Qlight S80L User manual

S80L / S80LK
Thank you for purchasing Q.Light product.
Please read this manual carefully before installing this system
for safe and long use of the product.
▪ Long self-life of light source by employing high-brightness LED
and suitable for machines having lots of vibration and impact..
▪ Excellent in diffusing signal light by employing unique
direct-diffusion system.
▪ Possible to select “steady light” or “flashing light” by using
built-in steady/flashing selection switch according to the
purpose of use.
▪ Material : Lens-AS, Body-ABS ▪ Protection Class : IP23
▪ Flashes(Flashing Type) : 60-80/Min.
1) S80L
▪ General Specification
Model Rated
Voltage Current Weight Flashes Color
DC12V 0.090A 0.21Kg
DC24V 0.080A 0.21Kg
AC110V 0.042A 0.38Kg
S80L
AC220V 0.021A 0.38Kg
60-80/Min.
Red-R
Amber-A
Green-G
Blue-B
▪ External View Drawing
2) S80LK
▪ General Specification
Model Rated
Voltage Current Weight Flashes Color
DC12V 0.090A 0.34Kg
DC24V 0.090A 0.34Kg
AC110V 0.042A 0.51Kg
S80LK
AC220V 0.021A 0.51Kg
60-80/Min.
Red-R
Amber-A
Green-G
Blue-B
▪ External View Drawing
Power line UL1015-NO.16(1.25sq) x 2C 400mm comes out from
the product.
▪ In case of product using AC voltage, connect the line without
polarity(wire color).
▪ In case of product using DC voltage, black line is negative(-).
Indoor Outdoor
▪ This product was manufactured with the structure for indoor use.
Installing in any direction is okay for indoor use.
▪ Outdoor use is limited at a place where no water or very little
water percolates. Mounting also should be done only with
vertical standing shape.
▪ Mount at the place where exists low vibration, low impact, low
moisture and low dust as long as possible.
▪ Refer to below information and drill necessary mounting holes on
OPERATING MANUAL
LED Steady/Flashing Light
All manuals and user guides at all-guides.com
all-guides.com

profitable part of the product.
(Make sure PCD from external view drawing.)
▪ S80L : Fix the product by using nuts(M4-3EA) originally
equipped on mounting bolt on bottom of the product.
▪ S80LK : Fix the product by using nuts(M5-3EA) originally
equipped on mounting bolt on bottom of the product.
This product has a built-in switch(1) on assembling board for
steady/flasing selection. Refer to following drawing and
explanation for right operating.
1) Lens Removal
Remove lens by turning it counterclockwise and make sure
related parts on assembling board.
2) Selecting Steady/Flashing Type
Choose steady light or flashing light by using Steady/Flashing
selection switch(1). “L” mode of the switch is steady type and
“LF” mode is flashing type.
3) Lens Assembling
Assemble the product in reverse order of separating.
▪ If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem
on product operating. Make sure the using voltage does not
exceed +/- 5% of the rated voltage.
▪ If lens or body of the product is contaminated by chemicals such
as thinner,benzene, the product can be damaged, discolored
or deformed. Please be careful.
▪ Do not give strong impact to the product. It can be a reason of
wire disconnection or short circuit.
▪ Do not strongly pull the wire out from the product. It can cause a
disorder.
Situation Main Cause Solution
Non- Lighting Partly
LED is Partly Damaged
Supplying Higher Voltage
than Rated Voltage
Making Sure Using
Voltage
Feeble Lighting Supplying Voltage Lower
Than Rated Voltage
Making Sure Using
Voltage
Wrong Operating L/LF
Selection Switch
Convert L/LF Selection
Switch
Lighting but
Non-Flashing Problem L/LF Selection
Switch
Contact Q.Light or Their
Agent
Wrong Wiring Making Sure Wiring
Neither Lighting nor
Flashing No Power Supply Making Sure
Power Supply
(S80L)
(S80LK)
Q-LIGHT CO., LTD.
http://www.qlightkr.com
E-mail : [e-mail]
Seoul Office (Domestic Sales & A/S)
Tel) 02-2679-6152
Ansung BD A-312, 410-13 Sindorim-Dong, Guro-Gu, Seoul
Overseas Marketing Team / Plant
Tel) 055-328-4082 Fax) 055-328-4083
Plant #1 : 178-1 Woogye-Ri, Sangdong-Myun, Kimhae-Si,
KyungNam, Korea
Plant #2 : 417-1 Geumsa-Dong, Geumjung-Gu, Busan
