Phoenix Contact FL EPA 2 User manual

User manual
FL EPA 2

2019-08-08
PHOENIX CONTACT GmbH & Co. KG • Flachsmarktstraße 8 • 32825 Blomberg • Germany
phoenixcontact.com
108452_en_01
FL EPA 2
Designation Order No.
FL EPA 2 1005955
FL EPA 2 RSMA 1005957
FL BT EPA 2 1005869
User manual
This user manual is valid for:
UM EN FL EPA 2, Revision 01

Table of contents
108452_en_01 PHOENIX CONTACT 3 / 50
Table of contents
1 For your safety ...........................................................................................................................5
1.1 Identification of warning notes ...............................................................................5
1.2 Qualification of users .............................................................................................5
1.3 Field of application of the product..........................................................................5
1.3.1 Product changes ....................................................................................6
1.4 Safety notes...........................................................................................................6
1.5 Industrial security...................................................................................................6
2 FL EPA 2 ....................................................................................................................................7
2.1 Characteristics.......................................................................................................7
2.1.1 Device versions ......................................................................................7
2.2 Country approvals for the FL WLAN EPA ..............................................................7
3 Installation ..................................................................................................................................9
3.1 Mechanical installation ..........................................................................................9
3.1.1 DIN rail mounting .................................................................................10
3.1.2 Wall or mast mounting .........................................................................11
3.1.3 Connectors ..........................................................................................12
3.2 Antenna connection (FL EPA 2 RSMA only)........................................................13
3.3 LED indicators .....................................................................................................13
4 Configuration ...........................................................................................................................15
4.0.1 Easy Config (“MODE” button) ..............................................................16
4.0.2 Using the MODE button .......................................................................16
4.0.3 Easy Config via web interface ..............................................................17
4.0.4 Easy Config modes ..............................................................................18
5 Web-based management ........................................................................................................21
5.1 General information .............................................................................................21
5.1.1 System overview ..................................................................................23
5.1.2 Easy Config ..........................................................................................24
5.1.3 Network settings ..................................................................................24
5.1.4 WLAN settings - Client mode ...............................................................25
5.1.5 WLAN settings - Access point mode ....................................................28
5.1.6 Bluetooth settings - General .................................................................29
5.1.7 Bluetooth settings - Mode-specific .......................................................30
5.1.8 Bluetooth LE settings ...........................................................................34
5.1.9 Firmware update ..................................................................................35
5.1.10 AT commands ......................................................................................36
5.1.11 System settings ....................................................................................37

FL EPA 2
4 / 50 PHOENIX CONTACT 108452_en_01
5.2 Restoring the factory defaults ..............................................................................38
5.3 PROFINET communication .................................................................................38
6 Technical data and accessories ...............................................................................................41
A Appendixes...............................................................................................................................45
A 1 List of figures .......................................................................................................45
A 2 List of tables ........................................................................................................47

For your safety
108452_en_01 PHOENIX CONTACT 5 / 50
1 For your safety
Read this user manual carefully and keep it for future reference.
1.1 Identification of warning notes
1.2 Qualification of users
The use of products described in this user manual is oriented exclusively to electrically
skilled persons or persons instructed by them. The users must be familiar with the relevant
safety concepts of automation technology as well as applicable standards and other
regulations.
1.3 Field of application of the product
This product is recommended for use in both industrial and domestic environments.
Functional ground needs to be connected in industrial environments to comply with
immunity requirements. For domestic environments, functional ground must be omitted if a
shielded Ethernet cable is used, in order to meet the emission requirements.
Observe the permitted operating temperatures of the EPA when using it outdoors. The
device is suitable for installation in protected outdoor areas (e.g., under a porch). Direct
sunlight may lead to overheating and permanent damage of the device.
Observe the applicable regulations for using wireless devices outdoors.
This symbol indicates hazards that could lead to personal injury.
There are three signal words indicating the severity of a potential injury.
DANGER
Indicates a hazard with a high risk level. If this hazardous situation is not
avoided, it will result in death or serious injury.
WARNING
Indicates a hazard with a medium risk level. If this hazardous situation is not
avoided, it could result in death or serious injury.
CAUTION
Indicates a hazard with a low risk level. If this hazardous situation is not avoided,
it could result in minor or moderate injury.
This symbol together with the NOTE signal word warns the reader of actions
that might cause property damage or a malfunction.
Here you will find additional information or detailed sources of information.

FL EPA 2
6 / 50 PHOENIX CONTACT 108452_en_01
1.3.1 Product changes
Modifications to hardware and firmware of the device are not permitted.
Incorrect operation or modifications to the device can endanger your safety or damage the
device. Do not repair the device yourself. If the device is defective, please contact
Phoenix Contact.
1.4 Safety notes
1.5 Industrial security
Connecting devices to a network via Ethernet entails the danger of unauthorized access to
the network.
If possible, deactivate unused communication channels.
Assign passwords such that third parties cannot access the wireless module and make
unauthorized changes.
Due to its communication interfaces, the wireless module should not be used in safety-
critical applications unless additional security appliances are used.
Please take additional protective measures in accordance with the IT security requirements
and the standards applicable to your application (e.g., virtual networks (VPN) for remote
maintenance access, firewalls, etc.) for protection against unauthorized network access.
On first request, you shall release Phoenix Contact and the companies associated with
Phoenix Contact GmbH & Co. KG, Flachsmarktstrasse 8, 32825 Blomberg in accordance
with §§15ff. AktG (German Stock Corporation Act), hereinafter collectively referred to as
“Phoenix Contact”, from all third-party claims made due to improper use.
For the protection of networks for remote maintenance via VPN, Phoenix Contact offers the
mGuard product range as security appliances, which is described in the latest Phoenix
Contact catalog (phoenixcontact.net/products).
Additional measures for protection against unauthorized network access can be found in
the AH EN INDUSTRIAL SECURITY application note. The application note can be
downloaded at phoenixcontact.net/products.
CAUTION: Noise susceptibility of medical equipment
This device emits radio frequency (RF) energy in the ISM (Industrial, Scientific, Medical)
band. Make sure that all medical devices used in proximity to this device meet appropriate
noise susceptibility specifications for this type of RF energy.
NOTE: Electrostatic discharge
This product contains parts that can be damaged by electrostatic discharge (ESD). Take
appropriate protective measures against electrostatic discharge.
NOTE: Risk of unauthorized network access
To prevent unauthorized network access, please read the following notes.

FL EPA 2
108452_en_01 PHOENIX CONTACT 7 / 50
2 FL EPA 2
2.1 Characteristics
The FL EPA 2 is an industrial wireless module for the wireless integration of industrial
Ethernet and PROFINET devices in cable-based networks through WLAN and/or
Bluetooth.
Among others, the FL EPA 2 is designed for the following typical applications:
– Wireless network connection for industrial machines, devices and vehicles
– Ethernet cable replacement between moving machine parts
WLAN or Bluetooth?
WLAN is the preferred technology when it is important to integrate multiple devices with high
data throughput and fast roaming.
Bluetooth has benefits if the application requires especially robust wireless connections or
if precise cable planning is not possible.
2.1.1 Device versions
Three device versions are available:
Depending on the model, not all of the properties described above are available.
2.2 Country approvals for the FL WLAN EPA
An up-to-date list of the country approvals can be found in the e-shop at
phoenixcontact.net/products.
The implementation of the Bluetooth PAN profile on mobile devices is not uniform and may
possibly be incompatible with the FL EPA 2. A Bluetooth PAN connection must be tested
individually.
5 GHz WLAN cannot be used at the same time as 2.4 GHz WLAN or Bluetooth.
The performance of both wireless modules is degraded if WLAN and Bluetooth are
activated simultaneously. Only one of the two wireless standards should be active for
applications that require maximum performance or real-time characteristics!
Table 2-1 Device versions
Type Description Order No.
FL EPA 2 Internal antenna, WLAN and Bluetooth 1005955
FL EPA 2 RSMA External antenna, WLAN and Bluetooth 1005957
FL BT EPA 2 Internal antenna, Bluetooth (one device) 1005869

FL EPA 2
8 / 50 PHOENIX CONTACT 108452_en_01

Installation
108452_en_01 PHOENIX CONTACT 9 / 50
3 Installation
3.1 Mechanical installation
Figure 3-1 Assembly drawing (all dimensions in mm, antenna connection for the
FL EPA 2 RSMA only)

FL EPA 2
10 / 50 PHOENIX CONTACT 108452_en_01
3.1.1 DIN rail mounting
The FL EPA RMS mounting kit (Order No. 2701133) is available as an accessory for
mounting the device on a 35 mm DIN rail.
Figure 3-2 Fixing the EPA to the mounting kit for the DIN rail
• Use the two screws provided to fix the EPA to the base plate.
• Place the EPA with the adapter on the top edge of the DIN rail.
• Push the EPA towards the DIN rail until it latches into place.
• For releasing the adapter from the DIN rail, pull the latch downwards using a
screwdriver and simultaneously remove the EPA from the DIN rail.

Installation
108452_en_01 PHOENIX CONTACT 11 / 50
3.1.2 Wall or mast mounting
The FL EPA WMS (Order No. 2701134) mounting kit can be used for EPA wall or mast
mounting.
.
Figure 3-3 Fixing the EPA to the mounting kit for wall/mast mounting
• Use the two screws provided to fix the EPA to the base plate.
• The two 4.5 mm bore holes can be used for mounting. Two steel clamps are provided
for mounting the EPA to a mast (25 mm ... 85 mm).

FL EPA 2
12 / 50 PHOENIX CONTACT 108452_en_01
3.1.3 Connectors
Figure 3-4 M12 connectors
Table 3-1 Power supply (M12 male connector, A-coded)
Graphic Pin Function
1 Power supply + (9 V DC - 30 V DC)
2 Digital input ground
3 Power supply ground
4 Digital input + (9 V DC - 30 V DC)
5 Functional ground
All LEDs except the LAN LED are illuminated if voltage is present at the digital input during
the boot process. The device is only ready to operate after another voltage reset.
The digital input function can be specified using the ATS2710/ATS4001 command. By
default, the device switches forward within the roaming list in the event of a falling edge.
The device is reset to its default settings if voltage is present at the digital input for more
than 10 sec.
If the line length exceeds 3 meters, the signal line for the digital input must be carried in the
same cable as the power supply and functional ground.
Table 3-2 LAN cable (M12 female connector, D-coded)
Graphic Pin Function Color coding (T568B)
1 Send Tx + Orange/white
2 Receive Rx + Green/white
3 Send Tx - Orange
4 Receive Rx - Green

Installation
108452_en_01 PHOENIX CONTACT 13 / 50
3.2 Antenna connection (FL EPA 2 RSMA only)
3.3 LED indicators
Figure 3-5 LED indicators
The device is provided with an RSMA (female) antenna socket. Only use suitable antenna
cables and adapters. The antenna socket may be damaged when trying to screw on
wrong connectors.
Avoid the use of long and/or low-quality antenna cables. They cause additional
attenuation and may reduce the range.
Torque the antenna cable to 1 Nm. Excessively high torques may damage the device.
Table 3-3 Meaning of the LED indicators
LED Color Meaning
PWR Off No power
Green Normal operation
WLAN Off WLAN deactivated
Flashing blue Access point mode: WLAN activated, no client connected
Blue Access point mode: connected to at least one client
Client mode: connected to access point
Flashing blue
rapidly
WLAN data activity (when connected)
Flashing pur-
ple
Client mode: scanning for access points
Purple Client mode: connecting to a detected access point
Red Unrecoverable error
LAN Off No Ethernet connection
Yellow Ethernet link present
Flashing yel-
low rapidly
Ethernet data activity (when connected)

FL EPA 2
14 / 50 PHOENIX CONTACT 108452_en_01
BT Off Bluetooth deactivated
Flashing blue NAP mode: Bluetooth activated, no client connected
Blue NAP mode: connected to at least one PANU client
PANU mode: connected to NAP
Flashing blue
rapidly
Bluetooth data activity (when connected)
Purple PANU mode: trying to connect to NAP
Red Unrecoverable error
A-B-C-D Green RSSI (received signal strength) or link quality
Table 3-4 Indication of received signal strength via the A-B-C-D LEDs
RSSI (WLAN client) / link quality (Bluetooth PANU) A B C D
No connection
RSSI / link quality low
RSSI / link quality sufficient
RSSI / link quality good
RSSI / link quality excellent
Table 3-3 Meaning of the LED indicators [...]
LED Color Meaning

Configuration
108452_en_01 PHOENIX CONTACT 15 / 50
4 Configuration
There are different ways of configuring the EPAs for operation:
Easy Config (“MODE” button)
Typical operating modes, such as direct connection of two EPAs to form a “wireless
Ethernet cable”, can be directly activated via the MODE button on the EPA. A PC is not
required. For a detailed description, please refer to Section 4.0.1 “Easy Config (“MODE”
button)” on page 16.
Web-based management (WBM)
The device includes a web-based management using a web browser. You can see the
current operating state and configure the device without using special software.
For parameter description, please refer to Section “Web-based management” on page 21.
AT commands
You can carry out all the EPA settings automatically from a control program, for example.
For this purpose, send the command to TCP port 8080 of the device. For development or
testing purposes, AT commands can also be transmitted to the EPA via the web-based
management.
The AT command reference can be found, for example, in the web-based management
application under the “Help” menu item.

FL EPA 2
16 / 50 PHOENIX CONTACT 108452_en_01
4.0.1 Easy Config (“MODE” button)
Figure 4-1 Control panel
The MODE button can be used to configure or reset the device.
4.0.2 Using the MODE button
1. Switch on the device and wait for the Link Quality LEDs to light up and go out again.
Then press the MODE button.
Step 1 must be carried out within five seconds after switching on the device.
2. Press the MODE button repeatedly to cycle through the Easy Config modes until the
desired mode is indicated by the A-B-C-D LEDs. Only suitable LED combinations are
shown.
3. Press and hold the MODE button for at least two seconds and release the button. This
will confirm the selected mode and restart the device.
Step 3 must be carried out within 20 seconds after step 2. Otherwise the device will exit
Easy Config setup and return to the previous settings.
The respective function is carried out when releasing the button (“falling edge”)

Configuration
108452_en_01 PHOENIX CONTACT 17 / 50
4.0.3 Easy Config via web interface
As an alternative to the MODE button, the Easy Config mode can also be activated via the
web interface. The required mode can be selected under the “Easy Config” menu item.
Figure 4-2 “Easy Config” web page
The “Set” button is used to activate the required mode.
Figure 4-3 “Easy Config” web page

FL EPA 2
18 / 50 PHOENIX CONTACT 108452_en_01
4.0.4 Easy Config modes
Modes 5 to 9 are used for defining the operating mode of the network (WLAN/Bluetooth,
with or without optimization for PROFINET operation). Set the device, which will later act as
an access point/NAP, to the desired mode.
Configure the clients for mode 4. The access point or NAP then configures the devices in
mode 4, matching the selected operating mode. As soon as a device is configured as a
client, the device is restarted.
The access point scans for configurable devices for 120 s (the scan can be canceled by
switching it off and on). The device is then also restarted. The connection is established
automatically.
Table 4-1 Indication of received signal strength via the A-B-C-D LEDs
Mode Role Description A B C D
1 Bluetooth
PANU
Configure the device as a Bluetooth client,
then discover devices in mode 4 and config-
ure them accordingly as a client
2 --- Reset configuration to factory defaults
3 --- Reset IP settings to factory defaults
4 Client Wait for discovery and configuration
5 WLAN AP
Configure the device as an access point, then
discover devices in mode 4 and configure
them accordingly as clients
6 Bluetooth
NAP
7 WLAN AP
with PROF-
INET optimi-
zation
8 Bluetooth
NAP with
PROFINET
optimization
9 Bluetooth
PANU with
PROFINET
optimization
10 Add PROF-
INET optimi-
zation only
11 Safety: dis-
able configu-
ration inter-
faces only
If a configuration exists, switch off all configu-
ration interfaces for safety-based communi-
cation.

Configuration
108452_en_01 PHOENIX CONTACT 19 / 50
The access point retains the configured IP address. The clients/PANU are assigned the IP
addresses in ascending order or - if not possible - in descending order.
Example: Based on the factory settings, the AP/NAP IP address is 192.168.0.254. The IP
addresses 192.168.0.253, 252, … are then assigned to the clients.
If the AP has previously been configured to 192.168.3.50, it will retain this address.
192.168.3.51, 52, … are then assigned to the clients/PANU.
A WLAN connection is established on channel 6. The channel can also be changed
subsequently using the access point web interface.
The connection is layer 2-transparent and thus also suitable for PROFINET.
If several wireless sets are used within a common backbone network, configuration via
Easy Config may lead to double assignment of IP addresses. This is due to the fact that
each wireless set starts at 192.168.0.254. In this case, assign unique addresses
beforehand or subsequently using the web interface.
For functionally safe communication, please refer to the information in Section “Safety-
related communication (PROFISafe/SafetyBridge)” on page 39.

FL EPA 2
20 / 50 PHOENIX CONTACT 108452_en_01
