Qlight ST45ML Series User manual

ST45 ( M ) L/56 ( M ) L/56 ( M ) EL/80(M)EL/80 ( M ) L SERIES
Thank you for purchasing Q.Light product. Please read this
manual carefully before installing this product for safe and long
use.
■POLE Mounting
▪ST45L/ ST56(E)L/ ST80(E)L LED Steady
▪ST45LF/ ST56(E)LF/ ST80(E)LF LED Steady/Flashing
▪ST45L-BZ/ ST56(E)L-BZ/ ST80(E)L-BZ
Build-in Buzzer LED Steady
▪ST45LF-BZ/ ST56(E)LF-BZ/ ST80(E)LF-BZ
Build-in Buzzer LED Steady/Flashing
■Direct Mounting
▪ST45ML/ ST56M(E)L/ ST80M(E)L LED Steady
▪ST45MLF/ ST56M(E)LF / ST80M(E)LF LED Steady/Flashing
▪ST45ML-BZ/ ST56M(E)L-BZ / ST80M(E)L-BZ
Build-in Buzzer LED Steady
▪ST45MLF-BZ/ ST56M(E)LF-BZ/ ST80M(E)LF-BZ
Build-in Buzzer LED Steady/Flashing
▪Easy color reformation and maintenance by employing connector
type lens assembling structure.
▪Long durability by employing LED of high brightness as light
source.
▪Volume(Buzzer Built-in Type): Max. 90dB/1m
▪Flashes(Flashing Type): 60-80/Min.
▪Protection Class: IP44(Build-in Buzzer type is IP23)
1) ST45(M)L/ ST45(M)LF/ ST45(M)L-BZ/ ST45(M)LF-BZ
Model
Layer
Voltage
Current
Weight(Pole)
Color
ST45(M)L
LED Steady
ST45(M)LF
LED
Steady/Flashing
ST45(M)L-BZ
LED
Steady/build-in
buzzer
ST45(M)LF-BZ
LED
Steady/Flashing/
Build-in Buzzer
1
AC/DC12V
0.040A
0.29Kg
RED-R
AC/DC24V
0.040A
0.29Kg
AC110V
0.024A
0.31Kg
AC220V
0.012A
0.31Kg
2
AC/DC12V
0.080A
0.33Kg
RED-R
GREEN-G
AC/DC24V
0.080A
0.33Kg
AC110V
0.026A
0.36Kg
AC220V
0.013A
0.36Kg
3
AC/DC12V
0.120A
0.38Kg
RED-R
AMBER-A
GREEN-G
AC/DC24V
0.120A
0.38Kg
AC110V
0.028A
0.40Kg
AC220V
0.014A
0.40Kg
4
AC/DC12V
0.160A
0.42Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
AC/DC24V
0.160A
0.42Kg
AC110V
0.031A
0.45Kg
AC220V
0.015A
0.45Kg
5
AC/DC12V
0.200A
0.47Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
WHITE-W
AC/DC24V
0.200A
0.47Kg
AC110V
0.033A
0.49Kg
AC220V
0.016A
0.49Kg
* Signal line current and a point of contact capacity (1 layer item)
Voltage
AC/DC12V
AC/DC24V
AC110V
AC220V
Signal current
0.040A
0.040A
0.024A
0.012A
Buzzer
current
0.015A
0.028A
0.021A
0.038A
■ST45L/ ST45LF/ ST45L-BZ/ ST45LF-BZ
(Upper diagram is POLE Mounting)
OPERATING MANUAL
LED Steady/Flashing Tower Lamp

■ST45ML/ ST45MLF/ ST45ML-BZ/ ST45MLF-BZ
(Upper diagram is Direct Mounting)
2) ST56(M)L/ ST56(M)LF/ ST56(M)L-BZ/ ST56(M)LF-BZ
Model
Layer
Voltage
Current
Weight(Pole)
Color
ST56(M)L
LED Steady
ST56(M)LF
LED
Steady/Flashing
ST56(M)L-BZ
LED
Steady/build-in
buzzer
ST56(M)LF-BZ
LED
Steady/Flashing/
Build-in Buzzer
1
AC/DC12V
0.120A
0.36Kg
RED-R
AC/DC24V
0.080A
0.36Kg
AC110V
0.048A
0.53Kg
AC220V
0.024A
0.53Kg
2
AC/DC12V
0.240A
0.45Kg
RED-R
GREEN-G
AC/DC24V
0.160A
0.45Kg
AC110V
0.057A
0.62Kg
AC220V
0.028A
0.62Kg
3
AC/DC12V
0.360A
0.53Kg
RED-R
AMBER-A
GREEN-G
AC/DC24V
0.240A
0.53Kg
AC110V
0.066A
0.77Kg
AC220V
0.033A
0.77Kg
4
AC/DC12V
0.480A
0.62Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
AC/DC24V
0.320A
0.62Kg
AC110V
0.075A
0.86Kg
AC220V
0.037A
0.86Kg
5
AC/DC12V
0.600A
0.70Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
WHITE-W
AC/DC24V
0.400A
0.70Kg
AC110V
0.082A
0.95Kg
AC220V
0.041A
0.95Kg
* Signal line and Buzzer current (1 layer item)
Voltage
AC/DC12V
AC/DC24V
AC110V
AC220V
Signal current
0.120A
0.080A
0.048A
0.024A
Buzzer
current
0.015A
0.028A
0.021A
0.038A
■ST56L/ ST56LF/ ST56L-BZ/ ST56LF-BZ
(Upper diagram is POLE Mounting.)
■ST56ML/ ST56MLF/ ST56ML-BZ/ ST56MLF-BZ
(Upper diagram is Direct Mounting)

3) ST56(M)EL/ ST56(M)ELF/ ST56(M)EL-BZ/ ST56(M)ELF-BZ
Model
Layer
Voltage
Current
Weight(Pole)
Color
ST56EL
ST56MEL
LED Steady
ST56ELF
ST56MELF
LED
Steady/Flashing
ST56EL-BZ
ST56MEL-BZ
LED
Steady/build-in
buzzer
ST56ELF-BZ
ST56MELF-BZ
LED
Steady/Flashing/
Build-in Buzzer
1
AC/DC12V
0.060A
0.35Kg
RED-R
AC/DC24V
0.040A
0.35Kg
AC110V
0.044A
0.51Kg
AC220V
0.022A
0.51Kg
2
AC/DC12V
0.120A
0.40Kg
RED-R
GREEN-G
AC/DC24V
0.080A
0.40Kg
AC110V
0.048A
0.55Kg
AC220V
0.024A
0.55Kg
3
AC/DC12V
0.180A
0.44Kg
RED-R
AMBER-A
GREEN-G
AC/DC24V
0.120A
0.44Kg
AC110V
0.053A
0.60Kg
AC220V
0.026A
0.60Kg
4
AC/DC12V
0.240A
0.49Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
AC/DC24V
0.160A
0.49Kg
AC110V
0.057A
0.64Kg
AC220V
0.028A
0.64Kg
5
AC/DC12V
0.300A
0.53Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
WHITE-W
AC/DC24V
0.200A
0.53Kg
AC110V
0.062A
0.69Kg
AC220V
0.031A
0.69Kg
* Signal line and Buzzer current (1 layer item)
Voltage
AC/DC12V
AC/DC24V
AC110V
AC220V
Signal current
0.060A
0.040A
0.044A
0.022A
Buzzer
current
0.015A
0.028A
0.021A
0.038A
■ST56EL/ ST56ELF/ ST56EL-BZ/ ST56ELF-BZ
(Upper diagram is POLE Mounting)
■ST56MEL/ ST56MELF/ ST56MEL-BZ/ ST56MELF-BZ
(Upper diagram is Direct Mounting)
4) ST80(M)L/ ST80(M)LF/ ST80(M)L-BZ/ ST80(M)LF-BZ
Model
Laye
r
Voltage
Current
Weight(Pol
e)
Color
ST80(M)L
LED Steady
ST80(M)LF
LED
Steady/Flashing
ST80(M)L-BZ
LED
Steady/build-in
buzzer
ST80(M)LF-BZ
LED
Steady/Flashing/
Build-in Buzzer
1
AC/DC12V
0.160A
0.64Kg
RED-R
AC/DC24V
0.080A
0.64Kg
AC110V
0.055A
0.79Kg
AC220V
0.027A
0.79Kg
2
AC/DC12V
0.320A
0.76Kg
RED-R
GREEN-G
AC/DC24V
0.160A
0.76Kg
AC110V
0.064A
0.91Kg
AC220V
0.032A
0.91Kg
3
AC/DC12V
0.480A
0.90Kg
RED-R
AMBER-
A
GREEN-G
AC/DC24V
0.240A
0.90Kg
AC110V
0.073A
1.05Kg
AC220V
0.036A
1.05Kg
4
AC/DC12V
0.640A
1.01Kg
RED-R
AMBER-
A
GREEN-G
BLUE-B
AC/DC24V
0.320A
1.01Kg
AC110V
0.084A
1.28Kg
AC220V
0.042A
1.28Kg
5
AC/DC12V
0.800A
1.14Kg
RED-R
AMBER-
A
GREEN-G
BLUE-B
WHITE-
W
AC/DC24V
0.400A
1.14Kg
AC110V
0.093A
1.41Kg
AC220V
0.046A
1.41Kg
* Sound signal line current and a point of contact capacity (1 layer
item)
Voltage
AC/DC12V
AC/DC24V
AC110V
AC220V
Signal current
0.160A
0.080A
0.055A
0.027A
Buzzer
current
0.015A
0.028A
0.021A
0.038A

■ST80L/ ST80LF/ ST80L-BZ/ ST80LF-BZ
(Upper diagram is POLE Mounting)
■ST80ML/ ST80MLF/ ST80ML-BZ/ ST80MLF-BZ
(Upper diagram is Direct Mounting)
3) ST80(M)EL/ ST80(M)ELF/ ST80(M)EL-BZ/ ST80(M)ELF-BZ
Model
Layer
Voltage
Current
Weight(Pole)
Color
ST80EL
ST80MEL
LED Steady
ST80ELF
ST80MELF
LED
Steady/Flashing
ST80EL-BZ
ST80MEL-BZ
LED
Steady/build-in
buzzer
ST80ELF-BZ
ST80MELF-BZ
LED
Steady/Flashing/
Build-in Buzzer
1
AC/DC12V
0.080A
0.52Kg
RED-R
AC/DC24V
0.040A
0.52Kg
AC110V
0.046A
0.69Kg
AC220V
0.023A
0.69Kg
2
AC/DC12V
0.160A
0.61Kg
RED-R
GREEN-G
AC/DC24V
0.080A
0.61Kg
AC110V
0.051A
0.78Kg
AC220V
0.025A
0.78Kg
3
AC/DC12V
0.240A
0.69Kg
RED-R
AMBER-A
GREEN-G
AC/DC24V
0.120A
0.69Kg
AC110V
0.057A
0.86Kg
AC220V
0.028A
0.86Kg
4
AC/DC12V
0.320A
0.78Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
AC/DC24V
0.160A
0.78Kg
AC110V
0.064A
0.95Kg
AC220V
0.032A
0.95Kg
5
AC/DC12V
0.400A
0.86Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
WHITE-W
AC/DC24V
0.200A
0.86Kg
AC110V
0.071A
1.03Kg
AC220V
0.035A
1.03Kg
* Signal line and Buzzer current (1 layer item)
Voltage
AC/DC12V
AC/DC24V
AC110V
AC220V
Signal current
0.080A
0.040A
0.046A
0.023A
Buzzer
current
0.015A
0.028A
0.021A
0.038A

■ST80EL/ ST80ELF/ ST80EL-BZ/ ST80ELF-BZ
(Upper diagram is POLE Mounting)
■ST80MEL/ ST80MELF/ ST80MEL-BZ/ ST80MELF-BZ
(Upper diagram is Direct Mounting)
Power lines and signal lines come out from the product. Please
connect them correctly after referring to below instruction.
■DC Steady(Built-in buzzer)
▪Signal line(Power line): UL1007-NO.22(0.3sq) 400mm
■DC Steady/Flashing, AC Steady, AC Steady/Flashing(Built-in
buzzer)
▪Power line: UL1015-NO.18(0.75sq)Ⅹ2C 400mm
▪Signal line: UL1007-NO.22(0.3sq) 400mm
▪In case of product using AC voltage, connect the line without
Polarity(wire color).
▪In case of product using DC voltage, black line is negative(-).
▸Steady(DC)-ST45(M)L-DC,ST56(M)EL-DC,ST56(M)L-DC,
ST80(M)EL-DC,ST80(M)L-DC
▸Steady(AC)-ST45(M)L-AC,ST56(M)EL-AC,ST56(M)L-AC
ST80(M)EL-AC,ST80(M)L-AC
▸Steady/Flashing(DC)
ST45(M)LF-DC,ST56(M)ELF-DC,ST56(M)LF-DC
ST80(M)EL-DC,ST80(M)LF-DC

▸Steady/Flashing(AC)
ST45(M)LF-AC,ST56(M)ELF-AC,ST56(M)LF-AC
ST80(M)EL-AC,ST80(M)LF-AC
This product is manufactured as kit type-light part and lens. Each
kit layer is assembled by connecting pin and pay deep attention
when assemble each kit accordingly. Please refer to following
drawing and explanation for right operating.
1) Make sure power is turned off before working.
2) Cover Removal
Unscrew the cover bolt①and remove the cover②.
3) Lens Kit Removal
Remove the lens kit as needed layer by layer by pulling up each
Lens kit③.
4) Lens Kit Change & Assembling
▪When assemble lens kits after lens kit change or color
reformation, refer to following drawing and make sure joining
point④(two vertical thick line on lens surface) and location of
connecting pin⑤.
▪Make sure whether the connecting pin is smoothly put into the
fitting hole⑥for safe joining.
▪Make sure whether rubber packing on top of lower lens kit is put
inside upper lens.
5) Assemble the product in reverse order of separating.
▪This product was manufactured with the structure for indoor use.
Outdoor use is prohibited.
▪Mount at the place where exists low vibration, low impact, low
moisture and low dust as long as possible. with vertical standing
shape.
▪Refer to below information and drill necessary mounting holes on
proper part of the product. (Make sure PCD from external view
drawing.)
▪Direct Mounting: Fix the product by using nuts(M4-3EA)
originally equipped on mounting bolt on bottom of the product.
▪Standard: Fix the product by using the nut originally equipped
with the pole.
▪Mount by using mounting bolts M8-2EA for L-type bracket
and mount by using another mounting bolts M5-4EA for Wall
Mounting-type and round type bracket.
■Direct Mounting
ST45ML Series
ST56ML Series
ST80ML Series
PCD 30, Ø5x3
PCD 40, Ø5x3
PCD 50, Ø5x3
▪Fix the product by using nuts(M4-3EA) originally equipped on
mounting bolt on bottom of the product.
Lens Kit Change & Color Reformation
Wiring Instruction -1

■POLE Mounting
ST45L/ST56L-Series
ST80L-Series
Standard
SCREW & NUT 18mm
SCREW & NUT 24mm
L-type bracket
LB18
LB24
Wall Mounting-
type bracket
LW18
LW24
round type bracket
SZ18
SZ24
bendable round
type bracket
SL18
SL24
* Please refer to below 6 Wiring Instruction-2 for the detail of bracket.
There are 4 main methods of Tower Lamp installation in
accordance with the locational condition or purpose of the
installation. By referring to the followings, select the method of
installation corresponding to the product.
Style
Size
18mm
SCREW & NUT
(standard)
Standard types
24mm
SCREW & NUT
(standard)
Standard types
LB18
LB24
LW18
LW24
SZ18
SZ24
SL18
SL24
▪Please do not connect power line to the signal line of
steady/flashing type. Do use a point of contact without power
line.
▪When changing lens kit, please do not pull with a strong power.
It can cause a break of lens kit.
▪When wiring is complete, make sure end of any unused wires
are insulated by tape. A short circuit of signal line can cause a
trouble.
▪If using voltage is seriously higher or lower than rated voltage,
it can reduce the self-life of the product or can cause a
problem on product operating. Make sure the using voltage
does not exceed +/-5% of the rated voltage.
▪If lens or body of the product is contaminated by chemicals
such as thinner, benzene, the product can be damaged,
discolored or deformed. Please be careful.
▪Do not strongly pull the wire out from the product. It can
cause a disorder.
Wiring Instruction -2
-
Caution

Situation
Main reason
Solution
Neither Lighting nor
Flashing
Wrong Wiring
Making Sure Wiring
Non- Lighting Partly
LED is partly damaged,
supplying higher
voltage then rated
voltage.
Making Sure Using
Voltage
Feeble Lighting
Supplying Voltage
Lower Than Rated
Voltage
Making Sure Using
Voltage
Lighting but
Non-Flashing
Wrong Wiring
Making Sure Wiring
No Sound
Problem with speaker
Contact Q.Light or Their
Agent
Neither Lighting nor
Flashing, No sound
Wrong Wiring
Making Sure Wiring
No Power Supply
Making Sure Power
Supply
Trouble shooting
Q-LIGHT CO., LTD.
http://www.qlightkr.com
E-mail : qlightk[email protected]
Overseas Marketing Team /Plant
Tel) 055-328-4082Fax)055-328-4083
178-1 Woogye-Ri, Sangdong-Myun, Kimhae-Si,
KyungNam, Korea
