SK(H)/ SKM(H)/ SKMP(H)
Stremlined Bulb/ Revolving Warning Light
SKMH - 24 - R
[Model
number] [Voltage] [Color]
| | |
• SK
• SKH
• SKM
• SKMH
• SKMP
• SKMPH
• 12 - DC12V
• 24 - DC24V
R-Red
A-Amber
G-Green
B-Blue
Please scan the QR code for more
detailed product information.
www.qlight.com
Model
number
Voltage Current
Bulb specications
Certicate Weight Color
Volts/
Watts
Conguration Part#
SK
DC12V 1.544A 12V15W
G23
15S
17
-
0.54kg
R-Red
A-Amber
G-Green
B-Blue
DC24V 0.766A 24V15W 18
SKH
DC12V 3.077A 12V35W
15S
halogen
39
DC24V 1.544A 24V35W 40
SKM
DC12V 1.544A 12V15W
G23
15S
17
0.58kg
DC24V 0.766A 24V15W 18
SKMH
DC12V 3.077A 12V35W
15S
halogen
39
0.59kg
DC24V 1.544A 24V35W 40
SKMP
DC12V 1.544A 12V15W
G23
15S
17
0.78kg
DC24V 0.766A 24V15W 18
SKMPH
DC12V 3.077A 12V35W
15S
halogen
39
DC24V 1.544A 24V35W 40
• Protection rating : IP54
• Ambient operating temperature : -20°C to +50°C
Ordering Specications
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o󰀨 the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s specication.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product
that would void the warranty.
1. During wiring or maintenance, please completely turn o󰀨 the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, re, electric shock and loss of life.)
Thank you for purchasing Qlight’s products. Please read this
user manual carefully prior to installation and operation to en-
sure safe and correct use.
Product Specications

2
SKM/ SKMHSK/ SKH
135
119
12
183
124
74
46
4-M4 BOLT
43 98 42
Ø10 CABLE ENTRY
(0.75sq)Ⱌ2P 2m
46
124
74
183
3135
119
9843 42
Ø10 CABLE ENTRY
4-Ø24 MAGNET
SKMP/ SKMPH
FULL AREA MAGNET
128
192
Ø10 CABLE ENTRY
124
142
119
(0.75sq)Ⱌ2P 2,000mm
183
• 보호등급 : IP54
• 사용온도 : -30℃ ~ + 50℃
Dimensions
(Units : mm)
• External power line - UL1015 AWG18(0.75sq)×2C 400mm (SK/ SKH only)
• Cigarette lighter plug, IEC42(0.75sq)×2P 2m
• SKM/ SKMH/ SKMP/ SKMPH models, please connect the cigarette lighter plug of the product to a cigarette lighter socket of a vehicle.
Wiring Instructions
Red
Black Power
Fuse
DC

3
Installation Environment and Protection Rating
• This product is designed for use with protection rating of IP54.
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
indicated(IP54), it may cause malfunction or damage to the product.
• In case of outdoor applications, install the product in the upright position. Do not install the product horizontal or upside-
down positions where water can potentially penetrate into the product and impact it’s operation.
• For further information, please visit our website (www.qlight.com).
Lens(PC)
Reector(PC/ STS)
Cigarette lighter plug
Light bulb
Parts Denition/ Installation
• First, machine holes on the mounting surface
(SK/ SKH only).
• Remove the M4 nuts from bolts and place the product through the mounting surface holes.
(SK/ SKH only)
• Fasten the ange nuts(M4) on the opposite side of the mounting
surface until the product is tightened securely
(SK/ SKH only).
• models have strong magnets at the base of the product that allows attachment to any metal surface.
Bulb Replacement Instructions/ Mounting Hole Specications
• Please wait at least 1 minute after turning o󰀨 the power
before replacing the bulb.
• In order to dissemble the bulb, please push down the bulb(①)
lightly and screw it counterclockwise.
• In order to put the bulb in to the unit, please place the bulb(①)
in the socket(②) and screw it clockwise while lightly pushing
down the bulb.
Assemble
bulb
Disassemble
bulb
①
②
• Machine holes on the mounting surface referring
to the diagram below.
98
74
46
4-Ø5 HOLES
■ Bulb Replacement Instructions
SK/ SKH SKMP/ SKMPH
■
Mounting Hole Specications
Housing(PC)
