Common Specications(QTG50/ QTG60/ QTG70)
• Modular steady/ashing type signal tower lights
• Excellent visibility from a distance with the use of a special color diffusing lens
• Can select from size selections of Ø50mm, Ø60mm, and Ø70mm to t your sophisticated
application needs
• The addition of modules and change in color arrangement can be achieved without the
use of tools by using the Lock-type structure
•
QTGA type offers a nifty integrated lens and cover for a simple aesthetically pleasing product
• A variety of mounting bracket selections for the pole mount type to t your location and
mounting needs
• Buzzer sound output : Sound volume of Max 85dB at 1m
•
Available in 2 customized options; sounds buzzer type and high volume(105dB) buzzer type
• Can be used with NPN open collector transistor driven input, which allows direct
connection to a PLC
• Flashing rate : 60-80 ashes/min
• Materials : Lens-PC, Housing-ABS, Pole-Al
• Ambient operating temperature : -30°C to +50°C
• Protection rating : Standard type-IP65, Built-in buzzer type-IP54
• Certicates : CE Compliant, UL Listed
• Compliant with RoHS directive
• Each modular color lens can be added without additional tools
QTG model uses a special contact structure for stable operation, the lens modules
lock into place by rotating the modular structures together. This allows for easy changes
to the color arrangement without any tools. Additional modules can be added.
• Buzzer volume is adjusted via the volume control lever
QTG type volume can be adjusted for each specic
working condition with the equipped buzzer volume
control lever at the bottom of the product.(-BZ type)
Clear and Strong Signal Light Emitted through the Colored Diffusion Lens
High volume buzzer (105dB) option can be tted to the top of the product.
(Customization)
High volume 105dB volume buzzer module fastened to the top of the product
provides 360 degree buzzer signal output which cannot be achieved with the
single directional buzzer.(Buzzer volume cannot be adjusted)
Integrated cover and lens model (QTGA50/ QTGA60/ QTGA70)
QTGA50/ QTGA60/ QTGA70 The sleek lens cover model is made of one
piece for a simple unied look.
Black body option available
Products can be congured with the black body and cover option. In addition,
the buzzer option is also available in a black color body and buzzer.
Can select from a variety of mounting brackets option to t your
application needs and build environment
There are a variety of mounting brackets options available depending on cost
and installation requirements.
1
2
3
4
1
4
3
2
Modular LED Tower Lights
QTG series

308 | www.qlight.com
• High buzzer module equipped on top(Lens should be within 4 layers)
• Black housing tower lights
• 2 buzzer sound types : Both prolonged (beep, beep)
and staccato (beep, beep, beep) buzzer output available
• Wall mount bracket options : Bracket structure
allows for threading through the bracket hole or
into the wall mount
• High buzzer module equipped on top/
Black housing tower lights.
Wall Mount Bracket
TWS45
Wall Mount Bracket
TWA45
Ordering Specication
• External power line standard : UL1015 AWG18(0.75sq)×2C 400mm
• Signal line standard : UL1007 AWG22(0.3sq) 400mm
• LED tower light can be wiring with external contact and transistor
※
Please refer to page 331-332 for detailed wiring instructions.
Wiring Instructions
65
54
85
5030
QTG50ML Ø50mm Direct Mount, LED Steady/Flashing Type
Signal/ Audible Line Current(per each layer )
Customization
QTG50ML series
Model number Layer Voltage Current Certicates Weight Color
QTG50ML
Steady
QTG50ML-BZ
Steady /w
built-in buzzer
QTG50MLF
Steady/Flashing
QTG50MLF-BZ
Steady/Flashing
/w built-in buzzer
QTGA50ML
Steady
QTGA50ML-BZ
Steady /w
built-in buzzer
QTGA50MLF
Steady/Flashing
QTGA50MLF-BZ
Steady/Flashing
/w built-in buzzer
1
AC/DC12V
AC/DC24V
AC110V-220V
0.080A
0.045A
Max 0.045A
DC24V only
DC24V only
0.19kg
0.19kg
0.29kg
● R-Red
2
AC/DC12V
AC/DC24V
AC110V-220V
0.160A
0.090A
Max 0.065A
0.27kg
0.27kg
0.37kg
● R-Red
● G-Green
3
AC/DC12V
AC/DC24V
AC110V-220V
0.240A
0.135A
Max 0.080A
0.36kg
0.36kg
0.46kg
● R-Red
● A-Amber
● G-Green
4
AC/DC12V
AC/DC24V
AC110V-220V
0.320A
0.180A
Max 0.100A
0.44kg
0.44kg
0.54kg
● R-Red
● A-Amber
● G-Green
● B-Blue
5
AC/DC12V
AC/DC24V
AC110V-220V
0.400A
0.225A
Max 0.120A
0.53kg
0.53kg
0.63kg
● R-Red
● A-Amber
● G-Green
● B-Blue
● W -White
※
AC type model has a free-voltage range of 100V-240V.
QTGA50ML series
• Customization
Voltage AC/DC12V AC/DC24V AC110V-220V
Signal line current 0.080A 0.045A Max 0.045A
Audible line current 0.016A 0.031A Max 0.030A
QTG50ML -3- 110/220
-RAG
[Model number] [Layer] [Voltage] [Color]
| | | |
• QTG50ML
• QTG50ML-BZ
• QTG50MLF
• QTG50MLF-BZ
• QTGA50ML
• QTGA50ML-BZ
• QTGA50MLF
• QTGA50MLF-BZ
• 1-1Layer
• 2-2Layers
• 3-3Layers
• 4-4Layers
• 5-5Layers
• 12-DC12V
• 24-DC24V
• 110/220
-AC110V-220V
● R-Red
● A-Amber
● G-Green
● B-Blue
●
W -White
Ø50mm LED Steady/Flashing Tower Lights
QTG50ML

Warning/
Signal/
Stackable
Explosion
Proof
Warning
Light Bar
Aviation
Obstruction
Lights
USB/ETN
Signal Tower
Lights
Wireless
Network
System
Vessels and
Heavy-Duty
Equipment
Signal Tower
Lights
Signal &
Electric Horn/
Speakers
Electric Horn/
Speakers
Industrial
LED Lights
www.qlight.com | 309
QTG50L series
QTGA50L series
• External power line standard : UL1015 AWG18(0.75sq)×2C 400mm
• Signal line standard : UL1007 AWG22(0.3sq) 400mm
• LED tower light can be wiring with external contact and transistor
※
Please refer to page 331-332 for detailed wiring instructions.
Wiring Instructions
Ordering Specication
QTG50L Ø50mm Pole Mount, LED Steady/Flashing Type
Customization
Mounting Bracket
85
5030
• 2 buzzer sound types : Both prolonged (beep, beep) and staccato (beep, beep,
beep) buzzer output available
• Customized pole length available
• High buzzer module equipped on top(Lens should be within 4 layers)
• Black housing tower lights
Model number Layer Voltage Current Certicates Weight Color
QTG50L
Steady
QTG50L-BZ
Steady /w
built-in buzzer
QTG50LF
Steady/Flashing
QTG50LF-BZ
Steady/Flashing
/w built-in buzzer
QTGA50L
Steady
QTGA50L-BZ
Steady /w
built-in buzzer
QTGA50LF
Steady/Flashing
QTGA50LF-BZ
Steady/Flashing
/w built-in buzzer
1
AC/DC12V
AC/DC24V
AC110V-220V
0.080A
0.045A
Max 0.045A
DC24V only
DC24V only
0.34kg
0.34kg
0.44kg
● R-Red
2
AC/DC12V
AC/DC24V
AC110V-220V
0.160A
0.090A
Max 0.065A
0.43kg
0.43kg
0.53kg
● R-Red
● G-Green
3
AC/DC12V
AC/DC24V
AC110V-220V
0.240A
0.135A
Max 0.080A
0.51kg
0.51kg
0.61kg
● R-Red
● A-Amber
● G-Green
4
AC/DC12V
AC/DC24V
AC110V-220V
0.320A
0.180A
Max 0.100A
0.60kg
0.60kg
0.70kg
● R-Red
● A-Amber
● G-Green
● B-Blue
5
AC/DC12V
AC/DC24V
AC110V-220V
0.400A
0.225A
Max 0.120A
0.68kg
0.68kg
0.78kg
● R-Red
● A-Amber
● G-Green
● B-Blue
● W -White
※
AC type model has a free-voltage range of 100V-240V.
65
54
• Customization
• High buzzer module equipped on top/
Black housing tower lights.
QTG50L - 3
-110/220 -
RAG
-LW18
[Model number] [Layer] [Voltage] [Color] [Mounting bracket]
| | | | |
• QTG50L
• QTG50L-BZ
• QTG50LF
• QTG50LF-BZ
• QTGA50L
• QTGA50L-BZ
• QTGA50LF
• QTGA50LF-BZ
• 1-1Layer
• 2-2Layers
• 3-3Layers
• 4-4Layers
• 5-5Layers
• 12-DC12V
• 24-DC24V
• 110/220
-AC110V-220V
● R-Red
● A-Amber
● G-Green
● B-Blue
●
W -White
• None
-Standard
• Bracket
-LB18 -LW18
-QZ18 -SZ18
-QL18 -SL18
-QLA18
Ø50mm LED Steady/Flashing Tower Lights
QTG50L
※
Please refer to page 34-39 for detailed dimensions.
Standard LB18 LW18 QZ18 SZ18 QL18 SL18 QLA18
Steel Steel PC PC Al PC Al PC

314 | www.qlight.com
QTG60ML : DC
QTG60MLF : DC
QTG60ML-BZ : DC
QTG60ML : AC
QTG60MLF-BZ : DC
QTG60MLF : AC
QTG60ML-BZ : AC
QTG60MLF-BZ : AC
QTG60L : DC
QTG60LF : DC
QTG60L-BZ : DC
QTG60L : AC
QTG60LF-BZ : DC
QTG60LF : AC
QTG60L-BZ : AC
QTG60LF-BZ : AC
Ø60
Ø60
Ø60
13.5
13.5
13.5
50
L1
12
12.5 50
85
123
L2
L3
50
50
12
12.5
12
12.5
Ø14 CABLE ENTRY
PCD 40
360˚/3-M4 BOLT
BUZZER VOLUME
CONTROL LEVER
BUZZER VOLUME
CONTROL LEVER
LAYER
1
2
3
4
5
L1
126
176
226
276
326
L2
161
211
261
311
361
L3
199
249
299
349
399
LAYER
1
2
3
4
5
L1
352
402
452
502
552
L2
387
437
487
537
587
L3
425
475
525
575
625
Ø60
13.550
Ø60
13.550
Ø60
13.550
L1
62
97
135
26.5200
26.5200
26.5200
L2
L3
Ø18 Ø18 Ø18
M18Ⱌ1.5 THREAD M18Ⱌ1.5 THREAD M18Ⱌ1.5 THREAD
QTG70ML : DC
QTG70MLF : DC
QTG70ML-BZ : DC
QTG70ML : AC
QTG70MLF : AC
QTG70ML-BZ : AC
QTG70MLF-BZ : DC
QTG70MLF-BZ : AC QTG70L : DC
QTG70LF : DC
QTG70L-BZ : DC
QTG70L : AC
QTG70LF : AC
QTG70L-BZ : AC
QTG70LF-BZ : DC
QTG70LF-BZ : AC
Ø70
Ø70
Ø70
13.5
13.5
13.5
50
50
50
L1
L2
L3
50
85
123
12
12.5
12
12.5
12
12.5
BUZZER VOLUME
CONTROL LEVER
LAYER
1
2
3
4
5
L1
126
176
226
276
326
L2
161
211
261
311
361
L3
199
249
299
349
399
Ø14 CABLE ENTRY
PCD 50
360˚/3-M4 BOLT
Ø70
Ø70
Ø70
13.5
13.5
13.550
50
50
L1
6228.5120
Ø24
M24Ⱌ1.5 THREAD M24Ⱌ1.5 THREAD M24Ⱌ1.5 THREAD
Ø24
L2
L3
97
135
28.5120
28.5120
Ø24
BUZZER VOLUME
CONTROL LEVER
QTG50ML : DC
QTG50MLF : DC
QTG50ML-BZ : DC
QTG50ML : AC
QTG50MLF-BZ : DC
QTG50MLF : AC
QTG50ML-BZ : AC
QTG50MLF-BZ : AC
QTG50L : DC
QTG50LF : DC
QTG50L-BZ : DC
QTG50L : AC
QTG50LF-BZ : DC
QTG50LF : AC
QTG50L-BZ : AC
QTG50LF-BZ : AC
LAYER
1
2
3
4
5
L1
116
156
196
236
276
L2
158
198
238
278
318
L3
204
244
284
324
364
LAYER
1
2
3
4
5
L1
344
384
424
464
504
L2
386
426
466
506
546
L3
432
472
512
552
592
Ø50
13.540
Ø50
13.540
Ø50
13.5
L112
50
92
12
12.5 12.5
L2
L3
L1
62
104
L2
L3
150200 28.5
200 28.5
200 28.5
40
138
12
12.5
BUZZER VOLUME
CONTROL LEVER
BUZZER VOLUME
CONTROL LEVER
Ø14 CABLE ENTRY
PCD 30
360˚/3-M4 BOLT
Ø50
13.540
Ø50
13.540
Ø50
Ø18 Ø18 Ø18
13.540
M18Ⱌ1.5 THREAD M18Ⱌ1.5 THREAD M18Ⱌ1.5 THREAD
LAYER
1
2
3
4
5
L2
309
359
409
459
509
L3
347
397
447
497
547
L1
274
324
374
424
474
Technical Diagram (Units : mm)
LED Steady/Flashing Tower Lights
QTG series

PB 1
Modular LED Signal Tower Lights
QTG50/ QTG60/ QTG70
54 65
85dB
5030
23
85dB
6030
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.




















Wiring diagrams Wiring diagrams
24V AC/DC
Steady/Flashing
• QTG(A)
☐☐
(
M)LF - Refer to this diagram for
buzzer type product
• QTG
☐☐
LF
Lens diameter
50(50mm) : QTG50(M)LF
60(60mm) : QTG60(M)LF
70(70mm) : QTG70(M)LF
110V/220V AC
Steady/Flashing
• QTG(A)
☐☐
(
M)LF - Refer to this diagram for
buzzer type product
• QTG
☐☐
LF
Lens diameter
50(50mm) : QTG50(M)LF
60(60mm) : QTG60(M)LF
70(70mm) : QTG70(M)LF
QTG50MLF
QTG50LF
QTG60MLF
QTG60LF
QTG70MLF
QTG70LF
QTG50MLF
QTG50LF
QTG60MLF
QTG60LF
QTG70MLF
QTG70LF
• In case of wiring with external contacts, refer to the wiring diagrams below according to your product’s type and voltage setting.
■
Wiring using external contact
Wiring Instructions
Red
Amber
Green
Blue
White
Brown
Black
White
Black
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Buzzer
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Buzzer
External contact External contact
Fuse Fuse
Steady
Steady
Flash
Power Power
Common Common
Common Common
Flash
Red
Amber
Green
Blue
White
Brown
Black
Gray
White
Black
NPN-Transistor
1
2
3
4
5
PNP-Transistor
1
2
3
4
5
PNP-Transistor
1
2
3
4
5
Flash
PNP-Transistor
1
2
3
4
5
• When using a transistor, please choose between the NPN or PNP type transistor which best matches the voltage and product type,
then connect them correctly according to the wiring diagrams below.
■
Wiring using transistor
Wiring diagrams
24V AC/DC
Steady/Flashing
• QTG(A)
☐☐
(
M)LF - Refer to this diagram for
buzzer type product
• QTG
☐☐
LF
Lens diameter
50(50mm) : QTG50(M)LF
60(60mm) : QTG60(M)LF
70(70mm) : QTG70(M)LF
110V/220V AC
Steady/Flashing
• QTG(A)
☐☐
(
M)LF - Refer to this diagram for
buzzer type product
• QTG
☐☐
LF
Lens diameter
50(50mm) : QTG50(M)LF
60(60mm) : QTG60(M)LF
70(70mm) : QTG70(M)LF
QTG50MLF
QTG50LF
QTG60MLF
QTG60LF
QTG70MLF
QTG70LF
QTG50MLF
QTG50LF
QTG60MLF
QTG60LF
QTG70MLF
QTG70LF
Red
Amber
Green
Blue
White
Brown
Black
White
Black
Red
Amber
Green
Blue
White
Brown
Gray
Black
White
Black
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Buzzer
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Buzzer
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
External Transistor-PNP External Transistor-PNP
Fuse Fuse
Steady Steady
Power Power
Flash Flash
Common Common
Common Common

2PB
Installation Environment and Protection Rating
• This product is designed for indoor use with protection rating of IP65(standard type) and IP54(buzzer type).
• If the product is installed in locations that subject it to excessive dust or water other than the designated IP protection rating
indicated(IP65), it may cause malfunction or damage to the product.
• For further information, please visit our website(www.qlight.com).
How to Change Lens Kit
• Disassembling lens kits
①
Twist the upper lens kit in a
counter-wise direction so the
“I” mark from both kits align.
②
Disassemble by removing the
upper lens kit from the lower
one.
• Assembling lens kits
①
Put the two lens kits together
by aligning the upper lens’ “I”
mark and the lower lens’ “I”
mark together.
②
Lock the two kits by twisting the
upper lens kit in a counter - wise
direction so the upper lens’ “
◁
”
mark aligns with the lower lens’
“I” mark.
Lens modules are connected through
cone-shaped contact point. In case
the contact point is damaged, it may
cause a contact failure.
※Cautions
Contact
Point
