RASOR DS503MT Mounting instructions

ELECTRIC SCISSORS
USE MANUAL
DS503MT

2
EN
COMPANY
ACKNOLEDGEMENT
Dear Customer,
thank you for choosing a Rasor®Elettromeccanica S.r.l. product.
Rasor®has been a reference point in the field of cutting systems in the textile, clothing,
furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for
years. Its production has been always synonymous with reliability attested by many of
satisfied customers.
Rasor®quality system supervises all the company activities in order to provide the Customer
with a service that meets its needs and expectations in terms of product quality, delivery
reliability and stock of finished products.
All the parts of the devices have been planned and produced to guarantee an optimum
performance. In order to keep the high quality level and the long reliabilty of the Rasor®
products, it is recommended using only original spare parts and to contact the head office
for any maintenance work.
Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by Luigi Spinelli. For more
than sixty years it has been producing automatic cutting systems, cutting units for textile
applications and electric and pneumatic cutters.
Initially considered as a point of reference for cutting systems in the
textile applications, the Rasor®products are nowadays widely used in
other fields: chemical, automotive, nautical and sport sectors and in
furniture manufacturing.
Rasor®can rely on the professional continuity of three generations,
thanks to the precious support of the promoting partner, to his passion, dedication and great
experience of seventy years.
The main characteristicof Rasor®is that each working phase, startingfrom the manufacturing
of the product up to its packing and delivery is carried out in Rasor®premises by qualified
operators who have professionaly grown up following the spirit of the company and of its
founders. This ensures the high quality which Rasor® has always considered as essential since
the beginning of its activity.
Following the innovative spirit mentioned above, our company is constantly focused on the
improvement of the product quality, on the study and development of new materials and
technologies.

EN
3
1. GENERAL SAFETY RULES
This manual is an integral part of electric scissors DS503MT and must be carefully
read before using it since it gives important indications with regards to its safe
installation, use and maintenance. Keep it with care.
Before using electric scissors DS503MT, read carefully the following general
safety rules.
• PACKAGING.
After taking off the packaging make sure that the machine is intact. In case of
doubt do not use it and contact an authorized service centre. Do not leave
pieces of packaging (plastic bags, foam polystyrene, boxes, etc.) within the
reach of children or disabled persons since they are potential sources of danger.
• AVOID DANGEROUS ENVIRONMENTS.
Prevent the electric scissors DS503MT components from coming in contact
with damp or wet surfaces.
•KEEPCHILDRENAWAY.
Unauthorized persons, in particular children, must be kept away fromthe working
area.
•FEEDCABLE.
Prevent the feed cable from coming in contact with hot objects, pointed surfaces
or sharp edges. Never pull the feed cable of the machine. It must never be
replaced by the user. If necessary contact professionally qualified staff.
• KEEP THE WORKING AREA ALWAYS IN ORDER.
The workplace must always be kept in order and well lightened; liquids or oil
traces must not be present.
• ALWAYS USE ELECTRIC SCISSORS DS503MT PROPERLY.
Use the scissors only to carry out the works they have been designed for; do
not use them improperly.
• OBSERVE THE USE OF THE TOOLS.
Do not cut excessively thick materials and always check blade conditions.
• AVOID ACCIDENTAL STARTINGS.
Before connecting electric scissors DS503MT, make sure that everything is
installed properly.
•CLOTHING.
Do not use large clothes or accessories that might get stuck in the moving
parts.
• GOGGLES AND PROTECTIVE METAL MESH GLOVES.
Always use goggles, protective metal mesh gloves approved by Rasor®during
use and maintenance operations (according to UNI EN 388:2004 standard).
• SPARE PARTS.
During maintenance and replacement operations use only original spare parts.
Blade maintenance must be only performed by Rasor®technicians.
• INSTALLATION.
Any installation that is not in conformity with these specifications could jeopardize
your safety and cancels the warranty.

4
EN
ALL RIGHTS ARE RESERVED ACCORDING TO THE
INTERNATIONALCOPYRIGHTCONVENTIONS,
The reproduction of any part of this manual, in any form, is forbidden without the
prior written authorization of Rasor®Elettromeccanica S.r.l.
The content of this guide can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this
manual to make it as complete and comprehensible as possible.
Nothing contained in this manual can be considered as a warranty, either
expressed or implied - including, not in a restrictive way, the suitability warranty
for any special purpose. Nothing contained in this manual can be interpreted as a
modification or confirmation of the terms of any purchase contract.
Rasor®Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of
explosions and at high risk of fire and they cannot cut wet or damp materials. Moreover,
they cannot work in case of rain.
In case of damage or malfunction, electric scissors DS503MT must not be used until the
Customer Care Technical Service has repaired them.
The original configuration of the electric scissors must not be changed at all.
On receiving the machine make sure the supply corresponds to what has been ordered.
In case of non-compliance immediately inform Rasor®.
Also make sure the scissors have not been damaged during transport.
Customer CareTechnical Service
WARNING
The installer and the maintenance man must know the content of this manual. Although
the main features of the machine described in this manual are not subject to change,
Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details
and accessories it deems necessary to improve the machine or to meet manufacturing or
commercial requirements at any time and without being obliged to update this manual
immediately.
Informative letter
For any information, please contact
RASOR®ELETTROMECCANICAS.r.l.
Via V. Caldesi, 6; 20161,MILANO (MI) - ITALY
Phone: [phone]; Fax: [phone]
e-mail: [email protected]
web: www.rasor-cutters.com
WARNING

EN
5
7
2. TRANSPORT AND PACKING
The electric scissors are delivered in a carrying case, inside which there are various options.
The code of the ordered product and its serial number are indicated outside the package (see
picture 1). The following accessories are contained in a bag inside the package:
1) Heptagonal blade (7 sides);
2) Hexagonal wrench for grinding wheel nut tightening;
3) Greasetube;
4) Brushes for electric motor;
5) Fuse;
6) Drift for blade disassembly;
7) Butterfly wrench for blade nut disassembly.
2
23
3. PLATE DATA
The manufacturer's identification and EC STANDARD 2006/42/EC conformity plate (see picture
below) is located on the front part of the electric scissors.
The plate must not be removed at all, even if the machine is resold. Always refer to
the serial number written on the plate itself when contacting the manufacturer.
Several safety warnings are printed on a card which is applied to the electric scissors feeding
cable; such warnings must be strictly followed by everyone dealing with the machine. The
company is not to be held responsible for damage to property or accidents to
people which might occur if the above-mentioned warnings are not observed. In
such a case, the operator is the only person responsible.
6
5
4
READ THE
INSTRUCTION
MANUAL
DO NOT
REMOVE
THE
SAFETY
DEVICES
HIGH
VOLTAGE
SHEARING
RISK
USE
METAL
GLOVES
USE
GOGGLES
1
1
Class II double insulation
Serial number
Year of production
Model
Electric
data
DS503MT
220 230 50 60 0.25 60
1800
ST

6
EN
4. PRODUCT DESCRIPTION
1
2
3
4
56
8
9
11
10
12 7
13
14
15
16
The fixture described in this manual are electric scissors model DS503MT which are used in
order to quickly cut composite materials, in particular the fiber glass. They are extremely
versatile, light and precise in the cutting operation. Thanks to the use of a thin foot and an
effective cutting system with heptagonal, circular or decagonal blade, it is possible to use the
electric scissors for the precise trimming of molds, stuffed materials, leathers and laminated
materials. One special feature of electric scissors DS503MT is their ability to sharpen the blade
in each moment without disassembling it by means of a grinding wheel mounted on the
scissors head. After carrying out this operation, it is possible to start cutting again.
The electric scissors DS503MT are extremely light (they weight only 900g) and handy and
allow carrying out quick and precise cuts, even with curve profiles. A high power motor,
perfectly balanced, with ahigh number of revolutions and totallyfree of maintenance, reduces
the vibrations to the minimum. For this reason the electric scissors comply with European
Directive No. 2002/44/EC concerning the risks deriving from mechanical vibrations.
The mechanical parts are made of high-quality steel and bronze and require lubrication after
several working hours.
1 Enabling push button 9 Emery grinding wheel
2 Spiral cable gland 10 Sharpening button
3 Spiral electrical cable 11 Blade protection guard
4 Two-pole Contur plug 12 Motor support
5 Supporting foot 13 Motor casing
6 Polygonal blade 14 Worm screw adjustment
7Greaser15Referencepoint
8 Brush holder cap 16 Carbide counterblade
Device components

EN
7
7. FIELD OF APPLICATIONS
6. RUMOR LEVEL
NOTE
It is advisable for electric scissors owners to verify the compliance with the standard concerning
safety of workers: Italian legislative decree 81/08.
The use of ear protecting devices is compulsory.
The maximum acoustic pressure level emitted by electric scissors DS503MT is about 60 dB (A).
Noise tests have been carried out in compliance with Standard UNI EN ISO 11202:2010.
The device noise levels, measured at different distances (without any sound wave filtering
system), vary in the extent of few db (A).
Electric scissors DS503MT have been designed, manufactured and assembled to cut every
kind of fabrics or materials, with the exception of metal, plastic or wood, by means of rotary
circular, decagonal or heptagonal blades.
This equipment must not work:
- in areas prone to explosions;
- in presence of fine dust or corrosive gases;
- on wet or damp materials;
- to cut plastic, metal and wooden materials.
It is forbidden to use electric scissors DS503MT for purposes different from the
above-mentioned ones.
5. TECHNICAL FEATURES
The technical data are only indicative and they can be changedwithout notice.
50 mm with carbide counterblade
1.800 rev./min
about 8 mm
60 W
0,5 A
900 g
1300 g
1,5 m
LUX 200
< 2,5 m/s2
0 ~ 55°C
10 ~ 95% without condensate
Temperature
Humidity
Weight (with package)
Electrical cable length
Minimum luminosit
y
for workin
g
o
p
erations
Vibrations at the start up
Cutting working depth
Motor power
Weight (with feeding cable)
Electric scissors DS503MT features
Blade diameter
Blade speed
Max. absorption
K190 steel circular blade
Extra steel heptagonal blade
HSS Germany steel heptagonal blade
HSS steel heptagonal blade
HSS steel heptagonal blade covered with
Teflon
®
Extra steel Germany heptagonal blade
HSS steel heptagonal blade
Solid carbide heptagonal blade
HSS steel decagonal blade
50SEXT
50SEXT G
50SHSS
Features of the available blades
50CK
50DHSS
50SGHSS
50CHSS
50SHSSTF
50SMD

8
EN
9. RESIDUAL RISKS
Even though the electric scissors are safe, operators must pay attention to preserve their and
other people’s safety.


At the end of the working operations, the motor could be very hot.

The cutting blade can work even when the protective device is disassembled.
8. USE WARNINGS
We recommend following the indications below in order to always work in safety conditions.
•All the operations must be carried out complying strictly with the safety rules of the
country where the machine is to be installed.
•It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of
the electric scissors.
•The Customer undertakes to comply with and make his staff observe all the rules and
regulations in force concerning safety, prevention of accidents and health in the work
place. Therefore, the Customer assumes the responsibility to strictly follow all the rules
and regulations in force, as well as the special provisions in force in sport and public
installations the Customer declares to know after receiving all the relative necessary
information.
•The electric scissors work also without their safety protective device. This
protective device must NEVER be removed.
•Always check the resistance of the material to be cut and the kind of blade which is being used.
•The Customer shall equip his own personnel with all the individual safety protections for
the execution of the works, as well as with the ones which might be prescribed by the
Manufacturer due to specific danger conditions of the plant or of the area where the
personnel must work.
•Only one operator must use the electric scissors always standing behind the guide handle.
Do not make any adjustment while the blade is working or while the electric plug is
connected.
•Always pay attention to the electric cable position to prevent it from being cut or damaged
by the blade.
•It is allowed to assemble electric scissors DS503MT on machines O.E.M. on condition
that their original structure is not modified. Otherwise, the intervention must be certified
by Rasor®.

EN
9

A
10. USE
3
To use the electric scissors manually, proceed as follows:
1) Lay the material to be cut on a table;
2) Connect the scissors to the power supply;
3) Put the material on the cutting foot;
4) Enable the enabling push button (see picture 3);
5) Push the electric scissors in the desired direction,
being careful to keep the material in front of them
as stretched as possible and preventing it from
curling in the front part of the scissors.
NOTE
The thrust on the electric scissors must be as uniform as
possible. To carry out linear cuts with precision (and to
follow predetermined paths), we also recommend using
the arrow point (see point “A” in figure 4).
11. MOTOR FUSE REPLACEMENT
In order to replace the motor fuse, proceed as follows:
1) Disconnect the scissorsfrom the powersupply;
2) Remove the screw from the fuse cover (see
point “A” figure 5);
3) Take out the glass fuse by means of the proper
pliers supplied (see figure 6);
4) Verify its integrity (see figure 7) and, in case, install a new
fuse checking the correct amperage;
5) Close the cover and tighten the screw.
WARNING
Never use the scissors when the fuse cover is open.
Risk of electric shock.
4
5
6
7
A

10
EN
13. EMERY GRINDING WHEEL ADJUSTMENT
After using the machine for some hours without
interruption, or if the machine cutting capacity is reduced,
it is necessary to sharpen the blade. To carry out this
operation, start the blade and press emery grinding wheel
“2” on the blade itself (by means of push button “1”, as
shown in figure 9) for 3-4 seconds.
Repeat this operation 2-3 times.
The emery grinding wheel can slide along its seat (see
figure 10) in order to vary the sharpening angle. If the
blade, aftervarious sharpening operations, hasa chamfer
(sharp perimeter) with an excessive length (higher than
1.5 mm), it is necessary to slightly move the emery
grinding wheel away from the blade. In order to do this,
it is sufficient to slightly loosen the screws without
removing them, making the emery grinding wheel slide
toward direction A, and then tighten the two screws
again.
12. REPLACEMENT OF THE MOTOR BRUSHES
Electric scissorsDS503MT are provided with a high power
permanent magnet motor and torque. For this reason it
is necessary to check periodically if the carbon brushes
are worn in order not to jeopardize the motor operation
and its duration period. Unscrew the caps located on the
cover by means of a slotted screwdriver; withdraw the
carbon brushes, check if they are worn and, if needed,
replace them. Assemble the two caps again, being careful
to hold them in a perfectly vertical position, and screw
them completely only when you are sure that the mouth
is the correct one.
Note: The brush must be inserted with its black part
directed inside the motor.
Note: A slight difference in the wear of the two brushes is absolutely normal in a permanent
magnet motor. Nevertheless, in the event that the difference between them is excessive, it is
necessary to apply to a technical center for a complete check of the fixture.
Before carrying out any operations on the electric scissors, make sure that the supply plug is
not connected to the mains.
WARNING

9
1
1
A
8
2

10

EN
11
14. LUBRICATION
Every 3-4 working hours, it is necessary to lubricate the
gear pair. In order to carry out this operation, remove
protective plug “A” located on the head of the electric
scissors and fill it with the grease supplied. Screw plug
“A” again a few turns. Screw plug “A” a few turns every 2-
3 working hours (see figure 11).
The blade must never be dirty with grease or oil.
WARNING A
If the blade is no more able to cut (even after repeating the
sharpeningoperationseveraltimes)it isnecessarytoreplace
it. In order to carry out this operation, use butterfly wrench
“1” and drift “3” locking the blade (shown in figure 12). In
order to replace the blade, proceed as follows:
1) Use some protective gloves in compliance with
Italian Legislative Decree 81/08.
2) Remove safety protection “B”, by unscrewing the two
slotted screws “A” by means of a screwdriver (not
supplied by the manufacturer), as shown in figure 13.
3) Insert drift “3” (see figure 14) in hole “C” in order
to lock the blade (the hole in the blade must
correspond to the hole in the structure).
4) Use butterfly wrench “1” in order to unscrew nut
“D” and remove blade “E” (see figure 15).
5) Replace the worn blade with the new one “2”,
being careful to center the blade on the shaft, in
the correct position, and remember to assemble it
with its sharp side (the one with the writing Rasor)
positioned towards the external side of the electric
scissors.
6) Assemble all the components again and carry out
some cutting and sharpening tests.
15. BLADE REPLACEMENT
13
3
1
2
3
14
C
1
15
A
A
B
1
D
E
11
12

12
EN
17. SPARE PARTS / EXPLODED VIEW
16. TROUBLESHOOTING


SOLUTION
Verify that the cutting foot has the correct position and
thrust force on the blade
Check the counterblade integrity
Check the kind of fabric
Sharpen the blade
Check the fabric thickness
Check the compatibility between blade and fabric
Make sure that the motor turns correctly
Reduce the feeding speed
Carry out the lubrication
Disassemble the blade and remove the material residues
Replace the protection fuse
Check the motor brushes

PROBLEM
The electric scissors are noisy
The scissors start slowly, work intermittently or
do not start
The fabric is not cut or it
g
ets stuck between the
blade and the counterblade
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
F 5001 SPIRAL ELECTRICAL CABLE F 5019CPL 220 V COMPLETE ROTOR F 503101 GEAR SCREW ADJUSTMENT F 5051 EMERY GRINDING WHEEL HINGE
F 5004 PUSH BUTTON SPRING F 5020 FAN F 50310F1 FUSE 1A F 5051/1 EMERY GRINDING WHEEL HINGE
SPRING
F 5005 PUSH BUTTON LEVER F 5021 6x19x6 MOTOR BEARING F 5032 GEAR RING CENTRAL PIN F 5051/2 SCREW FIXING THE HINGE SPRING
F 5006 UNIPOLAR ENABLING PUSH BUTTON F 5022 SPRING FIXING THE BEARING F 5033 GREASER CAP F 5051CPL COMPLETE EMERY GRINDING WHEEL
F 5007L CARBON BRUSH - LONG SERIES F 5023 COMPENSATION RING F 5034 GREASER F 5052 SCREW FIXING THE EMERY GRINDING
WHEEL HINGE
F 5008 PLATE FIXING THE SWITCH F 5024 LOWER MOTOR COVER F 5036 SHIM ADJUSTMENT WASHER F 5054 3,5MA SCREW FIXING THE FOOT
F 5009 U BOLT FIXING THE CABLE F 5025 SCREW FIXING THE MOTOR COVER F 5037 RING NUT FIXING THE BEARING F 5057 DRIFT LOCKING THE BLADE
F 5009/1 SCREW FIXING THE U BOLT F 502601CPL MOTOR SUPPORT F 5038 GEAR RING BEARING F 5059 WRENCH FOR BLADE DISASSEMBLY
F 501101 RIGHT CONTACT TERMINAL F 5027 JOINT F 5039CPL COMPLETE GEAR RING F 506002 BRUSH CONTACT SPRING
F 501102 LEFT CONTACT TERMINAL F 5029 5x11x4 GEAR SCREW BEARING F 5040 3,5MA SCREW FIXING THE GEAR RING F 5061L SCREW FIXING THE CONTACTS
F 5012 PLATE FIXING THE BEARING F 502901 5x13x4 GEAR SCREW BEARING F 5042 RING NUT FIXING THE BLADE F 5062 CARBON BRUSH HOLDER
F 5013 SCREW FIXING THE MOTOR COVER F 5029/2 SEGER RING F 5043 BLADE PROTECTION GUARD F 5063 CARBON BRUSH HOLDER CAP
F 5014 SCREW FIXING THE SWITCH PLATE F 5030 GEAR WORM SCREW F 5044 GUARD FIXING SCREW F 5064 WRENCH FOR EMERY DISASSEMBLY
F 5015 SCREW FIXING THE BEARING PLATE F 503001CPL COMPLETE GEAR SCREW F 5045 PLATE WITH EMERY F 7002 PLASTIC FLEXIBLE CABLE GLAND
F 5017 5x16x5 MOTOR BEARING F 50302 MOTOR COVER F 5046 STEEL WASHER LA 50SEXT 7-SIDE BLADE, 50 mm, EXTRA STEEL
F 5018 MOTOR FRAME WITH MAGNETS F 50302CPL COMPLETE MOTOR COVER F 5047 THREADED BUSH P053/1CPL FOOT WITH WELDED COUNTERBLADE
F 5018/1 PAIR OF PERMANENT MAGNETS F 50303 FUSE COVER F 5048 RETAINING RING PA FRN50MT COMPLETE SET OF DS503MT
ACCESSORIES
F 501901CPL 110 V COMPLETE ROTOR F 50304 SCREW FIXING THE FUSE COVER F 5049 COMPLETE EMERY UNIT PA T107900 LUBRICATING GREASE
F 501902CPL 48 V COMPLETE ROTOR F 50310 ELECTRONIC CIRCUIT WITH FUSE F 5050 EMERY CAP

F5020
®
dal 1946
F7002
F5013
F5001
F5013
F5007L
F5063
F5063
F5007L
F501902CPL F501901CPL
F5019CPL
F50302
F50310F1
PAFRN50MT
F50310F1
F50310
F50310
F5054
F5054
PO53/1CPL
F5051
F5059
F5033
F503101
F5006
F5025
F5018
F503001CPL
LA50SEXT
F5061L
F5007L
F5036
F5005
F5012
F5007L
F5009
F5043
F5025
F5027
F5034
F506002
F5051/1
F5047
LA50SEXT
F506002
F5057 F5049
F501101
F5044
F5009/1
F5014
F5049
PAT107900
F5061L
F5045
F502901
F5029
F5052
F5014
F5015
F5039CPL
F5046
F5022
F5062
F5017
F5037
F5044
F5052
F5024
F5030
F502601CPL
F5048
F5029/2
F5004
F5039
F5038
F501102
F5051CPL
F5015
F5008
F5009/1
F5023
F5025
F5050
F5038
F5026S
F5018/1
F5042
F5064
F5062
F5032
F5051/2
F5040
F50303
F50304
F50302CPL
F5021

WARRANTY
Rasor®Elettromeccanica S.r.l. electric scissors have a 12 month warranty from the date indicated
on the last page of this manual, except in case of different written agreements.
The warrantycovers all manufacturing andmaterial defects. Replacement andrepair operations
are covered only if carried out by our company and at our workshop. If in-warranty goods
need to be repaired, the customer must always send the complete machine to Rasor®.
Single units will not be repaired under warranty.
The material to be repaired must be sent CARRIAGE FREE.
Once the machine has been repaired, it will be sent CARRIAGE FORWARD to the customer.
The warranty covers neither technicians' intervention on site nor the machine disassembly
from the installation place.
If for practical reasons, one of our technicians is sent to the premises, the customer will be
charged the costs plus the travelling expenses.
The warranty does not include:
failure caused by wrong use or assembly,
failure caused by external agents,
failure caused by lack of maintenance or neglicence;
blades and parts subject to wear.
WARRANTY FORFEITURE:
In case of arrearage or other breaches of contract,
Whenever changes or repairs are carried out on our electric scissors without our
prior authorization,
Whenever the serial number is tampered with or cancelled,
Whenever the damage is caused by improper use, bad treatment, bumps, falls and
other causes not due to normal working conditions,
Whenever the unit seems tampered with, dismantled or previously repaired by
unauthorized staff,
In case the electric scissors are used for purposes that are different from the ones
described in this manual.
All repair operations carried out under warranty do not interrupt its duration.
All disputes will be settled in the court of justice of Milan (Italy).
We thank you in advance for the attention you will pay to this manual and we invite you to
inform us of any change you deem necessary to improve it and make it more complete.

RASOR ELETTROMECCANICA SRL
Via Vincenzo Caldesi 6
20161 Milan ∙ Italy
ph. [phone]
fax [phone]
[e-mail]
www.rasor-cutters.com
FOLLOW US:
