating instructions "Total pressure measuring and control unit"
TPG 300
BG 5970
Operating instructions "Total pressure measuring and control unit"
TPG 500
BG 6008
Communication protocol "Total pressure measuring and control unit"
TPG 300
BG 5973
Communication protocol "Total pressure measuring and control unit"
TPG 500
BG 6009
“Gauges” operating instructions
ModulLine gauges
(depending on the gauge
used)
Tbl. 1: Applicable documents
You can find these documents in the Pfeiffer Vacuum Download Center.
1.1.2 Variants
This document applies to the products with the following part numbers:
Part number Type Designation
PT 546 920-T Measurement board (Pirani) PI 300D
PT 549 214-T PI 300DN
PT 441 375-T Measurement board (cold cathode) PE 300DC9
PT 441 000-T Measurement board (Pirani/cold cathode) CP 300C9
PT 441 114-T CP 300C10
PT 441 080-T CP 300T11
PT 441 120-T CP 300T11L
PT 441 130-T Interface and relay board (RS-232-C) IF 300A
PT 441 250-T IF 300B
PT 441 390-T Interface and relay board (RS-422) IF 300C
PT 441 395-T Interface and relay board (Profibus) IF 300P
Tbl. 2: Variants
You can find the part number on the rating plate of the product.
Pfeiffer Vacuum reserves the right to make technical changes without prior notification.
The figures in this document are not to scale (dimensions in mm).
About this manual
7/48

1.2 Target group
These operating instructions are aimed at all persons performing the following activities on the product:
●Transportation
●Setup (Installation)
●Usage and operation
●Decommissioning
●Maintenance and cleaning
●Storage or disposal
The work described in this document is only permitted to be performed by persons with the appropriate
technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac-
uum.
1.3 Conventions
1.3.1 Instructions in the text
Usage instructions in the document follow a general structure that is complete in itself. The required ac-
tion is indicated by an individual step or multi-part action steps.
Individual action step
A horizontal, solid triangle indicates the only step in an action.
►This is an individual action step.
Sequence of multi-part action steps
The numerical list indicates an action with multiple necessary steps.
1. Step 1
2. Step 2
3. ...
1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Abbreviations
Abbreviation Explanation
ASCII American Standard Code for Information Interchange
ATM Atmosphere
CNTR-P Repeater direction control signal (Profibus)
ESD Electrostatic Discharge
IF Interface
GND Ground
HV High vacuum
MHV Miniature High Voltage
(coax high voltage connector in miniature design)
NN Mean sea level
PE Penning
Profibus DP Profibus distributed periphery
About this manual
8/48

Abbreviation Explanation
RS-232 Recommended Standard 232
(Standard for a serial interface often available on computers)
RS-422 Recommended Standard 422
(Interface standard for a wired differential serial data transfer)
RxD Received eXchange Data (incoming data line)
SHV Safe High Voltage (connector for coax cable)
TPG Total Pressure Gauge (total pressure measuring and control unit)
TxD Transmitted eXchange Data (outgoing data line)
Tbl. 3: Abbreviations used
1.4 Trademark proof
●Profibus® is a registered trading name of Profibus Nutzerorganisation e.V.
About this manual
9/48

2 Safety
2.1 General safety information
The following 4 risk levels and 1 information level are taken into account in this document.
DANGER
Immediately pending danger
Indicates an immediately pending danger that will result in death or serious injury if not observed.
►Instructions to avoid the danger situation
WARNING
Potential pending danger
Indicates a pending danger that could result in death or serious injury if not observed.
►Instructions to avoid the danger situation
CAUTION
Potential pending danger
Indicates a pending danger that could result in minor injuries if not observed.
►Instructions to avoid the danger situation
NOTICE
Danger of damage to property
Is used to highlight actions that are not associated with personal injury.
►Instructions to avoid damage to property
Notes, tips or examples indicate important information about the product or about this docu-
ment.
2.2 Safety instructions
Safety instructions according to product’s life stages
All safety instructions in this document are based on the results of a risk assessment.
Pfeiffer Vacuum has taken into account all the relevant life stages of the product.
Risks during installation
DANGER
Danger to life due to dangerous contact voltage
Voltages above 30 V (AC) or 60 V (DC) are considered dangerous in accordance with EN 61010. If
you come into contact with dangerous contact voltage, this can result in injury through electric shocks
or even death.
►Only connect the gauge to professionally grounded devices.
►Take additional safety measures on the system-side if processes in the vacuum system (e.g.
flashovers) can result in dangerous voltages at the gauge connections.
►Secure the line to the gauge.
Safety
10/48

Risks during disposal
WARNING
Health hazard through poisoning from toxic contaminated components or devices
Toxic process media result in contamination of devices or parts of them. During maintenance work,
there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub-
stances causes environmental damage.
►Take suitable safety precautions and prevent health hazards or environmental pollution by toxic
process media.
►Decontaminate affected parts before carrying out maintenance work.
►Wear protective equipment.
2.3 Safety precautions
The product is designed according to the latest technology and recognized safety engineering rules.
Nevertheless, improper use can result in danger to operator all third party life and limb, and product
damage and additional property damage.
Duty to provide information on potential dangers
The product holder or user is obliged to make all operating personnel aware of dangers
posed by this product.
Every person who is involved in the installation, operation or maintenance of the product
must read, understand and adhere to the safety-related parts of this document.
Infringement of conformity due to modifications to the product
The Declaration of Conformity from the manufacturer is no longer valid if the operator
changes the original product or installs additional equipment.
●Following the installation into a system, the operator is required to check and re-evalu-
ate the conformity of the overall system in the context of the relevant European Direc-
tives, before commissioning that system.
General safety precautions when handling the product
►When handling the gases and contaminated parts used, observe the applicable guidelines.
►Observe the protective measures.
►Observe the safety guidelines specified in this document.
–All work is only permissible when observing the relevant guidelines and adhering to the pro-
tective measures.
►Inform yourself about any contamination before starting work.
►Pass on safety instructions to all other users.
2.4 Proper use
The plug-in boards are analog measuring, interface and relay boards for the ModulLine total pressure
measuring and control units TPG 300 and TPG 500.
►Install, operate and maintain the product only in accordance with these operating instructions.
►Comply with the application limits.
►Observe the technical data.
2.5 Foreseeable improper use
Improper use of the product invalidates all warranty and liability claims. Any use that is counter to the
purpose of the product, whether intentional or unintentional, is regarded as misuse, in particular:
●Use outside the mechanical and electrical application limits in accordance with the technical data
●Use with corrosive or explosive media, if this is not explicitly permitted
●Use outdoors
●Use after technical changes (on the inside or the outside of the product)
●Use with replacement or accessory parts that are unsuitable or are not approved
Safety
11/48

2.6 Responsibilities and warranty
Pfeiffer Vacuum shall assume no responsibilities and warranty if the operating company or a third party:
●disregards this document.
●does not use the product for its intended purpose.
●carries out any modifications to the product (conversions, changes, maintenance work, etc.) that
are not listed in the corresponding operating instructions.
●operates the product with accessories that are not listed in the corresponding operating instruc-
tions.
The operator is responsible for the process media used.
2.7 Owner requirements
Safety-conscious working
1. Only operate the product in a technically flawless state.
2. Operate the product in line with its intended purpose, safety and hazard-conscious and only in
compliance with these operating instructions.
3. Fulfill the following instructions and monitor the observation of the following instructions:
–Proper use
–Generally applicable safety instructions and accident prevention regulations
–International, national and locally applicable standards and guidelines
–Additional product-related guidelines and regulations
4. Only use original parts or parts approved by Pfeiffer Vacuum.
5. Keep the operating instructions available at the place of installation.
6. Ensure personnel qualification.
2.8 Personnel qualification
The work described in this document may only be carried out by persons who have appropriate profes-
sional qualifications and the necessary experience or who have completed the necessary training as
provided by Pfeiffer Vacuum.
Training people
1. Train the technical personnel on the product.
2. Only let personnel to be trained work with and on the product when under the supervision of
trained personnel.
3. Only allow trained technical personnel to work with the product.
4. Before starting work, make sure that the commissioned personnel have read and understood
these operating instructions and all applicable documents, in particular the safety, maintenance
and repair information.
2.8.1 Ensuring personnel qualification
Specialist for mechanical work
Only a trained specialist may carry out mechanical work. Within the meaning of this document, special-
ists are people responsible for construction, mechanical installation, troubleshooting and maintenance
of the product, and who have the following qualifications:
●Qualification in the mechanical field in accordance with nationally applicable regulations
●Knowledge of this documentation
Specialist for electrotechnical work
Only a trained electrician may carry out electrical engineering work. Within the meaning of this docu-
ment, electricians are people responsible for electrical installation, commissioning, troubleshooting, and
maintenance of the product, and who have the following qualifications:
●Qualification in the electrical engineering field in accordance with nationally applicable regulations
●Knowledge of this documentation
In addition, these individuals must be familiar with applicable safety regulations and laws, as well as the
other standards, guidelines, and laws referred to in this documentation. The above individuals must
have an explicitly granted operational authorization to commission, program, configure, mark, and earth
devices, systems, and circuits in accordance with safety technology standards.
Safety
12/48

Trained individuals
Only adequately trained individuals may carry out all works in other transport, storage, operation and
disposal fields. Such training must ensure that individuals are capable of carrying out the required activi-
ties and work steps safely and properly.
2.8.2 Personnel qualification for maintenance and repair
Advanced training courses
Pfeiffer Vacuum offers advanced training courses to maintenance levels 2 and 3.
Adequately trained individuals are:
●Maintenance level 1
─Customer (trained specialist)
●Maintenance level 2
─Customer with technical education
─Pfeiffer Vacuum service technician
●Maintenance level 3
─Customer with Pfeiffer Vacuum service training
─Pfeiffer Vacuum service technician
2.8.3 Advanced training with Pfeiffer Vacuum
For optimal and trouble-free use of this product, Pfeiffer Vacuum offers a comprehensive range of
courses and technical trainings.
For more information, please contact Pfeiffer Vacuum technical training.
2.9 Operator requirements
Observing relevant documents and data
1. Read, observe and follow this operating instruction and the work instructions prepared by the op-
erating company, in particular the safety and warning instructions.
2. Install, operate and maintain the product only in accordance with these operating instructions.
3. Carry out all work only on the basis of the complete operating instructions and applicable docu-
ments.
4. Comply with the application limits.
5. Observe the technical data.
6. Please contact the Pfeiffer Vacuum Service Center if your questions on operation or maintenance
of the product are not answered by these operating instructions.
–You can find information in the Pfeiffer Vacuum service area.
Safety
13/48

3 Product description
3.1 Function
3.1.1 Pirani measuring system
Within certain limits, the heat conductivity of gases depends on the pressure. This physical occurrence
is utilized in the Pirani thermal conductivity vacuum gauge to measure the pressure. A thin wolfram wire
with high temperature coefficients is used as the measuring element. With a suitable control circuit, the
resistance of the wire and thus its temperature are kept constant. The electrical power that is fed to the
wire is a measure for the heat power dissipated in the gas through heat conduction and therefore a
measure of the pressure.
3.1.2 Cold cathode measuring system
The current that flows into a self-sustaining gas discharge with cold cathode (similar to Penning) de-
pends on the applied voltage, the composition of the gas and the pressure. A magnetic field penetrates
into the measuring room that causes the electrons on the spiral trajectories to move from the cathode
towards the anode, and as a result perform a sufficient number of ionizing impacts to maintain the dis-
charge, even with low gas density. If the anode voltage and magnetic field are now kept constant (with
known gas type), the discharge current is a measure for the pressure.
3.2 Identifying the product
You will need all the data from the rating plate to safely identify the product when communicating with
Pfeiffer Vacuum.
1. Read the data on the product rating plate.
2. Record this data.
3. Always have all rating plate specifications to hand.
3.3 Structure of the plug-in boards
Pirani measurement boards
When the total pressure measuring and control unit is switched on, the Pirani measuring circuits are al-
ways in operation. The analog signals are always available, irrespective of the pressure display.
Pirani measurement boards have:
●2 independent fine vacuum measuring circuits, each with
─1 gauge power supply plug
─2 calibration potentiometers
─1 analog signal output
Cold cathode measurement boards
When the gauge is switched on, the analog signals are always available, irrespective of the pressure
display. This measurement board has special electronics that limit the measurement current to 100 μA.
This results in a considerably longer service life for the gauges.
Cold cathode measurement boards for high vacuum have:
●2 measuring circuits, each with
─1 gauge power supply plug
─1 analog signal output
Pirani/cold cathode measurement boards
The properties of these measurement boards correspond with the Pirani and cold cathode measure-
ment boards. The measurement boards for the range 10-10 hPa (CP 300C10) and 10-11 hPa (CP
300T11 and CP 300T11L) have special electronics that limit the measurement current to 100 μA. This
results in a considerably longer service life for the gauges.
Pirani/cold cathode measurement boards have:
●1 Pirani measuring circuit
●1 cold cathode measuring circuit
Product description
14/48

Interfaces and relay boards
There are 4 types of interface and relay boards:
●2 with RS-232-C interfaces
●1 with RS-422 interface
●1 with Profibus-DP interface
All 4 types each have 5 relays with potential-free switching contacts. The types each have a different
switching voltage for the relays and different interface connections.
3.4 Interfaces
3.4.1 "OUTPUT" connection on PI 300 and CP 300
Each measuring circuit has an analog signal output. Suitable plugs are included with each measure-
ment board.
OUTPUT
0 ... 10 V
–+
Fig. 1: "OUTPUT" connection with 2 sockets
3.4.2 "CONTROL" connection on PE 300DC9
Each measuring circuit has a control input as well as an analog signal output. A suitable plug is included
with each measurement board.
4
5
1
2
3
6
7
Screen
Fig. 2: "CONTROL" connection on PE 300DC9
1 Analog GND IKR 1 5 IKR ON 2
2 Digital GND 6 Analog Output
3 Analog GND 7 Analog Output
4 IKR ON 1 Gehäuse Screen
2
4, 5
2
4, 5
Fig. 3: Switch and logic on the "CONTROL" connection
Switching the measuring circuit on or off externally (PE 300DC9)
1. First switch the gauge on manually or automatically if you want to control the gauge via the exter-
nal input.
2. Switch the measuring circuit on or off using one of the three options.
●manual
●automatic
●external, via a contact on the "CONTROL" connection
Product description
15/48

3.4.3 "RELAY" connection on IF 300A/C/P
1
9
15 8
Screen
Pin
1
2
9
3
11
10
12
5
4
6
14
13
8
15
7
Fig. 4: "RELAY" connection on IF 300A/C/P
The figure shows the contacts in rest position.
Pins Designation Switching function
15 8 7 Relay 1 1
14 6 13 Relay 2 2
5 12 4 Relay 3 3
11 3 10 Relay 4 4
2 1 9 Relay 5 Error status
Tbl. 4: Switch functions on IF 300A/C/P
3.4.4 "RELAY" connection on IF 300B
32
28
30
26
22
24
20
16
18
14
10
12
8
4
6
IF 300B
30
32
26
22
18
14
10
6
28
24
20
16
12
8
4
Fig. 5: "RELAY" connection on IF 300B
The figure shows the contacts in rest position.
Pins Designation Switching function
4 8 6 Relay 1 1
10 14 12 Relay 2 2
16 20 18 Relay 3 3
Product description
16/48

Pins Designation Switching function
22 26 24 Relay 4 4
28 32 30 Relay 5 Error status
Tbl. 5: Switching functions on IF 300B
3.4.5 "RS-232" connection on IF 300A
RXD
TXD
61
5
9
2
3
7
IF 300A
3
2
7
2
3
7
CTS
RTS
TXD
S GND
RXD
Screen
S GND
DSR
DTR
CCD
5
4
6
20
8
Computer
Fig. 6: "RS-232" connection on IF 300A
2 Receive data (RxD)
(relating to the measuring device)
7 Signal ground (S GND)
3 Transmit data (TxD)
(relating to the measuring device)
3.4.6 "RS-232" connection on IF 300B
RXD
TXD
2
3
7
IF 300B
3
2
7
2
3
7
CTS
RTS
TXD
S GND
RXD
Screen
S GND
DSR
DTR
CCD
5
4
6
20
8
Computer
14
113
25
Fig. 7: "RS-232" connection on IF 300B
2 Receive data (RxD)
(relating to the measuring device)
7 Signal ground (S GND)
3 Transmit data (TxD)
(relating to the measuring device)
Product description
17/48

3.4.7 "RS-422" connection on IF 300C
5
1
6
IF 300C
8
7
9
95
1
6
TX+
RX–
8
7
9
Screen
TX–
S GND
P GND
6
5
1
RX+
Fig. 8: "RS-422" connection on IF 300C
1 Protective ground (P GND) 7 Reception data (Rx-)
(relating to the measuring device)
2, 3, 4 unassigned 8 Transmission data (Tx+)
(relating to the measuring device)
5 Signal ground (S GND) 9 Transmission data (Tx)-
(relating to the measuring device)
6 Reception data (Rx+)
(relating to the measuring device)
Screen Screen
3.4.8 "Profibus" connection on IF 300P
Details on the Profibus-DP interface
You can find details on the Profibus-DP interface in the corresponding communication pro-
tocol.
Product description
18/48

IF 300P
5
9
61
8
9
6
7
4
5
2
3
1
Pin
Fig. 9: "Profibus" connection on IF 300P
1 Screen 6 VP (only required with bus end devices)
2 Do not connect 7 Do not connect
3 RxD/TxD-P (Line B) 8 RxD/TxD-N (Line A)
4 CNTR-P (optional) 9 Do not connect
5 DGND
3.5 Scope of delivery
The shipment includes the following parts:
●Plug-in board
●Plugs for analog signals
●Folding ferrite (for IF 300B)
●Operating instructions
Unpacking the product and checking completeness of the shipment
1. Unpack the product.
2. Remove the transport fasteners, transport protection etc.
3. Store the transport fasteners, transport protection etc. in a safe place.
4. Check that the shipment is complete.
5. Ensure that no parts are damaged.
Product description
19/48

4 Transport and storage
4.1 Transporting the product
NOTICE
Damage caused by incorrect transportation
Transportation in unsuitable packaging, or failure to install all transport locks, can damage the prod-
uct.
►Comply with the instructions for safe transportation.
Packing
We recommend keeping the transport packaging and original protective cover.
General information regarding safe transport
►Observe the weight specified on the transport packaging.
►Where possible, always transport or ship the product in the original transport packaging.
►Always use dense and impact-proof transport packaging for the product.
►Remove the existing protective cover and transport protections only immediately prior to installa-
tion.
►Reattach transport locks and transport protections prior to each transport.
4.2 Storing the product
NOTICE
Damage caused by improper storage
Improper storage will lead to damage to the product.
Static charging, moisture, etc. lead to defects on the electronic components.
►Comply with the instructions for safe storage.
Packing
We recommend storing the product in its original packaging.
General information for safe storage
►Store the product in a cool, dry, dust-free place, where it is protected against impacts and me-
chanical vibration.
►Always use dense and impact-proof packaging for the product.
►Where possible, store the product in its original packaging.
►Store electronic components in antistatic packaging.
►Maintain the permissible storage temperature.
►Avoid extreme fluctuations of the ambient temperature.
►Avoid high air humidity.
►Seal connections with the original protective caps.
►Protect the product with the original transport protection (where available).
Transport and storage
20/48
