Rapid Racking DS25 User manual

Rapid1
archive storage
Assembly instruction
AIST001

RAPID 1 ARCHIVE STORAGE
DS25, 35, 45 & DD50, 70, 90
IMPORTANT- ASSEMBLY INSTRUCTIONS
Tools required: Rubber mallet
AIST001
A
1Fit plastic feet to uprights.
2Assemble both ends first -Aand C. Starting
from the top allow 15 clear holes between each
shelf support C.
3Join both ends using front and rear beamsB.
4Add shelf supports D.
5Add shelves E.
B
D
C
A
B
C
E
F
BAY ASSEMBLY
We advise the use of protective
gloves and goggles, or eyeglasses
when assembling this product.
If you have any problems whatsoever please call 01285 686868 where a team of experts will be pleased to help.
The beam slots are tapered
and fit into the slots
as shown
C
M
Y
CM
MY
CY
CMY
K
AIST001 Rapid 1 Archive Storage.pdf 18/10/07 16:34:27

Uprights
COMPONENTS
RAPID 1 ARCHIVE STORAGE DS25, 35, 45 & DD50, 70, 90
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIST001
AB1830mm front and
rear beams
1
2
2
3
5
4
7
67
6
8
8
9
9
Keep heavier items
on the bottom shelves
Do not climb
on your shelving
Make sure it is on a
level and even floor
Keep your
shelving dry
Tie plates recommended
with more than one bay
BOX ASSEMBLY
C
DShelf supports
DS units - 455mm
DD units - 915mm
EShelves
FPlastic feet
4 of
SAFETY
DS units - 1830 mm x 455mm
DD units - 1830 mm x 915 mm
DS25/DD50 - 1448 mm
DS35/DD70 - 2109 mm
DS45/DD90 - 2743 mm
Side beams
DS units - 455mm
DD units - 915mm
Rapid 1 Archive Storage, Component Check List
DS25 DD50 DS35 DD70 DS45 DD90
Uprights ‘A’ 444444
Front/Rear Beams ‘B’ 66881010
Side Beams ‘C’ 66881010
Shelf Supports ‘D’ 334455
Chipboard Shelf ‘E’ 334455
Plastic Foot ‘F’ 444444
Archive Box ‘G’ 25 50 35 70 45 90
