Rapid Racking WIDE SPAN User manual

1
ASSEMBLY
INSTRUCTIONS
TESTED TO
If you have any problems with this product or its assembly, please contact The Rapid Racking Team on 01285 686868 for help and advice.
Uprights frames
2 of:
A
CFront and rear beams
EShelf supports
▪Not required for 890mm or 1250mm widths
▪600 mm deep bay: 2 per level
▪Other depths 3 per level
DChipboard shelves
1 per shelf level, width and depth to suit
BFloor fixing, 2per frame
2000mm, 2500mm
or 3000mm W
600mm or 900mm D
FBeam safety clips
2 per beam - 4 per level
SAFETY
COMPONENTS
Keep heavier items on the
bottom shelves.
Do not climb
on your shelving.
Make sure it is on a
level and even floor.
Keep your
shelving dry.
WIDE SPAN(MULTIPLE PACKAGES)

2
If you have any problems with this product or its assembly, please contact The Rapid Racking Team on 01285 686868 for help and advice.
ASSEMBLY - MULTIPLE SIZES
D
A
C
E
C
B
F
1. Join the upright frames using front and rear beams C, at the desired level.
2. Insert the beam safety clips F.
3. Add shelf supports Ewhere required, and evenly space.
4. Place shelves Donto front and rear beams C.
5. Secure the unit to the oor with the xings B.
NB: This shelving system is not designed to be loaded by mechanical means, e.g. fork lift truck.
Always load and unload by hand.
Safety advice: We advise you wear protective gloves when assembling this product.
Tools required: Rubber mallet, electric drill and metric spanners.
Posts (1) can be levelled
vertically with shims (5) if
necessary.
Floor xing with sleeve anchors
(2) is required for bays 2.5m
high or over.
1
2
5
4
3
