PR Lighting XR 1400 Framing User manual

1
XR 1400 Framing
PR-2737
The user manual contains important information about the safe installation and use of a projector. Please read
andfollowthese instructions carefullyandkeepthemanual in asafeplaceforfuturereference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1. SAFETYANDWARNINGS
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
●LUBRICATION
●TROUBLESHOOTING
3.APPEARANCE
4.INSTALLATION
●RIGGING
●POWERCONNECTIONS
●DMXCONTROLCONNECTIONS
●DMXTERMINATOR
●ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP
●GOBO/COLORFILTER REPLACEMENT
5.SETUPANDCONFIGURATION
●FRONTPANELOPERATION
●DMXSTARTADDRESS
●DMXWIRELESSCONTROL
●STAND-ALONEMODE
●MASTER/SLAVEMODE
●FIRMWARE UPGRADEVIAUSBINTERFACE
6.OPERATIONMENU
7.DMXPROTOCOL
8.ICONSOFTHETOUCHSCREEN
9.ERROR MESSAGES
10.TECHNICALDATA
11.CIRCUITDIAGRAMANDPCBCONNECTIONS
●CIRCUITDIAGRAM
12.COMPONENTORDERCODES
3
4
4
4
4
5
5
5
5
6
6
7
8
8
8
9
9
9
9
8
10
12
21
21
23
27
27
28
ACCESSORIES
Thefollowing itemsaresuppliedwith theprojectorand pleasecheck:
Name
Quantity
Unit
Remark
Gclamps
2
Pcs
XLRconnector
1
Set
Maleandfemale
Safetycord
2
Pcs
Sparegobos
4
Pcs
User manual
1
Pc
Ω clamps
2
Pcs
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are
subject to change without notice. Whilst every care is taken in the preparation of the manual we reserve the
right to change specifications in the course of product improvement. The publishers cannot be held responsible
for the accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and /
or the unit is in good condition before installation and use. Should there be any damage caused by
transportation, consult your dealer and do not use the unit. Any damage caused by improper use will not be
assumed by the manufacturer and / or dealer.
Any future technical changes in the user manual won’t be with any further notice.

3
Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one yearstarting from
thedeliverydate but the lightsource is notwithinthewarranty.
1. SAFETYANDWARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety information hereinafter!
Thefollowingsafetysignsareused intheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is transportation damage before using the projector. Should there be any
damagecausedbytransportation,consultyourdealeranddonotuseit.
●The manufacture is not responsible for loss caused bythe user not following the manual or changing the projector
ashe/shelikes.
●Pleasebenotedthatthedamagecausedbychangingtheprojectoratwillisnotwarranted.
●Do not hesitate to contact the dealer or the manufacturerif anyquestions or advice.
● Theprojectorisforindoor useonly,IP20.
● Use only in dry locations. Keep this unit away from rain and moisture, excessive heat, humidity and dust. Do not
allowcontact withwateroranyotherliquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated.
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictlyfollowtheproceduresinthemanual.
●No repairable partsintheprojectoranddo notopencoversfor maintenance byyourself.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned..
●Do notconnectthisdevicetoany typeofdimmerpack.
●Afterlamp switchedon,the minimumdistancebetweentheprojectorandilluminatedsurfaceis 10m.
●lensandotheroptical partsshallbereplacedimmediatelyiftheyhavedeformed or beendamaged,otherwise the
lightoutputwillbecompromised.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projector whilecovers(housing)areoff.
●Keep thelampcleananddo nottouchitwithbarehands.
●While operatingit, wearprotective items.
●Anyelectrical connectionmustbecarriedoutbyaqualified person.
●Before installation,pleaseconfirmthevoltagesupplied matcheswhatisrequired fortheprojector.
●Eachprojector mustbeproperlyearthed and installed asperrelatedelectrical standards.
●Do notusepower cord withitsinsulatordamaged andconnectthepowercord withothercables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully
orbypullingthepowercable.
●Allpowercordsmustconformto relatedsafetyandregulations.
●Whilebeingoperated,theprojectorshould notbeunder rainsor inhumidity.

4
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electricalparts’ lifewillbe shortened.
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety
cord suppliedthroughthesafetycord holesforsafetysupport.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from
powermains.
●After running for 5minutes, the temperature of the housing of the projector is 80℃.After stable operation,
itstemperatureis170℃.
●While thelampisstrickenforthefirsttime,therewillbesmokeandstrangesmell.It’s normal and does not
mean theprojectorhassomedefects.
●Do notmounttheprojectordirectlyoninflammablesurface.
●Do notprojectthebeamstraightlyoncombustible itemsandtheminimumdistance betweentheprojector
andilluminated itemsis10m.
●Aprojector should be installed with good ventilation and the minimum distance between the projector and
wallsis 50cm.Atthesametime,pleaseensurethe fansandairinletsandoutletsareworkable.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. Ifthe temperature is too high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,
restarttheprojector.
The accumulation of oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is verynecessary to
ensure a reliable use of it. Cooling fans need to be cleaned every 15days. Internal lens, reflectorand hotmirror need to be cleaned
periodicallyto optimize lightoutput.
Cleaning frequency is to be decided byoperations and its environment. Use soft cloth and normal detergent forglass for cleaning
work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean
anddo nottouchoptical parts with bare hands.
●Beforeanymaintenanceandcleaning,pleaseensuretheprojectisoffthepower.
●Onlyqualifiedpersonis allowedto do maintenance.
●During maintenanceandbeforemaintenance,theprojectormustbe offpower.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens
whether itrunsor not.
●Do notusealcoholorotherorganicsolvent to cleanthehousingtoavoiddamage.
●Do notuseanysolvent withchemical elementsto cleancolorfiltersor hotmirror.
●LUBRICATION
To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and
focuslensbelubricated every2 months. Highqualityandhightemperaturelubricant/greaseisadvised..
●TROUBLESHOOTING(Details varywithdifferentprojectors)
PROBLEM
ACTION
The projector doesn’t switch on
Checkthefuseonthe power socket.
Checkthelamp.
Thelampison but the projector doesn’t respond
to thecontroller
Makesurethatthe fixture’s start address is right
Replace orrepairtheXLRsignalcable.
Theprojector functionsintermittently
Makesurethefanisworkingwellorfansandtheirshieldsarenotblocked
Beam appearsdim, Lowinbrightness
Make surethe lampis withinitslifespan
Remove dustorgreasefromthelenses.

5
Theprojectimageappearstohaveahalo
Carefullycleanthelamp,opticallensesandothercomponents.
HeavilyDefectiveBeam
Checkif lensareingood condition(notcracked)
Cleandustor greaseonthelens.
3. APPEARANCE
HEAD
ARM
BASE
4. INSTALLATION
●RIGGING
Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a
projectorwithpower while itis locked.
CLAMP
HANDEL CONTROL
PANEL
106 256
256
106
HOLES for SAFETY CORDS
WARNING
TO pass 2 SAFETY CORDS
through 4 HOLES for safety
Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached
to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the
underside of the base as shown above) To pass the SAFETYCORD through the HOLES for safety! Always ensure that the
projector is firmlyanchored to avoid vibrationand slipping whilstfunctioning.Always ensurethatthe structurethatyouare going
to mounttheprojectortoissecureandstrongenoughtosupporttheweightofaXR1000 Framing.
WARNING:
●The projectorMUSTbeliftedorcarriedbythe HANDLESinsteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●POWERCONNECTION
Connectthepowercordasfollows:
L(live) =brown

6
E(earth)=yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projectorbeconnectedwithpowerseparatelyso thattheymaybeindividuallyswitchedonand off.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordancewiththe standardsconcerned.
●Ifanyquestionsabouttheelectricalinstallation,donotcontinuebutconsultaqualifiedelectrician.
●DMXCONTROLCONNECTION:
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the
projector)or5pinXLRplugsand sockets.TheXLR'sareconnected asshowninthefigure above.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected inany wayotherthan mentioned intheabove figure. The XR330BWSacceptsdigitalcontrolsignalsinprotocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminatorasshown inthefigurebelow.
DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX TERMINATOR
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents

7
electricalnoisefromdisturbingandcorruptingtheDMXcontrolsignals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged
intotheoutputsocketonthe lastprojectorinthechain.The connectionsare illustrated below.
● ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP
Beforeinstallation/replacement/alignment ofa lamp,disconnect the unit fromthe power and letitcool first.
LockTilt inthe figurebelowandopenthelamp coverafterits4 screws areloosened.
Afterremovalofthe lampcover, turnthelampanti-clockwiseand takeitout oftheceramic stand..
Insert a new lamp. Note: while placing a new lamp, do not touch the burner of the lamp with bare hands, otherwise the light output
will becompromised.
Fastenthe4 fast-fitscrewsafterthe lampcoverison
Important: The unit uses high voltage discharge lamp with external igniter( ). While using the lamp, please carefully read
“INSTRUCTIONS” packed with the lamp.
4 FAST-FIT SCREWS
BACK COVER LAMP
●Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to
impair thebeamoutput.While lamp’s installation, do not damage themetalwirearoundtheburner.
●Pleaseread "Instructions" enclosed withthelamp
●Do operate theprojector while adjustingthe lamp
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2

8
●GOBOREPLACEMENT
FRAMING MODULE
ROTATING GOBO WHEEL 2
EFFECT WHEEL
COLOUR WHEEL
ROTATING GOBO WHEEL 1
Lock the tilt and loosen the 6 fast-fit screws on the upper cover ,After removing the cover, you will see the structures as the figure
below.
Before replacing a gobo on the fixed gobo wheel, use your finger to remove the spring tightening it and take the old one out withdue
care.Atlastput thenewinto thewheel.
To replace a gobo on the rotating gobo wheel: take the rotator from the wheel, take the gobo out from the rotator by removing the
tightening spring. Put the new gobo back to the rotator, then tighten it with the spring. Please ensure the spring is in the narrow
locationof the rotator, which is the internal ring of it and flatten it. At last, pull up the spring strip usingproper tool and put the rotator
backtothe wheelwith theassistance byanother hand.
Note: Do nottouchtheglassgobowithbare hand.Placecleanandsoftpaperorclothbetweenhandand glassgobos.
Tighten6fast-fit screwsafterthecoverison.Unlockthetilt.
DANGER!
Beforereplacementofgobos,theprojectormust beoffthepower.
5. SETUPANDCONFIGURATION
●FRONTPANELOPERATION
Theprojectorconfigurationcanbesetconvenientlyviapushbuttonsandcolortouchscreen.
To browse through or change the projector ’s settings, touch the white area of the touch screen or press OK button for more than
3s(Only powered by the battery, pressing the OK button) to unlock the screen , then press ►key to enter the projector ’s function
menus. Each main menu has its sub-menus. And each menu stands for special function. For the details, please see the following 6th
point ”Operation Menu”.:

9
1. At the page to set the fixture’s functions, press ◄,►,▲,▼keysortheirrespective icons toselectthe functions desired.
2. While at 2nd,3rd and 4th level of menus, the◄key is for ESCAPE, but ►key won’t work, and OK key is used for ENTER.
Press OK keyto save the changesor enter into the sub menus. Press ▲or ▼keys to change the numbers(minus or plus).
Ortouchtheoptionneededforchange.
Shortcut keys: After the Function Menu is entered into, there are all options for the functions on the top of the screen. On the
rightthereare4 shortcutkeyslike ←,→LampControlandEnglish/Chinese.
●DMX STARTADDRESS
Each projector mustbegivena DMX start address so that the correct projector respondsto the correct controlsignals. ThisDMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3DMX modes. There are standard mode ,short mode and extended mode. For example standard mode
has 46 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 047, No. 3 projector’s address 093,No. 4
projector’s address 139,andsoon.
Switch on the Projector . Press OK key more than 3 seconds to unlock panel, then press ►key to enter into the fixture’s operation
menus.
Select DMX Address icon and press OK key or touch the icon directly on the display and select DMX address at the 2nd level menu
fortheaddresssetting.
Press▲or ▼keysortouch<、>displayedfortheDMXaddressdesired.
PressOKkeytoconfirm.
Pressthe◄keytogoback totheupperlevelmenu.
.
●DMXWIRELESSCONTROL
Theprojector haswireless control functionwith wirelessreceiver module andantennaforremotecontrol.
Thesetupofitisbelow:
1. Press OK for more than 3s to unlock the control panel, then press ►key to enter into the operation menu and select
“Config Settings”.
2. Select “Wireless First” or “Wireless Only” from the menu of “Signal Select”.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it,
Press “Enter” for the menu of Un-link Wireless under the upper level menu of Config Settings ,then the fixtureis unlinked
with thewirelesstransmitter.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
Connectthe first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projectors are connected in this way. Eventuallyconnect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
Start Addresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation mode can
besetaccordingly.
AfterPoweredon,thegroupwillruninMaster/SlaveMode

10
DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX TERMINATOR
MASTER SLAVE SLAVE
●FIRMWAREUPGRADEVIAUSBINTERFACE
Copythe.PRSfilefor upgradingtoUdiskandplugitintoUSBinterface.The upgradingfile nameorits filefoldercanbeseenviathe
USB firmware upgrading interface under menu SERVICE. Select the desired PRS file and tap the upgrading menu, then the system
will show Please Waiting…, which means the file is being copied into the system. After that, the Bootloader interface will be entered
into and the countdown 10s appear. Within 10s, if UP and DOWN keys are pressed at the same time, the system enters into firmware
upgrade interface. During this process, the power supply mustn’t be interrupted. If none key is pressed within 10s, the firmware
upgrade interface won’t be entered into.
6.OPERATIONMENU
1st LEVEL
2ndLEVEL
3rdLEVEL
4thLEVEL
5thLEVEL
Address
DMXAddress
1-512
IP Address
DefaultIPAddress
2.X.X.X /10.X.X.X
CustomIPAddress
X.X.X.X
SubNetMask
X.X.X.X
ArtNet
ArtNetUniverse
0-255
Reset
Total Reset
ReallyReset?
Pan&TiltReset
ReallyReset?
ColourSystemReset
ReallyReset?
GoboReset
ReallyReset?
Dimmer/Strobereset
ReallyReset?
Zo.Fo.Fr.Pr.Reset
ReallyReset?
OtherReset
ReallyReset?
ConfigSettings
DMXChannel Mode
Short Mode
StandardMode
ExtendedMode
ViewSelectedMode
Lamp Control
Lamp Control
OFF/ ON
On ByPower On
OFF/ ON
ControlByDMX
OFF/ ON
Lamp Power
1500/1700
1500/1700
SignalSelect
XLROnly
XLRFirst
WirelessOnly
WirelessFirst
WirelessIn/XLR Out

11
ArtNetOnly
ArtNetIn/XLR Out
LossofDMX
Normaltimeout
Hold LastValue
DisplayConfig
DisplayMode
OffAfterDelay
OnAlways
DisplayInvert
InvertOFF
InvertON
InvertAuto
LanguageSetting
English
Chinese
Touch Calibration
Input Password123
TemperatureUnit
CelsiusDegree
FahrenheitDegree
Un-LinkWireless
ReallyUn-Link?
Defaults
RestoreDefaults?
OptionSettings
Pan/TiltSettings
PanDMXInvert
OFF/ ON
TiltDMXInvert
OFF/ ON
PanTiltSwap
OFF/ ON
XYFeedback
OFF/ ON
Pan/Tilt mode
Speed/Time
InvertSettings
DimmerInvert
OFF/ ON
IrisInvert
OFF/ ON
ZoomInvert
OFF/ ON
CYMInvert
OFF/ ON
CTOInvert
OFF/ ON
DimmerCurve
Linear/SquareLaw
Defaults
RestoreDefaults?
Information
ViewDMXValues
Lamp Hours
Reset Lamp Hours
Total Hours
Temperature
DisplayBoardXX℃/F
PanandTiltXX℃/F
DriverBoard1XX℃/F
DriverBoard2XX℃/F
DriverBoard3XX℃/F
DriverBoard4XX℃/F
DriverBoard5XX℃/F
HeadSensorXX℃/F
SoftwareVersion
DisplayBoard
System=XXX
Boot=XXX
PanandTilt
System=XXX
Boot=XXX
DriverBoard1
System=XXX
Boot=XXX
DriverBoard2
System=XXX
Boot=XXX
DriverBoard3
System=XXX
Boot=XXX

12
DriverBoard4
System=XXX
Boot=XXX
DriverBoard5
System=XXX
Boot=XXX
ElectronicSN
ElectronicSN=
************
RDMDeviceLabel
RDMDeviceLabel
ANSIE1.20RDM
VersionX.X
FanStatus
Service
ManualEffectControl
StrobeXXX
DimmerXXX
…
USBUpdateSoftware
FactoryTest
Operation
Mode
DMXMode
ChangeOperationMode?
MasterMode
PresetMemory
ChangeOperationMode?
UserMemory1
ChangeOperationMode?
UserMemory2
ChangeOperationMode?
Stand-AloneMode
PresetMemory
ChangeOperationMode?
UserMemory1
ChangeOperationMode?
UserMemory2
ChangeOperationMode?
StaticScene
ChangeOperationMode?
User
Memories
Edit UserMemory
Edit UserMemory1
/
Edit UserMemory2
SceneXX
（1~200Scenes）
StrobeXXX
DimmerXXX
…
DelayTime XXX
DelayUnit
LinkTo StepXXX
Edit Static Scene
StrobeXXX
DimmerXXX
…
InitUserMemory
Reset UserMemory1
Reset UserMemory?
InputPassword123
Reset UserMemory2
Reset UserMemory?
InputPassword123
Reset Static Scene
Reset Static Scene?
Input Password 123
7.DMXPROTOCOL
Basic
mode
Standard
mode
Extended
mode
FunctionDescription
Decimal
Low
Decimal
High
1
1
1
Strobe
Close(LampSwitchesto1000 wattmodeafterStrobeisclosed for10
seconds)
0
10
Open
11
25
Strobespeedfromslowtofast
26
225
Macro(Randomstrobespeed slowto fast)
226
246
Open
247
255
2
2
2
Dimmer
Close
0
0
Dimmer fromdarktolight (0-100%)
1
255
3
3
DimmerFine
Finedimmer
0
255

13
3
4
4
CYMMacro
ThefollowingfunctionscanbeusedafterCMY,CTO,ColorWheel1andColor
Wheel2channelsaredisabled
No Function
0
7
ColourMacro1
8
9
ColourMacro2
10
11
ColourMacro3
12
13
ColourMacro4
14
15
ColourMacro5
16
17
ColourMacro6
18
19
ColourMacro7
20
21
ColourMacro8
22
23
ColourMacro9
24
25
ColourMacro10
26
27
ColourMacro11
28
29
ColourMacro12
30
31
ColourMacro13
32
33
ColourMacro14
34
35
ColourMacro15
36
37
ColourMacro16
38
39
ColourMacro17
40
41
ColourMacro18
42
43
ColourMacro19
44
45
ColourMacro20
46
47
ColourMacro21
48
49
ColourMacro22
50
51
ColourMacro23
52
53
ColourMacro24
54
55
ColourMacro25
56
57
ColourMacro26
58
59
ColourMacro27
60
61
ColourMacro28
62
63
ColourMacro29
64
65
ColourMacro30
66
67
LEEcolourswatches LEE
LEE4(MediumBastardAmber)
68
69
LEE10(MediumYellow)
70
71
LEE19(Fire)
72
73
LEE26(BrightRed)
74
75
LEE 58(Lavender)
76
77
LEE 68(SkyBlue)
78
79
LEE 71(TokyoBlue)
80
81
LEE79(JustBlue)
82
83
LEE88(LimeGreen)
84
85

14
LEE 90(DarkYellowGreen)
86
87
LEE 100(SpringYellow)
88
89
LEE 101(Yellow)
90
91
LEE 102(LightAmber)
92
93
LEE103(Straw)
94
95
Lee104(DeepAmber)
96
97
LEE105(Orange)
98
99
LEE106(PrimaryRed)
100
101
LEE 111(DarkPink)
102
103
LEE115(PeacockBlue)
104
105
LEE 116(MediumBlue-Green)
106
107
LEE 117(SteelBlue)
108
109
LEE 118(LightBlue)
110
111
LEE 119(DarkBlue)
112
113
LEE 120(DeepBlue)
114
115
LEE 121(LEEGreen)
116
117
LEE128(BrightPink)
118
119
LEE131(MarineBlue)
120
121
LEE 132(MediumBlue)
122
123
LEE 134(GoldenAmber)
124
125
LEE 135(DeepGoldenAmber)
126
127
LEE136(PaleLavender)
128
129
LEE 137(SpecialLavender)
130
131
LEE 138(PaleGreen)
132
133
LEE139(PrimaryGreen)
134
135
LEE141(BrightBlue)
136
137
LEE147(Apricot)
138
139
LEE148(BrightRose)
140
141
LEE152(PaleGold)
142
143
LEE154(PaleRose)
144
145
LEE157(Pink)
146
147
LEE 158(DeepOrange)
148
149
LEE162(Bastard Amber)
150
151
LEE164(FlameRed)
152
153
LEE165(DaylightBlue)
154
155
LEE169(LilacTint)
156
157
LEE170(DeepLavender)
158
159
LEE172(LagoonBlue)
160
161
LEE179(ChromeOrange)
162
163
LEE 180(DarkLavender)
164
165
LEE181(Congo Blue)
166
167
LEE197(AliceBlue)
168
169
LEE201(FullC.T.Blue)
170
171
LEE 202(HalfC.T.Blue)
172
173

15
LEE203(QuarterC.T.Blue)
174
175
LEE204(FullC.T.Orange)
176
177
LEE205(HalfC.T.Orange)
178
179
LEE206(QuarterC.T.Orange)
180
181
LEE247(LEEMinusGreen)
182
183
LEE 248(HalfMinusGreen)
184
185
LEE 281(ThreeQuarterC.T.Blue)
186
187
LEE285(ThreeQuarterC.T.Orange)
188
189
LEE352(Glacier Blue)
190
191
LEE353(Lighter Blue)
192
193
LEE715(CabanaBlue)
194
195
LEE778(MillenniumGold)
196
197
LEE 793(VanityFair)
198
199
CMYcolourmixingfromslowtofast
200
255
4
5
5
Cyan
Cyan (Linear 0-100%)
0
255
6
CyanFine
Cyanin16Bitprecision
0
255
5
6
7
Yellow
Yellow(Linear0-100%)
0
255
8
YellowFine
Yellowin16Bitprecision
0
255
6
7
9
Magenta
Magenta(Linear0-100%)
0
255
10
MagentaFine
Magentain16Bitprecision
0
255
7
8
11
CTO
Linear adjust fromhigh to low
0
255
12
CTOFine
CTOin 16 Bitprecision
0
255
8
9
13
ColourWheel1
Continual positioning
index0-360°
0
63
positioning
White/
64
67
White/colour1(Red)
68
71
Colour1(Red)
72
75
Colour1(Red)/colour2(Yellow)
76
79
Colour2(Yellow)
80
83
Colour2(Yellow)/colour3(Blue)
84
87
Colour3(Blue)
88
91
Colour3(Blue)/colour4(Green)
92
95
Colour4(Green)
96
99
Colour4(Green)/colour5(Pink)
100
103

16
Colour5(Pink)
104
107
Colour5（Pink））/colour6（Orange）
108
111
Colour6(Orange)
112
115
Colour6(Orange)/Colour7(UV)
116
119
Colour7(UV)
120
123
Colour7(UV)/white
124
127
Rainbowrotationspeed fromslowtofast
128
191
Rainbowreverserotationspeed fromslowtofast
192
255
10
14
ColourWheel1 Fine
ColourContinual positioningin16Bitprecision
0
255
9
11
15
Iris
LinearIrisfromsmalltobig0-100%
0
255
16
Irisin16 bit
Irisin16bitprecision
0
255
10
12
17
IrisMacro
0
10
IrisMacrodisabled
11
74
IrisMacro1:frombigtosmallwithspeedfromslowtofast
75
138
IrisMacro2:fromsmalltobigwithspeedfromslowtofast
139
202
IrisMacro3:Iriscontractsfromslowtofast
203
210
IrisMacro4(Macro1atrandom)withspeedfromslowtofast
211
218
IrisMacro5(Macro2 atrandom)withspeedfromslowto fast
219
226
IrisMacro6(Macro3 atrandom)withspeedfromslowto fast
227
255
Open
0
10
11
13
18
Rotatinggobowheel1
White
0
31
Gobo1
32
47
Gobo2
48
63
Gobo3
64
79
Gobo4
80
95
Gobo5
96
111
Gobo6
112
127
Clockwiserotationfromslowtofast
128
143
Anti-clockwiserotationfromslowto fast
144
159
Gobo1shakefromslowto fast
160
175

17
Gobo2shakefromslowto fast
176
191
Gobo3shakefromslowto fast
192
207
Gobo4shakefromslowto fast
208
223
Gobo5shakefromslowto fast
224
239
Gobo6shakefromslowto fast
240
255
12
14
19
Rotatinggobowheel1rotation
Indexing0-360°
0
127
Stop
128
128
Clockwiserotationfromslowto fast
129
188
Stop
189
195
Anti-clockwiserotationfromslowto fast
196
255
15
20
Rotatinggobowheel1rotationin16bit
Rotatinggobowheel1finerotation
0
255
13
16
21
Rotatinggobowheel2
White
0
31
Gobo1
32
47
Gobo2
48
63
Gobo3
64
79
Gobo4
80
95
Gobo5
96
111
Gobo6
112
127
Clockwiserotationfromslowtofast
128
143
Anti-clockwiserotationfromslowto fast
144
159
Gobo1shakefromslowto fast
160
175
Gobo2shakefromslowto fast
176
191
Gobo3shakefromslowto fast
192
207
Gobo4shakefromslowto fast
208
223
Gobo5shakefromslowto fast
224
239
Gobo6shakefromslowto fast
240
255
14
17
22
Rotatinggobowheel2rotation
Indexing0-360°
0
127
Stop
128
128
Clockwiserotationfromslowto fast
129
188
Stop
189
195
Anti-clockwiserotationfromslowto fast
196
255
18
23
Rotatinggobowheel2rotationin16bit
Rotatinggobowheel1finerotation
0
255
15
19
24
Framingblade1left
Framingblade1leftlinearlyclosingfrombigtosmall
0
255
25
Framingblade1leftin16bit
Framingblade1leftfineadjustment
0
255
16
20
26
Framingblade1right
Framingblade1rightlinearlyclosingfrombigtosmall
0
255

18
27
Framingblade1rightin16bit
Framingblade1rightfineadjustment
0
255
17
21
28
Framingblade2left
Framingblade2leftlinearlyclosingfrombigtosmall
0
255
29
Framingblade2leftin16bit
Framingblade2leftfineadjustment
0
255
18
22
30
Framingblade2right
Framingblade2rightlinearlyclosingfrombig tosmall
0
255
31
Framingblade2rightin16bit
Framingblade2rightfineadjustment
0
255
19
23
32
Framingblade3left
Framingblade3leftlinearlyclosingfrombigtosmall
0
255
33
Framingblade3leftin16bit
Framingblade3leftfineadjustment
0
255
20
24
34
Framingblade3right
Framingblade3rightlinearlyclosingfrombigtosmall
0
255
35
Framingblade3rightin16bit
Framingblade3rightfineadjustment
0
255
21
25
36
Framingblade4left
Framingblade4leftlinearlyclosingfrombigtosmall
0
255
37
Framingblade4leftin16bit
Framingblade4leftfineadjustment
0
255
22
26
38
Framingblade4right
Framingblade4rightlinearlyclosingfrombigtosmall
0
255
39
Framingblade4rightin16bit
Framingblade4rightfineadjustment
0
255
23
27
40
Framingmodulerotation
Framingmoduleindexing(0-360degrees)
Stop
Framingmoduleclockwiserotationfromslowto fast
Stop
Framingmoduleanti-clockwiserotationfromslowto fast
41
Framingmodulerotationin16bit
Framingmodulefinerotation
24
28
42
Prism1
Openposition(hole)
0
16
Prism
17
255
25
29
43
Prism1rotation
Prismindex
0
127
Stoprotating
128
128
Rotationspeedfromslowto fast
129
191
Stoprotating
192
192
Reverserotationspeedfromslowtofast
193
255

19
26
30
44
Prism2
Openposition(hole)
0
16
Prism
17
255
27
31
45
Prism2rotation
Prismindex
0
127
Stoprotating
128
128
Rotationspeedfromslowto fast
129
191
Stoprotating
192
192
Reverserotationspeedfromslowtofast
193
255
28
32
46
DualEffectWheel
No effect wheel
0
19
Proportionalindexing
20
127
Shakefromopentofullpositionwithspeedfromslowto fast
128
170
Shakefromopentohalfposition withspeedfromslowto fast
171
213
Shake. fromhalfpositiontofullpositionwithspeed fromslowtofast
214
255
29
33
47
DualEffectWheel1rotation
No rotation
0
0
Forwardsrotationfromslowtofast
1
127
No rotation
128
128
Backwardsrotation fromslowto fast
129
255
30
34
48
DualEffectWheel2rotation
No rotation
0
0
Forwardsrotationfromfastto slow
1
127
No rotation
128
128
Backwardsrotation fromslowto fast
129
255
31
35
49
LightFrost
LightFrostfrom0%to100%
0
255
32
36
50
HeavyFrost
HeavyFrostfrom0%to100%
0
255
33
37
51
Autofocus(Notrealizedyet)
WhileonlyIris,RotatingGoboWheel 1andRotatingGoboWheel2 arein use,the
projectorhasautomaticfocus function atsomedistance. Use "AutofocusCalibrations"
channel(34/38/52)tofocustheimage.Priority: GoboWheel2>GoboWheel1> IRIS
Thefollowing function canbe realized afterthefocuschannel(34/39/53)is disabled.
AutofocusOff
0
15
Autofocusfor5M
16
75
Autofocusfor10M
76
135
Autofocusfor15M
136
195
Autofocusfor20M
196
255
34
38
52
AutofocusCalibrations
focuscalibrationsup
0
127
focuscalibrationsdown
128
255
35
39
53
Focus
Linearlyfocusing
0
255

20
54
Focus Fine
Focusin16 precision
0
255
36
40
55
Zoom
Linearlyzooming
0
255
56
ZoomFine
Zoomin16Bitprecision
0
255
37
41
57
Pan
Panmovement
0
255
42
58
PanFine
Panmovementin16bitprecision
0
255
38
43
59
Tilt
Tiltmovement
0
255
44
60
Tilt fine
Tilt movement16bitprecision
0
255
39
45
61
Pan/Tiltspeed
fast Speed Mode
0
1
Pan&Tilt speed fromfast to slow
2
255
40
46
62
Power/Specialfunctions
No function:
0
4
Reserved
5
19
1.Toactivatefollowingfunctions,stayinDMX valueforat least5s
2.Thelamp isallowed tobeturnedoff5 minutesafterthelamp ison.Andthe lamp is
allowedtobeturned on5minutes afterthelampisoff.
3. Before the lamp on or lamp off, set “control by DMX”/Lamp Control/Config Setting
sas ONviacontrolpanel.
GraphicdisplayOn
20
24
GraphicdisplayOff
25
29
Reserved
30
34
Lamppower1200W
35
39
Lamppower1400W
40
44
Reserved
45
89
Pan/Tiltspeedmode
90
94
Pan/Tilttimemode
95
99
Reserved
100
129
LampOn
130
139
Pan/Tiltreset
140
149
Coloursystemreset
150
159
Gobo wheelsreset
160
169
Dimmer/Strobereset
170
179
Zoom/focus/frost/prismreset
180
189
Iris/dualeffectwheelreset
190
199
Totalreset
200
209
Reserved
210
229
Lamp Off
230
239
