Prevue Hendryx 58501 User manual

58501 — 06/22 — A4 Made in China for Prevue Pet Produ ts, In ., 224 N Maplewood Ave, Chi ago IL 60612 USA • 1 [312] 243-3624 • www.prevuepet. om • ustomerservi e @ prevuepet. om
HARDWARE
& TOOLS :
KEY:
L = Left Side
B = Back
F= Front
R = Right Side
CR = Center/Roof
CG = Center/
Floor Grille
CT = Center/Tray
CS = Center/Shelf
Ferret Stack | O e Story
PARTS LIST
Instructions online at www.prevuepet.com
]Cg
]Cr
]L2
]L1
]Cs
]Ct
]B2
]B1
]F2
]F1
]R2
]R1
Hex Screws
18 pcs
Casters
4 pcs
Hex Key
CUSTOMER SUPPORT
Please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL customerservice @ prevuepet.com
These pieces are
interchangeable:
]L1 = ]R1
]L2 = R2
⁕
HOW TO TELL THE DIFFERENCE : Several parts and panels may look similar. Here’s how to tell the difference:
Cr
Cg
Cs
CENTER PANELS
The roof panel (CR) has an attached
sliding door on top, and a screw hole
on both ends of the frame.
The ground floor grille panel (CG)
has NO door and NO screw hole on
the ends.
The shelf (CS) is longer, and has
threaded screw holes on the front
and back corners of the frame.
58501
MODEL
#
PLATFORM
RAMP
HAMMOCK

Orient the front legs (F1)
with the windbell lock
facing forward.
The extended portion of
the tray hannel rail (L1)
dovetails into the inside of
the frame leg.
Attach frames together
with a hex screw through
the bottom hole.
Orient the ba k legs (B1)
with the tray channel
backstop facing the back.
Attach legs to sides with
hex screws in the bottom
holes.
Attach the shelf (CS) with
hex screws through the holes
near the base of the legs.
NO ADDITIONAL TOOLS REQ IRED • For best results, follow the Assembly Steps in the order presented.
× 8
KEY:
L = Left Side
B = Back
F = Front
R = Right Side
CR = Center / Roof
CG = Center /
Floor Grille
CT = Center / Tray
CS = Center /
Shelf
1PIECES
]L1
]R1
]F1
]Cs
]B1
interchangeable
windbell lock
Ferret Stack | O e Story
ASSEMBLY
Instructions online at www.prevuepet.com
CUSTOMER SUPPORT
Please contact Prevue Pet Products:
PHONE [phone]
ONLINE www.prevuepet.com
EMAIL customerservice @ prevuepet.com
58501
MODEL
#
2PIECES
]Cg
Turn the assembled unit
upside down. Fully insert
a aster in each leg.
Turn it right-side up and set
the floor grille (CG) in place.
CASTERS
58501 — 06/22 — A4.1 Made in China for Prevue Pet Produ ts, In ., 224 N Maplewood Ave, Chi ago IL 60612 USA • 1 [312] 243-3624 • www.prevuepet. om • ustomerservi e @ prevuepet. om

Assembly completed. {
58501 — 06/22 — A4.2 For more wonderful ages, toys, and a essories for ats, birds, hi kens, rabbits, ferrets, dogs and small animals, visit www.prevuepet. om
3PIECES Stand the side panel (L2) and the lower ba k
panel (B2) in position and attach together with a
hex screw at the top and bottom corners. →
Hook a ramp to the
underside of the platform.
←
Place the platform in the cage,
on the middle horizontal wire.
↓
Continue adding and attaching the right
side (R2) and front (F2)] panels with hex
screws at the top and bottom corners.
↘
→
Place the roof (CR) in position and attach
and attach with a hex screw on each end.
interchangeable
4PIECES
]L2]R2
]F2
]Cr
]B2
]Ct
× 10
Add the hammo k.
Rotate the windbell lock up and
slide the tray into the channels.
PLATFORM
HAMMOCK
RAMP
Hand-tighten the screws so they
remain loose. This will ease the
assembly of the roof.
⁕
Tighten the s rews over the entire age with the hex key until all s rews are snug.
⁕
