Rapid Racking DES24 User manual

Rapid2
Economy storage
Assembly instruction
AIST003

RAPID 2 ECONOMY STORAGE DES24 & DES30
IMPORTANT - ASSEMBLY INSTRUCTIONS
Tools required: Rubber mallet
AIST003
A
1Fit plastic feet E to uprights A.
2Assemble both ends first - Aand C. Starting
from the top allow 6 clear holes between each
shelf support C.
3Join both ends using front and rear
beams B.
4Add shelves D.
C
D
B
A
C
B
E
BAY ASSEMBLY
We advise the use of protective
gloves and goggles, or eyeglasses
when assembling this product.
If you have any problems whatsoever please call 01285 686868 where a team of experts will be pleased to help.

1600 mm Uprights
4 of
COMPONENTS
RAPID 2 ECONOMY STORAGE DES24 & DES30
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIST003
ABFront and rear beams
12 of
1
1
2
4
4
5
5
3
Keep heavier items
on the bottom shelves
Do not climb
on your shelving
Make sure it is on a
level and even floor
Keep your
shelving dry
Tie plates recommended
with more than one bay
BOX ASSEMBLY
C380mm side beams
12 of
D
Shelves
6 of
E
Plastic feet
4 of
SAFETY
DES24 unit - 1220mm x 380mm
DES30 unit - 1525mm x 380mm
DES24 unit 1220mm
DES30 unit 1525mm
