1 About this manual
IMPORTANT
Read carefully before use.
Keep the manual for future consultation.
1.1 Validity
This operating instructions is a customer document of Pfeiffer Vacuum. The operating instructions de-
scribe the functions of the named product and provide the most important information for the safe use of
the device. The description is written in accordance with the valid directives. The information in this op-
erating instructions refers to the product's current development status. The document shall remain valid
provided that the customer does not make any changes to the product.
1.1.1 Applicable documents
OmniControl control unit Number
Gauge/IO option operating instructions PT 0687 BN
Data option operating instructions PT 0688 BN
Declaration of conformity Part of this document
You can find these documents in the Pfeiffer Vacuum Download Center.
1.1.2 Variants
These instructions apply to control units with the following type designations:
●OmniControl 200, rack unit with integrated power supply pack
●OmniControl 300, rack unit with integrated power supply pack
●OmniControl 400, rack unit with integrated power supply pack
●OmniControl 001, rack unit without integrated power supply pack
●OmniControl 001 Mobile, handheld device without integrated power supply pack
1.2 Target group
These operating instructions are aimed at all persons performing the following activities on the product:
●Transportation
●Setup (Installation)
●Usage and operation
●Decommissioning
●Maintenance and cleaning
●Storage or disposal
The work described in this document is only permitted to be performed by persons with the appropriate
technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac-
uum.
1.3 Conventions
1.3.1 Instructions in the text
Usage instructions in the document follow a general structure that is complete in itself. The required ac-
tion is indicated by an individual step or multi-part action steps.
Individual action step
A horizontal, solid triangle indicates the only step in an action.
►This is an individual action step.
About this manual
7/48

Sequence of multi-part action steps
The numerical list indicates an action with multiple necessary steps.
1. Step 1
2. Step 2
3. ...
1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Stickers on the product
This section describes all the stickers on the product along with their meanings.
Rating plate (example)
Rating plates of the devices are affixed to the housing where they
can be clearly seen.
CUS
Safety approved
USA CAN
TÜV Rheinland
Test seal
The test seal provides information regarding additional certifica-
tions.
Warning hot surface
This sticker warns of injuries caused by high temperatures as a re-
sult of contact without protection during operation.
Tbl. 1: Stickers on the product
1
2
3
Fig. 1: Position of the stickers on the product
1 TÜV test seal 3 Rating plate
2 Hot surface warning sign
1.3.4 Abbreviations
Abbreviation Meaning in this document
µSD microSD
AC Alternating Current voltage
About this manual
8/48

Abbreviation Meaning in this document
APR Piezo gauge
AR Analog output with two switch-points
AWG American Wire Gauge
CCT Capacitive gauge
CMR Capacitive gauge
CPT Piezo-resistive gauge
DC Direct Current voltage
DCU Display Control Unit
FCR Fluorocarbon rubber
HPT Pirani/Bayard-Alpert combination
HPU Handheld Programming Unit (aid for controlling and monitoring pump parameters)
IKR Cold cathode gauge
IMR Hot cathode gauge
IO Input Output (in out)
LED Light emitting diode
MPT Pirani/Cold cathode combination
PBR Hot cathode gauge
PCR Pirani/capacitive gauge
PE Protective earth (earthed conductor)
PKR Pirani/cold cathode transmitter
PPT Pirani transmitter
[P:xxx] Electronic drive unit control parameters. Printed in bold as a three-digit number in
square brackets. Frequently displayed in conjunction with a short description.
Example: [P:312] software version
RPT Piezo/Pirani combination
RS-485 Standard for a physical interface for asynchronous serial data transmission (recom-
mended standard)
S1 Switch on power supply pack
TTemperature (in °C)
TC Turbopump electronic drive unit (turbo controller)
TM Drive and magnetic bearing electronics
TPR Pirani gauge
USB Universal serial bus
Tbl. 2: Abbreviations used in this document
About this manual
9/48

2 Safety
2.1 General safety information
The following 4 risk levels and 1 information level are taken into account in this document.
DANGER
Immediately pending danger
Indicates an immediately pending danger that will result in death or serious injury if not observed.
►Instructions to avoid the danger situation
WARNING
Potential pending danger
Indicates a pending danger that could result in death or serious injury if not observed.
►Instructions to avoid the danger situation
CAUTION
Potential pending danger
Indicates a pending danger that could result in minor injuries if not observed.
►Instructions to avoid the danger situation
NOTICE
Danger of damage to property
Is used to highlight actions that are not associated with personal injury.
►Instructions to avoid damage to property
Notes, tips or examples indicate important information about the product or about this docu-
ment.
2.2 Safety instructions
All safety instructions in this document are based on the results of the risk assessment carried out in
accordance with Low Voltage Directive 2014/35/EU. Where applicable, all life cycle phases of the prod-
uct were taken into account.
Risks during installation
DANGER
Danger to life from electric shock
When establishing the voltages that exceed the specified safety extra-low voltage (according to IEC
60449 and VDE 0100), the insulating measures will be destroyed. There is a danger to life from elec-
tric shock at the communication interfaces.
►Connect only suitable devices to the bus system.
DANGER
Danger to life from electric shock
Touching exposed and voltage-bearing elements causes an electric shock. Improper connection of
the mains supply leads to the risk of touchable live housing parts. There is a risk to life.
►Before the installation, check that the connection leads are voltage-free.
►Make sure that electrical installations are only carried out by qualified electricians.
►Provide adequate grounding for the device.
►After connection work, carry out an earthed conductor check.
Safety
10/48

DANGER
Danger to life from electric shock
Power supply packs that are not specified or are not approved will lead to severe injury to death.
►Make sure that the power supply pack meets the requirements for double isolation between
mains input voltage and output voltage, in accordance with IEC 61010-1 IEC 60950-1 and
IEC 62368-1.
►Make sure that the power supply pack meets the requirements in accordance with IEC 61010-1
IEC 60950-1 and IEC 62368-1.
►Where possible, use original power supply packs or only power supply packs that correspond
with the applicable safety regulations.
WARNING
Risk of fatal injury due to electric shock on account of incorrect installation
The device's power supply uses life-threatening voltages. Unsafe or improper installation can lead to
life-threatening situations from electric shocks obtained from working with or on the unit.
►Ensure safe integration into an emergency off safety circuit.
►Do not carry out your own conversions or modifications on the unit.
WARNING
Risk of danger to life through missing mains disconnection device
The vacuum pump and electronic drive unit are not equipped with a mains disconnection device
(mains switch).
►Install a mains disconnection device according to SEMI-S2.
►Install a circuit breaker with an interruption rating of at least 10,000 A.
WARNING
Health hazard through poisoning from toxic contaminated components or devices
Toxic process media result in contamination of devices or parts of them. During maintenance work,
there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub-
stances causes environmental damage.
►Take suitable safety precautions and prevent health hazards or environmental pollution by toxic
process media.
►Decontaminate affected parts before carrying out maintenance work.
►Wear protective equipment.
Risks during operation
WARNING
Danger to life due to incorrect operation
The OmniControl and its options are not designed as safety-related controllers. Manual misuse of the
OmniControl or options, or automatically executed programming of the OmniControl’s auto control
function may result in damage relating to materials, the environment, health, or life.
►Only use the OmniControl, options, or auto control function to control functions that will not cause
damage.
►To ensure correct settings, ensure that the operating instructions are available to qualified per-
sonnel and operators.
Safety
11/48

Risks during maintenance
WARNING
Danger to life from electric shock during maintenance and service work
The device is only completely de-energized when the mains plug has been disconnected and the
vacuum pump is at a standstill. There is a danger to life from electric shock when making contact with
live components.
►Before performing all work, switch off the main switch.
►Wait until the vacuum pump comes to a standstill (rotation speed =0).
►Disconnect all connection cables.
►Remove the mains plug from the device.
►Secure the device against unintentional restarting.
Risks during troubleshooting
WARNING
Danger to life from electric shock in the event of a fault
In the event of a fault, devices connected to the mains may be live. There is a danger to life from
electric shock when making contact with live components.
►Always keep the mains connection freely accessible so you can disconnect it at any time.
2.3 Safety precautions
Duty to provide information on potential dangers
The product holder or user is obliged to make all operating personnel aware of dangers
posed by this product.
Every person who is involved in the installation, operation or maintenance of the product
must read, understand and adhere to the safety-related parts of this document.
Infringement of conformity due to modifications to the product
The Declaration of Conformity from the manufacturer is no longer valid if the operator
changes the original product or installs additional equipment.
●Following the installation into a system, the operator is required to check and re-evalu-
ate the conformity of the overall system in the context of the relevant European Direc-
tives, before commissioning that system.
General safety precautions when handling the product
►Use only power supply packs that comply with the applicable safety regulations.
►Observe all applicable safety and accident prevention regulations.
►Check that all safety measures are observed at regular intervals.
►Recommendation: Establish a secure connection to the grounded conductor (PE); protection class
I or Ⅲ.
►Never disconnect plug connections during operation.
►Keep lines and cables away from hot surfaces (> 70 °C).
►Do not carry out your own conversions or modifications on the unit.
►Observe the unit protection degree prior to installation or operation in other environments.
2.4 Limits of use of the product
Feature OmniControl 200/300 OmniControl 400 OmniControl 001 OmniControl 001 Mo-
bile
Installation location weatherproof (indoors),
Rack or table
weatherproof (in-
doors),
Rack or table
weatherproof (in-
doors),
Rack or table
weatherproof (indoors),
Handheld device or
profile rail
Air pressure 53 kPa to 106 kPa 53 kPa to 106 kPa 53 kPa to 106 kPa 53 kPa to 106 kPa
Safety
12/48

Feature OmniControl 200/300 OmniControl 400 OmniControl 001 OmniControl 001 Mo-
bile
Installation altitude max. 5000 m max. 2000 m max. 5000 m max. 5000 m
Rel. air humidity max. 80 % at
T ≤ 31 °C,
up to max. 33% at T ≤
50°C
max. 80 % at
T ≤ 31 °C,
up to max. 33% at
T ≤ 50°C
max. 80 % at
T ≤ 31 °C,
up to max. 33% at
T ≤ 50°C
max. 80 % at
T ≤ 31 °C,
up to max. 33% at T ≤
50°C
Protection class I I Ⅲ Ⅲ
Protection degree IP20 IP20 IP20 IP20
Ambient temperature 0 °C to +50 °C 0 °C to +50 °C 0 °C to +50 °C 0 °C to +50 °C
Overvoltage category Ⅱ Ⅱ I I
Degree of pollution 2 2 2 2
Tbl. 3: Permissible ambient conditions
2.5 Proper use
●OmniControl control units are used exclusively to control the electronic drive units of Pfeiffer Vac-
uum vacuum pumps and their accessories.
●The version with integrated power supply pack also supplies the operating voltage for the vacuum
pump.
2.6 Foreseeable improper use
Improper use of the product invalidates all warranty and liability claims. Any use that is counter to the
purpose of the product, whether intentional or unintentional, is regarded as improper use; in particular:
●Connection to the current supply that does not comply with the provisions of IEC 61010 or IEC
60950
●Operating modes that may result in hazardous situations with connected devices if unintentionally
or automatically activated
●Operation with excessive irradiated heat output
●Use in areas with ionizing radiation
●Operation in potentially explosive areas
●Use of accessories or spare parts that are not listed in these instructions
Safety
13/48

3 Product description
3.1 Identifying the product
►To ensure clear identification of the product when communicating with Pfeiffer Vacuum, always
keep all of the information on the rating plate to hand.
►Learn about certifications through test seals on the product or at www.certipedia.com with compa-
ny ID no. 000024550.
3.2 Product features
Feature OmniControl 200 OmniControl 300 OmniControl 400 OmniCon-
trol 001
OmniCon-
trol 001 Mobile
Power supply
pack: AC in yes yes yes no no
DC out 24 V ± 2 %
200 W
24 V ± 2 %
300 W
48 V ± 2 %
400 W
no no
RS-485 with
DC in/out 24 V
3 A
24 V
3 A
24 V
3 A
24 V ± 10 %
3 A
24 V ± 10 %
3 A
Number of op-
tions 0 - 1 Front
0 - 2 Rear
0 - 1 Front
0 - 2 Rear
0 - 1 Front
0 - 2 Rear
0 - 1 Front
0 - 3 Rear
0 - 1
Suitable for
Pfeiffer Vacuum
products
with integrated
electronic drive
unit,
without power sup-
ply pack
with integrated
electronic drive
unit,
without power sup-
ply pack
with integrated
electronic drive
unit,
without power sup-
ply pack
with integrated
electronic drive
unit,
with power supply
pack
with integrated
electronic drive
unit,
with power supply
pack
Tbl. 4: Product features
3.3 Scope of delivery
●OmniControl control unit (optionally with table mount installed)
●Operating instructions
3.4 Function
The OmniControl is a control unit for Pfeiffer Vacuum vacuum pumps with integrated electronic drive
unit. This device provides an overview of all control parameters for the electronic drive unit. In addition,
a gauge may be connected if the “gauge/IO” option is available.
1
Fig. 2: OmniControl 200 front view
1 Touch display
Product description
14/48

1
2
3
4
5
6
7
Fig. 3: OmniControl 200 rear view
1 Connecting socket RS-485 5 Mains switch S1
2 Placeholder options 6 Mounting bracket for mains connection
3 Earthed conductor, M4 7 Connecting socket DC out
4 Power supply plug AC in, mains input
Product description
15/48

4 Interfaces
4.1 Interface RS-485
DANGER
Danger to life from electric shock
When establishing the voltages that exceed the specified safety extra-low voltage (according to IEC
60449 and VDE 0100), the insulating measures will be destroyed. There is a danger to life from elec-
tric shock at the communication interfaces.
►Connect only suitable devices to the bus system.
The interface designated “RS-485” is intended for connecting a Pfeiffer Vacuum electronic drive unit or
a gauge. The connectors are isolated from the maximum occurring supply voltage in a galvanically safe
way. The electrical connections are optically decoupled internally.
Designation Value
Serial interface RS-485
Baud rate 9600 Baud
Data word length 8 bit
Parity none (no parity)
Start bits 1
Stop bits 1
Tbl. 5: Features of the RS-485 interface
Pin Assignment
1 2
34
5
1 RS-485 D+
2 +24 V output, ≤ 210 mA loading capacity
3 GND
4 RS-485 D-
5 not connected
Tbl. 6: Terminal layout of the RS-485 connecting socket M12
Interfaces
16/48

1
23
4
5
6
7
Fig. 4: Cross-linking an OmniControl in the RS-485 bus
1 TC 400/TM 700 5 DigiLine xPT 200
2 Y-connector for RS-485 6 Connection cable with 2 accessory ports, RS-485
3 M12 to M12 extension cable 7 MVP 010/015/0301)
4 OmniControl 001
Networking as RS-485 Bus
The group address of the electronic drive unit is 963.
1. Install the devices according to the specification for RS-485 interfaces.
2. Make sure that all devices connected to the bus have different RS-485 device addresses [P:797].
3. Connect all devices to the bus with RS-485 D+ and RS-485 D-.
4.2 Gauge/IO option
Pressure measurement with the OmniControl
The OmniControl offers a precise pressure display with existing gauge/IO function.
The option designated “gauge/IO” in the OmniControl enables the connection of a Pfeiffer Vacuum
pressure gauge. The connections in the OmniControl with integrated power supply pack are galvanically
safe and are isolated from the maximum supply voltage for the OmniControl.
gaugeIO
12
3
Fig. 5: Gauge/IO option
1 15-pin D-sub connector (IO) 3 Gauge socket
2 LED at gauge socket
1) The example of an RS-485 bus does not represent a power supply for vacuum pumps connected.
Interfaces
17/48

You can find more information in the corresponding operating instructions at the Pfeiffer Vacuum Down-
load Center.
4.3 Data option
The option designated “data” in OmniControl is intended for the connection of a USB stick and a micro
SD card. You can record values acquired by the OmniControl on these storage media devices.
µSD USBdata
12
3
4
Fig. 6: Data option
1 µSD socket 3 LED at USB socket
2 USB socket 4 LED at µSD socket
You can find more information in the corresponding operating instructions at the Pfeiffer Vacuum Down-
load Center.
Interfaces
18/48

5 Installation
5.1 Preparing for installation
General comments regarding installation
►Choose a site for installation where access to the product and to supply lines is possible at all
times.
►Install the device upright.
►Respect the ambient conditions stated for the area of use.
►A minimum distance of 50 mm from the upper cooling vents to adjacent components must be
maintained.
►Ensure adequate cooling options, e.g., in the control cabinet.
5.2 Installing the device in a rack
NOTICE
Damage caused by overheating
The ambient temperature must not exceed the permissible operating temperature of the device.
►Make sure there is unobstructed circulation of air when installing the device.
►Periodically check and clean the installed air filter, if necessary.
The device is suitable for installation in a 19" mounting rack 3HE in accordance with DIN 41494.
Installing the device in a rack
1. Install guide rails in the rack as required.
2. Push the device upright into the rack all the way to the front panel.
3. Secure the front panel with 4 collar screws and plastic nipples included in the shipment.
5.3 Connecting the electrical supply
DANGER
Danger to life from electric shock
Touching exposed and voltage-bearing elements causes an electric shock. Improper connection of
the mains supply leads to the risk of touchable live housing parts. There is a risk to life.
►Before the installation, check that the connection leads are voltage-free.
►Make sure that electrical installations are only carried out by qualified electricians.
►Provide adequate grounding for the device.
►After connection work, carry out an earthed conductor check.
WARNING
Risk of fatal injury due to electric shock on account of incorrect installation
The device's power supply uses life-threatening voltages. Unsafe or improper installation can lead to
life-threatening situations from electric shocks obtained from working with or on the unit.
►Ensure safe integration into an emergency off safety circuit.
►Do not carry out your own conversions or modifications on the unit.
WARNING
Risk of danger to life through missing mains disconnection device
The vacuum pump and electronic drive unit are not equipped with a mains disconnection device
(mains switch).
►Install a mains disconnection device according to SEMI-S2.
►Install a circuit breaker with an interruption rating of at least 10,000 A.
Installation
19/48

Dimensions of connection lead
●Cross section: min. AWG 18 or 1 mm²
●Length: max. 3 m
Pfeiffer Vacuum recommends the use of original accessory parts.
●Information and ordering options for approved range of accessories for the OmniCon-
trol can be found online.
5.3.1 Connection diagram
Fig. 7: Connection diagram for the OmniControl with integrated power supply pack
Installation
20/48
