RAB HAZL34-40 User manual

INSTRUCTIONS
HAZL34™ INSTALLATION



IMPORTANT
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.



WARNING: Make certain power is OFF before installing or maintaining xture. No user serviceable parts inside.
CAUTION: TO REDUCE THE RISK OF IGNITION OF HAZARDOUS ATMOSPHERES, DISCONNECT THE LUMINARE FROM SUPPLY CIRCUIT
BEFORE OPENING. KEEP TIGHTLY CLOSED WHEN IN OPERATION.
CLASS I DIV. 2 GROUP A, B, C, D.
MIN. 90°C SUPPLY CONDUCTORS.
REFER TO TOOL LIST ON PAGE #4


 Driver Box Cover Silicone Covers and
loosening Captive ScrewTether Cable
the Driver Box Cover
2. Remove the threaded Knockout Plug (Fig. 1). Attach the Pendant
(by others) to the Fixture (Fig. 2)
the Set Screw to secure the Pendant (Fig. 3).
3. Pendant through the Knockout,
connect to the Terminal Block (Fig. 2) 
Note: Torque value 4.4 inch-lbs.
4.  Driver Box CoverCaptive Screws (Fig.4) and
2.5 N. M.Silicone Covers.
WARNING: To prevent wiring damage or abrasion, do not expose
wiring to edges of sharp objects.
HAZL34-40
HAZL34-80
Drive Box Cover Captive
Screws
Tether Cable
Figure 15
  
Knockout Plug
Set Screw
Terminal Block
Pendant
HAZL34-120
Silicone Covers
Silicone Covers
Pendant

INSTRUCTIONS
HAZL34™ INSTALLATION



 
2. Fasteners (by others) the Mounting Surface
Fig. 5 & 6).
3. 
 through the Conduit Entry
(Fig. 6). Connect to the Terminal Block (Fig. 2) 
Note: Torque value 4.4 inch-lbs.
4. 
 Loosen the Pivot Screw and Locking Screw (Fig. 7)
to desired angle (Fig. 8). Tighten Pivot Screw and Locking Screw.




Fasteners
(by others)
Mounting Surface
Conduit Entry Plugs
Locking Screw
Pivot Screw
Yoke Bracket
Yoke Bracket

INSTRUCTIONS
HAZL34™ INSTALLATION



Figure 13

 
2. (by others) 
3. CM Brackets using the Pivot (Fig. 12).
4.  through Conduit Entry (Fig. 6).
Connect to the Terminal Block (Fig. 2) Note: Torque value 4.4 inch-lbs.
 
 Loosen the Pivot Screw and Locking Screw (Fig. 12)(Fig. 8). Tighten Pivot Screw and Locking Screw.


Spring Hooks
(provided)

Fasteners
(by others)
Pivot Screw
Locking Screw
440mm
(17- 5/16”)
154mm
(6 -1/16”)
 
2. Install Rings or Eye-bolts (by others) to hang the ChainSpring Hooks (provided) 
3.  Chain (Fig. 10).
4.  Conduit Entry (Fig. 6).
 Terminal Block (Fig. 2) Note: Torque value 4.4 inch-lbs.

Rings or
Eye-Bolts
(by others)
Chains


CM Brackets


INSTRUCTIONS
HAZL34™ INSTALLATION


HAZL34 - IN - 0623
Easy Answers
rablighting.com
Visit our website for product info
Tech Help Line
Call our experts: 888 722-1000
e-mail
Answered promptly - sal[email protected]
Free Lighting Layouts
Answered online or by request
© 2023 RAB LIGHTING Inc.
RAB WARRANTY: RAB’s warranty is subject to all terms and conditions found at rablighting.com/warranty.


CAUTION: Be sure xture temperature is cool enough to touch.
Do not clean or maintain while xture is energized.
 
2. 
 

2. 
Note: These instructions do not cover all details or variations in equipment nor do they
provide for every possible situation during installation, operation or maintenance.

(only)

in 
 
2. 
3. 
4. 
 
 

PINK
LIGHT
FIXTURE
Vaux 12V
YELLOW
GROUND
GROUND
( - ) DIM V
( + ) DIM V
COMMON
LINE BLACK
WHITE
PURPLE

P-100542

 LED Fixture
Assembly (Fig. 13).
2. Wire Guard on the LED
Fixture Assembly.
3. Secure the Wire Guard(provided)  
Note: Torque value 0.7 N. M.
Wire Guard
LIST OF TOOLS FOR INSTALLATION
LED Fixture
Assembly
Pre-drilled
Screw Holes
Wire Guard


• 
• 
• 
• (14mm) 
• 
