RASOR GRT10L Mounting instructions

USE MANUAL
GRT10LGRT10L THREE-PHASE
CUTTING UNIT

2
EN
COMPANY
ACKNOWLEDGMENT
Dear Customer,
thank you for choosing a Rasor®Elettromeccanica S.r.l. product.
Rasor®has been a reference point in the field of cutting systems in the textile, clothing,
furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for
years. Its production has been always synonymous with reliability attested by many of
satisfied customers.
Rasor®quality system supervises all the company activities in order to provide the Customer
with a service that meets its needs and expectations in terms of product quality, delivery
reliability and stock of finished products.
All the parts of the devices have been planned and produced to guarantee an optimum
performance. In order to keep the high quality level and the long reliabilty of the Rasor®
products, it is recommended to use only original spare parts and to contact the head
office for any maintenance work.
Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by Luigi Spinelli. For more
than sixty years it has been producing automatic cutting systems, cutting units for textile
applications and electric and pneumatic cutters.
Initially considered as a point of reference for cutting systems in the
textile applications, the Rasor®products are nowadays widely used in
other fields: chemical, automotive, nautical and sport sectors and in
furniture manufacturing.
Nowadays Rasor®can rely on the professional continuity of two
generations, with the experience inherited from the promoting partner, with his passion
and dedication.
The main characteristic of Rasor®is that each working phase, starting from the manufacturing
of the product up to its packing and delivery is carried out in Rasor®premises by qualified
operators who have professionaly grown up following the spirit of the company and of its
founders. This ensures the high quality which Rasor®has always considered as essential
since the beginning of its activity.
Following the innovative spirit mentioned above, our company is constantly focused on the
improvement of the product quality, on the study and development of new materials and
technologies.

EN
3
1. GENERAL SAFETY RULES
This manual is an integral part of cutting unit GRT10L and must be carefully
read before using it since it gives important indications with regards to its safe
installation, use and maintenance. Keep it with care.
Before using cutting unit GRT10L, read carefully the following general safety
rules.
• PACKAGING.
After taking off the packaging make sure that the cutting unit is intact. In
caseofdoubtdonotuseitandcontactanauthorizedservicecentre.Donot
leave pieces of packaging (plastic bags, foam polystyrene, boxes, etc.) within
the reach of children or disabled persons since they are potential sources of
danger.
• AVOID DANGEROUS ENVIRONMENTS.
Prevent the cutting unit GRT10L components from coming in contact with
damp or wet surfaces.
•KEEPCHILDRENAWAY.
Unauthorized persons, especially children, must be kept away from the working
area.
•FEEDCABLE.
Prevent the feed cable from coming in contact with hot objects, pointed
surfaces or sharp edges. Never pull the feed cable of the machine. It must
never be replaced by the user. If necessary contact professionally qualified
staff.
•KEEPTHEWORKINGAREAALWAYSINORDER.
The workplace must always be kept in order and well lightened; liquids or oil
traces must not be present.
• ALWAYS USE CUTTING UNITS GRT10L PROPERLY.
Use the cutting units only to carry out the works they have been designed
for; do not use them improperly.
•OBSERVETHEUSEOFTHETOOLS.
Do not cut excessively thick materials and always check blade conditions.
• AVOID ACCIDENTAL STARTS.
Before connecting cutting unit GRT10L, make sure that everything is installed
properly.
• CLOTHING.
Do not use large clothes or accessories that might get stuck in the moving
parts.
• GOGGLES AND PROTECTIVE METAL MESH GLOVES.
Always use goggles, protective metal mesh gloves recommended by Rasor®
during use and maintenance operations (according to UNI EN 388:2017
standard).
•SPAREPARTS.

4
EN
ALL RIGHTS ARE RESERVED ACCORDING TO THE
INTERNATIONAL COPYRIGHT CONVENTIONS,
The reproduction of any part of this manual, in any form, is forbidden without
the prior written authorization of Rasor®Elettromeccanica S.r.l.
The content of this guide can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this
manual to make it as complete and comprehensible as possible.
Nothing contained in this manual can be considered as a warranty, either
expressed or implied - including, not in a restrictive way, the suitability warranty
for any special purpose. Nothing contained in this manual can be interpreted as a
modification or confirmation of the terms of any purchase contract.
Rasor®Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of
explosions and at high risk of fire and they cannot cut wet or damp materials. Moreover, they
cannot work in case of rain.
In case of damage or malfunction, cutting unit GRT10L must not be used until the Customer
Care Technical Service has repaired them.
The original configuration of the cutting unit must not be changed at all.
On receiving the machine make sure the supply corresponds to what has been ordered.
In case of non-compliance immediately inform Rasor®.
Also make sure the cutting unit has not been damaged during transport.
Customer Care Technical Service
WARNING
The installer and the maintenance man must know the content of this manual. Although
the main features of the machine described in this manual are not subject to change,
Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details
and accessories it deems necessary to improve the machine or to meet manufacturing
or commercial requirements at any time and without being obliged to update this
manual immediately.
Informative letter
Forany information,please contact
® ELETTROMECCANICAS.r.l.
Via V. Caldesi, 6; 20161,MILANO (MI) - ITALY
Tel: [phone]; Fax: [phone]
e-mail: [email protected]
web: www.rasor-cutters.com
WARNING
RASOR

EN
5
2. TRANSPORT AND PACKAGING
2
3. PLATE DATA
The manufacturer's identification and CE STANDARD 2006/42/EC conformity plate (see picture
below) is located on the front part of the cutting unit.
The plate must not be removed at all, even if the machine is resold. Always refer to
the serial number (written on the plate itself) when contacting the manufacturer.
Several safety warnings are printed on a card which is applied to the cutting unit feeding
cable; such warnings must be strictly followed by everyone dealing with the machine. The
company is not to be held responsible for damage to property or accidents to
people which might occur if the above-mentioned warnings are not observed. In
such a case, the operator is the only person responsible.
13
12
Year of production
Model
Electric data
10L
750,36
2___
L___
READ
THE
INSTRUCTION
MANUAL
DO NOT
REMOVE
THE
SAFETY
DEVICES
HIGH
VOLTAGE
SHEARING
RISK
USE
METAL
GLOVES
USE
GOGGLES
The cutting unit is delivered in a cardboard box, inside which there are various options. The
code of the ordered product and its serial number are indicated outside the package (see
picture1).Thefollowingaccessoriesarecontainedinsidethepackage:
1) Poligonal blade;
2) Wrench for blade nut disassembly.
3) Drift for blade disassembly.
Serial number

6
EN
4. PRODUCT DESCRIPTION
The fixture described in this manual is a cutting unit model GRT10L which can be assembled
on automatic machines (e.g. spreaders, computerized cutting) by means of proper holes
located in the motor support. GRT10L can operate continuously and it can cut at various
widths by means of multiple installation. By cutting with the blade and the counterblade
always in contact and thanks to the steel upper quality of the blade supplied, GRT10L
guarantees the clean separation without frayings of the two borders of the cut material.
The three-phase motor with extremely compact dimensions and extreme reliability with
100 mm diameter blades, guarantees cuts with thickness up to 3.5 cm. Asharpenerassembled
on the cutting unit head allows sharpening the blade at any moment without disassembling it.
After carrying out this operation, it is possible to start cutting again. A high power motor,
perfectly balanced, with a high number of revolutions and totally free of maintenance, reduces
the vibrations to the minimum, thus making the cutting unit comply with Italian Legislative
Decree No. 81 dated 9/4/2008 “Testo Unico sulla Salute e Sicurezza sul Lavoro” (Consolidated
Act on Health and Safety at Work), Title VIII - CHAPTER III (worker protection from
mechanical vibration risks). The mechanical parts are made of high resistance steel, bronze and
aluminium and require lubrication after several working hours.
1
3
4
7
810
12
13
9
2
14
11 5
6
1 Connector block 8 Aluminium base covered with
Teflon®
2 Motor cover 9 Poligonal blade
3 Cable gland 10 Plate locking the threads
4 Motor frame 11 Greaser
5 Sharpener push button 12 Carbide counterblade
6 Emery grinding wheel 13 Motor flange with assembly
holes
7 Movable front protection 14 Motor support
Device components

EN
7
5. TECHNICAL FEATURES
This technical data is only indicative and may be subject to change without notice.
7. FIELD OF APPLICATION
6. NOISE LEVEL
NOTE
It is advisable for cutting unit GRT10L owners to verify the compliance with the standard
concerning safety of workers: Italian legislative decree 81/08.
The maximum acoustic pressure level emitted by cutting unit GRT10L is about 60 dB (A).
Noise tests have been carried out in compliance with Standard UNI EN ISO 11202:2010. The
device noise levels, measured at different distances (without any sound wave filtering system),
vary in the extent of few db (A).
Cutting unit GRT10L has been designed, manufactured and assembled to cut every kind of
fabrics or materials, with the exception of metal, plastic or wood, by means of rotary poligonal
blades.
This equipment must not work:
-inareaspronetoexplosions;
- in presence of fine dust or corrosive gases;
- on wet or damp materials;
- to cut plastic, metal and wooden materials.
It is forbidden to use cutting unit GRT10L for purposes different
from the above-mentioned ones.
100 mm with carbide counter
blade
550 rpm
about 35 mm
Three-phase-Asynchronous, 75 W
(
IP20-CL F
)
0,36 A
2800 g
3800 g
1,5 mt
LUX 200
<2,5m/s
2
0 ~ 55°C
10 ~ 95% without condensate
Cutting working depth
Motor power
Weight (with feeding cable)
Cutting unit GRT10L features
Blade diameter
Blade speed
Max. Absorption
Temperature
Humidity
Weight with package
Electric cable length
Minimum light for working
o
p
erations
Vibrations at the start up
6 side blade Ø 100 mm in H.S.S. steel
circular blade Ø 100 mm in Extra Steel
4 side blade Ø 100 mm, in Extra Steel
Germany
6 side blade Ø 100 mm in H.S.S. steel
covered with Teflon®
6 side blade Ø 100 mm in integral hard
metal
cutter circular blade Ø 100 mm, in
Extra Steel
10CFR
10EHSSTF
Features of the available blades
10EHSS
10CSW
10SEXTG
10EMD

8
EN
8. USE WARNINGS
Firstly make sure that the lines are able to feed the cutting unit correcltly, in
compliance with the safety rules (for the feature required see par. 5).
We suggest installing a magnetothermic safety device before the cutting unit and check
that the ground circuit is effective. Before working on the feeding cable pull the plug out.
Check that electric connections and protections correspond to the driving force and the
plate data values (voltage and current), required by the different electric circuits.Byreferring
to the CEI 11-27/1 standard all the works carried out by means of electric current must be
performed by a staff, who has been provided with all the devices required by the above-
mentioned standard. For the works carried out under voltage, it is necessary that the
employer certifies the suitability, against formative processes.
The cutting unit GRT10 is supplied with electric cable connected
to the connector block located beside the motor.Theuser
must connect the cutting unit to the mains (the cable complies
with the CEI 20-22 III Standard). Never change the length of
the cable supplied. If it is necessary, use a longer cable and
replacetheonesupplied
.Toconnectthenewcableopen the
cover “A”byunscrewingthe4cross-slottedscrews
“B”(see
picture 3). Connect the phase cable to the terminal board.
The minimum section of the connecting cables must be
determined by the operator in charge of the installation.We
recommend to use safety cables and socket IMQ approved.
Check the connection by enabling the cutting unit and verify
the rotation direction.Thecuttingunitisprovidedwith earthing
3
9. ELECTRIC CONNECTION
B
A
B
We recommend following the indications below in order to work in safety conditions.
All the operations must be carried out complying strictly with the safety rules of the
country where the device is to be installed.
It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of
the cutting unit.
The Customer undertakes to comply with and make his staff observe all the rules and
regulations in force concerning safety, prevention of accidents and health in the work
place. Therefore, the Customer assumes the responsibility to strictly follow all the rules and
regulations in force, as well as the special provisions in force in sport and public installations
the Customer declares to know after receiving all the relative necessary information.
The cutting unit also works without its safety protective device. This protective
devicemustNEVERberemoved.
Always check the resistance of the material to be cut and the kind of blade which is being
used.
The Customer shall equip his own personnel with all the individual safety protections for
the execution of the works, as well as with the ones which might be prescribed by the
Manufacturer due to specific danger conditions of the plant or of the area where the
personnel must work.
Do not make any adjustment while the blade is working or while the electric plug is
connected.
Always pay attention to the electric cable position to prevent it from being cut or damaged
by the blade.
It is allowed to assemble cutting unit GRT10L on machines O.E.M. on condition that their
original structure is not modified. Otherwise, the intervention must be certified by Rasor®.
WARNING

EN
9
10. RESIDUAL RISKS
11. INSTALLATION AND USE
Even though the cutting unit is safe, operators must pay attention to preserve their and
other people’s safety.
At the end of the working operations, the motor could be very hot.
The cutting blade can work even when the protective device is disassembled.
To install and use the cutting unit manually, proceed as follows:
1) Fix the cutting unit on level squares or angles by means of four 5MA screws, by inserting
them in the four holes located in the motor lower cover (see pictures 4 and 5).
NOTE
The cutting unit can be installed in any position/angle: vertically, laterally and it can be turned
upside down. It is not compulsory for the Teflon base to touch the machine table.
2) Lay the material to be cut;
3) Connect the cutting unit to the electric feeding;
4) Put the material on the cutting foot;
5) Adjust the front mobile protection according to the thickness of the material to be cut (see
picture 6);
6) Carry out the cutting operation.
NOTE
Cutting unit GRT10L can work in a fixed position (the material has to be moved) or it can
move forward while the material is kept in the same position. Make sure the material to be
cut is properly stretched, preventing it from curling.
45
(yellow-green cable). Possible faulty earthing connections may cause unsafe working
conditions. Possible damages are not at RASOR®s.r.l. charge.
The electric feeding must be supplied by a line protected against overcurrent by means of
the automatic switch (magnetothermal) or delayed fuses with a suitable dimensions. The
current of the safety devices must be as low as possible considering the max. absorption of
the machine (see identification plate).
6
WARNING
The operator must arrange a disconnetting switch on the supply line in order to switch off
the machine, if necessary.
WARNING
Never use the two bolts which fix the motor to the cutting part to fasten cutting
unit GRT10L. This operation may cause the motor shaft to break. In this case,
warranty is not valid.

10
EN
12. BLADE SHARPENING
13. LUBRICATION
Every 3-4 working days, it is necessary to lubricate the
pair of gears. To carry out this operation, remove
protective plug “A” located on the motor support of
the cutting unit and fill it with lubricating grease Rasor.
Screw plug “A” again few turns. Screw plug “A” some
turns every 3-4 working days (see picture 9).
9
A
After many hours of a continuative use of the cutting
unit, or if it would not be able to cut anymore, it is
necessary to sharpen the blade. To carry out this
operation, start the blade and press sharpener “2”
located on it for 3-4 seconds (by pressing push button
“1”, as shown in picture 7). Repeat the operation 2-3
times.
If the sharpening operation is not effective, check the
wear of emery grinding wheel “3” (see picture 8).
If emery grinding wheel “3” is too worn or dirty, replace
it.
1
2
8
3
7
The blade must never be dirty with grease or oil.
WARNING

EN
11
If the blade is no more able to cut (even after repeating
the sharpening operation several times) it is necessary to
replace it. To carry out this operation, use wrench “1”
and drift “3” locking the blade (shown in picture 10).
To replace the blade, proceed as follows:
1) Use some protective gloves in compliance with
Italian Legislative Decree 81/08;
2) Remove the mobile front safety protection “A” (see
picture 11) by unscrewing pin “C” and removing
the two washers “D” as shown in picture 12.
Remove the fixed rear safety protection “B” (see
picture 11) by unscrewing the two cross screws
“E” by means of the proper screwdriver (not
supplied by the manufacturer) as shown in picture
13.
3) Insert drift “3” into hole “F” (see picture 14), so
as to lock the blade (the hole on the blade must
correspond to the one on the motor support).
4) Use wrench “1” to unscrew nut “G” and remove
blade “H” (see picture 14).
5) Replace the worn blade with the new one “2”,
being careful to center the blade on the gear, in
the correct position, and remember to assemble it,
so that the Rasor writing can be seen by the
operator.
6) Assemble all the components again and carry out
the sharpening.
14. BLADE REPLACEMENT
110
11
BA
13
H
1
G
14
3
2
F
C
D12
E
3

12
EN
15. TROUBLESHOOTING
SOLUTION
Check that the blade and the counterblade are in contact
Check the kind of fabric
Sharpen the blade
Check the fabric thickness
Check the compatibility between blade and fabric
Make sure that the motor turns correctly
Reduce the speed of travel
Check the counterblade integrity
Carry out the lubrication
Disassemble the blade and remove the material residues
Check the wear of the pair of gears
Check the electric connections on the O.E.M. unit
Check the electric connections
Check the feeding cable
PROBLEM
The cutting unit is noisy
The fabric isnot cut or it gets stuck
between the blade and the counterblade
The cutting unit starts slowly, works
intermittently or it does not start
16. SPARE PARTS / EXPLODED VIEW
CODE DESCRIPTION CODE DESCRIPTION CODE DESCRIPTION
10EHSS HEXAGONAL BLADE Ø 100 mm, H.S.S.
STEEL GRT8615 SPACER SW1081S CARBIDE COUNTERBLADE
CODE DESCRIPTION
GMT1000 COMPLETE MOTOR GRT10, 3ph 380 V
50 Hz GRT8616 DOWEL FASTENING THE FAN SW108200 SCREW FASTENINGTHE COUNTERBLADE
T104800 GREASER
GMT1000/48
0COMPLETE MOTOR GRT10, 3ph 480 V 60 Hz GRT8617 MOTOR BEARING mm 6x19x6 SW108600 EMERY Ø 25x9x6 mm
T1049S PLATE LOCKING THE THREAD
GMT1060 COMPLETE MOTOR GRT10, 3ph 380 V
60 Hz GRT8618 MOTOR BEARING mm 10x30x9 SW1086CPL COMPLETE SHARPENER
T105000 SCREW 2.6MA FASTENING THE PLATE
LOCKING THE THREAD
GRT1013 COMPLETE ROTOR GRT10 GRT8619 COMPENSATION RING SW108700 SHARPENER PIN
T105200 MOTOR SUPPORT FIXING BOLT
GRT1014 MOTOR FRAME SCREW SW104101 SCREW FOR THE REAR GUARD FIXING SW108800 EMERY SPRING Ø 11 mm
T105300 SPLIT WASHER
GRT101800 WORM SCREW MOD. 1 5P SW104101S REAR PROTECTION GUARD SW108900 SHARPENER BUSH
T105400 ANTI-FRICTION BUSH
GRT1018CPL COMPLETE PAIR OF GEARS SW104101SC
PL REAR PROTECTION SET SW109000 EMERY SPRING Ø 6 mm
T105600 WASHER
GRT1059CPL GEAR BEVEL MOD. 1 5P SW1044S FRONT PROTECTION GUARD SW109100 SHARPENER CAP WITH BEARING
T105700 RING LOCKING THE GEAR BEVEL
BEARING
GRT10M18 MOTOR COVER SW1044SCPL FRONT PROTECTION SET SW109200 SCREW FASTENING THE SHARPENER
CAP
T105800 GEAR BEVEL BEARING
GRT10M19 MOTOR FAN SW1055SL COMPLETE MOTOR SUPPORT SW109300 WASHER
T106000 LEFT SCREW FASTENING THE GEAR
BEVEL
GRT10M21 UPPER MOTOR FLANGE SW1074MS LEFT BASE WITH BEVEL T101801 ELASTIC PIN
T106100 RING UNDER BLADE
GRT10M24 MOTOR FRAME SW1074MSC
PL COMPLETE LEFT BASE WITHBEVEL
T106300 RING NUT FASTENING THE BLADE
GRT10M26 LOWER MOTOR FLANGE SW1076S SPRING WITH DOWEL
T107000 SCREW FASTENING THE
BASE/PLATFORM/SECTOR
GRT10M97 COMPLETE TERMINAL BOX SUPPORT SW107900 SCREW FASTENING THE
COUNTERBLADE HOLDER
T104500 SCREW FASTENING THE FRONT
PROTECTION T107500 BLADE ASSEMBLING/DISASSEMBLING
WRENCH
GRT27 FLAME RETARDANT FEEDING CABLE SW1080S COUNTERBLADE HOLDER
T104501 CONVEXED WASHER T107600 DRIFT LOCKING THE BLADE
T107900 LUBRICATING GREASE
T104700 GREASER CAP

GRT27
GRT10M26
GRT10M19
GRT10M18
GRT8619
GRT1013
GRT10M24
GRT10M21
GMT1000 (3-PH, 380V, 50Hz)
GMT1060 (3-PH, 380V, 60Hz)
GMT1000/480 (3-PH, 480V, 60Hz)
GRT8617
GRT8616
GRT8615
GRT1014
GRT8618
GRT10M97
GRT1059CPL
GRT101800
T101801
GRT1018CPL
SW1055SL
T105300
T105200
SW104101S
SW104101SCPL
T107900
T107600
T107500
T105000
T105000
T106100
T105400
10EHSS
GRT1059CPL
T1049S
T106000
T106300
T105600
T105700
T105800
T104501
T104501
T104500
SW1044S
SW1044SCPL
T104700
T104800
SW108200
SW1074MSCPL
SW1080S
SW1081S
SW104101
SW104101
SW109300
SW109100
SW109200
SW108900
SW108800
SW108700
SW109000
SW1086CPL
SW108600
T107000
SW107900
SW1074MS
SW1076S

WARRANTY
Rasor®Elettromeccanica S.r.l. cutting unit has a 12 month warranty from the date indicated
on the last page of this manual, except in case of different written agreements.
The warrantycovers all manufacturing andmaterial defects. Replacement and repair operations
are covered only if carried out by our company and at our workshop. If in-warranty goods
need to be repaired, the customer must always send the complete machine to Rasor®.
Single units will not be repaired under warranty.
The material to be repaired must be sent CARRIAGE FREE.
Once the machine has been repaired, it will be sent CARRIAGE FORWARD to the customer.
The warranty covers neither technicians' intervention on site nor the machine disassembly
from the installation place.
If for practical reasons, one of our technicians is sent to the premises, the customer will be
charged the costs plus the travelling expenses.
The warranty does not include:
failure caused by wrong use or assembly,
failure caused by external agents,
failure caused by lack of maintenance or neglicence;
blades and parts subject to wear.
WARRANTY FORFEITURE:
in case of arrearage or other breaches of contract,
whenever changes or repairs are carried out on our cutting units without our prior
authorization,
whenever the serial number is tampered with or cancelled,
whenever the damage is caused by improper use, bad treatment, bumps, falls and
other causes not due to normal working conditions,
whenever the unit seems tampered with, dismantled or previously repaired by
unauthorized staff,
in case the cutting units are used for purposes that are different from the ones described
in this manual.
All repair operations carried out under warranty do not interrupt its duration.
All disputes will be settled in the court of justice of Milan (Italy).
We thank you in advance for the attention you will pay to this manual and we invite you to
inform us of any change you deem necessary to improve it and make it more complete.

RASOR ELETTROMECCANICA SRL
Via Vincenzo Caldesi 6
20161 Milan ∙ Italy
ph. [phone]
fax [phone]
[email protected]
www.rasor-cutters.com
FOLLOW US:
