Rapid Racking Rapid1 Heavy duty shelving User manual

Rapid1
Heavy duty shelving
Assembly instruction
AIS001

If you have any problems whatsoever please call 01285 686868 where a team of experts will be pleased to help.
RAPID 1 HEAVY DUTY SHELVING Multiple sizes
IMPORTANT - ASSEMBLY INSTRUCTIONS
Tools required: Rubber mallet
AIS001
A
1Fit plastic feet F to uprights A.
2Assemble both ends first - Aand Bstarting from
the top. For optimum clear entry allow 14 clear
holes between top shelf and 2nd shelf, 14 clear
between 2nd and 3rd shelf, this will leave
15 clear holes between 3rd and bottom shelf.
3Tap together using rubber mallet.
4Join both ends using front and rear beams C.
5Add shelf supports D.
6Add shelves E.
7Fit plastic caps to uprights G.
ASSEMBLY - 4 shelf bay 1980mm high
We advise the use of protective
gloves and goggles, or eyeglasses
when assembling this product.
A
B
B
C
CD
*
D
*
E
F
G
E
1 of per level up to 915mm wide
2 of per level up to 1220 mm wide
For bays of extra height and levels follow the above procedure, assembling both ends A& B
to give the best clear entry for your application.

If you have any problems whatsoever please call 01285 686868 where a team of experts will be pleased to help.
Uprights
4 of
COMPONENTS
RAPID 1 HEAVY DUTY SHELVING Multiple sizes
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIS001
ABSide beams
Either 380mm, 455 mm, 610mm,
760 mm, 915 mm or 1220mm
2 of per shelf level
CFront and rear beams
DShelf supports
Either 380mm, 455 mm,
610 mm, 760mm, 915 mm or 1220 mm
1 of per shelf level
(2 of per shelf level on wide bays 1220mm.
A third shelf support can be added later to
increase weight loadings if required - please
ask for details).
EShelves
FPlastic feet
4 of
GPlastic top caps
4 of
1 of per shelf level, widths and
depths to suit beam
4 Level bay units - 1980mm H
5 Level bay units - 2440mm H
6 Level bay units - 3050mm H
7 Level bay units - 3660mm H
9 Level bay units - 4575mm H
Either 915mm, 1220mm, 1525mm, 1830mm, 2134 mm
or 2440mm
2 of per shelf level
(Beam section - Lup to 1525mm, 1830mm and above)
Keep heavier items
on the bottom shelves
Do not climb
on your shelving
Make sure it is on a
level and even floor
Keep your
shelving dry
Tie plates recommended
with more than one bay
SAFETY
