Rapid Racking Garment Rack User manual

Garment Rack
Assembly instruction
AIS020

GARMENT RACKING
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIS020
1Fit feet Fto uprights A.
2Assemble both ends first - Aand B. Starting
from the bottom insert the first side beam Bin
the first two holes. Insert the second beam B
leaving 26 clear holes from the first beam. Insert
the top beam at the top of the upright A. Tap
together with a rubber mallet.
3Add the front and rear beam Cto the bottom
level and place the chipboard shelf Eon to the
beams.
4Insert 2 front and rear garment rails Dat the
top of the uprights A.
5Insert the remaining front and rear garment rails
at the desired height. (2 of for 1980mm H, 4 of
for 3048mm H)
ASSEMBLY
A
We advise the use of protective
gloves and goggles, or eyeglasses
when assembling this product.
Tools required: Rubber mallet
B
Hanging rail
locating system
A
B
C
D
D
E
F
If you have any problems with this product or its assembly, please contact your local distributor or
call our helpline on 01285 686868 where a team of experts will be pleased to help.

Uprights
COMPONENTS
GARMENT RACKING
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIS020
A
Keep heavier items
on the bottom shelves
Do not climb
on your shelving
Make sure it is on a
level and even floor
Keep your
shelving dry
Tie plates recommended
with more than one bay
x4 up to 2440 mm high
x4 over 2440 mm high
BSide beams
610 mm
6 off per bay
SAFETY
1980 mm or 3048 mm
4 off per bay
CFront and rear beams
915 mm, 1220mm or 1524mm
2 off per shelf level
DFront and rear garment rails
915 mm, 1220mm or 1524mm
4 off per 1980mm bay
6 off per 3048mm bay
EChipboard shelf
1 off FFeet
4 off
If you have any problems with this product or its assembly, please contact your local distributor or
call our helpline on 01285 686868 where a team of experts will be pleased to help.
