PR Lighting PR-8170A User manual

1
XRLED 1500-W Spot
PR-8170A
This product manual contains important information about the safe installation and use of this projector.
Pleasereadandfollowtheseinstructions carefullyandkeepthismanualin asafeplace forfuturereference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1. SAFETYANDWARNINGS……………………………………………………………………………………
2. INSTRUCTIONS………………………………………………………………………………………………
3.APPEARANCE…………………………………………………………………………………………………
4.INSTALLATION…………………………………………………………………………………………………
5.SETUPANDCONFIGURATION………………………………………………………………………………
6.OPERATION MENU……………………………………………………………………………………………
7.DMXPROTOCOL………………………………………………………………………………………………
8.TECHNICALDATA……………………………………………………………………………………………
9.CIRCUITDIAGRAM AND.PCBCONNECTIONS……………………………………………………………
10COMPONENTORDERCODES………………………………………………………………………………
3
4
5
5
8
10
14
21
24
29
The following items are suppliedwiththeprojector and please check:
Name
Quantity
Unit
Remark
Gclamp
2
Pcs
XLRconnector
1
Set
Maleand female
Safetycord
2
Pc
User manual
1
Pc
Ω clamp
2
Pcs
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilstevery careistakeninthe preparationofthemanualwe reservetherightto changespecificationsin the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequencearisingfromthem.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / orthe unit are
in good condition before installation anduse. Should there be any damage caused by transportation, consult yourdealer and
donot usethe unit.Any damage causedby improperusewill notbeassumed bythemanufacturerand/ordealer.
Anyfuturetechnicalchangesarenotsubjecttofurthernotice.
Note: Forthe products made by Guangzhou PR lighting Ltd, the warranty forthe whole product is one yearstarting from
thedelivery date but the light source isnotwithinthewarranty.

3
1. SAFETYANDWARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety information hereinafter!
Thefollowingsafetysignsareusedinthe usermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking, check if there is transportation damage before usinga projector. Should there be any damage
causedbytransportation,consultyourdealeranddonotuseit.
●The manufacturer is not responsible for any loss caused by the user not following the manual or changing a
projectoras he/shelikes.
●Please be noted that the damagecausedbychangingaprojectoratwillisnot warranted.
● Do not hesitate to contact the dealer or the manufacturer if any questions or advice.
● Aprojector withIP20 canonlybe used indoors.
●For a projector with IP20, keep it away fromrain and moisture, excessive heat, humidity and dust. Do not allow
itscontact withwateror anyother liquids.
●A projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
running.
●.Any maintenance and repair ofa projector shouldn’t be carried out by a user and the user shouldn't open it for
anyrepairwork.
●Don’t look straightly into the light sources especially for epileptics, otherwiseeyeswillbeburned.
●Do notconnecta projector toanytypeofdimmerpack.
●Ifthelamp, lensandscreenprotectivecoveroftheaprojector haveobviousdamage, i.e.,to theextent thatit
hurtstheperformancelikecrackingordeformation.Pleasestop usingitandreplacethemwith theoriginalparts,
otherwise itsperformancewillbecompromised.
● For theinstallationlocationofaprojector, it shouldn’t be seen in the distance of less than 4 meters for a long
time.
●Before operation, please confirm that all covers (housing) are on and screws tightened. It’s forbidden to use a
projector whilecovers(housing)areoff .
●Keep thelampclean and do nottouchit withbare hands.
●Whileoperatingit,wearprotective itemslikeeyegoggles,gloves andetc..
●Anyelectricalconnectionmustbe carriedoutbyaqualifiedperson.
●Beforeinstallation,pleaseconfirmthevoltagesuppliedmatcheswhatisrequired foraprojector.
●Eachprojectormustbeproperlyearthed and installedasper relatedelectrical standards.
●Do notusepowercordwith its insulatordamaged andconnectthepowercord withother cables.
●If a projector is not used or under cleaning,, please hold the plug and unplug it.Do not unplug it forcefully or by
pullingthepower cable.
●Allpowercords mustconformto relatedsafetyandregulations.

4
●If a projector is not water and dust proof, while being operated it should not be under rains or in humidity to
avoidshortcircuit.
●Do not switch on and off a projector constantly in very short intervals, otherwise the light source’s and other
electrical parts’ lifewillbeshortened .
●There are safety cord holes at the bottomof the base ofa projector. In view of safety, please run the safetycord
suppliedthroughthesafetycord holes for safetysupport.
●Beforeanyinstallation,maintenanceandcleaningwork,pleaseensureaprojectorisdisconnected frompower
mains.
●Whilerunningnormally undernormalambienttemperature, thetemperatureofthe external surfaceofthemetal
housingofaprojectorincludingthatofthe heatsinkmay reach75℃atmaximum.
●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not
mean aprojector hassomedefects.
●While it running, don’t touch the metal housing to avoid being burned!
●Donotmounta projectordirectlyoninflammable surface.
●Donotprojectthebeamstraightlyoncombustibleitemsandtheminimum distancebetweena projector
andilluminateditemsis5m.
●Aprojector should be installed with good ventilation and the minimum distance between aprojector and a wall
is50cm.Atthesametime,pleaseensure the fansandairinletsandoutletsareworkable.
●Do not let the front lens under sunlight or other strong light sources at any angle, otherwise the danger of fire
canbecausedbythefocusedbeambythelensinsideaprojector.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. Ifthe temperature istoo high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,
restart theprojector.
The accumulation of oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is very
necessary to ensure a reliable use of it. Cooling fans need to be cleaned every 15days. Internal lens, reflector and hot mirror need
to becleanedperiodically tooptimize lightoutput.
Cleaning frequency is to be decided by operations and its environment. Use soft cloth and normal detergent for glass for
cleaning work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep
lenscleananddonottouchopticalparts withbarehands.
●Beforeanymaintenanceandcleaning,pleaseensuretheprojectisoffthepower
●Onlyqualifiedpersonisallowedtodo maintenance
●Duringmaintenanceandbefore maintenance, theprojector mustbe offpower.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens
whether itrunsor not
●Do notusealcoholorotherorganicsolvent toclean the housingto avoiddamage.
●Do notuseanysolventwithchemical elementsto clean colorfiltersorhotmirror.
●LUBRICATION
To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and
focuslensbelubricated every2 months. Highqualityand hightemperaturelubricant/grease isadvised..

5
●TROUBLESHOOTING
PROBLEM
ACTION
Theprojectorcan’t be switched on
Check ifthe fuse is burned
Check ifthe power cord isconnected well
Check if the switching power supply is bad or not connected well. A
professionaltechnicianisrequired fortherepair
Check if the control board is connected well. .Aprofessional technician
isrequiredfor therepair
Theprojectorcanbeswitchedon, but theLED
lamp’s brightness can’t be controlled
Check if the LED driver board is connected well. A professional
technicianisrequired fortherepair
Theprojector canbe switchedonnormally,but
notcontrolledbytheDMXcontroller
Makesure thatthe fixture’s start address is right
ReplaceorrepairtheXLRsignalcable.
Thebeamisnotbright anditsbrightness
decreasessharply
Makesurethefansare workingwellor fansandtheirshieldsarenotblocked
bydust.
Makesurethattheinternalopticsisclean.
Theprojectimageappearsto havea halo
Carefullycleanthe LEDlamp,opticallensesandothercomponents.
HeavilyDefectiveBeam
Check if lensareingood condition(notcracked)
Cleandustor greaseonthelens.
3. APPEARANCE
4. INSTALLATION
●RIGGING
During transportation, please lock the projector well; Before the use of projector please unlock the head. It’s forbidden to run the
projector withoutunlockPan andTilt
BASE
ARM
HEAD

6
Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to
each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of
the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
Always ensure that the structure that youare going to mount the projector is secure and is strong enough to supportthe weight ofthe
fixture.
WARNING:
●TheprojectorMUSTbeliftedorcarriedby the HANDLESinsteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●.Forsafety, itshouldnotbehungby itssides.
●POWERCONNECTIONS
Connectthepower cordas follows:
L(live)=brown
E(earth) =yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projector be connected withpower separately so that they maybeindividually switched on andoff.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordancewiththe standardsconcerned.
●Ifany questionsaboutthe electricalinstallation,donot continue butconsulta qualifiedelectrician.
● The lighting fixture iswith waterproof power socket, it should be equipped with same IPrating power
plug.
●DMXCONTROLCONNECTION
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
CLAMP
SAFETY
CORD
WARMING
Please run safety cord
through 2 safety holes for
safety

7
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the
projector)or5pinXLRplugsandsockets.TheXLR'sareconnectedasshowninthe figureabove.
Note: care should be taken to ensure that none of the pins touch the metallic bodyof the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminatorasshowninthe figurebelow.
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noisefromdisturbingandcorruptingthe DMXcontrol signals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged
intotheoutputsocketonthe lastprojector inthechain.The connectionsare illustrated below
●REPLACEMENTOFGOBOS
OUTPUTINPUT
Terminator OUTPUTINPUT DMX512
Controller
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2

8
Lockthetiltand unfasten6 fastfitscrewsin the front cove. Open the cover and you’ll see the structures as the figures above.
For the replacement of color filters, use the fingersto removethe filters and place newones.
For the rotating gobos: remove the rotatorbyhand; remove the gobo after the tightening spring forthe gobo is taken out. Place a new
gobo in the rotator and putback the spring. And ensure the spring is into the narrowend of the rotator, i.e., inner ring of the rotator. At
last, usea proper toolto pull the tighteningclipandput therotatorback tothe wheel with the help ofthe other hand.
Note:Donottouchthecolor filters,glass gobos withbarehand.Theremustbe softandcleanpaperorclothbetweenthehandandthe
glass gobo.Tightenthe6 fastfitscrewsafterthecoverisputback.UnlocktheTilt.
DANGER!
BEFORETHEREPLACEMENTOFGOBOANDCOLORFILTER,THEPROJECTORMUSTBEOFF
POWER.
5.SETUPANDCONFIGURATION
●FRONTPANELOPERATION
Theconfigurationandstartaddresscanbesetconvenientlyviapushbuttonandcolortouchscreen.
To view or change its setup, touch any white area of the screen or push the key OK for more than 3 seconds to unlock the
display(While only on battery, push OK key). After the unlocking, push ►keyto enter into function menus. Each main menu has its
Rotatinggobowheel1
Colorwheel
Rotatinggobowheel2

9
submenus and each submenu has a specific function. For details, please see the “OPERATION MENU” with following
the 6th point..
1. Inthepageoffunction setup,pushanykeyof ◄, ►, ▲and ▼oricon for thefunctiondesired.
2. At2nd ,3rd and4th level menus, key ◄means ESCAPE, key ►won’t function, key OK means ENTER.Push key OK to
save any changes o enter into submenus. Push key ▲or ▼to change numbers(plus or minus) or tap any item required
forchanges.
Push the left key or shortcut key X to go back to the upper level menu. If none pushed, the system will go back to initial display
automatically.
Shortcut keys: after the interface of FUNCTION MENU, the upper part is with menus for many functions. On the right, there are 4
shortcut keys,whichare←,→,lamp control or English/Chinese menus.
●DMX STARTADDRESS
Eachprojector must be givena DMX start address so that the correct projector responds to the correct controlsignals. This DMXstart
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3 DMXmodes. There are short mode ,standard mode and extended mode. For example standard mode
has 31 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 032, No. 3 projector’s address 063, No. 4
projector’s address94,and soon.
Launch theprojector. Press key OK more than 3seconds to unlock the display. After the unlocking, push key ►to enter into menus.
Afterselecting the sign of DMXsetting,pushOKkeyortap the screendirectlyandselectDMXaddressat2nd level menus.
Pushkey▲or▼or tap sign< or >to set the number desired.
Push OK keytoconfirm.
Pushkey◄and it willreturnto the upper menu
.
●DMXWIRELESSCONTROL
The projector has wirelesscontrol function with wirelessreceiver module andantennafor remote control.
The setupofitisbelow:
1. Enter into the projector’s menu. Select the menu “Config Settigns” via the keysof ▲and ▼
2. Select DMX control Mode---- Wireless First (Note: Do not select XLR ONLY). The DMX wireless control
function is activated.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press
“Enter” for the menu of Unlink Wireless under the upper level menu of Config Settigns.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR controlcable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
StartAddressesofallSlavesare001;Operationmodeof the Master can be set any mode for a Master’ and Slaves’ operation mode can
besetaccordingly.
AfterPowered on,thegroup willruninMaster/SlaveMode

10
6. OPERATIONMENU
1st LEVEL
2ndLEVEL
3rdLEVEL
4thLEVEL
5thLEVEL
Address
DMXAddress
Shortmode：1～486
Standard mode：1～482
Extendmode：1～475
IP Address
DefaultIPAddress
2.X.X.X/10.X.X.X
CustomIPAddress
X.X.X.X
SubNetMask
X.X.X.X
ArtNetUniverse
0-255
Reset
Total Reset
ReallyReset?
Confirm/Cancel
Pan&TiltReset
ReallyReset?
Confirm/Cancel
ColourSystemReset
ReallyReset?
Confirm/Cancel
GoboReset
ReallyReset?
Confirm/Cancel
Zo.Fo.Fr.Pr.Reset
ReallyReset?
Confirm/Cancel
OtherReset
ReallyReset?
Confirm/Cancel
ConfigSettings
DMXChannelMode
ShortMode27CH
Standard Mode31CH
ExtendedMode38CH
ViewSelected Mode
Strobe
…..
Signal Select
XLROnly
XLRFirst
WirelessOnly
WirelessFirst
WirelessIn/XLROut
ArtNet Only
ArtNetIn/XLROut
LossofDMX
Normaltimeout
Hold LastValue
DisplayConfig
DisplayMode
OffAfterDelay
OnAlways
DisplayInvert
InvertOFF
InvertON
InvertAuto
LanguageSetting
English
Chinese
TouchCalibration
TemperatureUnit
CelsiusDegree
Fahrenheit Degree
OUTPUTINPUT
Terminator OUTPUTINPUT
MasterSlaveSlave

11
Un-LinkWireless
ReallyUn-Link?
Confirm/Cancel
FactoryDefaults
RestoreDefaults?
Confirm/Cancel
OptionSettings
Pan/TiltSettings
PanDMX Invert
OFF/ ON
TiltDMX Invert
OFF/ ON
PanTiltSwap
OFF/ON
XYFeedback
OFF/ ON
Pan/Tiltmode
Speed/Time
InvertSettings
IrisInvert
OFF/ ON
ZoomInvert
OFF/ ON
CYMInvert
OFF/ ON
CTOInvert
OFF/ ON
DimmerSettings
Gamma Curve
Gamma 2.0/2.2/2.4/2.6
LEDRefreshRate
1200/2400/4800/10000/1200
0/15000/20000/25000Hz
DimmerSpeed
Fast/Medium/SlowSpeed
FanSettings
Standard/Theatre
Defaults
RestoreDefaults?
Confirm/Cancel
Information
ViewDMXValues
Channel Value
Strobe XXX
Dimmer XXX
DimmerFine XXX
CYMMacro XXX
Cyan XXX
Yellow XXX
Magenta XXX
CTO XXX
ColourWheel XXX
ColourWheelFine XXX
Iris XXX
IrisMacro XXX
Rot.Gobo1Wheel XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1RotationF XXX
Rot.Gobo2Wheel XXX
Rot.Gobo2Rotation XXX
Rot.Gobo2RotationF XXX
Prism XXX
PrismRotation XXX
EffectWheel XXX
EffectWheelR XXX
Frost XXX
Focus XXX
Zoom XXX
Pan XXX
PanFine XXX
Tilt XXX
TiltFine XXX
Pan/TiltSpeed&Time XXX
Power/SpecialFun XXX
Lamp Hours
LampHous=XXXXH
ResetLampHours
Total Hours
Total Hous=XXXXH
Temperature
DisplayBoardXX℃/F
Pan&TiltBoardXX℃/F
Driver Board1XX℃/F
Driver Board2XX℃/F

12
Driver Board3XX℃/F
Driver Board4XX℃/F
FanBoardXX℃/F
LEDSensorXX℃/F
SoftwareVersion
DisplayBoard
Sys=XXX
Boot=XXX
Pan&Tilt Board
Sys=XXX
Boot=XXX
Driver Board1
Sys=XXX
Boot=XXX
Driver Board2
Sys=XXX
Boot=XXX
Driver Board3
Sys=XXX
Boot=XXX
Driver Board4
Sys=XXX
Boot=XXX
FanBoard
Sys=XXX
Boot=XXX
ElectronicSN
ElectronicSN=
************
RDMDeviceLabel
XR LED 1500-WSpot
ANSIE1.20RDM
FanStatus
LEDFan
HeadFan1
HeadFan2
Service
ManualEffectControl
Strobe XXX
Dimmer XXX
DimmerFine XXX
CYMMacro XXX
Cyan XXX
CyanFine XXX
Yellow XXX
YellowFine XXX
Magenta XXX
MagentaFine XXX
CTO XXX
CTOFine XXX
ColourWheel XXX
ColourWheelFine XXX
Iris XXX
IrisFine XXX
IrisMacro XXX
Rot.Gobo1Wheel XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1Rotation F XXX
Rot.Gobo2Wheel XXX
Rot.Gobo2Rotation XXX
Rot.Gobo2RotationF XXX
Prism XXX
PrismRotation XXX
EffectWheel XXX
EffectWheelR XXX
Frost XXX
Focus XXX
FocusFine XXX
Zoom XXX
ZoomFine XXX

13
Pan XXX
PanFine XXX
Tilt XXX
TiltFine XXX
Pan/TiltSpeed&Time XXX
FactoryTest
Operation
Mode
DMXMode
ChangeOperationMode?
Confirm/Cancel
MasterMode
PresetMemory
ChangeOperationMode?
Confirm/Cancel
UserMemory1
ChangeOperationMode?
Confirm/Cancel
UserMemory2
ChangeOperationMode?
Confirm/Cancel
Stand-AloneMode
PresetMemory
ChangeOperationMode?
Confirm/Cancel
UserMemory1
ChangeOperationMode?
Confirm/Cancel
UserMemory2
ChangeOperationMode?
Confirm/Cancel
StaticScene
ChangeOperationMode?
Confirm/Cancel
User
Memories
EditUserMemory
EditUserMemory1
/
EditUserMemory2
SceneXX
（1~200
Scenes）
Paste?
Confirm/
Cancel
Strobe XXX
Dimmer XXX
DimmerFine XXX
CYMMacro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
YellowFine XXX
Magenta XXX
MagentaFine XXX
CTO XXX
CTOFine XXX
ColourWheel XXX
ColourWheelFine XXX
Iris XXX
IrisFine XXX
IrisMacro XXX
Rot.Gobo1Wheel XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1RotationF XXX
Rot.Gobo2Wheel XXX
Rot.Gobo2Rotation XXX
Rot.Gobo2Rotation F XXX
Prism XXX
PrismRotation XXX
EffectWheel XXX
EffectWheelR XXX
Frost XXX
Focus XXX
FocusFine XXX
Zoom XXX
ZoomFine XXX
Pan XXX
PanFine XXX
Tilt XXX
TiltFine XXX
Pan/TiltSpeed&Time XXX
FadeTime XXX
HoldTime XXX
DelayUnit MS/S/MIN
LinkToStep XXX
EditStaticScene
Paste?
Confirm/Cancel
Strobe XXX
Dimmer XXX
DimmerFine XXX
CYMMacro XXX
Cyan XXX

14
CyanFine XXX
Yellow XXX
YellowFine XXX
Magenta XXX
MagentaFine XXX
CTO XXX
CTOFine XXX
ColourWheel XXX
ColourWheelFine XXX
Iris XXX
IrisFine XXX
IrisMacro XXX
Rot.Gobo1Wheel XXX
Rot.Gobo1Rotation XXX
Rot.Gobo1RotationF XXX
Rot.Gobo2Wheel XXX
Rot.Gobo2Rotation XXX
Rot.Gobo2RotationF XXX
Prism XXX
PrismRotation XXX
EffectWheel XXX
EffectWheelR XXX
Frost XXX
Focus XXX
FocusFine XXX
Zoom XXX
ZoomFine XXX
Pan XXX
PanFine XXX
Tilt XXX
TiltFine XXX
Pan/TiltSpeed&Time XXX
Init UserMemory
ResetUserMemory1
ResetUserMemory?
InputPassword123
ResetUserMemory2
ResetUserMemory?
InputPassword123
ResetStaticScene
ResetStaticScene?
InputPassword123
Remark:
1. In the synchronous control ofmultiple projectors parameters canbe transmitted from the master including:DMX mode,
displaysetting,operation mode(usermemory);
2. allprojectorsAcceptingparameterswillautomaticallybe setto slavemode.
7. DMXPROTOCOL
Short
mode
Standard
mode
Extended
mode
FunctionDescription
DecimalLow
DecimalHigh
1
1
1
Strobe
Close
0
0
Pulsestrobespeedfromslowtofast
1
127
Strobespeedslowtofast
128
255
2
2
2
Dimmer
Close
0
3
Dimmerfromdarkto light(0-100%)
4
255
3
3
Dimmer Fine

15
Finedimmer
0
255
3
4
4
CYMMacro
ThefollowingfunctionscanbeusedafterCMY,CTO,and ColorWheels
channelsaredisabled
NoFunction
0
9
ColourMacro1
10
11
ColourMacro2
12
13
ColourMacro3
14
15
ColourMacro4
16
17
ColourMacro5
18
19
ColourMacro6
20
21
ColourMacro7
22
23
ColourMacro8
24
25
ColourMacro9
26
27
ColourMacro10
28
29
ColourMacro11
30
31
ColourMacro12
32
33
ColourMacro13
34
35
ColourMacro14
36
37
ColourMacro15
38
39
ColourMacro16
40
41
ColourMacro17
42
43
ColourMacro18
44
45
ColourMacro19
46
47
ColourMacro20
48
49
ColourMacro21
50
51
ColourMacro22
52
53
ColourMacro23
54
55
ColourMacro24
56
57
ColourMacro25
58
59
ColourMacro26
60
61
ColourMacro27
62
63
ColourMacro28
64
65
ColourMacro29
66
67
ColourMacro30
68
69
ColourMacro31
70
71
ColourMacro32
72
73
ColourMacro33
74
75
ColourMacro34
76
77
ColourMacro35
78
79
ColourMacro36
80
81
ColourMacro37
82
83
ColourMacro38
84
85

16
ColourMacro39
86
87
ColourMacro40
88
89
ColourMacro41
90
91
ColourMacro42
92
93
ColourMacro43
94
95
ColourMacro44
96
97
ColourMacro45
98
99
ColourMacro46
100
101
ColourMacro47
102
103
ColourMacro48
104
105
ColourMacro49
106
107
ColourMacro50
108
109
ColourMacro51
110
111
ColourMacro52
112
113
ColourMacro53
114
115
ColourMacro54
116
117
ColourMacro55
118
119
ColourMacro56
120
121
ColourMacro57
122
123
ColourMacro58
124
125
ColourMacro59
126
127
ColourMacro60
128
129
ColourMacro61
130
131
ColourMacro62
132
133
ColourMacro63
134
135
ColourMacro64
136
137
ColourMacro65
138
139
ColourMacro66
140
141
ColourMacro67
142
143
ColourMacro68
144
145
ColourMacro69
146
147
ColourMacro70
148
149
ColourMacro71
150
151
ColourMacro72
152
153
ColourMacro73
154
155
ColourMacro74
156
157
ColourMacro75
158
159
ColourMacro76
160
161
ColourMacro77
162
163
ColourMacro78
164
165
ColourMacro79
166
167
ColourMacro80
168
169
ColourMacro81
170
171

17
ColourMacro82
172
173
ColourMacro83
174
175
ColourMacro84
176
177
ColourMacro85
178
179
ColourMacro86
180
181
ColourMacro87
182
183
ColourMacro88
184
185
ColourMacro89
186
187
ColourMacro90
188
189
ColourMacro91
190
191
ColourMacro92
192
193
ColourMacro93
194
195
ColourMacro94
196
197
ColourMacro95
198
199
CMYcolour mixingfromslowto fast
200
255
4
5
5
Cyan
Cyan (Linear0-100%)
0
255
6
CyanFine
Cyanin16Bitprecision
0
255
5
6
7
Yellow
Yellow(Linear0-100%)
0
255
8
Yellow Fine
Yellowin16Bitprecision
0
255
6
7
9
Magenta
Magenta(Linear0-100%)
0
255
10
MagentaFine
Magentain 16Bitprecision
0
255
7
8
11
CTO
Linear adjust fromhigh to low
0
255
12
CTOFine
CTOin 16Bitprecision
0
255
8
9
13
ColourWheel
Continualpositioning
index0-360°
0
63
positioning
White
64
67
White/Color1(UV)
68
71
Color1(UV)
72
75
Color1(UV)/Color2(Red)
76
79
Color2(Red)
80
83
Color2(Red)/Color3(Pink)
84
87
Color3(Pink)
88
91
Color3(Pink)/Color4(Orange)
92
95

18
Color4(Orange)
96
99
Color4(Orange) /Color5(Green)
100
103
Color5(Green)
104
107
Color5（Green））/Color6（Blue）
108
111
Color6(Blue)
112
115
Color6(Blue)/ White
116
119
White
120
127
Clockwiserainboweffectrotationspeedfromslowto fast
128
191
Anti-clockwiserainboweffectrotationspeedfromslowtofast
192
255
10
14
ColourWheelFine
ColourContinualpositioningin 16Bitprecision
0
255
9
11
15
Iris
LinearIrisfromsmalltobig0-100%
0
255
16
Irisin16 bit
Irisin16bitprecision
0
255
10
12
17
IrisMacro
IrisMacrodisabled
0
10
IrisMacro1:frombigtosmallwithspeedfromslowtofast
11
74
IrisMacro2:fromsmalltobigwithspeedfromslowto fast
75
138
IrisMacro3:Iriscontractsfromslowto fast
139
202
IrisMacro4(Macro1atrandom)withspeedfromslowto fast
203
210
IrisMacro5(Macro2atrandom)withspeedfromslowto fast
211
218
IrisMacro6(Macro3atrandom)withspeed fromslowto fast
219
226
Open
227
255
11
13
18
Rotatinggobowheel 1
White
0
31
Gobo1
32
47
Gobo2
48
63
Gobo3
64
79
Gobo4
80
95
Gobo5
96
111
Gobo6
112
127
Clockwiserotation fromslowtofast
128
143
Anti-clockwiserotationfromslowto fast
144
159
Gobo1shakefromslowtofast
160
175
Gobo2shakefromslowtofast
176
191
Gobo3shakefromslowtofast
192
207
Gobo4shakefromslowtofast
208
223
Gobo5shakefromslowtofast
224
239
Gobo6shakefromslowtofast
240
255
12
14
19
Rotatinggobowheel 1 rotation
Indexing0-360°
0
128

19
Clockwiserotation fromslowtofast
129
188
Stop
189
195
Anti-clockwiserotation fromslowtofast
196
255
15
20
Rotatinggobowheel 1 rotationin16 bit
Rotatinggobowheelfinerotation
0
255
13
16
21
Rotatinggobowheel 2
White
0
31
Gobo1
32
47
Gobo2
48
63
Gobo3
64
79
Gobo4
80
95
Gobo5
96
111
Gobo6
112
127
Clockwiserotation fromslowto fast
128
143
Anti-clockwiserotation fromslowtofast
144
159
Gobo1shakefromslowtofast
160
175
Gobo2shakefromslowtofast
176
191
Gobo3shakefromslowtofast
192
207
Gobo4shakefromslowtofast
208
223
Gobo5shakefromslowtofast
224
239
Gobo6shakefromslowtofast
240
255
14
17
22
Rotatinggobowheel 2 rotation
Indexing0-360°
0
128
Clockwiserotation fromslowtofast
129
188
Stop
189
195
Anti-clockwiserotationfromslowtofast
196
255
18
23
Rotatinggobowheel 2 rotationin16 bit
Rotatinggobowheelfinerotation
0
255
15
19
24
Prism
NoPrism
0
16
Prism
17
255
16
20
25
Prismrotation
Prismindex
0
127
Prismstops
128
Rotationspeed fromslowtofast
129
191
Stoprotating
192
Reverserotation speed fromslowto fast
193
255
17
21
26
EffectWheel
No effect wheel
0
19
Effectwheelin
20
255
18
22
27
EffectWheelRotation
Forwardsrotationfromslowtofast
0
127

20
Reverserotation fromslowto fast
128
255
19
23
28
Frost
LightFrostfrom0%to100%
0
255
20
24
29
Focus
Linearly focusing
0
255
30
FocusFine
Focusin16precision
0
255
21
25
31
Zoom
Linearly zooming
0
255
32
ZoomFine
Zoomin 16 Bit precision
0
255
22
26
33
Pan
Panmovement
0
255
23
27
34
PanFine
Panmovementin16bitprecision
0
255
24
28
35
Tilt
Tiltmovement
0
255
25
29
36
Tiltfine
Tilt movement16 bit precision
0
255
26
30
37
Pan/Tiltspeed
FastSpeedMode
0
1
Pan &Tilt speed fromfast toslow
2
255
27
31
38
Power/Specialfunctions
No function:
0
4
Reserved
5
19
Toactivatefollowingfunctions,stayinDMXvalue foratleast5s
GraphicdisplayOn
20
24
GraphicdisplayOff
25
29
Reserved
30
44
Reserved
45
46
FanStandard Mode
47
48
FanTheatreMode
49
50
Reserved
51
52
DimmerFastSpeed
53
54
DimmerMediumSpeed
55
56
DimmerSlowSpeed
57
58
Gamma Curve2.0
59
60
Gamma Curve2.2
61
62
Gamma Curve2.4
63
64
Gamma Curve2.6
65
66
LEDRefreshRate1200Hz
67
68
LEDRefreshRate2400Hz
69
70
LEDRefreshRate4800Hz
71
72
