Qlight EMCL50U Series User manual

EMCL50U Series
EMCL50U - 24 - R
[Model number] [Voltage] [Color]
 | | |
• EMCL50U
• EMCL50U-BZ
• 24 - DC24V R-Red
A-Amber
G-Green
67
85dB
5525
Ø
50
19
98
M30
Model number Layers Voltage Current Certicate Weight Color
EMCL50U
Steady
EMCL50U-BZ
Steady w/built-
in buzzer
3DC24V 0.041A 0.19Kg
R-Red
A-Amber
G-Green
EMCL50U, EMCL50U-BZ
Product Specications
Industrial LED beacon
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
1. During wiring or maintenance, please completely turn o󰀨 the
power of the product. (Failure to follow this may lead to an electric
shock.)
2. Do not install the product in locations that subjects it to excessive
dust or water other than the conditions designated by the IP
protection ratings indicated for each product. (Failure to follow
these instructions may cause a re to the product, electric shock,
physical injury, malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service
is required, please contact your local Qlight contact point.
(Failure to follow these instructions may lead to re, electric shock,
or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow
these instructions may lead to re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives
or property, please make sure to have a double safety device.
(Failure to follow this may cause damage to property, re, electric
shock and loss of life.)
Precautions for Safety
Failure to follow the instructions below may cause a
loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation
around the product.
2. Please turn o󰀨 the power of the product immediately if it fails
to operate properly.
3. Carefully wire the product according to each product’s
specication.
4. Please be careful in preventing chemicals such as thinner,
benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause
malfunction or damage to the product, re, and electric
shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause
damage to property, the product, or malfunction of the
product that would void the warranty.
Dimensions
(Units : mm)
Ordering Specications
Please scan the QR code for more
detailed product information.
www.qlight.com

EMCL50U, EMCL50U-BZ
• EMCL50U series can be wired by using both external contact
and transistor.
• Wiring to transistor, use the PNP transis- tor. Please wire properly
based on wiring instructions.
EMCL50U, EMCL50U-BZ
Ø32 HOLE
EN - EMCL50U - 2305A
Lens(PC)
Nut(AI)
Housing(Al)
Power Power
Fuse Fuse
Steady Steady
External transistor-PNP
Red
Amber
Green
Buzzer
Red
Amber
Green
Buzzer
External contact
Red
Amber
Green
Brown
Black
Red
Amber
Green
Brown
Black
• M12 connector type
EMCL50U, EMCL50U-BZ
No. Color Wiring
1RED Pin 1
2AMBER Pin 2
3GREEN Pin 3
4Common Pin 4
5Buzzer Pin 5
5PIN CONNECTOR
12
34
5
EMCL50U, EMCL50U-BZ
Wiring Instructions Parts Denition/ Installation
Mounting Hole Specications Installation Environment and Protection Rating
• This product is designed for indoor use with protection rating of IP67.
• If the product is installed in locations that subject it to excessive dust
or water other than the designated IP protection rating
indicated, it may cause malfunction or damage to the product.
• For further information, please visit our website (www.qlight.com).
• Machine holes on the mounting surface referring to the
diagram below.
