Qlight SAMP User manual

1
Product SpecicationsOrdering Specications
Controllable AMP for Warning Light Bar
SAMP
SAMP - 12
[Model number] [Voltage]
| |
• SAMP • 12 - DC12V
• 24 - DC24V
Model
number
Voltage Current
Sound
pattern
Frequency/
Repeat time
Certicate
Weight
SAMP
DC12V
DC24V
4.150A
1.870A
Fire 300-700Hz/ 140cycle
- 1.09kg
Emergency 350-750Hz/ 14cycle
Ambulance 610-690Hz/ 50cycle
Buzzer 2,200Hz
Horn sound 595-1,040Hz
Please scan the QR code for more
detailed product information.
www.qlight.com
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o󰀨 the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s specication.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn o󰀨 the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, re, electric shock and loss of life.)

2
2-Ø7 HOLES(Slot hole)
1458.6
175
23
73
123
179
87
11
165
FITTING HOLES
24
7
SAMP
Amber fuse
(20A)
Red fuse(10A)
Power supply
SAMP
Housing(Steel)
Bracket
(Steel)
Microphone
Bolt
Nut
Dimensions
(Units : mm)
AMP CONNECTORELM CONNECTOR
ⴘ
ⴙ
ⴚ
ⴝ
ⴘ
ⴙ
ⴚ
ⴝ
ⴞ
ⴞ
78 6
342
AMP CONNECTOR
5
1
• Please connect AMP connector to ELM connector.
• Refer to the connector pin map above for wiring instructions.
• For the power unit, please make sure to use a fuse to ensure the product operates properly.
• Please wiring instructions to Warning Light Bar(ELM).
Wiring Instructions
(+)External power
(-)External power
Speaker
Warning light
Speaker
(+)External power (RED)
( - )External power (BLACK)
Speaker (BROWN)
Warning light(BLUE)
Speaker (GREEN)
Parts Denition/ Installation
• First, machine taps or holes on the mounting surface .
• The mounting hole of this product is 7mm in diameter.
• Insert the bolt through the hole of the product, and tighten the nut from the opposite side of the mounting surface.
• Please fasten the nuts until the bolts are tightened securely.
• Use a at washer and spring washer in the bolt assembly if the product will experience severe vibration and shock.
Power (BLACK)
Speaker (BROWN)
Warning light (BLUE)
Speaker (GREEN)

3
Power
Volume
Y / L W / L H / L
YELP WAIL
HI-LO
BUZZ HORN AUX
①
④ ⑥ ⑧⑤ ⑦ ⑨
② ③ ⑩
2-Ø8 SLOT HOLES
2-Ø13 HOLES
18
123
110
Number Functions Action
①
Emergency button Policy sound on, entire warning light bar
②
Alarm button Alarm sound on
③
Emergency sound/warning light button Emergency sound on, entire warning light bar
④
Policy sound button Policy sound on
⑤
Fire sound button Fire sound on
⑥
Emergency sound button Emergency sound on
⑦
Buzzer sound button Buzzer sound on
⑧
Horn sound button Horn sound on
⑨
AUX button use of external inputs
⑩
HOOK KEY Button for voice announcement when pressed down.
Product Functions
Mounting Hole Specications
• Machine holes on the mounting surface referring to the diagram below.

Qlight Co., Ltd. www.qlight.com | [email protected]
Head O󰀩ce | Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea
Tel. [phone](Toll free. [phone]) Fax. [phone]
Factory | 185-25, Mukbang-ro, Sangdong-myeon, Gimhae-si, Gyeongsangnamdo, Korea Tel. [phone](Toll free. [phone])
Qlight OverSEAs Sales Dept | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel : [phone]
Qlight Public Relations & Marketing Team O󰀩ce | 704 Nakdong-daero, Sasang-gu, Busan, Korea(Eomgung-Dong) Tel. [phone]
Qlight USA, Inc. www.qlight.com www.qlightusa.com | [email protected]
3003 North First Street, Suite #341, San Jose, CA 95134 USA Tel. +1 - 408 - 519 - 5740 Fax. +1 - 408 - 519 - 5739
SHANGHAI Qlight Electronic Co., Ltd. www.qlight.com www.qlightcn.com | [email protected]
China Factory/ Shanghai Sales O󰀩ce | #19, Nanda Road, Baoshan Area, Shanghai, China Tel. +86 - 21 - 6651 - 7100 Fax. +86 - 21 - 6315 - 3929
China Factory Site 2 (Qidong) | #33, Haiyan Road, Qidong High-tech Industrial Development Zone, Qidong, Jiangsu Province, China
Tel +86 - 513 - 8384 - 9999 Fax +86 - 513 - 8384 - 9910
Product Operation Inquiry / Customer Support [phone]
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : Suite #1510, STX-V Tower, 128 Gasan digital 1-ro, Geumcheon-gu, Seoul, Korea (Postal Code : 08507)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea (Postal Code : 50805)
For your safety
Specication and dimensions listed in this catalogue subject to change without notice for product quality improvement.
The newest product information is available on our website.(www.qlight.com)
Please read the instruction manual attached to the product carefully before installation and use.
www.qlight.com
EN - SAMP - 2106A
