SoundPoint® IP 430 Quick Start Guide
SoundPoint® IP 430 Quick Start Guide
Thank you for choosing the SoundPoint®
IP 430, a two-line Voice over IP telephone
with features and functions such as
Multiple Call Appearances, Call Hold,
Transfer, and Conferencing over an IP
network.
The following items are included in
your SoundPoint® IP 430 package. If
you are missing any items, contact your
SoundPoint® IP 430 reseller.
Handset
and Cord
Power Adapter
(Country-specific
AC cord provided)
Wallmount/Base Stand
Network (Ethernet) Cable
SoundPoint® IP 430 Console
Windowed Keycaps
Blank Label Sheet
Quick Start Guide
SoundPoint® IP 430 Features
Line Keys with LED
indicators
Hookswitch
Handsfree
Speaker
Hold Key
Volume Keys Handsfree Microphone
Speakerphone Key
Headset Key
Microphone Mute
Display Control Keys
Call/Message Indicator
Context-sensitive Soft Keys
Graphical LCD Feature Keys
Dial Pad

SoundPoint® IP 430 Quick Start Guide
2Connecting Network and Power
AC Power Option:
Power over Ethernet Option:
Network Port *NOTE: Use only the
power adapter shipped
with the unit to ensure
correct functionality.
Power Adapter*
(24V DC)
Optional PC
Connection
IEEE 802.3af
compliant
Power over
Ethernet
Hub/Switch
(Terminal or
Midspan)
Optional PC
Connection
Handset
Headset
(Optional
accessory)
SoundPoint® IP 430 Installation
1Connecting Handset and Headset

SoundPoint® IP 430 Quick Start Guide
With mounting tab of the base
unit facing up, fasten the base
stand to wall using wall anchors
(not included). When base
stand is secured to wall and all
cables are connected, snap the
SoundPoint® IP 430 into place.
SoundPoint® IP 430 Startup
As soon as power is supplied, the
SoundPoint® IP 430 starts an automated
process of establishing itself on the
network and downloading software and
applications.
Check with your system administrator
if specific configuration is required for
your application software or if any errors
appear during the download process.
For further instructions on how to use
your new SoundPoint® IP 430, consult
the User Guide available from www.
polycom.com.
Deskmount Method:
1
Attaching the Base Stand
The base stand can be attached to the SoundPoint® IP 430 in one of two ways:
2
Wallmount Method:
On the back of the phone,
remove the key located behind
the hookswitch. Reposition it so
that the end tab (at 45º angle) is
facing up. This will ensure that
the handset remains in place
within the cradle in a wallmount
position.
Connect all cables. Align tabs of base
stand as shown.
Snap firmly
into place.
1 2 3
