Polycom V700 User manual

OTN Training Reference Material
Polycom Desktop V700 Reference Guide

Table of Contents
1.0 Terminology
1.1. Types of Videoconferences
1.2. Styles of Videoconferences
1.3. Modes of Videoconferences
1.4. Telemedicine Tools
1.5. Learning Tools
2.0 Equipment Guide
2.1. Equipment Components
2.2. Equipment Guide
2.3. Hooking Up a Laptop
2.4. Framing the Camera
2.5. Equipment Troubleshooting
2.6. Technical Support
3.0 Etiquette
3.1. Etiquette Guidelines
3.2. Presenter Guide
4.0 Contacts
4.1. Useful Contacts

Types of Videoconferences
Educational Videoconferences
»Open: posted on Learning Centre and
Ncompass Calendar.
»Closed: invited participants only.
Administrative Videoconferences
»Team meetings between different sites.
For example committee meetings, all
staff announcements or policy
discussions.
»
Clinical Videoconferences
»Direct: health care provider and patient.
»Indirect: healthcare providers discussing
specific patients and making a plan of care.
3 | OTN Training Services

Styles of Videoconferences
Point-to-point Videoconference
• Two sites only.
• Other site is always seen on monitor.
• Option to dial directly (must be scheduled).
• Often for clinical use (consultant dials patient).
Multipoint Videoconferences
• Three or more sites.
• Uses a bridge program.
• Starts and ends automatically.
• Often used for educational/administrative use.
4 | OTN Training Services

Modes of Videoconferences
Full screen mode
• Screen displays the person speaking or
making the loudest noise.
• Default mode
• Must mute if your site is not the presenter
• Recommended for presentations
Multi-Screen mode
• Visual set-up where all sites are visible on
the screen at the same time
•“Brady Bunch” layout (3+1, 5+1, etc.)
•Mode is selected by the scheduling site
5 | OTN Training Services

Telemedicine Tools
Ncompass Scheduling
Ncompass is an online scheduling tool that allows OTN
Members to self-schedule and manage both clinical and
non-clinical videoconference events. Ncompass users can
book video systems, send emails to participants and
maintain a searchable calendar of events. In addition,
Ncompass allows Members to publish open events so that
others can view public events from the Learning Centre. A
vital part of organizing events on the Network, it is
recommended that at least two members of your team be
trained in Ncompass.
OTN Telemedicine Directory
The OTN Telemedicine Directory provides Members with an
easy way to access Telemedicine consultants and programs.
It is also a place to promote, coordinate and manage
services offered via Telemedicine. The consultant profile
features the types of referrals a consultant accepts,
specialized areas of practice and the geographic area
served. The site profile features the programs available at a
site, the site type and geographical area served. To create
your own account and request a profile, email
[email protected].

Learning Tools
OTN Learning Centre
The Learning Centre provides an online and easy-to-use
single point of access to all OTN Member distance education
offerings. The Learning Centre makes it easier to find
education events (including searches by area of therapeutic
care) as well as actively promote those relevant to your
organizations. The Learning Centre can also be used to
promote and build education programs. Please visit
www.learning.otn.ca for more details.
OTN Webcasting Centre
Webcasting refers to the process where an educational
videoconference session is broadcast over the OTN network
and the web (Internet) at the same time. There are two
kinds of webcasts:
oLive Webcasts: Participants can log on to their
computer and view the live videoconference session
at the same time that it is being broadcast over the
OTN network.
oArchived Webcasts: This means that the
videoconference has been “taped” and is available for
viewing at any time.
7 | OTN Training Services

Equipment Components
Camera
The camera is usually located at the top of the
equipment and is what captures the video feed that is
transmitted to other videoconference systems that are
connected to the event. For both clinical carts and
room-based systems, the camera can be controlled
by using the arrows on the remote control.
Codec
The codec is the main brain of the system controlling
the camera, monitor and any other medical
peripherals plugged into the system. If the codec is
switched off, then no videoconferencing is possible.
The codec derives its name from the functions that it
serves. It both codes video signals that are sent to the
other sites as well as de-codes video signals that it
receives from the far sites.
Monitor
The monitor is purely a display screen and works in
conjunction with the codec. Consequently, it is
important to emphasis that if the codec is turned on -
then the monitor should be turned on as well. This
ensures that if someone connects to an event early,
you will be able to see them on the monitor. Please
note that turning off the monitor does not turn the
system off.
8 | OTN Training Services

Equipment Components
Microphone
The microphone has a range of 20 to 25 feet. The
microphone is extremely powerful and can pick up
peripheral sound such as whispering, tapping pens
and swiveling chairs. Ideally the microphone can be
placed underneath the monitor or at the end of a
table. Never place the microphone directly in front of
the monitor speakers as this will create unnecessary
feedback.
Network and Power
The network cable has to be plugged into a dedicated
OTN jack. If you plug the network cable into a regular
network jack then the system will not work.
Consequently, you need to know precisely where the
OTN jacks are located before moving the system to
different locations. For the clinical cart use the
Uninterrupted Power Supply (UPS) to power the
system entirely on or off. For a room based system,
use a surge-protected power bar.
9 | OTN Training Services

Polycom Desktop V700 Reference Guide
Verify that the power cable
is plugged into the power outlet in the
wall.
Verify that the network cable
is plugged into the network outlet in the
wall. The network cable must be
plugged into the OTN-dedicated
network outlet.
Verify that the Power is turned On
Three power switch on this system
• Two at the back
• One on the front
Power light located along the top of the
unit to the left of the camera. It should
be displayed as orange when system is
on.
Verify that lens cover is open.
If cover is open, screen will show self
view or room image. If cover is closed,
screen will be black.
Place call to site using the directory
Press the directory button on the
remote. Scroll down the list and highlight
the desired location. Press the green Call
button to connect.
Pick up the remote control.
Unmute your videoconferencing sound
by pressing the “Mute” button on the
remote control.
OTN SERVICE DESK 1-866-454-6861
1
3
4
6
2
2.2 | OTN Training Services
5

Polycom Desktop V700 Reference Guide
The diagram to the left illustrates the Polycom Remote
Control and highlights some of the more commonly used
buttons that are supported in OTN videoconferences.
Call: The call button is used to initiate a point-to-point
videoconference.
Hang up: The hang up button is used to end a point-topoint
videoconference.
Snap: The snap feature should be disabled and is not
supported.
Directory: The directory button is used to access the
Global Address Book.
Directional Arrows / Select Button: The directional
arrows are used to navigate the menu screens. The
select button is used to select an item in a menu.
Home: The home button is used to bring up the menu
screen.
Zoom: The zoom button is used to move the camera
in/out.
Volume: The volume button increases/decreases the
incoming volume.
Far/Near: The far/near buttons are used to switch
between far and near camera modes.
Mute: The mute button mutes the outgoing sounds from
your site.
Auto: The auto feature should be disabled and is not
supported.
Camera: The camera button will allow the user to select
other input devices (i.e. the AMD Patient Camera)
Preset: The preset button is used to set camera and
device presets.
Delete: The delete button is used to delete camera and
device presets.
Number Keys: The number keys are used to select
presets; the corresponding alphabetical keys are used in
the directory to jump to sites starting with each letter
when initiating a videoconference.
Graphics: The graphics button is used to display an
image from a laptop that is connected to the
videoconference system.
2.2 | OTN Training Services

Hooking up a Laptop
Turn the power on the laptop.
Connect the VGA cable
from the videoconference system to the
laptop.
Press the same keys
you would use when displaying your
desktop through a projector, usually
one of the following combinations:
Fn+F4 (or) Fn+F7 (or) Fn+F8.
To return to the camera view:
Press the purple “Graphics” button
again.
5
2
3
4
To display the desktop:
Press the purple “Graphics” button.
TROUBLESHOOTING
If the desktop still does not
appear on the screen, you need
to change the resolution of your
computer. Select 1024 X 768
for the best results.
1
BEST PRACTICE
Make sure to switch between the
desktop and camera view for more
interactive presentations.
2.3 | OTN Training Services

Framing the Camera
Positioning the Camera
A big part of using the equipment effectively is
framing the camera properly. The
videoconference should mimic a face-to-face
session as much as possible. Therefore make
sure the subject is framed in a head and
shoulders shot so the participating site(s) can
see the presenter or patient clearly.
Ideally when you frame the camera, visualize a
line dividing the monitor in half. The subject’s
face should be in the upper half of the screen
and the framing should be centered. The
subject’s face should be close enough that you
could recognize them on the street or bus.
However, if the camera framing is too close it
could make the person feel self-conscious. In
addition, if the framing is too close the subject
might move out of frame easier.
Lighting and Background
Always have a solid background behind you.
This could be a wall, door with no windows or a
covered window. In addition, ensure that you
have proper lighting so that you are seen
clearly.
13 | OTN Training Services

Equipment Troubleshooting
The system doesn’t work / won’t power up
• Ensure that the system is plugged into the power outlet.
• Verify that the network cable is plugged into the appropriate port in the wall.
• Check that the cables are securely plugged into the back of the codec.
• Call the OTN Service Desk (1-866-454-6861) if the problem persists.
I cannot connect to a site
• Ensure that all cables and plugs are securely plugged in.
• Check that you have the correct site selection.
• Contact OTN Service Desk (1-866-454-6861) for assistance.
I cannot hear the other site
• Ensure that the other site has un-muted their microphone.
• Verify that the other site has positioned their microphone correctly.
• Check that your site has its volume turned up.
• Call the OTN Service Desk (1-866-454-6861) if the problem persists.
I hear echoes when I am speaking to the remote site
• Echoes are always caused by the far site in a call. Have the far site decrease the
volume and make sure that their microphones are placed away from the system and
monitor speakers.
I cannot see the other site
• Verify that your monitor is turned on and the privacy shutter is opened.
• Make sure that the other site has their camera positioned correctly
• Call OTN Service Desk if the above has been checked and the problem persists.
My monitor is displaying black and white (no color)
• Check that all cables and plugs are securely plugged in at the back of the codec.
The session was interrupted and connections lost
• Keep system on, attempt to reconnect.
• Call the OTN Service Desk (1-866-454-6861) if the problem persists.
My screen is dusty and has finger marks on it
• Clean with a damp cloth after turning off the monitor.
• To keep the system looking brand new, periodically clean it with a mild detergent
solution.
• Never use strong solvents such as thinner or benzene, or abrasive cleaners since
they will damage the cabinet.
• As a safety precaution, unplug the system before cleaning it. Never attempt to
sterilize this unit. If the system must be used in a sterilized environment, use suitable
protective covers.
14 | OTN Training Services

Technical Support
When to call for Technical Support
Contact your organizational IT staff or Telemedicine Coordinator when:
Your internet is down.
Network cable is broken or missing.
You cannot find the remote control.
You do not know which network jack to plug into.
Contact OTN Service Desk when:
Call does not connect
Video camera problems
Call quality is poor
Call drops and you are unable to reconnect
OTN Service Desk Support Hours: Mon –Fri 7:00 AM to 7:00 PM
Please Call: 1- 866-454- 6861
15 | OTN Training Services

Etiquette Guidelines
Participate in an audio-visual check
Start the video conference with a roll call or speak with the host site.
Mute appropriately
Remember to mute when not speaking. This will ensure that video does not switch to
another site if someone makes a noise when using voice activated mode
If you need to move the microphone during the session, mute it first.
Engage the remote audience
Look into the camera occasionally when you are speaking. This helps you to maintain
good eye contact with the remote audience.
Do not move out of camera range so that people are always able to see you.
Speak clearly and naturally
The microphone will automatically amplify the sound.
There is no need to shout. Quiet talkers should sit closer to the mic.
Modulate your voice so it is not a monotone.
Pause between speakers
Due to a slight audio delay, pause and wait for a longer than normal period if you want
to be able to hear comments or are expecting a response from other sites.
Reduce background noise
Avoid unnecessary tapping, rustling of papers, and side conversations when your site
is speaking, as this will add audio noise at the receiving sites.
Enhance video display
Avoid rapid movements or erratic hand gestures.
Avoid wearing clothing with loud patterns, or solid red and white.
Professional behaviour
Be aware of the scheduled start and end time.
Assume that you are visible and can be heard throughout the meeting.
Do not interrupt when others are talking and use respectful language at all times.
Focus discussion and questions on the content of the session.
Respect individual confidentiality.
Administrative meetings
Participants at all sites should be introduced.
Say your name and site the first few times you respond to help familiarize others with your voice.
After the session
Leave room clean and put video conference equipment away
16 | OTN Training Services

Presenter Guide
While videoconferencing is an effective communications medium, you must
be prepared to accept a small loss of resolution. Your visual guides needs tobe adapted
in order to maximize the audience’s view at both the local and
remotes sites. The following suggestions are for presenters in order to help
them create effective PowerPoint slides.
Use a simple PowerPoint template in landscape format
oUse dark print with a plain light background or light print and a plain dark
background; a dark blue background is recommended.
Allow for a 1 inch margin on all borders
Limit the amount of words per slide
oUse no more than five bullets of information per slide.
oUse brief phrases instead of sentences.
Keep any graphics simple
oUse simple bold tables like pie charts or bar graphs.
oAvoid complex tables and scatter plots.
Use a consistent font size
oAt least 30-point font for text and 44 for headings.
Select a simple, clear, and bold font
oArial, Tahoma, Verdana.
oAvoid italics.
oUse lower case for text.
Avoid animation and special effects ( sounds, fly-ons, fade-ins)
oUse simple slide transition.
Send a copy of the presentation to all receiving sites for
distribution (in case of problems)
If possible, have a second medium available (hard copy and
document camera)
17 | OTN Training Services

Useful Contacts
Service Desk
Respond to OTN customers by providing expert technical
support before, during and after videoconferences.
1-866 -454-6861 (option 1)
[e-mail]
Contact Centre
Respond to OTN customers by providing technical support
before, during and after videoconferences.
1-866 -454-6861 (option 2)
[email protected]a
Training Team
Provide live training sessions to new OTN customers that focus
on knowledge acquisition and application.
[email protected]
Privacy Officer
Contact OTN’s Privacy Team if you experience a privacy breach
at your site.
[email protected]
18 | OTN Training Services
