Razor 13013211 User manual

OWNER’S MANUAL
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
A5 DLX™ SCOOTER
OWNER’S MANUAL
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
Read and understand this entire manual before
allowing child to use this product!

SAFETY WARNINGS
AN IMPORTANT MESSAGE TO PARENTS: This manual contains
important information. For your child’s safety, it is your responsibility to
review this information with your child and make sure that your child
understands all warnings, cautions, instructions and safety topics. All
children and preteens should ride with adult guidance at all times. Razor USA
recommends that you periodically review and reinforce the information in this
manual with younger riders, and that you inspect and maintain your child’s
scooter to ensure their safety.
GENERAL WARNING: Scooter riding can be a hazardous activity.
Scooters can, and are intended to move and it is therefore possible to get into
dangerous situations and/or lose control and/or fall. If such things occur you
can be seriously injured or die. LIKE ANY OTHER MOVING PRODUCT, USING
A SCOOTER CAN BE A DANGEROUS ACTIVITY AND MAY RESULT IN INJURY
OR DEATH EVEN WHEN USED WITH PROPER SAFETY PRECAUTIONS. USE AT
YOUR OWN RISK AND USE COMMON SENSE.
• Always wear safety equipment, such as helmet, knee pads and elbow
pads. Always wear a helmet when riding your scooter and keep the
chinstrap securely buckled.
• Always wear shoes.
• Ride on smooth, paved surfaces away from motor vehicles.
• Avoid sharp bumps, drainage grates, and sudden surface changes. Scooter
may suddenly stop.
• Avoid streets and surfaces with water, sand, gravel, dirt, leaves, and other
debris. Wet weather impairs traction, braking, and visibility.
• Do not ride at night.
• Brake will get hot from continuous use. Do not touch after braking.
• Avoid excessive speed associated with downhill rides.
• Adults must assist children in the initial assembly and/or adjustment
procedures to fold/unfold scooter, and adjust handlebar and steering
to height.
• Obey all local traffic and scootering laws and regulations.
• Watch out for pedestrians.
• Do not exceed 220 lb (100 kg) total weight on the A5 DLX scooter.
• A parent’s decision to allow his or her child to ride this product should be
based on the child’s maturity, skill and ability to follow rules.
• Do not allow children under age eight (8) to use the scooter. All children
and preteens should ride with adult supervision at all times.
• Rider weight does not necessarily mean a child’s size is appropriate to fit or
maintain control of the scooter.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Direct parental supervision is required. Scooters are meant to be used only
in controlled environments free of potential traffic hazards and not on public
streets. Do not allow your child to ride a scooter in any areas where vehicle
traffic is present. Child must maintain a hold on the handlebars at all times.
Never allow more than one child at a time to ride a scooter. Never use near
steps, sloped driveways, hills, roadways, alleys or swimming pool areas. Keep
fingers and other body parts away from the product when folding or unfolding.
Adults must not allow children to assist in assembling and/or folding or
unfolding the scooter.
Do not ride a scooter in wet weather. Scooters are intended for use on solid,
flat, clean and dry surfaces, such as pavement or level ground without loose
debris, such as rocks or gravel. Wet, slick or uneven and rough surfaces may
impair traction and contribute to possible accidents. Do not ride a scooter in
mud, ice, puddles or water. Avoid excessive speeds that can be associated
with downhill rides. Never risk damaging surfaces, such as carpet or flooring,
by use of a scooter indoors. Do not ride at night or when visibility is impaired.
PROPER RIDING ATTIRE
Always ensure child is wearing proper protective equipment, such as an
approved safety helmet. A helmet may be legally required by local law or
regulation in your area. A child should always wear shoes and keep shoelaces
tied and out of the way of the wheels. Never ride barefooted or in sandals.
Knee pads and elbow pads are recommended.
WARNING: ALWAYS INSPECT SCOOTER PRIOR TO RIDING. Properly
inspecting and maintaining your scooter can reduce the risk of injury. Always
inspect your scooter before riding and regularly maintain it. Check and secure
all fasteners before every ride. Replace worn or broken parts immediately.
WARNING: CHECK LOCAL LAWS REGARDING SCOOTER USE.
Check local laws and regulations to see where and how you may use
your Razor scooter legally. In many states and local areas scooter riders
are required BY LAW to wear a helmet. Check local laws and regulations
regarding laws governing helmet use and scooter operation in your area.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE
WARNINGS FURTHER INCREASES RISK OF SERIOUS INJURY. USE
AT YOUR OWN RISK AND WITH APPROPRIATE AND SERIOUS
ATTENTION TO SAFE OPERATION. USE CAUTION.

BEFOREYOU BEGIN
qRequired Tools
5 mm
Allen Wrench
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents that may have occurred during shipping. Because
your scooter was assembled and packed at the factory, there should not be any problems, even if the box has a few
scars or dents.
WARNING: DO NOT USE
NON-RAZOR PRODUCTS WITH
YOUR SCOOTER.
Razor scooters have been built to
certain Razor design specifications.
The original equipment supplied at
the time of sale was selected on
the basis of its compatibility with
the frame, fork and all other parts.
Certain aftermarket products may
not be compatible and will void the
warranty.
Product ID Locations:
1. Side of Deck Plate
2. Box - side of UPC (not shown)
Box Contents:
• Scooter
• Owner’s Manual
• 5 mm Allen Wrench
Quick-Release Lever
Extension Tube
Anti-Rattle Folding Mechanism
T-bar
Collar Clamp
Kickstand

2 Insert and secure the left and right handlebars
by pressing the spring-loaded buttons and
inserting them into the T-bar.
3 Make certain BOTH handlebars are properly
locked onto the T-bar.
ASSEMBLY AND SET-UP
WARNING:
Keep fingers clear of the pivoting
mechanism when folding or
unfolding the scooter. Make sure
others are standing clear.
Unfolding the Scooter for First Time Use
1To release the folding mechanism, place the
scooter on the ground, put one foot on the deck
plate and pull the Anti-Rattle knob up.
Raise T-bar up until it is securely locked in the
upright position.
Note: To activate the anti-rattle feature twist the knob to the right to tighten. Please note there is no need
to over tighten.
Note: The Anti-Rattle knob is spring-loaded and
will automatically lock in the upright position
when fully upright.
WARNING: Failure to
properly engage the spring-loaded
buttons may cause the handlebars
to dislodge while riding and may
cause you to lose control and
fall. When correctly engaged the
handlebars will not rotate nor will
they move sideways. Note that
when properly engaged, the spring-
loaded buttons are clearly visible in
the holes on the T-bar.

Adjusting the Handlebar Height
1To adjust the height of the handlebars, open
the quick-release lever and slide the T-bar to the
desired position and resecure the quick release
lever to lock into place.
2The tension of the quick-release lever can be adjusted by manually tightening or loosening the Allen bolt. Be
careful not to over-tighten. You should always be able to open and close the quick-release lever by hand and the
T-bar should slide freely when the quick-release is open.
ASSEMBLY AND SET-UP
Note: When the T-bar is raised to the maximum
height, depress the push button located directly
below the quick release lever to unlock the T-bar.
WARNING: Failure to
properly secure the quick-release
lever may cause the T-bar to
telescope up or down while riding
and may cause you to lose control
and fall.

ASSEMBLY AND SET-UP
Collar Clamp
Using a 5 mm Allen wrench, check that the collar clamp bolt is tightened securely. This item is tightened
and quality inspected at the factory, but there is a slight chance that the effects of shipping or handling
may have caused the bolt to loosen.
WARNING: Failure to
properly install and tighten the
collar clamp may cause the rider
to lose control and fall.
12
34

USAGE
Loose Parts
Check and secure all fasteners before every ride. Make sure the
collar clamp, quick-release lever, anti-rattle knob, and handlebar
spring buttons are locked properly in place before riding.
Replacement Parts
Replace worn or broken parts immediately.
Safety Gear
Always wear proper protective equipment, such as an approved
safety helmet, elbow pads and kneepads. Always wear shoes
(lace-up with rubber soles) and keep shoelaces tied and out of
the way of the wheels. Never ride barefooted or in sandals.
Be Careful!
You will see people on TV and maybe even people you know doing
tricks and stunts. These are people who have been practicing on
scooters for a very long time. Don’t try something until you are
ready. Avoid steep inclines and don’t ride too fast — you can lose
control and fall. Skateboard parks are not designed for scooters.
Never ride in traffic or on the street and watch your surroundings
for pedestrians, bikers, boarders and skaters.
Maintain a hold on the handlebars at all times.
How to Ride
Place one foot on the baseboard, push forward with the other foot. Steer with both hands on the handlebars.
For enhanced cornering, lean slightly into the direction of the turn. For controlled stops, apply the brake by stepping
on the rear brake. Razor recommends that you practice applying the brake at various speeds and in an open area
free from obstructions before riding your scooter around others.
PRE-RIDE CHECKLIST

USAGE
1To fold scooter you must first deactivate the anti-
rattle feature. Twist the knob left until loose.
No need to loosen knob more than one full turn.
3Lower T-bar to fold.
2Pull the anti-rattle knob up.
Folding Scooter WARNING:
Keep fingers clear of the pivoting
mechanism when folding or
unfolding the scooter. Make sure
others are standing clear.

Cleaning Your Scooter
Wipe with a damp cloth to remove dirt and dust. Do not use industrial cleaners or solvents as they may damage the
surfaces. Do not use alcohol, alcohol-based or ammonia-based cleaners as they may damage or dissolve the plastic
components or soften the decals or decal adhesive.
Wheels and Bearings
Under normal circumstances and conditions, Razor wheels and wheel bearings are maintenance free. Nonetheless, it
is the responsibility of the owner or guardian to periodically inspect the wheels for wear and tear, the axle for proper
tightness, and bearings for side-to-side play, and loose parts. When a wheel or wheel bearing develops play, this is an
indication of excess wear and replacement is necessary. Replace immediately with only genuine Razor wheels. Worn
wheels/bearings are considered normal wear-and-tear and are not covered by the Razor Warranty. Wheels other than
genuine Razor wheels may not be compatible with your Razor scooter.
WARNING: Wheelies
and other stunt-type riding reduces
your ability to maneuver and control
your scooter. Take the necessary
precautions, such as wearing
appropriate protective gear and
practice in a area safe for stunt
riding and free from obstructions.
REPAIR AND MAINTENANCE
