RAB SWISHFA -2X2 User manual

INSTRUCTIONS
SWISH® FA INSTALLATION





IMPORTANT
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.



WARNING: Make certain power is OFF before installing or maintaining xture. No user serviceable parts inside.
CAUTION: For proper weatherproof function all gaskets must be seated properly and all screws inserted and tightened
rmly. Apply weatherproof silicone sealant around the edge of the ceiling mounting box and/or junction box. This is
especially important with an uneven ceiling surface. Silicone all plugs and unused conduit entries.



To mount in an insulated or non-insulated ceiling - 

 Rotate and slide the Housing 
Tee-Grid Bar 

  Grid Clips (4) against the
Tee-Grid Bar to secure the Housing 
 
HousingSupport Wires (supplied by
others) through the Support Wire Hole 
4.  Access Plate 

  Access Plate and remove the Access Plate
(Fig. 1) Conduit Knockouts on the
Access Plate 

 (Fig 4). Push all
 Splice Box. 
WARNING: To prevent wiring damage or abrasion, do not
expose wiring to edges of sheet metal or other
sharp objects.
7.  Access Plate and tighten Access Plate Screw.
 

SWISHFA -2X2 SWISHFA -2X4
Tee-Grid
Bar
Access Plate
Screw
Housing
Grid Clip
Support Wire
(supplied by others)
Conduit Knockouts
Firmly bend Grid
Clips against the
Tee-Grid Bar
Tee-Grid Bar
Housing
nominal 4” Support Wire Hole
Support Wire
(supplied by others)
Tee-Grid Bar
Access Plate
Grid Clips (4)

INSTRUCTIONS
SWISH® FA INSTALLATION


 





(Fig. 4).
 LINE 
 COMMON 
  GROUND 
GROUND 

4. 
 


Factory Settings: 2X2 - 29W, 4000K, 2X4 - 39W, 4000K
 Locate the Selector Switches

 (CCT)(W) 
(Fig 6).

Fig. 4

CAUTION: Be sure xture temperature is cool enough to touch.
Do not clean or maintain while xture is energized.
 
solution.
 
 

 
PINK
LIGHT
FIXTURE
Vaux 12V
YELLOW
GROUND
GROUND
( - ) DIM V
( + ) DIM V
COMMON
LINE BLACK
WHITE
PURPLE
Selector Switches
Color Temperature (CCT) Selection Switch
Power (W) Selection Switch
2X2
2X4

INSTRUCTIONS
SWISH® FA INSTALLATION


SWISH FA-IN-1122 RAB WARRANTY: RAB’s warranty is subject to all terms and conditions found at rablighting.com/warranty
 


CAUTION: FOR BATTERY BACKUP FIXTURE. 
in BATTERY. 

BATTERY
 (Fig. 7).
NOTE: 



CAUTION: 




 

 

 

 
 

Note: These instructions do not cover all details or variations in equipment
nor do they provide for every possible situation during installation, operation
or maintenance.
 UNSWITCHED HOT HOT AC
 UNSWITCHED circuit, connect UNSWITCHED and
SWITCHED lines together.
 SWITCHED circuit, connect SWITCHED HOT

4. DIMDIM
leads to dimming connections.
 
 
connect the BATTERY.
7. 

charging.
 

9. 

 
illuminated indicating that the BATTERY
 
(internal battery)


 
automatically returns to charging mode.
